A general statistical analysis for fMRI data

1
A general statistical analysis for fMRI data

• Keith Worsley12, Chuanhong Liao1, John Aston123,
• Jean-Baptiste Poline4, Gary Duncan5, Vali Petre2,

• Frank Morales6, Alan Evans2
• 1Department of Mathematics and Statistics, McGill
  University,
• 2Brain Imaging Centre, Montreal Neurological
  Institute,
• 3Imperial College, London,
• 4Service Hospitalier Frédéric Joliot, CEA, Orsay,

• 5Centre de Recherche en Sciences Neurologiques,
  Université de Montréal,
• 6Cuban Neuroscience Centre

2
fMRI data 120 scans, 3 scans each of hot, rest,
warm, rest, hot, rest,
(a) Highly significant correlation
960
hot
fMRI data
rest
940
warm
920
0
50
100
150
200
250
300
350
400
940
(b) No significant correlation
hot
fMRI data
920
rest
warm
900
0
50
100
150
200
250
300
350
400
850
fMRI data
840
(c) Drift
830
0
50
100
150
200
250
300
350
400
Time, t (seconds)
Z (effect hot warm) / S.d. N(0,1) if no
effect
3
(No Transcript)
4
FMRISTAT Simple, general, valid, robust, fast
analysis of fMRI data

• Linear model
• ?
  ?
• Yt (stimulust HRF) b driftt c errort
• AR(p) errors
• ? ?
  ?
• errort a1 errort-1 ap errort-p s WNt

unknown parameters
5
(No Transcript)
6
FMRIDESIGN example Pain perception
(c) Response, x(t) sampled at the slice
acquisition times every 3 seconds
Time, t (seconds)
7
(No Transcript)
8
FMRILM step 1 estimate temporal correlation
?

• AR(1) model errort a1 errort-1 s WNt
• Fit the linear model using least squares.
• errort Yt fitted Yt â1 Correlation (
  errort , errort-1)
• Estimating errorts changes their correlation
  structure slightly, so â1 is slightly biased.
• Bias correction is very quick and effective
• Raw autocorrelation Smoothed 15mm
  Bias corrected â1
•
  -0.05 0

9
FMRILM step 2 refit the linear model
Pre-whiten Yt Yt â1 Yt-1, then fit using
least squares Effect hot warm
Sd of effect
T statistic Effect / Sd
10
Higher order AR model? Try AR(4)
â1
â2
0
â3
â4
0
0
AR(1) seems to be adequate
11
has no effect on the T statistics
AR(1) AR(2)
AR(4)
12
(No Transcript)
13
Results from 4 runs on the same subject
Run 1 Run 2 Run 3 Run 4
Effect Ei
Sd Si
T stat Ei / Si
14
MULTISTAT combines effects from different
runs/sessions/subjects

• Ei effect for run/session/subject i
• Si standard error of effect
• Mixed effects model
• Ei covariatesi c Si WNiF ? WNiR

from FMRILM
?
?
Usually 1, but could add group, treatment,
age, sex, ...
Random effect, due to variability from run to run
Fixed effects error, due to variability within
the same run
15
REML estimation of the mixed effects model using
the EM algorithm

• Slow to converge (10 iterations by default).
• Stable (maintains estimate ?2 gt 0 ), but
• ?2 biased if ?2 (random effect) is small, so
• Re-parametrise the variance model
• Var(Ei) Si2 ?2
• (Si2 minj Sj2) (?2
  minj Sj2)
• Si2
  ?2
• ?2 ?2 minj Sj2 (less biased estimate)

?
?


16
?
Problem 4 runs, 3 df for random effects sd ? ...
Run 1 Run 2 Run 3 Run 4
MULTISTAT
Effect Ei
very noisy sd
Sd Si
and Tgt15.96 for Plt0.05 (corrected)
T stat Ei / Si
so no response is detected
17
Solution Spatial regularization of the sd

• Basic idea increase df by spatial smoothing
  (local pooling) of the sd.
• Cant smooth the random effects sd directly, -
  too much anatomical structure.
• Instead,
• random effects sd
• fixed effects sd
• which removes the anatomical structure before
  smoothing.

? )
sd smooth ?
fixed effects sd
18
Random effects sd (3 df)
Fixed effects sd (448 df)
19
Effective df depends on the smoothing

• dfratio dfrandom(2 1)
• 1 1 1
• dfeff dfratio dffixed
• e.g. dfrandom 3, dffixed 112, FWHMdata
  6mm
• FWHMratio (mm) 0 5 10 15 20 infinite
• dfeff 3 11 45 112 192
  448

FWHMratio2 3/2 FWHMdata2

Random effects Fixed effects
variability bias
compromise!
20
Final result 15mm smoothing, 112 effective df
Run 1 Run 2 Run 3 Run 4
MULTISTAT
Effect Ei
less noisy sd
Sd Si
and Tgt4.90 for Plt0.05 (corrected)
T stat Ei / Si
and now we can detect a response!
21
Conjunction All Ti gt threshold Min Ti gt
threshold
Minimum of Ti
Average of Ti
For P0.05, threshold 1.82
For P0.05, threshold 4.90
Efficiency 82
22
If the conjunction is significant, does it mean
that all effects gt 0?

• Problem for the conjunction of 20 effects, the
  threshold can be negative!?!?!
• Reason significance is based on the wrong null
  hypothesis, namely all effects 0
• Correct null hypothesis is at least one effect
  0. Unfortunately the P-value depends on the
  unknown gt 0 effects
• If the effects are random, all effects gt 0 is
  meaningless. The only parameter is the (single)
  population effect, so that the conjunction just
  tests if population effect gt 0.
• P-values now depend on the random effects sd, not
  the fixed effects sd. But the minimum (i.e. the
  conjunction) is less efficient (sensitive) than
  the average (the usual test).

23
(No Transcript)
24
FWHM the local smoothness of the noise

• Used by STAT_THRESHOLD to find the P-value of
  local maxima and the
  spatial extent of clusters of voxels above a
  threshold.
• u normalised residuals from linear model
  residuals / sd
• u vector of spatial derivatives of u
• ? Var(u)1/2 (mm-3)
• FWHM (4 log 2)1/2 ?-1/3 (mm)

  (If residuals are modeled as white noise
  smoothed with a Gaussian kernel, this would
  be its FWHM).
• ? and FWHM are corrected for low df and large
  voxel size so they are approximately unbiased.
• For a search region S, the number of resolution
  elements is Resels(S)
  Vol(S) AvgS(FWHM-3) Vol(S) AvgS(?) (4 log
  2)-3/2
• For local maxima in S, P_value Resels(S) x
  (function of threshold).
• For a cluster C, P-value depends on Resels(C)
  instead of Vol(C), so that clusters in smooth
  regions are less significant.
• Need a correction for the randomness of ? and
  FWHM - depends on df .
• Correction is more important for small clusters C
  than for large search regions S.

25
. FWHM depends on the spatial correlation
between neighbours
Resels1.90 P0.007
Resels0.57 P0.387
26
T gt 4.90 (P lt 0.05, corrected)
Tgt4.86
27
Smooth the data before analysis?

• Temporal smoothing or low-pass filtering is used
  by SPM99 to validate a global AR(1) model. For
  our local AR(p) model, it is not necessary (but
  harmless).
• Spatial smoothing is used by SPM99 to validate
  random field theory. Can be harmful for focal
  signals. Should fix the theory! STAT_THRESHOLD
  uses the better of the Bonferroni or the random
  field theory.
• A better reason for spatial smoothing is greater
  detectability of extensive activation choose the
  FWHM to match the activation (e.g. 10mm FWHM for
  10mm activations) or try a range of FWHMs i.e.
  scale space but thresholds are higher

28
False Discovery Rate (FDR)

• Benjamini and Hochberg (1995), Journal of the
  Royal Statistical Society
• Benjamini and Yekutieli (2001), Annals of
  Statistics
• Genovese et al. (2001), NeuroImage
• FDR controls the expected proportion of false
  positives amongst the discoveries, whereas
• Bonferroni / random field theory controls the
  probability of any false positives
• No correction controls the proportion of false
  positives in the volume

29
P lt 0.05 (uncorrected), Z gt 1.64 5 of volume is
false
Signal Gaussian white noise
Signal
True
Noise
False
FDR lt 0.05, Z gt 2.82 5 of discoveries is false
P lt 0.05 (corrected), Z gt 4.22 5 probability of
any false
30
Comparison of thresholds

• FDR depends on the ordered P-values (not
  smoothness)
• P1 lt P2 lt lt Pn. To control the FDR at a
  0.05, find
• K max i Pi lt (i/n) a, threshold the
  P-values at PK
• Proportion of true 1 0.1 0.01
  0.001 0.0001
• Threshold Z 1.64 2.56 3.28
  3.88 4.41
• Bonferroni thresholds the P-values at a/n
• Number of voxels 1 10 100 1000
  10000
• Threshold Z 1.64 2.58 3.29
  3.89 4.42
• Random field theory resels volume / FHHM3
• Number of resels 0 1 10
  100 1000
• Threshold Z 1.64 2.82 3.46
  4.09 4.65

31
P lt 0.05 (uncorrected), Z gt 1.64 5 of volume is
false
FDR lt 0.05, Z gt 2.91 5 of discoveries is false
P lt 0.05 (corrected), Z gt 4.86 5 probability of
any false
Which do you prefer?
32
(No Transcript)
33
Estimating the delay of the response

• Delay or latency to the peak of the HRF is
  approximated by a linear combination of two
  optimally chosen basis functions

delay
basis1
basis2
HRF
shift

• HRF(t shift) basis1(t) w1(shift)
  basis2(t) w2(shift)
• Convolve bases with the stimulus, then add to
  the linear model

34

• Fit linear model, estimate w1 and w2
• Equate w2 / w1 to estimates, then solve for
  shift (Hensen et al., 2002)
• To reduce bias when the magnitude is small, use
• shift / (1 1/T2)
• where T w1 / Sd(w1) is the T statistic for the
  magnitude
• Shrinks shift to 0 where there is little
  evidence for a response.

w2 / w1
w1
w2
35
Delay of the hot stimulus ( shift 5.4 sec)
T stat for magnitude T stat for
shift
Delay (secs) Sd of delay
(secs)
36
Varying the delay and dispersion of the reference
HRF
T stat for magnitude T stat for
shift
Delay (secs) Sd of delay
(secs)
37
T gt 4.86 (P lt 0.05, corrected)
Delay (secs)
6.5 5 5.5 4 4.5
38
T gt 4.86 (P lt 0.05, corrected)
Delay (secs)
6.5 5 5.5 4 4.5
39
(No Transcript)
40
EFFICIENCY for optimum block design
Sd of hot stimulus
Sd of hot-warm
0.5
0.5
20
20
0.4
0.4
15
15
Optimum design
Magnitude
0.3
0.3
10
10
Optimum design
0.2
0.2
X
5
5
0.1
0.1
0
X
0
0
0
5
10
15
20
5
10
15
20
InterStimulus Interval (secs)
(secs)
(secs)
1
1
20
20
0.8
0.8
15
15
Delay
0.6
0.6
Optimum design X
Optimum design X
10
10
0.4
0.4
5
5
0.2
0.2
(Not enough signal)
(Not enough signal)
0
0
0
5
10
15
20
5
10
15
20
Stimulus Duration (secs)
41
EFFICIENCY for optimum event design
0.5
(Not enough signal)
uniform . . . . . . . . .
____ magnitudes . delays
random .. . ... .. .
0.45
concentrated
0.4
0.35
0.3
Sd of effect (secs for delays)
0.25
0.2
0.15
0.1
0.05
0
5
10
15
20
Average time between events (secs)
42
How many subjects?

• Variance sdrun2 sdsess2
  sdsubj2
• nrun nsess nsubj
  nsess nsubj nsubj
• The largest portion of variance comes from the
  last stage, i.e. combining over subjects.
• If you want to optimize total scanner time, take
  more subjects, rather than more scans per
  subject.
• What you do at early stages doesnt matter very
  much - any reasonable design will do

43

• Comparison
• Different slice acquisition times
• Drift removal
• Temporal correlation
• Estimation of effects
• Rationale
• Random effects
• FWHM
• Map of delay

• SPM99
• Adds a temporal derivative
• Low frequency cosines (flat at the ends)
• AR(1), global parameter, bias reduction not
  necessary
• Band pass filter, then least-squares, then
  correction for temporal correlation
• More robust, low df
• No regularization, low df
• Global, OK for local maxima, but not clusters
• No

• FMRISTAT
• Shifts the model
• Polynomials
• (free at the ends)
• AR(p), voxel parameters, bias reduction
• Pre-whiten, then least squares (no further
  corrections needed)
• More efficient, high df
• Regularization, high df
• Local, is OK for local maxima and clusters
• Yes

44
References

• Worsley et al. (2002). A general statistical
  analysis for fMRI data. NeuroImage, 151-15.
• Liao et al. (2002). Estimating the delay of the
  fMRI response. NeuroImage, 16593-606.
• http//www.math.mcgill.ca/keith/fmristat -
  200K of MATLAB code
• - fully worked example

45
Functional connectivity

• Measured by the correlation between residuals at
  every pair of voxels (6D data!)
• Local maxima are larger than all 12 neighbours
• P-value can be calculated using random field
  theory
• Good at detecting focal connectivity, but
• PCA of residuals x voxels is better at detecting
  large regions of co-correlated voxels

Activation only
Correlation only
Voxel 2


Voxel 2







Voxel 1
Voxel 1



46
Correlations gt 0.7, Plt10-10 (corrected)
First Principal Component gt threshold
