Running Clustering Algorithm in Weka

1
Running Clustering Algorithm in Weka
Presented by Rachsuda Jiamthapthaksin Computer
Science Department University of Houston
2
What is Weka?

• Data mining software in Java
• Supervised learning (classification)
• Unsupervised learning (clustering)
• Tools
• Exploration
• Visualization
• Experiment
• Statistical summary

3
Download Weka

• http//www.cs.waikato.ac.nz/ml/weka/
• Window (weka-3-5-6jre.exe)
• Linux

4
Getting Start
5
Memory Limitation in Weka

• Run Chooser from DOS to increase memory
• C\gt java -Xmx128m -classpath ./progra1/weka-
  3-5/weka.jar weka.gui.GUIChooser

6
Weka GUI
7
Explorer
8
Open Files (.csv, .arff)
9
Datasets Description
Datasets statistics
Attributes
10
Remove Class Attribute
Non-class attributes
11
Select A Clustering Algorithm
12
Select A Clustering Algorithm
13
Select A Clustering Algorithm
14
Parameters Setting
15
Run A Clustering Algorithm
16
DBSCAN Results

• Run information
• Scheme weka.clusterers.DBScan -E 0.9 -M 6
  -I weka.clusterers.forOPTICSAndDBScan.Databases.Se
  quentialDatabase -D weka.clusterers.forOPTICSAndDB
  Scan.DataObjects.EuclidianDataObject
• Relation iris-weka.filters.unsupervised.attri
  bute.Remove-R5
• Instances 150
• Attributes 4
• sepallength
• sepalwidth
• petallength
• petalwidth
• Test mode evaluate on training data
• Model and evaluation on training set
• DBScan clustering results
•

• Clustered DataObjects 150
• Number of attributes 4

17
Simplify A Tested Dataset
18
Simplify A Tested Dataset
19
Parameters Setting
20
DBSCAN Clustering Results

• Run information
• Scheme weka.clusterers.DBScan -E 0.3 -M 50
  -I weka.clusterers.forOPTICSAndDBScan.Databases.Se
  quentialDatabase -D weka.clusterers.forOPTICSAndDB
  Scan.DataObjects.EuclidianDataObject
• Relation iris-weka.filters.unsupervised.attri
  bute.Remove-R1-2,5
• Instances 150
• Attributes 2
• petallength
• petalwidth
• Test mode evaluate on training data
• Model and evaluation on training set
• DBScan clustering results
•

• Clustered DataObjects 150
• Number of attributes 2
• Epsilon 0.3 minPoints 50
• Index weka.clusterers.forOPTICSAndDBScan.Database
  s.SequentialDatabase

21
Run k-Means in Weka
22
Parameters Setting
23
k-Means Clustering Results

• Run information
• Scheme weka.clusterers.SimpleKMeans -N 2
  -S 10
• Relation iris-weka.filters.unsupervised.attri
  bute.Remove-R1-2,5
• Instances 150
• Attributes 2
• petallength
• petalwidth
• Test mode evaluate on training data
• Model and evaluation on training set
• kMeans
• Number of iterations 6
• Within cluster sum of squared errors
  5.179687509974782

24
ArffViewer Convert Datasets Extension
25
Open A Datasets file
26
Select A Datasets File
27
View the Dataset
28
Manipulate the Dataset (Optional)
29
Save As .Arff File
30
Weka Documentation
