Title: ADF/NDB Navigation


1
ADF/NDB Navigation
  • AST 241
  • Professor Barnhart

2
NDB Background
  • Oldest form of radio navigation still in use
  • Operate in the LF/MF range (190 535 kHz- or
    between 100 and 10,000 meters)
  • Still in use because of its simplicity and low
    cost to set up and operate decent accuracy
  • Little used for enroute navigation in the US but
    still used for approaches
  • Used for enroute nav. In much of the world

3
NDB background
  • NDBs are also useful at ranges up to 600 N.M.
  • Ground equipment consists of a simple a.m. radio
    station
  • Aircraft receiver is little more complicated than
    an AM radio.

4
Principles of NDB Navigation
  • Transmitters vary in power from 25 watts for
    Locator Outer Markers (LOMs) on an ILS approach
    to as much as 2000 watts.
  • The range of the most powerful transmitters is
    listed as 75 miles but is usually much greater.
  • 4 types of NDBs Compas locators, Approach aids
    (25 NM), Enroute beacon, High power beacons- used
    in some costal areas- largely obsolete

5
Aircraft Equipment
  • The Automatic Direction Finder (ADF) consists of
  • AM receiver
  • Sense Antenna
  • Loop Antenna (directional antenna)
  • Indicator (fixed or movable card)

6
Aircraft Equipment Ctn.
  • The Automatic in ADF comes from the fact that the
    directional antenna is rotated electronically
    rather than manually by rotating the antenna or
    turning the aircraft to make signal strength
    determinations.

7
ADF Operation
  • There is a switch on the receiver marked
  • OFF/ADF/ANT/BFO
  • ANT- gives maximum receiver sensitivity and
    should be used for tuning and identifying (3
    letter coded I.D. except for LOMs which have 2
    letter I.D.s)
  • BFO (ContinuousWave) position is used for better
    identifying unmodulated signals which are used in
    other parts of the world.

8
ADF Operation Ctn.
  • After identifying station be sure to place
    selector switch in the ADF mode as the
    indicator will not display any bearing
    information in the ANT mode
  • Leave volume up continuously when using the ADF
    as NDB frequencies can shift
  • Most units have a Test function which swings
    the needle dont use if the needle doesnt
    swing. This verifies proper signal reception.

9
ADF indicators
  • Fixed card
  • With a fixed card there are two ways to determine
    magnetic bearing to the station
  • Turn the aircraft toward the station and note
    heading
  • MH RB MB (to the station)
  • MH aircraft magnetic heading
  • RB Relative bearing
  • MB Magnetic Bearing (to the station)
  • (If the result is more than 360 then subtract 360

10
ADF Indicators
  • Movable Card Indicators
  • Set aircraft heading at top of the indicator and
    read the relative bearing to the station.

11
NDB Navigation Techniques
  • Homing
  • Turing the aircraft such that the needle always
    points directly toward the station- easy but
    inefficient as it does not compensate for
    crosswinds
  • Results in a curved path to the station in a
    crosswind situation

12
NDB Navigation Techniques
  • Tracking
  • Establishing a wind correction angle that negates
    the drift caused by the crosswind
  • Principle WHEN THE ANGLE OF DEFLECTION THE
    ANGLE OF INTERCEPTION YOURE ON COURSE
  • Or when the angle formed by the aircraft heading
    and the desired course is the same as the angle
    between either the 0 or 180 mark on the indicator
    and the pointer, the aircraft is on course.

13
Tracking ctn.
  • Tracking tip- When tracking inbound on an NDB
    bearing and you note youre off course
  • Note the angle of deflection, double it, and use
    that as your intercept heading. When that angle
    of deflection is then noted on the indicator
    (from the nose or tail) the aircraft is back on
    course
  • Establish an initial track by taking half of that
    intercept angle out

14
Tracking Ctn.
  • Example
  • You want to track inbound on the 360 bearing to
    the station. There is a wind from the west.
  • While tracking (heading north) unaware of the
    wind you note a left needle deflection of 10
    degrees.
  • Double that to 20 degrees for your intercept
    heading and turn the aircraft left to 340 degrees.

15
Tracking Ctn.
  • As you turn to 340 you notice the needle move
    toward the top of the indicator.
  • As you continue on 340 the needle will drift
    toward the right. When it indicates 20 degrees,
    the aircraft is back on course.
  • Take half your calculated intercept heading and
    use that as your initial track heading (350
    degrees). This results in a 010 degree indication
    on the indicator.
  • Repeat the process until track correction and
    needle deflection are equal.

16
NDB/ADF Limitations
  • Night Effect-
  • NDBs emit three signals, among these are the
    ground wave and the sky wave. Normally the
    ground wave is the strongest which is the one use
    for navigation.
  • The skip zone is the difference or gap between
    the ground wave and the reflected sky wave.
  • Light passing through the ionosphere causes
    height fluctuations within it varying the angle
    of the reflected sky wave and possibly causing
    signal confusion during this time between the two
    signals. The needle may wander. Resolves
    shortly after sunrise or sunset.

17
Fading
  • Usually occurs at night when ground wave and sky
    wave interact going in and out of phase causing
    the signals to be either canceled or reinforced
    as the atmosphere changes.
  • Pilots will notice a rythmic swinging of the
    needle and a volume fluctuation of the
    identifier.
  • Average the fluctuations and note the bearing
    when the signal seems strong.

18
Shoreline Effect
  • Ground waves change direction as they pass from
    land to water and visa versa they are bent
    slightly.
  • Pilots should note potential bearing indication
    errors when flying in the vicinity of costal
    areas. NDBs used primarily for oceanic
    navigation have been designed to minimize this
    error.

19
Other sources of Error
  • Terrain- mountains, areas with high
    concentrations of iron
  • Interference- between two stations may cause the
    ADF to oscillate between one station and the
    other- indicated by receiving two simultaneous
    I.D. codes. Usually resolves itself with
    proximity.

20
Thunderstorms
  • Lightening can create signal disturbances causing
    the needle to momentarily swing in the direction
    of the storm. As such ADF is sometimes referred
    to as a Poor mans Storm Scope.
  • Pilots should not rely on ADF indications in the
    vicinity of thunderstorms.

21
ADF Accuracy
  • Variable- not possible to determine. As such,
    back up ADF indications whenever possible.

22
The End
  • Questions?
