4 Bit Serial to Parallel Data Stream Converter

1
4 Bit Serial to Parallel Data Stream Converter

• Vinaya Anne
• Kristy Lypen
• Michael Scheel
• Victor Zavaleta

2
Design Specifications

• Convert a serial data stream every 4 clock cycles
  to a 4 bit parallel stream
• Operate at the positive edge of the clock
• Drive a 10pF load at 25MHz
• Minimize skew
• Area less than 40mil2

3
Parameters

• D Flip-Flop
• WnCaclulated 10.4m m WnActual 23.2m
  m
• WpCaclulated 27.6m m WpActual 27.6m
  m
• Based on CLoad of Output 179f F
• Buffer
• Total Area 1750 x 600 mm Power 400mW

4
Block Diagram
P A R A L L E L
S E R I A L
D Flip Flop
Latch / Buffer
Schmidt Trigger
D Flip Flop
Frequency Counter
D A T A
D A T A
D Flip Flop
5
Schmidt Trigger Schematic
6
Trip Points of Schmidt Trigger
7
D Flip-Flop Schematic
8
D Flip-Flop Propagation Delay Waveform
9
Schematic D Flip-Flop / Logic Circuit
10
Output Waveforms
11
Layout of Four D Flip-Flops
12
Clock
13
Buffer Schematic
14
Buffer Transient Response
15
Questions?
