Title: Amino Acids and Proteins


1
Chapter 18
  • Amino Acids and Proteins

2
An Introduction to Biochemistry
  • Goal understand the structure of biomolecules
    and the relationship between their structures and
    their functions.
  • Classes proteins, carbohydrates, lipids and
    nucleic acids.
  • Biomolecules are often complex but their
    interactions and functional groups are no
    different than the simple organic molecules

3
Protein Structure and Function An Overview
  • Proteins result from combining amino acids via
    peptide bonds.
  • 20 amino acids are responsible for all proteins
    in living organisms (Table 18.3 memorize)

4
Protein Structure and Function An Overview
  • The amino acids are a-amino acids.

5
Protein Structure and Function An Overview
  • As mentioned Proteins are formed by combining
    amino acids through peptide bonds (amide bonds)

6
Protein Structure and Function An Overview
  • Dipeptide bond - 2 different amino acids combine
  • Tripeptide bond - 3 different amino acids combine
  • Polypeptide bond many amino acids are attached
    through peptide bonds

7
Protein Structure and Function An Overview
  • Proteins have 4 levels of structure
  • Primary structure
  • Secondary structure
  • Tertiary structure
  • Quaternary structure

8
Protein Structure an Function An Overview
9
Amino Acids
  • Intermolecular forces decide the shape and
    function of proteins
  • Non-polar side chains hydrophobic
  • Polar, acidic, and basic side chains
    hydrophilic

10
Acid-Base Properties of Amino Acids
  • Amino acids contain an acidic COOH group and a
    basic NH2 group
  • They can and do perform intermolecular acid-base
    reactions where the H of the COOH group is
    transferred to the NH2 group
  • Result is a zwitterion

11
Acid-Base Properties of Amino Acids
  • Zwitterions can act as an acid or as a base

12
Acid-Base Properties of Amino Acids
  • Amino Acids are never present in their neutral
    form.
  • The charge of an amino acid molecule depends on
    the amino acid and the pH of the medium solution.
  • Isoelectric Point (pI) - the pH at which the
    overall charge of all the amino acids in a sample
    is zero.

13
Handedness
  • Handedness affects everything you do. Same is
    true with biomolecules

14
Handedness
  • Chiral Having right- or left-handedness with two
    different non- superimposable mirror image forms.

15
Handedness
  • Achiral The opposite of chiral having
    superimposable mirror images and thus no right-
    or left- handedness.

16
Molecular Handedness and Amino Acids
  • Some molecules exhibit chirality while others do
    not.

17
Molecular Handedness and Amino Acids
  • Note Molecules that exhibit a chiral center have
    4 different groups on the central atom
  • Enantiomers (optical isomers) 2 mirror image
    forms of a chiral molecule
  • Stereoisomers molecules with the same formula
    but a different arrangement of the atoms
  • Section 13.3 discussed cis-trans isomers
  • Amino acids enantiomers D, L

18
Molecular Handedness and Amino Acids
  • Pairs of enantiomers have similar physical
    properties but they differ in their biological
    activity

19
Primary Protein Structure
  • Primary protein structure is described by the
    sequence in which the amino acids are linked by
    peptide bonds
  • The amine will always be on the left side (N
    Terminal) and the carboxylic acid on the right (C
    Terminal)
  • Build onto the right of the first acid
  • The individual amino acids joined in the chain
    are referred to as residues

20
Primary Protein Structure
  • Angiotensin II The order must be

21
Shape-Determining Interactions in Proteins
  • The structure-function relationship of a protein
    depends on the internal interactions holding the
    protein chains in place.
  • Hydrogen bonds along the backbone
  • Hydrogen bonds of the R groups
  • Ionic attractions between R groups (salt bridge)
  • Hydrophobic interactions
  • Sulfur-Sulfur bonds

22
Shape-Determining Interactions in Proteins
23
Secondary Protein Structure
  • Secondary Protein Structure describes the spatial
    arrangement of the polypeptide backbones in the
    protein
  • Depends on internal interaction between backbone
    atoms
  • Fibrous Proteins
  • a - Helix
  • ß - Sheet
  • Globular Proteins (even globular proteins contain
    sections that are fibrous)

24
Secondary Protein Structure
  • Alpha-helix
  • Single protein chain
  • The coil is held in place by H bonds every 4
    amino acid residue along the chain.
  • The chain is a right-handed coil and the H bonds
    lie parallel to the vertical axis.
  • Viewed from the top, the side chains point to the
    exterior of the helix.

25
Secondary Protein Structure
  • Beta- Sheets
  • Made up of several protein chains
  • Chains lie side by side
  • R-groups point above and below the sheet

26
Secondary Protein Structure
  • Globular Proteins
  • Globe-like shape
  • Often contains irregularly shaped portions as
    well as fibrous portions
  • Proteins are folded in what appears to be an
    irregular manner
  • Structure varies with function
  • Hydrophilic R-groups on the external surface of
    the protein account for their water solubility

27
Secondary Protein Structure
28
Tertiary Protein Structure
  • Tertiary Structure describes how the protein is
    folded and the shape that results
  • Depends on interactions of the side chains that
    are far apart along the same backbone
  • Each protein folds in a distinctive manner so as
    to maximize stability
  • Governed by the interactions described previously

29
Tertiary Protein Structure
30
Tertiary Protein Structure
  • Native protein A protein with the shape
    (secondary, tertiary, and quaternary structure)
    in which it exists naturally and functions in
    living organisms.
  • Simple protein A protein composed of only amino
    acid residues.
  • Conjugated protein A protein that incorporates
    one or more nonamino acid units in its
    structure.

31
Tertiary Protein Structure
32
Tertiary Protein Structure
33
Quaternary Protein Structure
  • Quaternary Protein Structure describes how more
    than one polypeptide subunits associate to form a
    three dimensional protein unit

34
Quaternary Protein Structure
35
Chemical Properties of Proteins
  • Hydrolysis of a protein occurs in the same way
    as the hydrolysis of an amide because that is
    what a peptide bond is the formation of an amide

36
Chemical Properties of Proteins
  • Denaturation the loss of secondary, tertiary,
    or quaternary protein structure due to disruption
    of noncovalent interactions and/or disulfide
    bonds that leaves peptide bonds and primary
    structure intact.

37
Chemical Properties of Proteins
  • Denaturation
  • Heat
  • Mechanical Agitation
  • Detergents
  • Organic Compounds
  • pH change
  • Inorganic Salts

38
Homework
  • 18.1, 18.3, 18.4, 18.5, 18.7, 18.8, 18.11, 18.12,
    18.13, 18.14, 18.15, 18.16, 18.17, 18.20, 18.21,
    18.23, 18.24, 18.25, 18.26, 18.29, 18.30, 18.31,
    18.32, 18.33, 18.34, 18.35, 18.36, 18.38, 18.39,
    18.42, 18.43, 18.44, 18.45, 18.46, 18.47, 18.48,
    18.49, 18.51, 18.53, 18.54, 18.56, 18.57, 18.58,
    18.59, 18.60, 18.61, 18.66, 18.68, 18.69, 18.70,
    18.88, 18.89, 18.90, 18.92, 18.96
