LIVER HEAMANGIOMAS

1
??? ???? ?????? ??????
2
LIVER HEAMANGIOMAS
3
Definition Classification

• Hemangiomas are benign tumors of the endothelial
  cells which normally line the blood vessels.
• These tumors exhibit endothelial hyperplasia and
  form extra blood vessels.
• Approximately 60 of hemangiomas occur in the
  head and neck area. About 25 occur in the trunk
  and 15 occur in the arms or legs.
• Most (about 80) hemangiomas grow as a single
  tumor, while about 20 occur in multiple areas.
• While hemangiomas often grow within the skin,
  they can also develop in virtually any internal
  organ, including the liver, lungs,
  gastrointestinal tract, and even the brain.

4

• Cavernous hemangioma is the most common primary
  liver tumor
• Its occurrence in the general population ranges
  from 0.4-20, as reported in an autopsy series
  (Karhunen, 1986).
• Hemangiomas are uncommon in cirrhotic livers the
  fibrotic process in cirrhotic liver may prohibit
  their development (Dodd, 1999).

5
Pathophysiology

• The natural history of liver hemangioma is not
  completely understood.
• Hemangiomas are probably congenital in origin.
• Hereditary factors may play a role in the
  pathogenesis of some familial forms.
• Although the growth of hemangiomas is reported in
  the literature, ectasia is believed to contribute
  to lesion enlargement.
•
  (Nghiem, 1997)
• Hemangiomas become fibrotic and shrink in
  patients with progressive cirrhosis (Brancatelli,
  2001).

6
CONT..Pathophy..

• Several pharmacologic agents have been postulated
  to promote tumor growth.
• Steroid therapy, estrogen therapy, and pregnancy
  can increase the size of an already existing
  hemangioma.
• Hemangiomas also have been reported in pregnant
  women following ovarian stimulation therapy with
  clomiphene citrate and human chorionic
  gonadotropin.
• Whether any of these agents or conditions
  actually induces the development of hemangiomas
  de novo remains unclear.

7
Clinical Presentation

• Sex female-to-male ratio of 51 to 61.
• Cavernous hemangioma of the liver affects both
  sexes equally in children and in autopsy series.
• Age Hemangiomas can occur in individuals of any
  age.
• They frequently occur in middle-aged women.
• Hepatic hemangiomas are rare in infancy.
• Have been detected prenatally in a growing fetus.

8
Conti.. Clinical Present..

• The vast majority of hemangiomas (85) are
  asymptomatic.
• They most often are discovered when the liver is
  imaged for another reason or when the liver is
  examined at laparotomy or autopsy.
• Right upper quadrant pain is
• The most common complaint
• May result from thrombosis and infarction of the
  lesion, hemorrhage into the lesion, or
  compression of adjacent tissues or organs.
• Physical examination Infrequently,
• An enlarged liver.
• The presence of an arterial bruit over the right
  upper quadrant.

9
Conti.. Clinical Present..

• Rarely, hemangiomas may present as a large
  abdominal mass.
• Other atypical presentations include
• Cardiac failure from massive arteriovenous
  shunting,
• Jaundice from compression of the bile ducts,
• Gastrointestinal bleeding from hemobilia, and
• Fever of unknown origin.
• An illness that resembles a systematic
  inflammatory process has been described with
  findings of fever, weight loss, anemia,
  thrombocytosis, increased fibrinogen level, and
  elevated erythrocyte sedimentation rate.

10
Complications

• Complications depend on the size and location of
  the tumor.
• Pressure on the stomach and duodenum caused by
  large
• pedunculated lesions may cause vague
  abdominal pain, early
• satiety, nausea, and vomiting.
  (Tran-Minh, 1991).
• Pedunculated hemangiomas may twist and cause
  acute abdominal pain.

  (Tran-Minh, 1991)
• Compression of the inferior vena cava may result
  in Budd-Chiari syndrome.
  (Hanazaki,
  2001)
• Acute thrombosis may result in acute inflammatory
  changes that cause fever, abdominal pain, and
  abnormal liver function.

•
  (Pol, 1998)
• Spontaneous or post-traumatic rupture is a
  catastrophic complication that occurs in about
  1-4 of hemangiomas it has a considerable
  mortality rate, as high as 60.
  (Cappellani, 2000)

11
As Part Of Well-defined Clinical Syndromes

• In Klippel-Trenaunay-Weber syndrome, hepatic
  hemangiomas occur in association with congenital
  hemiatrophy and nevus flammeus, with or without
  hemimeganencephaly.
• In Kasabach-Merritt syndrome, giant hepatic
  hemangiomas are associated with thrombocytopenia
  and intravascular coagulation.
• Osler-Rendu-Weber disease is characterized by
  numerous small hemangiomas of the face, nares,
  lips, tongue, oral mucosa, gastrointestinal
  tract, and liver.
• Von Hippel-Lindau disease is marked by cerebellar
  and retinal angiomas, with lesions also in the
  liver and pancreas.
• Multiple hepatic hemangiomas have been reported
  in patients with systemic lupus erythematosus.
• Cutaneous hemangiomas are a common finding.
• No correlation was found between the presence of
  both cutaneous and hepatic hemangiomas in
  individual patients.

12
Lab Studies

• Results usually are normal.
• Anemia and reduced hematocrit levels may be
  present in patients with ruptured hemangiomas.
• Thrombocytopenia can result from sequestration
  and destruction of platelets in large lesions.
• Hypofibrinogenemia has been attributed to
  intratumoral fibrinolysis.
• In patients with giant hemangiomas associated
  with Kasabach-Merritt syndrome, bleeding and
  clotting parameters may be abnormal.
• Normal alpha-fetoprotein and carcinogenic
  embryonic antigen (CEA) levels bolster clinical
  suspicion of a benign hepatic mass lesion.

13
Differential diagnosis

• Hepatic hemangiomas should be differentiated from
  other hypervascular benign and malignant
  space-occupying liver lesions.
• Benign lesions include cysts, adenomas, focal
  nodular hyperplasia, and regenerating nodules.
• Malignant lesions include hepatocellular
  carcinoma and metastasis heamangioendothelioma.

14
Pathology

• Usually, they occur as solitary lesions.
• They may be multiple in as many as 50 of
  patients (Mergo, 1998). No lobar predilection
  exists.
• Hemangiomas typically measure less than 5 cm
  some authors call those larger than 4-5 cm giant
  hemangiomas (Cappellani, 2000 Yang, 2001).
• Sizes range from 2 mm to more than 20 cm.
• Grossly, these lesions often appear as having a
  flat surface or as bulging subcapsular lesions.
• Lesions are reddish-blue and well demarcated from
  surrounding tissue.
• Large tumors may become pedunculated.
• They may be associated with focal nodular
  hyperplasia (Vilgrain, 2000).

15
Histologic Findings

• Cavernous hemangioma are atypical or irregular in
  arrangement and size.
• Microscopically
• Mesenchymal in origin.
• Hemangiomas are composed of cavernous vascular
  channels lined by single layers of flattened
  endothelium and are separated by fibrous septa.
• These vascular spaces may contain thrombin,
  calcifications, or prominent scarring with
  hyalinization (sclerosed hemangioma).
• Malignant transformation has not been reported.

16

• Most hemangiomas are incidentally detected at
  imaging studies.
• Ultrasonography is a cost-effective imaging
  modality for diagnosis of a hemangioma.
• CT and/or MRI may be required to specifically
  diagnose hemangioma

17
Imaging Studies

• The modalities used for diagnosis of hepatic
  hemangiomas include ultrasonography (US),
  bolus-enhanced CT with sequential scans,
  single-photon emission computerized tomography
  (SPECT) with colloid 99m-labeled RBCs, magnetic
  resonance imaging (MRI), hepatic arteriography,
  and digital subtraction angiography (DSA).
• Ultrasound
• This is the most commonly initial diagnostic
  tool.
• Usually homogeneous
• Well-defined hyperechoic masses (though few can
  appear relatively hypoechoic when imaged within a
  fatty liver)
• Giant lesions can appear heterogeneous secondary
  to internal complex composition
• Posterior acoustic enhancement is commonly seen.
• CT scan
• Focal, well-circumscribed, low attenuation
  lesions on pre-contrast images
• Nodular, peripheral centripetal enhancement on
  dynamic contrast enhanced imaging

18
Gray-scale and Doppler sonograms show a
well-defined, uniformly hyperechoic liver mass
with peripheral feeder vessels. These features
are characteristic of a hemangioma
19
(No Transcript)
20
Contrast-enhanced CT scan obtained during the
arterial-dominant phase demonstrates a hemangioma
with homogeneous and intense contrast enhancement
21
Contrast-enhanced CT scans reveal the pathognomic
features of a hemangioma, namely, peripheral
nodular enhancement and progressive centripetal
fill-in (arrow). The smaller, peripheral lesion
(circled) shows homogeneous enhancement
22
(No Transcript)
23
MRI

• Has a sensitivity and specificity of greater than
  90
• Can differentiate hemangiomas from other liver
  lesions especially the Small ones
• Typically hemangiomas are homogeneously
  hypointense relative to the liver on T1-weighted
  and markedly hyperintense (lightbulb sign) on
  T2-weighted images relative to the liver
• On dynamic, contrast-enhanced MR imaging,
  hemangiomas can demonstrate immediate homogeneous
  enhancement (lesions lt 1.5cm)
• Peripheral, nodular centripetal enhancement
  pattern progressing to homogeneity (lesions
  1.5-5cm)
• Peripheral nodular centripetal enhancement with
  persistent central hypointense region (lesionsgt
  5cm)

24

• Giant cavernous hemangioma of the liver Axial
  T1-weighted pre-contrast imageshows a
  hypointense mass within the right hepatic lobe.
• Sequential enhanced delayed images
  showperipheral nodular centripetal enhancement
  with persistent central hypointensity

25
Hemangioma appears as a hypointense mass on
T1-weighted MRIs and as a hyperintense mass on
dual-echo T2-weighted MRIs. Note that the signal
intensity of the lesion is similar to that of the
adjacent CSF
26
Dynamic gadolinium-enhanced MRIs demonstrate the
progressive, centripetal contrast enhancement in
a hemangioma
27
(No Transcript)
28
Single-photon emission computerized tomography
(SPECT)

• SPECT with colloid 99m-labeled RBCs appears to be
  as sensitive and specific as MRI.
• At present, SPECT scan is most likely the
  investigation of choice to confirm the diagnosis
  of hepatic hemangioma.
• The sensitivity for detecting large lesions of
  the liver (gt2-3cm) is also high. Hemangiomas as
  small as 0.5 cm may be detected with SPECT.

29
SPECT images were obtained one hour post
injection. These demonstrate two foci of
increased blood pool activity the smaller one in
the left lateral lobe of the liver and a second
larger lobular one in the posterior right lobe of
the liver. These corresponded in location to the
hypodense lesions seen on the CT study
30
SPECT examination Axial scans of blood-pool
scintigraphy with 99mTc-labeled erythrocytes A
well-circumscribed area (arrow) of increased
activity is present in the left lobe of the
liver, which indicates pathology with a high
blood content.
31
Arteriography

• This invasive modality still may be useful in
  helping diagnose some hepatic hemangiomas.
• Branches of the hepatic artery may be displaced
  and crowded together or stretched around the
  lesion, with normal vascular tapering.
• Hemangiomas are characterized by the early
  opacification of irregular areas or lakes, with
  persistence of contrast in these areas long after
  arterial emptying. The hemangioma may appear as a
  ring or C-shaped lesion with an avascular center.
• Other Tests
• A precise diagnosis can be achieved in most cases
  by employing a combination of laparoscopy and
  fine-needle biopsy under sonographic guidance.

32

• Liver biopsy
• Obtaining percutaneous biopsies of hepatic
  hemangiomas carries an increased risk of
  hemorrhage.
• It is contraindicated
• It may be reasonable in differentiation small
  liver lesion from hepatocellular carcinoma.
• It may shorten the diagnostic workup.

33
Medical Care

• Most hepatic hemangiomas are small and
  asymptomatic at the time of diagnosis, and are
  likely to remain that way so they may be safely
  left alone.
• Routine follow-up
• Malignant transformation is not reported.
• Is not indicated in confirmed hepatic
  hemangiomas.
• Unless symptoms develop or tumor enlargement is
  suspected.
• Lesions should be reimaged every 3-6 months
• To rule out tumor enlargement in cases was in
  doubt at time of tumor detection.

34
Management Of Large Hemangiomas

• No medical therapy is known to reduce the size or
  eliminate hepatic hemangiomas.
• The risk of rupture may warrant therapy in the
  case of large and symptomatic hepatic
  hemangiomas.
• Therapeutic modalities include
• surgical resection,
• surgical enucleation,
• arterial embolization,
• radiation therapy,
• orthotopic liver transplantation.
• Surgical resection is the treatment of choice.

35
Arterial embolization

• Resection may not be possible due to
• Massive or diffuse nature of the lesion
• Its proximity to vascular structures.
• Branches of the hepatic artery can be embolized
  with polyvinyl alcohol and other substances.
• Embolization results in shrinking of the tumor,
  thereby minimizing the risk of complications.
• Complications Pain, fever, and nongranulomatous
  arteritis with eosinophilic infiltration.

36
Hepatic irradiation and ligation of feeding
vessels

• Hepatic irradiation over 3 weeks has been
  reported to produce complete regression of
  hepatic hemangiomas, with minimal morbidity.
• Transhepatic compression sutures and selective
  ligation of large feeding vessels have
  successfully reduced intratumoral shunting that
  otherwise would have led to intractable cardiac
  failure.

37
Surgical Treatment

• Surgery is indicated for
• symptomatic hemangiomas,
• rapidly growing tumors,
• Large lesions (gt10 cm).
• if hemangioma cannot be differentiated from
  hepatocellular carcinoma.
• Surgical resection
• An open or a laparoscope-assisted technique.
• Hepatic lobectomy may be necessary in the case of
  large lesions.
• The procedure is safe and well tolerated, with
  minimal postoperative morbidity and an average
  length of hospital stay of 6 days.
• In the absence of tumor-promoting factors such as
  estrogen therapy, tumors rarely recur after
  successful resection.

38
Liver transplantation

• Patients with severe symptoms from large or
  diffuse hemangiomas that are not resectable can
  undergo total hepatectomy and orthotopic liver
  transplantation, with the expectation of good
  long-term results.

39

• Consultations
• Consultation with a surgeon is warranted if
  resection is the choice of therapy.
• Diet
• No special dietary requirements or therapy is
  indicated.
• Activity
• No restriction of physical activity is indicated.
• Avoid trauma to right upper abdominal quadrant,
  especially if the hepatic hemangioma is large.
• No medications are useful to shrink or eradicate
  hepatic hemangiomas.

40
Thank you

• By assistant lecturer
• Dina Ismail
