LonWorks PLC

1
LonWorks PLC

• (c) 2013 R. Newman
• University of Florida

2
What is LonWorks Protocol

• Multiple medium protocol for home automation
  (domotics) and control
• Local Operating Network (LON)
• Narrowband PLC, TP, CX, fiber optics, RF
• TP 78 kbps using Differential Manchester
• PLC 5.4 or 3.6 kbps depending on frequency band
• Developed by Echelon Corp.
• 60 million devices by 2006
• Multiple standards
• International and open industry standard
• European standards
• China national standards

3
LonWorks Standards

• International and open industry standard
• Submitted to ANSI 1999 - ANSI/CEA-709.1
• Basis for IEEE 1473-L (in-train controls)
• SEMI (semiconductor equipment manufacturing)
• One of several data link/physical layers of the
  BACnet ASHRAE/ANSI standard for building
  automation.
• ISO and IEC standards ISO/IEC 14908-1, -2, -3,
  and -4 (communications protocol, twisted pair
  signaling technology, power line signaling
  technology, and Internet Protocol (IP)
  compatibility)
• European standards
• AAR electro-pneumatic braking systems for freight
  trains
• IFSF (European petrol station control)
• EN 14908 (European building automation standard)
• Part of Household Appliances Control and
  Monitoring Application Interworking
  Specification (AIS) standards of CECED (European
  Committee of Domestic Equipment Manufacturers)
• China national standards
• Controls standard, GB/Z 20177.1-2006
• Building and intelligent community standard, GB/T
  20299.4-2006

4
LonWorks Major Elements

• LonTalk protocol
• Neuron chips
• LonWorks transceivers
• Network management/applications
• SNVTs (Standard Network Variable Types)

5
LonTalk Protocol

• Media
• Twisted pair, powerline, radio frequency, fiber
  optics, coaxial cable
• Highest data rate 1.2 Mbps
• Reliability
• Supports end-to-end acks with ARQ
• Broadcast acks also
• Medium access
• Proprietary collision prediction algorithm
• Collision detection on some media (e.g., TP)
• Optional priority feature
• Network management/applications
• SNVTs

ACK implosion problem!
6
LonTalk Addressing

• Hierarchical
• Domain, subnet, node also Group
• All nodes in domain, subnet addressable
• Channel physical medium
• Domain logical set of nodes on one or more
  channels
• Communication only possible in domain
• Multiple domains may share channel(s)
• Subnet must share a channel
• cannot span a router, 127 node max
• Domain may have up to 255 subnets
• Group may use multiple channels
• Node may be in up to 15 groups, lt64 nodes/group
• Domain may have up to 255 groups

7
LonTalk Delivery Services

• Unacknowledged
• Most commonly used
• Widest bandwidth
• Unacknowledged/Repeated
• No acks, but multiple copies sent per settings
• Acknowledged
• Used when reliability required
• Timeout set at installation time
• Priority
• Time slots may be set aside for priority traffic
• Used sparingly reduces bandwidth available

8
LonTalk Network Management

• All nodes are network management capable
• Find unconfigured nodes and download network
  addresses.
• Stop, start and reset node applications
• Configure routers and bridges
• Download new application programs
• Change the network variable configuration table
• type of protocol service used to send the network
  variable
• whether the variable is sent in a priority slot.

9
LonWorks Transceivers

• Twisted Pair
• 78 Kbps/4600 ft (1400 m)
• 1.25 Mbps/430 ft (130 m)
• Powerline
• Spread spectrum (proprietary) or narrowband
• 10 Kbps, Up to 2000 m on clear line
• Radio Frequency
• 400-470 MHz licensed
• 900 MHz unlicensed
• Configuration
• Installation announces devices presence
• Binding network variable tells device what data
  to share with whom

Longer distance gt more attenuation gt lower SNR
(noise is constant) gt lower data rate (Shannon's
Thm)
10
LonWorks Datalink Layer

• Error Detection (CRC)
• Flexible allocation of bandwidth
• Priority access mechanisms
• Graceful behavior under overload
• p-persistent CSMA
• Message collision avoidance
• Optional collision resolution, collision
  detection

CSMA When current transmission
done p-persistence Tx with prob. p Optimal p is
1/N for N contenders
CD not possible on RF or PLC medium gt Collision
avoidance important
11
LonWorks Network Layer

• Node address information
• Message routing to segment
• determining which nodes on the network receive
  various messages
• Network bandwidth usage control
• Routers
• segment traffic
• communicate between different channels

12
LonWorks Transport Layer

• Broadcast addressing
• Unicast addressing
• Multicast addressing - groups
• Repeated service
• Acknowledged service
• Unacknowledged service
• Duplicate packet detection
• Authentication

13
LonWorks Session Layer

• Acknowledgment of received message
• Application-to-application communication
• Retry if the correct response is not received
  from the remote node
• Request to a destination group and receive
  individual responses from the group
• Request - response message authentication

14
LonWorks Presentation Layer

• Input, output, and configuration variables for
  the node
• Standard data representations for physical
  quantities
• Network variable description

15
LonWorks Application Layer

• Memory storage for application program
• Built-in real-time operating system
• Device drivers for the I/O hardware on the Neuron
  Chip
• Standard Network Variable Types (SNVTs)

16
SNVTs

• Standard Network Variable Types
• A key to interoperability
• Standardizes variables used to name and describe
  things and their states
• Maintained by LonMark International
• Each standard known as an SNVT
• Pronounced snivit
• E.g., temperature is a 16-bit quantity
  representing -274 to 6279.5 Celcius

17
SNVT Examples

• Variable Type Units
• Temperature Degrees Celsius
• Real Time MM,DD,YYYY
• Event Count Counts
• of Full Scale Percent
• Volume Gallons, CCF, liters
• Flow Gal or liters/hour
• Weight Kilograms, Lbs.
• Speed Miles or Km/hour
• Alphanumeric ASCII Characters
• Alphanumeric Kanji Characters

Variable Type Units Switch State Boolean Device
State Boolean Energy Kilowatt-Hours Power Watts
Voltage DC or AC RMS Current Amps AC,
RMS Resistance Ohms Sound Level dBrnc Voltage dB
microvolts
Alphanumeric International characters Day of
Week Enumerated List (Mon-Sun) Elapsed
Time Second, Milliseconds, Days or Hours Phone
State Enumerated List (On-hook, off-hook, busy,
ringing, etc.) PressureLbs./sq.in, Pascals,
Inches-Hg Relative Humidity Percent
18
