Relationship Between Cartesian and Ellipsoidal Coordinates

1
Lecture 5

• Relationship Between Cartesian and Ellipsoidal
  Coordinates

2
Geodetic and Cartesian Coords
3
Relationship Between Cartesian and Ellipsoidal
Coordinates
4
Computation of the X Y Z coordinates of a point
located at a geometric height h above the
reference ellipsoid.
5
Geocentric Cartesian Coordinates
6
Conversion from Latitude, Longitude, and Height
to ECEF XYZ.
7
Example
The geodetic coordinates of an observer on earth
are
Given that a 6378160m and
e2 0.006694541855 Calculate the corresponding
Cartesian coordinates
Page 65 Stolz An Introduction to Geodesy
8
Example
9
The Inverse Formula
More important given Cartesian coords eg ECEF
WGS84, calculate geodetic coords
1st Approach
10
Conversion of Cartesian Coordinates to Geodetic
Coordinates
2nd Approach
iterative solution as h is a function of f and
vice versa
11
Converting geodetic (ellipsoidal) coordinates to
Cartesian coordinates and the inverse conversion
Task Given the geodetic latitude longitude and
height above the ellipsoid, calculate the
corresponding Cartesian coordinates for a point
above the ellipsoid. Perform the inverse
conversion using the results of the first section
as input data (i.e. X, Y, and Z Cartesian
coordinates)
Input Data Semi-major axis of the WGS84
ellipsoid (in meters), height above the ellipsoid
(in meters), and the flattening , latitude and
longitude information,
a 6378137
h 313.13
f .003
f 23o 20 10.22
l 245o 10 40.22
12
calculate the radius of curvature in the prime
vertical
n 6381489.59834
13
Inverse Solution
The longitude requires no iteration since it only
depends on given Cartesian coordinates. But you
need to be careful about the quadrant! How?
Examine the sign of Y and X. In this case, both
X and Y have negative values therefore the angle
is in the third quadrant, therefore,
14
calculate approx values for f and h
15
calculate values for f and h
16
