The Pebble Bed Modular Reactor Project

1
The Pebble Bed Modular Reactor Project

• Johan Slabber
• Chief Technology Officer
• PBMR (Pty) Ltd

2
Distribution of Electricity Generating Plants in
South Africa
3
The Project

• PBMR (Pty) Ltd intends to
• Build a demonstration module at Koeberg near Cape
  Town
• Build an associated fuel plant at Pelindaba near
  Pretoria
• Commercialize and market 165MWe modules in single
  or multi-module configuration for the local and
  export markets
• Transform PBMR (Pty) Ltd into a world-class
  company

4
The PBMR Company

• Current staff of 650 people growing to 900 in
  2009
• Worlds largest technology nuclear development
  team
• (2000 people in total involved in project
  worldwide)
• More than 50 PhDs and with 2.5 degrees per
  person on
• average
• Shareholders SA Gov, Industrial Development
• Corporation, Eskom and Westinghouse
• Worlds Best suppliers
• SA proud of PBMR team - know what we are doing

5
Supportive South African Government

• PBMR announced as National Strategic Project
• Committed to nuclear power, in the form of PBMR,
  as a significant portion (20-25) of future
  electric supply
• Approved funding for developing Demonstration
  plant for commissioning in 2010
• Affirmed program to develop human capital to
  helpenhance sustainable development in Africa

6
Growth in SA Electricity Demand

• Compound annual demand growth of 3.4 per year
  since 1992 (2004 peak 34,210MW compared to 22,640
  in 1992)
• National Energy Regulators Integrated Resource
  Plan shows
• Projected growth of 2.8/annum to 2022
• New build capacity of over 20,000MW required by
  2022
• Growth at 4 would require 40,000MW
• Eskom predicts growth in demand of 1200 MW p/a
  over next 20 years

7
Diversity of Energy Sources

• The expansion of generating capacity in South
  Africa should include a diversity of energy
  sources, including coal, hydro, nuclear, wind,
  solar, wave, tidal etc.
• To meet energy development challenges, South
  Africa needs to optimally use all energy sources
  available and vigorously pursue energy efficient
  programmes

8
World Electricity Market

• World capacity in January 2002 was 3,465GW (100
  x Eskom)
• World average growth of 3 per annum since 1980
  (equates to 600 PBMRs per year)
• MIT forecasts world demand to triple by 2050
• Current world spending is about 100bn per year
  on new power stations
• Fossil fuel costs have risen dramatically
• Environmental pressure is increasing

9
Resurgence of Nuclear Energy

• Thirty nuclear plants are being built today in 12
  countries around the world
• Green guru James Lovelock and Greenpeace
  co-founder Patrick Moore calls for massive
  expansion of nuclear to combat global warming
  (May 2004)
• George Bush signs energy bill and describes
  nuclear as one of the nations most important
  sources of energy (Aug 2005)
• US Energy Secretary Samuel Bodman predicts
  nuclear will thrive as a future emission-free
  energy source (April 2005)
• Tony Blair proposes new generation of nuclear
  plants to combat climate change (July 2004)

10
Resurgence of Nuclear Energy

• China plans to build 27x1000MW nuclear reactors
  over the next 15 years
• India plans a ten-fold nuclear power increase
• France to replace its 58 nuclear reactors with
  EPR units from 2020, at the rate of about one
  1600 MWe unit per year.
• IAEA predicts at least 60 new reactors will
  become operational within 15 years

11
Views on Nuclear

• "How are we going to satisfy the extraordinary
  need for energy in really rapidly developing
  countries? I don't think solar and wind are going
  to do it. We are going to have to find a way to
  harness all energy supplies that includes
  civilian nuclear power."
• Condoleezza Rice, US Secretary of State, Sept
  2005

12
Views on PBMR

• The long-term future of power reactors belongs
  to very high temperature reactors such as the
  PBMR. Nils Diaz, Chairman of the US Nuclear
  Regulatory Commission, July 2004
• I feel we made a mistake in halting the HTR
  programme. Klaus Töpfer, Germanys former
  Minister of Nuclear Power and Environment.
  Davos, January 2003
• The PBMR technology could revolutionize how
  atomic energy is generated over the next several
  decades. It is one of he near-term technologies
  that could change the energy market. Prof.
  Andrew Kadak, Massachusetts Institute of
  Technology, January 2002
• Little old South Africa is kicking our butt with
  its development of the PBMR. This should be a
  wake-up call for the US. Syd Ball, senior
  researcher at Oak Ridge National Laboratory, 11
  June 2004.

13
PBMR Uniquely Positioned

• Non-CO2 emitting option in climate change debate
• Inherent safety reducing regulation burden
• Small unit flexibility with short construction
  periods
• Accepted as very low nuclear proliferation risk
• Close enough to commercial deployment to achieve
  first to market dominance
• Eskom build program of at least 20 000 MW over
  the next 15 years

14
Advantages to South Africa

• Ability to site on coast, away from coal fields
• RSA based turnkey supplier allows localisation
  of manufacture on sub-contractors
• Locally controlled technology limiting foreign
  exchange exposure
• About 56 000 local jobs created during full
  commercial phase
• R23 billion net positive impact on Balance of
  Payments

15
Salient Features

• Can be placed near point of demand
• Small safety zone
• On-line refuelling
• Load-following characteristics
• Process heat applications
• Well suited for desalination purposes
• Synergy with hydrogen economy

16
Why PBMR could be the first successful
commercialGeneration IV reactor
17
PBMR Design Objectives
(SourceA Technology Roadmap for Generation IV
Nuclear Energy Systems U.S. DOE Dec 2002)

• PBMR design objectives are in line with the
  requirements of the Generation IV nuclear energy
  systems
• According to the current planning should come on
  line in 2010

PBMR
18
The Technology
The PBMR is a small-scale, helium-cooled,
direct-cycle, graphite-moderated,
high-temperature reactor (HTR). Although it is
not the only gas-cooled HTR currently being
developed in the world, the South African project
is internationally regarded as the leader in the
power generation field.
19
Schematic Diagram of Power Conversion Unit
Net Electrical Efficiency41.2
900C 8.6MPa
20
Physical Layout of PBMR Main Power System
Compressors
Recuperator
Generator
Reactor Unit
Gearbox
Power Turbine
Intercooler
CCS
CBCS
21
PBMR Fuel Design
22
Fuel Handling System
Fuel Handling System Schematic Diagram

• PBMR spent fuel to be kept on site
• A 165 MWe module will generate 32 tons
• of spent fuel pebbles per year, about one
• ton of which is uranium
• Fuel spheres are pre-packagedfor final
• disposal purposes
• Draft nuclear waste management policy
• issued for public comment in 2003

23
Reactor Safety Fundamentals

• Main safety objective is to preserve the
  integrity of the fuel under all postulated events
• To reach this objective it is therefore necessary
  to ensure that the fuel does not heat up or is
  degraded by some other means to a point where the
  activity retention capability is lost

24
Reactor Safety Fundamentals

• The ultimate fuel temperature and the fuel
  element structural characteristics determine the
  activity retention capability during operation
  and following an event.
• Three factors determine the ultimate fuel
  temperature during operation and following an
  event
• - Production of heat in the core
• - Removal of heat from the core
• - The heat capacity of the core

25
PBMR Core Size and Shape

• All ceramic
• Low powerdensity
• Large heat capacity

26
PBMR Passive Decay Heat Removal Mechanisms
Centre Reflector
Pebble Core
Side Reflector
Core Barrel
RPV
RCCS
Reactor Cavity
Reactor Cavity Cooling System
27
Fuel Temperature Rise Followinga Depressurized
Loss of Forced Cooling
Safe Temperature
28
Safety Features Summary

• Simple design base
• If fault occurs, system shuts itself down
• The transfer medium (helium) is chemically inert
• Coated particle provides excellent containment
  for the fission product activity
• No need for safety grade backup systems
• No need for off-site emergency plans
• License application for small safety zone
• Inherent safety proven during public tests

29
Demonstration Plant Building
Nuclear Island
Conventional Island
30
Demonstration Plant Building
31
Multi-Module Concept
32
What Happens Next?

• EIA reopened and public meetings started
• Construction to start in 2007 (subject to
  positive conclusion of regulatory processes)
• Demonstration module and fuel plant to be
  completed by 2011
• First commercial modules to be completed by 2013

33
Questions
34
Thank You
