IRRInet-M IRRInet-ACE Product Introduction
Presented By AK
Updated Dec 2, 2007
2
Upon completion of this presentation, you should
be able to

• Understand all HW options
• Understand all Configuration options
• Understand Migration of new HW into legacy
  systems
• Understand all Models and Options
• Understand all about on-site programming tool
  (Pocket-PC)

3
IRRInet-M - General View
IRRInet-M AC

• Commonality
• Inputs/Outputs
• - 12 Outputs, 4 DI on the Basic board
• - 12 Outputs, 4 DI on the Expansion board
• Communication Ports
• - RS232/485
• - RS232
• - Radio/Line
• Power
• - 12V DC in
• - 5, 7.5, 9.5, 12V DC (2Amp) Power out for
  portable radio
• 20 LED for Status display
• 1 Push button (various functions)

IRRInet-M DC
4
IRRInet-M Master/Slave configuration (1)
IRRInet-M supports 3 modes of operations
RTU (loaded with IRRI 7.0 Master) Performing all
irrigation functions (IRRIV Capabilities) Reportin
g to the ICC, Via the MDLC Cloud
Stand Alone (loaded with IRRI 7.0
Master) Performing all irrigation functions as a
stand-alone unit when the system is installed
without an ICC
Remote I/O (loaded with IRRI 7.0 Slave) Serving
as a Distributed I/O for another unit (the Master)
5
IRRInet-M Master/Slave configuration (2)
MDLC
ICC
FIU
Master
Master
Slave
6
IRRInet-M RS485 Port Options
MDLC
D
ICC
FIU
RS485
Master
Master
RS485
A
RS485
C
Slave
RS485
B
Master
Slave
PIU
7
IRRInet-M RS232 Port Options
F
MDLC
RS232
RS232
E
ICC
IRRInet-M FIU
A
RS232
Master
Master
RS232
B
RS232
D
Slave
RS232
C
Master
Slave
PIU
8
IRRInet-M Radio Port Options (it is Radio or
Line, Configurable)
Please note!
C and D may not co-exist with the same unit
MDLC
RS232
E
ICC
A
IRRInet-M FIU
Master
Master
B
D
Slave
C
Legacy Scorpio/IRRIcom Impact
Slave
9
IRRInet-M Line Port Options (it is Radio or
Line, Configurable)
Line
MDLC
RS232
C
ICC
A
IRRInet-M FIU
Master
Line
Line
B
Master
Slave
10
Q I need to add a new device to a network that
already has Scorpio(s) or IRRIcom(s). What do I
do?A Below
FIU
MDLC
ICC
IRRInet XL/XM
IRRIcom
Scorpio
IRRInet-M
11
Q When should I use IRRInet-M and when should I
use IRRInet-ACE?A Below
MDLC
?
FIU
IRRInet-ACE
IRRInet-M
ICC

• This release will deliver the following for the
  IRRInet-ACE
• IRRIV 7.X (Master) running on the IRRInet-ACE
• Usage of current released I/O Modules
• Support on-site programming, using Pocket PC
  machine (ARM based)

• It takes a whole System Planner to explain all
  considerations but)
• Communication Media
• larger variety on IRRInet-ACE
• Line needed? only on IRRInet-M
• Number of needed Ports (only 3 on IRRInet-M, 5 on
  IRRInet-ACE
• I/O specification
• DC solenoids, only on IRRInet-M
• Analog I/O only on IRRInet-ACE
• I/O count
• Up to 24 Outputs and 8 inputs on IRRInet-M, up to
  8 Modules on IRRInet-ACE
• RUNGS needed? Only on IRRInet-ACE

12
Q I have an IRRInet XL/XM I need to replace, or
add. What do I do?A Below
FIU
MDLC
ICC
IRRInet-ACE
IRRInet XL/XM
Master
IRRInet-M
13
Q I need to add IRRInet-ACE, but this unit MUST
operate the legacy Scorpio, IRRIcom or Impact.
What do I do?A Below
MDLC
FIU
ICC
IRRInet-ACE
RS485
IRRInet XL/XM
IRRInet-M Router
Slave
Impact
Scorpio
IRRIcom
14
Q In fact, the IRRInet-ACE does not have
dedicated Modules for Irrigation, So?A Below
MDLC
FIU
ICC
IRRInet-ACE
RS485
IRRInet-M
B. Use the ACEs Relay I/O Module for AC
solenoids, or any other ACE original I/O Module
15
IRRInet-M AC Users Connections
16
IRRInet-M DC Users Connections
17
IRRInet-M New Front Label

• New Design
• 20 LED's for (detailed explanation in the
  Manual)
• CPU Status
• I/O Status
• Error Logger Status

18
IRRInet-M Push Button

• Various Functions
• Reset (and download SW)
• Test
• Scroll Page for LED Display

19
SW Features
User Configuration
20
On-Site Programming SW(Pocket PC Connectivity
(ARM Only)
2 Modes of operation Terminal Stand-Alone
21
Configuration Tool
STS
22
IRRInet-M Models and Options (1)
IRRInet-M DC
IRRInet-M AC
23
IRRInet-M Models and Options (2)
For VHF Radio
For UHF Radio
24
IRRInet-ACE Models and Options
For IRRInet-ACE use ACE3600 catalog pages, and
25
New deliverables summary
26
