Why Systolic Architecture

1
Why Systolic Architecture ?
2
Motivation Introduction

• We need a high-performance , special-purpose
  computer
• system to meet specific application.
• I/O and computation imbalance is a notable
  problem.
• The concept of Systolic architecture can map
  high-level
• computation into hardware structures.
• Systolic system works like an automobile assembly
  line.
• Systolic system is easy to implement because of
  its
• regularity and easy to reconfigure.
• Systolic architecture can result in
  cost-effective , high-
• performance special-purpose systems for a wide
  range
• of problems.

3
Key architectural issues in designing
special-purpose systems

• Simple and regular design
• Simple, regular design yields
  cost-effective special
• systems.
• Concurrency and communication
• Design algorithm to support high
  concurrency and
• meantime to employ only simple.
• Balancing computation with I/O
• A special-purpose system should be match a
  variety
• of I/O bandwidth.

4
Basic principle of systolic architecture

• Systolic system consists of a set interconnected

• cells , each capable of performing some simple

• operation.
• Systolic approach can speed up a compute-bound
• computation in a relatively simple and
  inexpensive
• manner.
• A systolic array in particular , is illustrated
  in next
• page. (we achieve higher computation throughput

• without increasing memory bandwidth)

5
Basic principle of a systolic system
6
CONVOLUTION

• In mathematics and, in particular, functional
  analysis, convolution is a mathematical operator
  which takes two functions f and g and produces a
  third function that, in a sense, represents the
  amount of overlap between f and a reversed and
  translated version of g.
• Typically, one of the functions is taken to be a
  fixed filter impulse response, and is known as a
  kernel. Such a convolution is a kind of
  generalized moving average, as one can see by
  taking the kernel to be an indicator function of
  an interval.

7
CONVOLUTION

• Visual explanation of convolution. Make each
  waveform a function of the dummy variable t.
  Time-invert one of the waveforms and add t to
  allow it to slide back and forth on the t-axis
  while remaining stationary with respect to t.
  Finally, start the function at negative infinity
  and slide it all the way to positive infinity.
  Wherever the two functions intersect, find the
  integral of their product. The resulting waveform
  (not shown here) is the convolution of the two
  functions. If the stationary waveform is a unit
  impulse, the end result would be the original
  version of the sliding waveform, as it is
  time-inverted back again because the right edge
  hits the unit impulse first and the left edge
  last. This is also the reason for the
  time-inversion in general, as complex signals can
  be thought to consist of unit impulses.

8
CONVOLUTION

• Discrete convolution
• For discrete functions, one can use a discrete
  version of the convolution operation. It is given
  by
• When multiplying two polynomials, the
  coefficients of the product are given by the
  convolution of the original coefficient
  sequences, in this sense (using extension with
  zeros as mentioned above).
• Generalizing the above cases, the convolution can
  be defined for any two integratable functions
  defined on a locally compact topological group.
• A different generalization is the convolution of
  distributions.
• Evaluating discrete convolutions using the above
  formula applied directly takes O(N2) arithmetic
  operations for N points, but this can be reduced
  to O(N log N) using a variety of fast algorithms.

9
CONVOLUTION

• Code
• include ltstdio.hgt
• include ltstdlib.hgt
• int main( )
• int w 1,2,2,1
• int x 11,2,3,4,5,6,3,2,1
• int y 20
• int w_len 4
• int x_len 9
• int i, j, temp
• for( i1 i lt (w_lenx_len), i)
• yi 0
• for( i1 i lt (w_lenx_len - 1) i)
• for( j 1 j lt w_len j)
• if ( ( i j lt 0 ) ( i j gt (x_len -1 ) )
  )
• temp 0
• else
• temp x i j

10
Design B1

• Previously propose for cir-cuits to implement a
  pattern matching processor and for circuit to
  implement polyno-mial multiplication.

- Broadcast input , move results , weights stay -
(Semi-systolic convolution arrays with global
data communication
11
CONVOLUTION

• y1 x1.w1
• y2 x2.w1 x1.w2
• y3 x3.w1 x2.w2 x1.w3
• y4 x4.w1 x3.w2 x2.w3 x1.w4
• y5 x5.w1 x4.w2 x3.w3 x2.w4
• y6 x6.w1 x5.w2 x4.w3 x3.w4
• y7 x7.w1 x6.w2 x5.w3 x4.w4 y10
  x9.w2 x8.w3 x7.w4
• y8 x8.w1 x7.w2 x6.w3 x5.w4 y11
  x9.w3 x8.w4
• y9 x9.w1 x8.w2 x7.w3 x6.w4 y12
  x9.w4

12
Design B2

• The path for moving yis is wider then wis
  because of yis carry more bits then wis in
  numerical accuracy.
• The use of multiplier-accumlators may also help
  increase precision of the result , since extra
  bit can be kept in these accumulators with modest
  cost.

Broadcast input , move weights , results
stay (Semi-) systolic convolution arrays with
global data communication
13
CONVOLUTION

• y1 x1.w1
• w1 y2 x2.w1 x1.w2
• w1 w2 y3 x3.w1 x2.w2 x1.w3
• w1 w2 w3 y4 x4.w1 x3.w2 x2.w3 x1.w4
• w1 w2 w3 y5 x5.w1 x4.w2 x3.w3 x2.w4
• y6 x6.w1 x5.w2 x4.w3 x3.w4
• y7 x7.w1 x6.w2 x5.w3 x4.w4 y10
  x9.w2 x8.w3 x7.w4
• y8 x8.w1 x7.w2 x6.w3 x5.w4 y11
  x9.w3 x8.w4
• y9 x9.w1 x8.w2 x7.w3 x6.w4 y12
  x9.w4

14
Design F

• When number of cell is large , the adder can be
  implemented as a pipelined adder tree to avoid
  large delay.
• Design of this type using unbounded fan-in.

- Fan-in results, move inputs, weights stay -
Semi-systolic convolution arrays with global data
communication
15
CONVOLUTION

• y1 x1.w1
• y2 x2.w1 x1.w2
• y3 x3.w1 x2.w2 x1.w3
• y4 x4.w1 x3.w2 x2.w3 x1.w4
• y5 x5.w1 x4.w2 x3.w3 x2.w4
• y6 x6.w1 x5.w2 x4.w3 x3.w4
• y7 x7.w1 x6.w2 x5.w3 x4.w4
• y8 x8.w1 x7.w2 x6.w3 x5.w4
• y9 x9.w1 x8.w2 x7.w3 x6.w4
• y10 x9.w2 x8.w3 x7.w4
• y11 x9.w3 x8.w4
• y12
  x9.w4

16
Design R1

• Design R1 has the advan-tage that it dose not
  require a bus , or any other global net-work ,
  for collecting output from cells.
• The basic ideal of this de-sign has been used to
  imple-ment a pattern matching chip.

- Results stay, inputs and weights move in
opposite directions - Pure-systolic convolution
arrays with global data communication
17
CONVOLUTION

• x1 y1 x1.w1 w1
• x2 y2 x2.w1 x1.w2 w2
• x3 y3 x3.w1 x2.w2 x1.w3 w3
• x4 y4 x4.w1 x3.w2 x2.w3 x1.w4 w4
• x5 y5 x5.w1 x4.w2 x3.w3 x2.w4
• x6 y6 x6.w1 x5.w2 x4.w3 x3.w4
• y7 x7.w1 x6.w2 x5.w3 x4.w4 y10
  x9.w2 x8.w3 x7.w4
• y8 x8.w1 x7.w2 x6.w3 x5.w4 y11
  x9.w3 x8.w4
• y9 x9.w1 x8.w2 x7.w3 x6.w4 y12
  x9.w4

18
CONVOLUTION

• Description
• For the sequence of computations shown on the
  previous page, design a structural VHDL code such
  that the computation is fully pipelined. xi
  represents a single datum input to circuit from
  the testbench, while yi is the output back to
  the testbench. New values of xi move into the
  circuit every clock cycle, and new values of yi
  move out to the testbench every clock cycle.
  Clock is another input ot the system.
• The individual components of the system should be
  described behaviorally. 25
• Show a plan for architecting your design for a
  pipelined implementation. 25
• Write the top level VHDL structural code for the
  design. 25
• Write a testbench for the system. 25
