Virtual Topologies

1
Virtual Topologies

• Self Test with solution

2
Self Test

• When using MPI_Cart_create, if the cartesian grid
  size is smaller than processes available in
  old_comm, then
• error results.
• new_comm returns MPI_COMM_NULL for calling
  processes not used for grid.
• new_comm returns MPI_UNDEFINED for calling
  processes not used for grid.

3
Self Test

• When using MPI_Cart_create, if the cartesian grid
  size is larger than processes available in
  old_comm, then
• error results.
• the cartesian grid is automatically reduced to
  match processes available in old_comm.
• more processes are added to match the requested
  cartesian grid size if possible otherwise error
  results.

4
Self Test

• After using MPI_Cart_create to generate a
  cartesian grid with grid size smaller than
  processes available in old_comm, a call to
  MPI_Cart_coords or MPI_Cart_rank
  unconditionally(i.e., without regard to whether
  it is appropriate to call) ends in error because

• calling processes not belonging to group have
  been assigned the communicator MPI_UNDEFINED,
  which is not a valid communicator for
  MPI_Cart_coords or MPI_Cart_rank.
• calling processes not belonging to group have
  been assigned the communicator MPI_COMM_NULL,
  which is not a valid communicator for
  MPI_Cart_coords or MPI_Cart_rank.
• grid size does not match what is in old_comm.

5
Self Test

• When using MPI_Cart_rank to translate cartesian
  coordinates into equivalent rank, if some or all
  of the indices of the coordinates are outside of
  the defined range, then
• error results.
• error results unless periodicity is imposed in
  all dimensions.
• error results unless each of the out-of-range
  indices is periodic.

6
Self Test

• With MPI_Cart_shift(comm, direction, displ,
  source, dest), if the calling process is the
  first or the last entry along the shift direction
  and that displ is greater than 0, then
• error results.
• MPI_Cart_shift returns source and dest if
  periodicity is imposed along the shift direction.
  Otherwise, source and/or dest return
  MPI_UNDEFINED.
• error results unless periodicity is imposed along
  the shift direction.

7
Self Test

• MPI_Cart_sub can be used to subdivide a cartesian
  grid into subgrids of lower dimensions. These
  subgrids
• have dimensions one lower than the original grid.

• attributes such as periodicity must be reimposed.

• possess appropriate attributes of the original
  cartesian grid.

8
Answer

• B
• A
• B
• C
• B
• C

9
Course Problem

• Description
• The new problem still implements a parallel
  search of an integer array. The program should
  find all occurrences of a certain integer which
  will be called the target. When a processor of a
  certain rank finds a target location, it should
  then calculate the average of
• The target value
• An element from the processor with rank one
  higher (the "right" processor). The right
  processor should send the first element from its
  local array.
• An element from the processor with rank one less
  (the "left" processor). The left processor should
  send the first element from its local array.

10
Course Problem

• For example, if processor 1 finds the target at
  index 33 in its local array, it should get from
  processors 0 (left) and 2 (right) the first
  element of their local arrays. These three
  numbers should then be averaged.
• In terms of right and left neighbors, you should
  visualize the four processors connected in a
  ring. That is, the left neighbor for P0 should be
  P3, and the right neighbor for P3 should be P0.
• Both the target location and the average should
  be written to an output file. As usual, the
  program should read both the target value and all
  the array elements from an input file.

11
Course Problem

• Exercise
• Modify your code from Chapter 7 to solve this
  latest version of the Course Problem using a
  virtual topology. First, create the topology
  (which should be called MPI_RING) in which the
  four processors are connected in a ring. Then,
  use the utility routines to determine which
  neighbors a given processor has.

12
Solution

• Note The sections of code shown in red are new
  code in which the MPI_RING virtual topology is
  created. The section of code in blue is where the
  new topology is used by each processor to
  determine its left and right neighbors.

13
Solution

• include ltstdio.hgt
• include ltmpi.hgt
• define N 300
• int main(int argc, char argv)
• int i, target /local variables/
• int bN, aN/4 /a is name of the array each
  slave searches/
• int rank, size, err
• MPI_Status status
• int end_cnt
• FILE sourceFile
• FILE destinationFile
• int left, right /the left and right
  processes/
• int lx, rx /store the left and right
  elements/
• int gi /global index/

14
Solution

• int blocklengths2 1, 1 / initialize
  blocklengths array /
• MPI_Datatype types2 MPI_INT, MPI_FLOAT /
  initialize types array /
• MPI_Datatype MPI_Pair
• MPI_Aint displacements2
• MPI_Comm MPI_RING / Name of the new cartesian
  topology /
• int dim1 / Number of dimensions /
• int period1, reorder / Logical array to
  control if the dimension should "wrap-around" /
• int coord1 / Coordinate of the processor in
  the new ring topology /
• err MPI_Init(argc, argv)
• err MPI_Comm_rank(MPI_COMM_WORLD, rank)
• err MPI_Comm_size(MPI_COMM_WORLD, size)
• / Initialize displacements array with memory
  addresses /
• err MPI_Address(gi, displacements0)
• err MPI_Address(ave, displacements1)
• / This routine creates the new data type
  MPI_Pair /
• err MPI_Type_struct(2, blocklengths,
  displacements, types, MPI_Pair)

15
Solution

• if(size ! 4)
• printf("Error You must use 4 processes to run
  this program.\n")
• return 1
• dim0 4 / Four processors in the one row
  /
• period0 1 / Have the row "wrap-around" to
  make a ring /
• reorder 1
• / Create the the new ring cartesian topology
  with a call to the following routine /
• err MPI_Cart_create(MPI_COMM_WORLD, 1, dim,
  period, reorder, MPI_RING)
• if (rank 0)
• / File b.data has the target value on the
  first line /
• / The remaining 300 lines of b.data have the
  values for the b array /
• sourceFile fopen("b.data", "r")
• / File found.data will contain the indices of
  b where the target is /
• destinationFile fopen("found.data", "w")

16
Solution

• if(sourceFileNULL)
• printf("Error can't access file.c.\n")
• return 1
• else if(destinationFileNULL)
• printf("Error can't create file for
  writing.\n")
• return 1
• else
• / Read in the target /
• fscanf(sourceFile, "d", target)
• /Notice the broadcast is outside of the if, all
  processors must call it/
• err MPI_Bcast(target, 1, MPI_INT, 0,
  MPI_COMM_WORLD)
• if (rank 0)
• / Read in b array /
• for (i0 iltN i)
• fscanf(sourceFile,"d", bi)

17
Solution

• / Again, the scatter is after the if, all
  processors must call it /
• err MPI_Scatter(b, N/size, MPI_INT, a, N/size,
  MPI_INT, 0, MPI_COMM_WORLD)
• / Each processor easily determines its left and
  right neighbors /
• / with the call to the following utility
  routine /
• err MPI_Cart_shift(MPI_RING, 0, 1, left,
  right)
• if (rank 0)
• / P0 sends the first element of its subarray a
  to its neighbors /
• err MPI_Send(a0, 1, MPI_INT, left, 33,
  MPI_COMM_WORLD)
• err MPI_Send(a0, 1, MPI_INT, right, 33,
  MPI_COMM_WORLD)
• / P0 gets the first elements of its left and
  right processor's arrays /
• err MPI_Recv(lx, 1, MPI_INT, left, 33,
  MPI_COMM_WORLD, status)
• err MPI_Recv(rx, 1, MPI_INT, right, 33,
  MPI_COMM_WORLD, status)
• /Master now searches the first fourth of the
  array for the target /
• for (i0 iltN/size i)
• if (ai target)

18
Solution

• end_cnt 0
• while (end_cnt ! 3)
• err MPI_Recv(MPI_BOTTOM, 1, MPI_Pair,
  MPI_ANY_SOURCE, MPI_ANY_TAG, MPI_COMM_WORLD,
  status)
• if (status.MPI_TAG 52)
• end_cnt /See Comment/
• else
• fprintf(destinationFile,"P d, d f\n",
  status.MPI_SOURCE, gi, ave)
• fclose(sourceFile)
• fclose(destinationFile)
• else
• / Each slave sends the first element of its
  subarray a to its neighbors /
• err MPI_Send(a0, 1, MPI_INT, left, 33,
  MPI_COMM_WORLD)
• err MPI_Send(a0, 1, MPI_INT, right, 33,
  MPI_COMM_WORLD)
• / Each slave gets the first elements of its
  left and right processor's arrays /

19
Solution

• / Search the b array and output the target
  locations /
• for (i0 iltN/size i)
• if (ai target)
• gi (rank)N/sizei1 /Equation to convert
  local index to global index/
• ave (targetlxrx)/3.0
• err MPI_Send(MPI_BOTTOM, 1, MPI_Pair, 0,
  19, MPI_COMM_WORLD)
• gi target / Both are fake values /
• ave3.45 / The point of this send is the
  "end" tag (See Chapter 4) /
• err MPI_Send(MPI_BOTTOM, 1, MPI_Pair, 0, 52,
  MPI_COMM_WORLD) /See Comment/
• err MPI_Type_free(MPI_Pair)
• err MPI_Finalize()
• return 0

20
Solution

• The results obtained from running this code are
  in the file "found.data" which contains the
  following
• P 0, 62, -7.666667
• P 2, 183, -7.666667
• P 3, 271, 19.666666
• P 3, 291, 19.666666
• P 3, 296, 19.666666
• Notice that in this new version of the code we
  obtained the same results as the stencil version,
  which we should have.
• If you want to confirm that these results are
  correct, run the parallel code shown above using
  the input file "b.data" from Chapter 2.
