Groundwater Storage Project

1
Groundwater Storage Project Wasco,
California By Will Boschman, Gen. Mgr.
WASCO Rose Country
2
Location of Semitropic Water Storage District
Semitropic Water Storage District
State Water Project
Bakersfield
3
Location of Semitropic Water Storage District
Semitropic Water Storage District
Central Valley Project
Bakersfield
4
Location of Semitropic Water Storage District
Semitropic Water Storage District
Central Valley Project
State Water Project
California Aqueduct
Bakersfield
5
(No Transcript)
6
Semitropic Water Storage District
19 miles
Water Service Area 142,600 ac.
27 miles
Applied Irrigation Water 475,000 ac. ft./year
Size 220,000 Acres 344 sq. miles
7
Semitropic Water Storage District
8
Semitropic Water Storage District Cropping
Pattern - 2003
9
DISTRICTS CHALLENGES (LATE 80S)

• Groundwater Overdraft

10
Observed Lift
Projected Lift
Without Importing Surface water
11
DISTRICTS CHALLENGES (LATE 80S)

• Groundwater Overdraft

• Rising Energy Costs

• Water Costs (State) Steadily Increasing

• Water Shortages

• Paying For Water We Didnt Get (1991-No Water)

• Agricultural Economy Not Good

12
Semitropic Water Storage District
Banking Project
SWP-CALIFORNIA AQUEDUCT
CVP-FRIANT- KERN CANAL
GROUND WATER RESERVOIR
DEFINED STORAGE CAPACITY 1.65 MILLION Ac. Ft.
EIR. CERTIFIED SUMMER 1994 JANUARY 2000
13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
Banking Partner Interrelationships
Semitropic Water Storage District
California Aqueduct
Metropolitan Water District
Santa Clara Valley Water District
Alameda County Water District
Zone 7 Water District
Newhall Land And Farming Co.
Vidler Water Company
17
Semitropics Banking Program Contributes To
Drought Year Needs For Over 20 Million Californian
s
Equivalent To 15 to 20 Gallons Per Person Per
Day
18
Semitropic Water Storage District Pre-banking
Project Conditions
Total Irrigated Acreage 144,662.56
19
Direct Recharge
In-Lieu Recharge
Water Is Stored By Percolating Directly To Storage
Water Is Stored By Substituting Surface Water
For An Equal Amount Of Groundwater
20
DIRECT RECHARGE
21
DIRECT RECHARGE
22
DIRECT RECHARGE
23
In-Lieu Recharge
24
In-Lieu Recharge
25
MAIN DRAIN ROAD SIPHONINCREASING SYSTEM CAPACITY
26
MAIN DRAIN ROAD SIPHON
27
(No Transcript)
28
(No Transcript)
29
P565 PUMPING PLANT
30
POND ROAD PUMPING PLANT
31
CONCRETE CANAL LINING PROJECTINCREASING SYSTEM
CAPACITY
32
POND POSO CONCRETE CANAL LINING PROJECT
33
POND POSO CONCRETE CANAL LINING PROJECT
34
P667 PUMPING PLANT
35
POND POSO CONCRETE CANAL LINING PROJECT
36
POND POSO CONCRETE CANAL LINING PROJECT
37
(No Transcript)
38
Stored Water Recovery Well
39
In-Lieu Recharge And Recovery
40
(No Transcript)
41
(No Transcript)
42
(No Transcript)
43
Stored Water RecoveryReverse Flow Pump
44
240cfs Reverse Flow Pump Station
45
FARM ROAD SIPHON
46
Stored Water Recovery5400 HP, 300 cfs Pumpback
Pumping Plant
47
Project Obstacles/Accountability

• Stored water is kept In trust
• Semitropic writes a report every two years on
  impacts of water moving into and out of the Bank
• A Banking Partner may audit Semitropics
  accounting related to the Bank at any time

48
Project Obstacles/ Accountability (Cont.)

• Environmentally, Relatively Easy

• Public And Local Understanding of Groundwater
  Banking

• Acceptance By Our Board and In District Water
  Users

• Acceptance By Neighboring/Surrounding Districts

• Formed Formal Groundwater Monitoring Committee

49
(No Transcript)
50
Groundwater Monitoring Committee
51
(No Transcript)
52
Pumpback Facilities
SWRU 250 CFS
Proposed Pumpback (PB2) (250 CFS for 10
Months) (170 CFS for 5 Months) Existing Pumpback
(PB1) (300 CFS for 5 Months)
170 CFS
420 CFS
Existing 300 CFS

53
(No Transcript)
54
(No Transcript)
55
Stored Water Recovery Unit
56
(No Transcript)
57
120 PIPE
58
120 PIPE
59
PROJECT STATUSMay 1,2004

• I. Project Costs
• 1. Capital
• Original Project 140 M
• Expanded Project 130 M
• ______
• Total 270 M
• 2. O M Fees 4.5 M/Year
• 3. Transfer Fees
• Water Into Storage 63.00/A.F.
• Water Out of Storage 63.00/A.F. Plus Energy
  Costs

II. Capital Funds Spent To Date 90 M III.Water
in Storage 750,000 A.F. IV. Water Withdrawn
From Storage 175,000 A.F.
60
SEMITROPIC WATER STORAGE DISTRICTNEW
UNITEXPECTED GROUNDWATER QUALITY

• Based on samples collected during a five week
  20,000 acre-foot pumpback into the California
  Aqueduct at 300cfs between November 5th and
  December 12th, 2001.
• Based on one production test well and two casing
  hammer test wells located within the new well
  field (SWRU)
• Also in 2001 data was collected from over 260
  wells and an operation model constructed which
  estimates blended water quality for wells used in
  pump back operation.

61
DESIGN/BUILD/FINANCE TEAM

• LAYNE CHRISTENSEN COMPANY Well Drilling
• WELLS FARGO PUBLIC FINANCE - Financing
• W.M. LYLES CO. Pipe Installation/Structural
• GEI CONSULTING/BOOKMAN-EDMONSTON - Engineering
• BRAUN ELECTRIC - Electrical
• HANSON PIPE Pipe Supplier
• BOYLE ENGINEERING, INC. Treatment Facilities
• ARB, INC. Treatment Facilities Construction
• HDR Water Treatment/Technical Support

62
- Return Capacity to Aqueduct New Well Field
(1) 150,000 AF/Yr Additional
District Wells (2)
50,000 AF/Y

Additional Dry Year Yield
200,000 AF/Yr - New Capacity Into
Storage 45,000
AF/Yr - Additional Defined Storage
650,000 AF (1) From 65
new wells producing 250 cfs for 10 months(2)
From existing wells producing 170 cfs for 5
months
POTENTIAL INCREASE IN BANKING PROJECT DUE TO NEW
UNIT
63
EXISTING AND EXPANDED BANKING PROJECT
CAPABILITIES

• Can provide in a 50 SWP year 356,500 AF of dry
  year supply
• Can take into storage 315,000 AF/Yr of surplus
  wet year water
• Can store 1,650,000 AF
• EIR complete

64
STORED WATER RECOVERY UNIT WELLFIELD LAND
OWNERSHIP MARCH - 2004
65
SEMITROPIC GROUNDWATER BANKING PROJECTBENEFITS

• Semitropic (Agriculture)
• Groundwater Overdraft Correction
• Reduce Groundwater Pumping Lifts

66
(No Transcript)
67
(No Transcript)
68
(No Transcript)
69
SEMITROPIC GROUNDWATER BANKING PROJECTBENEFITS

• Semitropic (Agriculture)
• Groundwater Overdraft Correction
• Reduce Groundwater Pumping Lifts

• Operational Flexibility (More Plumbing)

70
SEMITROPIC GROUNDWATER BANKING PROJECTBENEFITS

• Semitropic (Agriculture)
• Groundwater Overdraft Correction
• Reduce Groundwater Pumping Lifts
• Operational Flexibility (More Plumbing)

• Urban Partners
• Increase Dry Years Supply
• Optimize Use Of Water Supplies
• Enhance Water Supply Reliability
• Provide Water Management Tool (Any Year)

• Private Partner
• Provides Place To Put Water Until Needed
• Use Of Private Sector Funds For Water
  Facilities
• Provides Means For True Water Marketing
• Enhance Corporate Profits

71
(No Transcript)
72
Location Map
Semitropic WSD
California Aqueduct
Coastal Branch
Cross Valley Canal
Santa Margarite Lake
San Luis Obispo
Bakersfield
Soda Lake
Lopez Lake
Twitchell Reservoir
Santa Maria
73
(No Transcript)
74
(No Transcript)
75
(No Transcript)
76
Conceptual Plan for Transferring50,000 af/yr
between SWP/CVP and Millerton (F-K)
Millerton Reservoir
50,000 af/yr of SWID water left in storage on
behalf of transferor and/or for reallocation
Kern River
77
Overview

• The Semitropic Groundwater Bank is a
• proven water resource management tool
• that allows its Partners the ability to store

• and extract water supplies.
• Utilization of the Bank provides flexibility
• and reliability to the Partners to assure a
• firm water supply to their customers.

78
NEW UNIT

• 150,000 Shares will be issued and sold by
  Semitropic to participants in the NEW UNIT. Each
  share will provide the shareholder with the
  following use of the NEW UNIT
• 1 AF/Yr Recovery plus Lower Priority capacity on
  a when available basis
• 3 AF Storage plus Lower Priority capacity on a
  when available basis
• 0.33 AF/Yr Recharge plus Lower Priority
  capacity on a when available basis

79
Banking PartnersStorage and Recovery
Allocations
5. Reserved Under M O U 6. All Participants Have
Right To Use Unused Capacity

• Depends upon amount of State Entitlement
  allocated to Semitropic during year.
• Made Available Under The Stored Water Recovery
  Unit Program In 2004.
• Excludes 40,131 AF in storage for Sate of
  California.
• Lower Priority Participants Only Have Rights to
  Unused Capacity.

80
(No Transcript)
81
HWY 46 SUBSTATION
82
HYDRO PLANT
83
(No Transcript)
84
GAS ENGINE
85
SOLAR SITE
86
SOLAR SITE
87
THE END
88
Policy Issue Wellhead vs. Downstream Treatment ?
Water Quality Comparison
50,000 AF/month
California Aqueduct
89
Policy Issue Wellhead vs. Downstream Treatment ?
Water Quality Comparison
50,000 AF/month
Stored Water Recovery Wells
California Aqueduct
15,000 AF/month
65,000 AF/month
90
Policy Issue Wellhead vs. Downstream Treatment ?
Water Quality Comparison
50,000 AF/month
Stored Water Recovery Wells
California Aqueduct
15,000 AF/month
65,000 AF/month
91
POLICY QUESTIONS

• 1. Should Pump-in Water Be Treated for All
  Constituents That Exceed Ambient In the Aqueduct?
• 2. Should There Be Recognition of Benefits or
  Improvement in Some Constituents to Offset
  Degradation in Others?
• 3. Should Downstream Users Be Paid an
  Incremental Amount to Treat Constituents That Do
  Not Meet Then Current Standards?
• 4. Should Downstream Users Be Paid an Amount to
  Treat Constituents That Result in Incremental
  Degradation?
• 5. Should Policies for Conveying Raw Water Be
  Adjusted or Relaxed in Dry or Drought Years?

92
KERN COUNTY MAP
SWRU WELL FIELD (PROPOSED)
SEMITROPIC WSD
93
KERN COUNTY MAP
SWRU WELL FIELD (PROPOSED)
SEMITROPIC WSD
94
SWRU WELL FIELD (PROPOSED)
SEMITROPIC WSD
95
KERN COUNTY MAP
SWRU WELL FIELD (PROPOSED)
SEMITROPIC WSD
ARVIN - EDISON WSD
