Title: Examples of One-Dimensional Systolic Arrays


1
Examples of One-Dimensional Systolic Arrays
2
Motivation Introduction
  • We need a high-performance , special-purpose
    computer
  • system to meet specific application.
  • I/O and computation imbalance is a notable
    problem.
  • The concept of Systolic architecture can map
    high-level
  • computation into hardware structures.
  • Systolic system works like an automobile
    assembly line.
  • Systolic system is easy to implement because of
    its
  • regularity and easy to reconfigure.
  • Systolic architecture can result in
    cost-effective , high-
  • performance special-purpose systems for a wide
    range
  • of problems.

3
Pipelined Computations
  • Pipelined program divided into a series of tasks
    that have to be completed one after the other.
  • Each task executed by a separate pipeline stage
  • Data streamed from stage to stage to form
    computation

4
Pipelined Computations
  • Computation consists of data streaming through
    pipeline stages
  • Execution Time Time to fill pipeline (P-1)
    Time to run in steady state (N-P1)
  • Time to empty pipeline (P-1)

P of processors N of data items (assume P
lt N)
This slide must be explained in all detail. It is
very important
5
Pipelined Example Sieve of Eratosthenes
  • Goal is to take a list of integers greater than 1
    and produce a list of primes
  • E.g. For input 2 3 4 5 6 7 8 9 10, output is
    2 3 5 7
  • A pipelined approach
  • Processor P_i divides each input by the i-th
    prime
  • If the input is divisible (and not equal to the
    divisor), it is marked (with a negative sign) and
    forwarded
  • If the input is not divisible, it is forwarded
  • Last processor only forwards unmarked (positive)
    data primes

6
Sieve of Eratosthenes Pseudo-Code
  • Code for last processor
  • xrecv(data,P_(i-1))
  • If xgt0 then send(x,OUTPUT)
  • Code for processor Pi (and prime p_i)
  • xrecv(data,P_(i-1))
  • If (xgt0) then
  • If (p_i divides x and p_i x ) then
    send(-x,P_(i1)
  • If (p_i does not divide x or p_i x) then
    send(x, P_(i1))
  • Else
  • Send(x,P_(i1))

/
Processor P_i divides each input by the i-th prime
7
Programming Issues
  • Algorithm will take NP-1 to run where N is the
    number of data items and P is the number of
    processors.
  • Can also consider just the odd bnys or do some
    initial part separately
  • In given implementation, number of processors
    must store all primes which will appear in
    sequence
  • Not a scalable approach
  • Can fix this by having each processor do the job
    of multiple primes, i.e. mapping logical
    processors in the pipeline to each physical
    processor
  • What is the impact of this on performance?

processor does the job of three primes
8
Processors for such operation
  • In pipelined algorithm, flow of data moves
    through processors in lockstep.
  • The design attempts to balance the work so that
    there is no bottleneck at any processor
  • In mid-80s, processors were developed to support
    in hardware this kind of parallel pipelined
    computation
  • Two commercial products from Intel
  • Warp (1D array)
  • iWarp (components for 2D array)
  • Warp and iWarp were meant to operate
    synchronously Wavefront Array Processor (S.Y.
    Kung) was meant to operate asynchronously,
  • i.e. arrival of data would signal that it was
    time to execute

9
Systolic Arrays from Intel
  • Warp and iWarp were examples of systolic arrays
  • Systolic means regular and rhythmic,
  • data was supposed to move through pipelined
    computational units in a regular and rhythmic
    fashion
  • Systolic arrays meant to be special-purpose
    processors or co-processors.
  • They were very fine-grained
  • Processors implement a limited and very simple
    computation, usually called cells
  • Communication is very fast, granularity meant to
    be around one operation/communication!

10
Systolic Algorithms
  • Systolic arrays were built to support systolic
    algorithms, a hot area of research in the early
    80s
  • Systolic algorithms used pipelining through
    various kinds of arrays to accomplish
    computational goals
  • Some of the data streaming and applications were
    very creative and quite complex
  • CMU a hotbed of systolic algorithm and array
    research (especially H.T. Kung and his group)

11
Example 1 pipelined polynomial evaluation
  • Polynomial Evaluation is done by using a Linear
    array with 2D.
  • Expression
  • Y ((((anxan-1)xan-2)xan-3)xa1)x a0
  • Function of PEs in pairs
  • 1. Multiply input by x
  • 2. Pass result to right.
  • 3. Add aj to result from left.
  • 4. Pass result to right.

12
Example 1 polynomial evaluation
Y ((((anxan-1)xan-2)xan-3)xa1)x a0
Multiplying processor
X is broadcasted
Adding processor
  • Using systolic array for polynomial evaluation.
  • This pipelined array can produce a polynomial on
    new X value on every cycle - after 2n stages.
  • Another variant you can also calculate various
    polynomials on the same X.
  • This is an example of a deeply pipelined
    computation-
  • The pipeline has 2n stages.

x
an-1
an-2
an
x
a0
x
x
.
X


X

X
X

13
Example 2Matrix Vector Multiplication
  • There are many ways to solve a matrix problems
    using systolic arrays, some of the methods are
  • Triangular Array performing gaussian elimination
    with neighbor pivoting.
  • Triangular Array performing orthogonal
    triangularization.
  • Simple matrix multiplication methods are shown in
    next slides.

14
Example 2Matrix Vector Multiplication
  • Matrix Vector Multiplication
  • Each cells function is
  • 1. To multiply the top and bottom inputs.
  • 2. Add the left input to the product just
    obtained.
  • 3. Output the final result to the right.
  • Each cell consists of an adder and a few
    registers.
  • At time t0 the array receives 1, a, p, q, and r (
    The other inputs are all zero).
  • At time t1, the array receive m, d, b, p, q, and
    r .e.t.c
  • The results emerge after 5 steps.

15
Matrix Multiplication
Example 2Matrix Vector Multiplication
  • At time t0 the array receives 1, a, p, q, and r
    ( The other inputs are all zero).
  • At time t1, the array receive m, d, b, p, q, and
    r .e.t.c
  • The results emerge after 5 steps.

16
  • Each cell (P1, P2, P3) does just one instruction
  • Multiply the top and bottom inputs, add the left
    input to the product just obtained, output the
    final result to the right
  • The cells are simple
  • Just an adder and a few registers
  • The cleverness comes in the order in which you
    feed input into the systolic array
  • At time t0, the array receives l, a, p, q, and r
  • (the other inputs are all zero)
  • At time t1, the array receives m, d, b, p, q,
    and r
  • And so on.
  • Results emerge after 5 steps

To visualize how it works it is good to do a
snapshot animation
17
Systolic Processors, versus Cellular Automata
versus Regular Networks of Automata
Data Path Block
Data Path Block
Data Path Block
Data Path Block
Systolic processor
Control Block
Control Block
Control Block
Control Block
Cellular Automaton
These slides are for one-dimensional only
18
Systolic Processors, versus Cellular Automata
versus Regular Networks of Automata
Control Block
Control Block
Control Block
Control Block
Data Path Block
Data Path Block
Data Path Block
Data Path Block
Regular Network of Automata
19
Introduction to Convolution circuits synthesis
  • Perkowski

20
FIR-filter like structure
a4
0
0
0
b2
b1
b4
b3



a4b4
21
a4
0
0
a3
b2
b1
b4
b3



a4b4
a3b4a4b3
22
a3
a4
0
a2
b2
b1
b4
b3



a4b4
a3b4a4b3
a4b2a3b3a2b4
23
a2
a3
a4
a1
b2
b1
b4
b3



a4b4
a3b4a4b3
a4b2a3b3a2b4
a1b4a2b3a3b2a4b1
24
a1
a2
a3
0
b2
b1
b4
b3



a4b4
a3b4a4b3
a4b2a3b3a2b4
a1b4a2b3a3b2a4b1
a1b3a2b2a3b1
25
We insert Dffs to avoid many levels of logic
a4
a2
a3
b2
b1
b4
b3



a4b4
a4b3
a4b2
a4b1
26
a3
a1
a2
b2
b1
b4
b3



a4b4
a4b3a3b4
a4b2a3b3
a3b1
a4b1a3b2
27
a2
0
a1
b2
b1
b4
b3



a4b4
a4b3a3b4
a4b2a3b3a2b4
a4b1a3b2a2b3
a2b1
a3b1a2b2
The disadvantage of this circuit is broadcasting
28
We insert more Dffs to avoid broadcasting
a4
a2
a3
0
0
0
b2
b1
b4
b3



a4b4
0
0
0
29
a3
a1
a2
a4
0
0
b2
b1
b4
b3



a4b4
a3b4
a4b3
0
0
Does not work correctly like this, try something
new.
30
a3
a1
a2
a4
0
0
b2
b1
b4
b3
0
0
a1b2
a2b1
0
a1b3
a2b2
a3b1
a1b4
a2b3
a3b2
a4b1
a2b4
a3b3
a4b2
0
a3b4
a4b3
0
0
Second sum
a4b4
0
0
0
First sum
31
FIR-filter like structure, assume two delays
b2
b1
b4
b3



32
b2
b1
b4
b3



33
b2
b1
b4
b3



34
b2
b1
b4
b3



35
b2
b1
b4
b3



36
b2
b1
b4
b3



37
b2
b1
b4
b3



38
b2
b1
b4
b3



39
b2
b1
b4
b3



40
b2
b1
b4
b3



41
b2
b1
b4
b3



42
b2
b1
b4
b3



43
b2
b1
b4
b3



44
b2
b1
b4
b3



45
Example 3FIR Filter or Convolution
46
Example 3 Convolution
  • There are many ways to implement convolution
    using systolic arrays, one of them is shown
  • u(n) The input of sequence from left.
  • w(n) The weights preloaded in n PEs.
  • y(n) The sequence from right (Initial value 0)
    and having the same speed as u(n).
  • In this operation each cells function is
  • 1. Multiply the inputs coming from left with
    weights and output the input received to the next
    cell.
  • 2. Add the final value to the inputs from right.

47
Convolution (cont)
  • Systolic array.

The input of sequence from left.
  • Each cell operation.

This is just one solution to this problem
48
Various Possible Implementations
Convolution is very important, we use it in
several applications. So let us think what are
all the possible ways to implement it
Two loops
  • Convolution Algorithm

49
Bag of Tricks that can be used
  • Preload-repeated-value
  • Replace-feedback-with-register
  • Internalize-data-flow
  • Broadcast-common-input
  • Propagate-common-input
  • Retime-to-eliminate-broadcasting

50
Bogus Attempt at Systolic FIR
  • for i1 to n in parallel
  • for j1 to k in place
  • yi wj x ij-1

Inner loop realized in place
Stage 1 directly from equation
Stage 2 feedback yi yi
feedback from sequential implementation
Stage 3
Replace with register
51
Bogus Attempt continued Outer Loop
for i1 to n in parallel for j1 to k in
place yi wj x ij-1
Factorize wj
52
Bogus Attempt continued Outer Loop - 2
  • for i1 to n in parallel
  • for j1 to k in place
  • yi wj x ij-1

Because we do not want to have broadcast, we
retime the signal w, this requires also retiming
of X j
53
Bogus Attempt continued Outer Loop - 2a
for i1 to n in parallel for j1 to k in
place yi wj x ij-1
  • Another possibility of retiming

54
Bogus Attempt continued Outer Loop - 3
for i1 to n in parallel for j1 to k in
place yi wj x ij-1
  • Yet another approach is to broadcast common input
    x i-1

55
Attempt at Systolic FIR now internal loop is in
parallel
1
3
2
56
Outer Loop continuation for FIR filter
57
Continue Optimize Outer LoopPreload-repeated
Value
Based on previous slide we can preload weights Wi
58
Continue Optimize Outer LoopBroadcast Common
Value
This design has broadcast. Some purists tell this
is not systolic as systolic should have all short
wires.
59
Continue Optimize Outer LoopRetime to Eliminate
Broadcast
We delay these signals yi
60
The design becomes not intuitive. Therefore, we
have to explain in detail How it works
y1x1w1
y1x1w1
x1
x2
61
Types of systolic structure
Polynomial Multiplication of 1-D convolution
problem
  • Convolution problem
  • weight w1, w2, ..., wk
  • inputs x1, x2, ..., xn
  • results y1, y2, ..., ynk-1
  • yi w1xi w2xi1 ...... wkxik-1
  • (combining two data streams)
  • H. T. Kungs grouping work
  • assume k 3

62
A family of systolic designs for convolution
computation
  • Given the sequence of weights
  • w1 , w2 , . . . , wk
  • And the input sequence
  • x1 , x2 , . . . , xk ,
  • Compute the result sequence
  • y1 , y2 , . . . , yn1-k
  • Defined by
  • yi w1 xi w2 xi1 . . . wk xik-1

63
Design B1
  • Previously proposed for circuits to implement a
    pattern matching processor and for circuit to
    implement polynomial multiplication.

-
  • Broadcast input ,
  • move results systolically,
  • weights stay
  • - (Semi-systolic convolution arrays with global
    data communication

64
Types of systolic structure design B1
  • wider systolic path (partial result yi move)

Please analyze this circuit drawing snapshots
like in an animated movie of data in subsequent
moments of time
broadcast
Results move out
Discuss disadvantages of broadcast
65
Types of systolic structure Design B2
  • Inputs broadcast
  • Weights move
  • Results stay
  • wi circulate
  • use multiplier-accumulator hardware
  • wi has a tag bit (signals accumulator to output
    results)
  • needs separate bus (or other global network for
    collecting output)

xin
Win
Wout
y y Winxin Wout Win
y
66
Design B2
  • The path for moving yis is wider then wis
    because of yis carry more bits then wis in
    numerical accuracy.
  • The use of multiplier-accumulators may also help
    increase precision of the result , since extra
    bit can be kept in these accumulators with modest
    cost.

Broadcast input , move weights , results
stay (Semi-) systolic convolution arrays with
global data communication
Semisystolic because of broadcast
67
Types of systolic structure design F
  • Input move
  • Weights stay
  • Partial results fan-in
  • needs adder
  • applications signal processing, pattern
    matching

x3
x2
x1
W3
W2
W1
ADDER
y1s
Zout Wxin xout xin
68
Design F
  • When number of cell is large , the adder can be
    implemented as a pipelined adder tree to avoid
    large delay.
  • Design of this type using unbounded fan-in.

- Fan-in results, move inputs, weights stay -
Semi-systolic convolution arrays with global data
communication
69
Types of systolic structure Design R1
  • Inputs and weights move in the opposite
    directions
  • Results stay
  • can use tag bit
  • no bus (systolic output path is sufficient)
  • one-half the cells are work at any time
  • applications pattern matching

70
Design R1
  • Design R1 has the advan-tage that it dose not
    require a bus , or any other global net-work ,
    for collecting output from cells.
  • The basic ideal of this de-sign has been used to
    imple-ment a pattern matching chip.

- Results stay, inputs and weights move in
opposite directions - Pure-systolic convolution
arrays with global data communication
71
Types of systolic structure design R2
  • Inputs and weights move in the same direction at
    different speeds
  • Results stay
  • xjs move twice as fast as the wjs
  • all cells work at any time
  • need additional registers (to hold w value)
  • applications pipeline multiplier

72
Design R2
  • Multiplier-accumulator can be used effectively
    and so can tag bit method to signal the output of
    each cell.
  • Compared with R1 , all cells work all the time
    when additional register in each cell to hold a w
    value.

- Results stay , inputs and weights move in the
same direction but at different speeds -
Pure-systolic convolution arrays with global
data communication
73
Types of systolic structure design W1
  • Inputs and results move in the opposite direction
  • Weights stay
  • one-half the cells are work
  • constant response time
  • applications polynomial division

yout yin Wxin xout xin
74
Design W1
  • This design is fundamental in the sense that it
    can be naturally extend to perform recursive
    filtering.
  • This design suffers the same drawback as R1 ,
    only appro-ximately 1/2 cells work at any given
    time unless two inde-pendent computation are
    in-terleaved in the same array.

-Weights stay, inputs and results move in
opposite direction - Pure-systolic convolution
arrays with global data communication
75
Overlapping the executions of multiply-and-add
in design W1
76
Types of systolic structure design W2
  • Inputs and results move in the same direction at
    different speeds
  • Weights stay
  • all cells work (high throughputs rather than fast
    response)

77
Design W2
  • This design lose one advan-tage of W1 , the
    constant response time.
  • This design has been extended to implement 2-D
    convolution , where high throughputs rather than
    fast response are of concern.

-Weights stay, inputs and results move in
the same direction but at different speeds -
Pure-systolic convolution arrays with global
data communication
78
Remarks on Linear Arrays
  • Above designs are all possible systolic designs
    for the
  • convolution problem. (some are semi-)
  • Using a systolic control path , weight can be
    selected on-
  • the-fly to implement interpolation or adaptive
    filtering.
  • We need to understand precisely the strengths
    and
  • drawbacks of each design so that an
    appropriate design
  • can be selected for a given environment.
  • For improving throughput, it may be worthwhile
    to
  • implement multiplier and adder separately to
    allow
  • overlapping of their execution. (Such as next
    page show)
  • When chip pin is considered
  • pure-systolic requires four I/O ports
  • semi-systolic requires three I/O ports.

79
FIR circuit initial design
Pipelining of xi
delays
80
FIR circuit registers added below weight
multipliers
Notice changed timing here
81
FIR Summary comparison of sequential and
systolic
82
Conclusions on 1D and 1.5D Systolic Arrays
  • Systolic arrays are more than processor arrays
    which execute systolic algorithms.
  • A systolic cell takes on one of the following
    forms
  • A special purpose cell with hardwired functions,
  • A vector-computer-like cell with instruction
    decoding and a processing element,
  • A systolic processor complete with a control unit
    and a processing unit.

Smarter processor for SAT, Petrick, etc.
83
Large Systolic Arrays as general purpose
computers
  • Originally, systolic architectures were
    motivated for high performance special purpose
    computational systems that meet the constraints
    of VLSI,
  • However, it is possible to design systolic
    systems which
  • have high throughputs
  • yet are not constrained to a single VLSI chip.

84
Problems with systolic array design
  • 1. Hard to design - hard to understand
  • low level realization may be hard to realize
  • 2. Hard to explain
  • remote from the algorithm
  • function cant readily be deduced from the
    structure
  • 3. Hard to verify

85
Key architectural issues in designing
special-purpose systems
  • Simple and regular design
  • Simple, regular design yields
    cost-effective special
  • systems.
  • Concurrency and communication
  • Design algorithm to support high
    concurrency and
  • meantime to employ only simple blocks.
  • Balancing computation with I/O
  • A special-purpose system should be a match
    to a variety
  • of I/O bandwidths.

86
Two Dimensional Systolic Arrays
  • In 1978, the first systolic arrays were
    introduced as a feasible design for special
    purpose devices which meet the VLSI constraints.
  • These special purpose devices were able to
    perform four types of matrix operations at high
    processing speeds
  • matrix-vector multiplication,
  • matrix-matrix multiplication,
  • LU-decomposition of a matrix,
  • Solution of triangular linear systems.

87
General Systolic Organization
88
All previously shown tricks can be applied
Example 2 Matrix-Matrix Multiplication
89
Seth Copen Goldstein, CMU A.R. Hurson2. David
E. Culler, UC. Berkeley,3. Keller_at_cs.hmc.edu4.
Syeda Mohsina Afrozeand other students of
Advanced Logic Synthesis, ECE 572, 1999 and 2000.
Sources
Write a Comment
User Comments (0)
About PowerShow.com
