Earthquake Science

1
Earthquake Science (Seismology)
2

• Quick review of last lecture (fault, epicentre,
  seismic waves, magnitude)
• Earthquake Intensity
• Elastic-rebound theory
• Fault classification
• Earthquakes and plate boundaries
• Benioff-Wadati zone

3
Earthquake Terminology
Fault A surface across which two blocks can move
relative to each other.
Focus The location on a fault where earthquake
rupture initiates.
Hypocentre The calculated position of an
earthquake focus.
Epicentre That point on the Earth's surface
directly above the hypocentre.
Magnitude A measure of the strength of an
earthquake, as determined by seismographic
observations.
4
Seismic Waves 101
P waves
Primary (or compressional)
S waves
Secondary (or shear)
Body waves travel through Earth.
Love waves
Rayleigh waves
Surface waves travel around the surface of Earth.
5
Surface-wave magnitude formula (most common)
MS log10(A) 1.656log10(D) 1.818
A amplitude in microns (mm) D epicentral
distance in degrees (divide by 111 to go from km
to degrees)
672 mm
A 672 mm (measured) D 10006.6 - 1500 5100
km ... D 5100/111 46 degrees MS log10(A)
1.656log10(D) 1.818 7.4
6
Intensity

• Intensity is a measure of the effects of an
  earthquake on the natural and built environment.
• While the magnitude of an earthquake is
  constant, the intensity changes with epicentral
  distance.
• In N.A., the Modified Mercalli intensity scale
  is used (I-XII)

7
Earthquake Intensity Map
A map of earthquake intensity is also called an
isoseismal map.
New Madrid Earthquake sequence of 1811-1812
8
http//www.abag.ca.gov/bayarea/eqmaps/doc/mmi.html
9
http//www.abag.ca.gov/bayarea/eqmaps/doc/mmi.html
10
http//www.abag.ca.gov/bayarea/eqmaps/doc/mmi.html
11
http//www.abag.ca.gov/bayarea/eqmaps/doc/mmi.html
12
http//www.abag.ca.gov/bayarea/eqmaps/doc/mmi.html
13
Recently, intensity measurements have been
carried out using the web.
14
(No Transcript)
15
(No Transcript)
16
Internet Intensity Map
A map of earthquake intensity is also called an
isoseismal map.
Produced using web response forms.
Parkfield, CA, 28 Sept., 2004 M 6
17
Elastic Rebound Theory
Fault
Fence
Original position
Stress Accumulates
Earthquake stress released
Rebound to original shape
18
Elastic Rebound Theory
1. Stress on a fault slowly accumulates 2. During
an earthquake, stress on the fault is released 3.
After an earthquake, stress begins to
re-accumulate
19
Elastic Rebound Theory The Earthquake Cycle
For an active fault, earthquakes will repeat
periodically.
1460
1855
Turakirae Head, New Zealand
20
Earthquakes and Plate Boundaries
More than 90 of earthquakes occur near plate
boundaries in fact the earthquake distribution
can be used to outline tectonic plates ...
21
(No Transcript)
22
Earthquakes and Plate Boundaries
Although there are exceptions rare earthquakes
do occur in stable continental regions
New Madrid Earthquake sequence of 1811-1812
Seismic Intensity Map
23
Three basic categories of faults
Normal fault upper block drops down
Thrust (reverse) fault upper block pushes up
Strike-slip fault blocks slide past each other
24
Normal fault

• Occurs where plates are pulling apart under
  tension
• Divergent plate boundary
• Example Iceland

25
Strike-slip fault

• Occurs where plates are sliding past each other
• Transform plate boundary
• Example San Andreas Fault, California

26
Thrust (reverse) faults

• Occurs where plates are pushing together under
  compression
• Convergent plate boundary
• Example Japan

27
Benioff-Wadati Zone

• Dipping zone of earthquakes
• Occurs at a convergent plate boundary
