Title: Bridges, Routers and Switches Part One


1
Bridges, Routers and SwitchesPart One
  • Three things are certain
  • Death, taxes, and lost data.
  • Guess which has occurred.
  • Haiku error message

2
Bridging
  • Bridges connect two independent LANs to form
    internetworks

3
Types of Bridges
  • Transparent
  • Source Routing
  • Transnational

4
Bridges
  • Each LAN is referred to as a Network Segment

5
Bridge Ports
  • Bridge Ports connect the Bridge to the Network
  • Consist of a Network Interface (Ethernet, Token
    Ring, FDDI)

6
Bridges Form One Logical Network
7
Bridging and ISO Model
  • Bridges function at at the Media Access (MAC)
    layer

8
Bridging and ISO Model
  • Bridges see the network at the MAC layer
  • Bridges make forwarding decisions based on MAC
    (Physical) addresses

9
Bridging and ISO Model
  • Bridges have no knowledge of paths between
    address
  • Bridges are transparent to higher level protocol
  • Bridges are protocol independent, the same bridge
    can pass IP, IPX, DecNet traffic

10
Transparent Bridges
  • Usually used on Ethernet networks
  • Called Transparent because nodes are not aware of
    its presence
  • Defined by IEEE 802.1 standard
  • Forwards frames between networks
  • Self learning

11
Transparent Bridges
  • Maintains a data base of all known node address
    on each port

12
Transparent Bridges
  • Transparent Bridges are self learning
  • Examine every frame which passes a port
  • Determines the source address
  • Compares each address to its data base
  • If address is not in data base then the bridge
    adds the address

13
Transparent Bridges
14
Transparent Bridge Frame Forwarding
  • Examines Destination address
  • If address is on the same LAN as the incoming
    port, ignores the frame
  • If Not
  • Looks up destination address in its Data Base
  • If Address is found
  • Forward out the appropriate Port
  • If Address is not found
  • Forwards out all Ports

15
Spanning Tree Algorithm
16
Spanning Tree Algorithm
17
Spanning Tree Algorithm
18
Spanning Tree Algorithm
19
Spanning Tree Algorithm
  • Eliminates all active loops in the network by
    creating a set of paths with only one path
    between each node
  • Bridges negotiate which paths are to remain open
    and which paths will be blocked
  • If a path becomes inaccessible, the bridges will
    reconfigure the network, creating a new spanning
    tree and new set of paths

20
Source Route Bridging
  • Only used in Token Ring environments

21
Source Route Bridging
  • NOTE Despite its name Source Routing is
    Bridging and takes place at the MAC layer

22
Source Route Bridging
  • Node maintain their own routing table
  • When a frame is transmitted to a node on another
    ring, the packet must contain the route or path
  • Node discovers the route by sending out an
    Explorer Frame with the address of the
    destination Node
  • Depending on the protocols used the node may send
    an All Route Exploder Frame or a Singe Route
    Explorer Frame

23
Source Route Bridging
  • The route explorer frame records the Bridge
    Number and Ring Number of all bridges and
    networks crossed
  • When it reaches the destination node, the
    destination node sets a flag and transmits the
    frame back to the sending node
  • The Route Explorer Frame now has the route to the
    destination station
  • If two Routes return to the sending node, it
    usually uses the first route received

24
Source Route Bridging
25
Source Route Bridging
  • Source Route Bridges can connect rings running at
    different speeds

26
Whats Wrong with Source Routing?
  • Takes processing resources of end nodes
  • Each Ring and Bridge must be assigned a Ring
    Number and Bridge Number - Any error in assigning
    these numbers causes fatal errors
  • Fatal errors happen often

27
Source Route Bridging
28
Source Route Bridging
  • Allows loops
  • How many paths though this network?

29
Source Route Bridging
  • What else is wrong with Source Routing?
  • What is good about Source Routing?

30
Source Route and Transparent Bridges in Same
Network
  • Usually not very reliable - may work in some
    simple networks
  • Source Routed traffic can only cross Source Route
    Bridges

31
Transnational Bridges
  • Connect two dissimilar topologies

32
Advantages of Bridging
  • Easy to install and configure
  • Inexpensive
  • Transparent to Network
  • Automatically adapt to Network Changes
  • Bridge unroutable protocols

33
Disadvantages of Bridges
  • Can not take advantage of redundant paths in the
    network
  • Can not prevent Broadcast Storms
  • Because bridges form a single logical network the
    network becomes large and therefore difficult to
    manage

34
Routers What makes a Protocol Routable
  • To be routable a protocol must assign addresses
    so that the address contain Network and Node
    address
  • Routable Protocols include
  • IP
  • IPX
  • DecNet
  • Vines
  • Non-Routable Protocols
  • NetBios

35
Routers
  • Function of a Router is to efficiently forward
    packets between networks
  • Very often more than one path exists, a router
    must chose the best path
  • Routers function at the Network layer of the OSI
    Model, routing decisions are made using the
    address assigned by a Network layer protocol such
    as IP

36
Routers
  • Since routers function at the Network layer
    routers are protocol dependent devices
  • Must support IP, IPX, AppleTalk, DecNet, etc.

37
Routers
  • Multiple Protocols
  • Most routers can route a verity of protocols
  • The ability to route multiple protocols is
    implemented in software

38
Routers
39
Routers
  • Routers can connect dissimilar LAN topologies
  • Routers can connect LANs to the WAN

40
Routers - Why use Routers
  • Segment Networks
  • Congestion Control
  • Source Quench technique - Router can request a
    source to stop transmitting until congestion is
    relieved

41
Routers
  • Bridges examine each frame on the network segment
  • Routers only receive packets addressed to them
  • Packets are addressed to routers from
    workstations or other routers

42
Routers Node Configuration
43
Routers Routing Tables
  • Routers maintain a Routing Table
  • The Routing Table instructs the router where (out
    which interface) to send the packet
  • Packets are routed one hop at a time

44
Routers Routing Table
45
Routers - Multiple Routes
46
Routers Multiple Routes
Routing Table Router 1 Target Net Next Hop
Router Metric Net4 Attached
0 Net 1 Router 2
1 Net 1 Router 3
2 Net 3 Router 3
1 Net 3 Router 2
2 Net 2 Router 3
1 Net2 Router 2 2

47
Routers Metric Values
  • Chose route with lowest Metric value
  • Metric value can represent
  • Hops
  • Transmission Delay
  • Administrative Considerations (Cost)
  • Line Capacity

48
Routers - Backup Links
49
Routers - Routing Protocol
  • Routing Tables are dynamically created by the
    router
  • Router communicate with other routers to learn
    all paths through the network
  • This communication consists of all or portions of
    each routers routing table

50
Routers - Routing Protocol
  • Routers use these Routing Tables to build a map
    of the network topology
  • The time it takes for all routers in a network to
    exchange routing tables is called Convergence
  • Router to Router communication is implemented
    according to Routing Protocols

51
Routers - Routing Protocol Design Goals
  • Ideally Routing Protocols would meet all these
    criteria
  • Be able to find the optimal path
  • Simple enough algorithm to require a minimum of
    processing power and overhead
  • Robust enough to function when the unexpected
    happens, such as hardware failures
  • Rapid convergence - failure to converge quickly
    can cause (temporary) network outages
  • There a numerous Routing Protocol, each has its
    strengths and weaknesses

52
Routers - Routing Protocols
  • Two types of Routing Protocols
  • Distance-Vector Algorithm
  • Link-State Algorithm

53
Routers - Distance-Vector Algorithm
  • Each router calculates the metric value of the
    links to all its neighbors
  • Each router then sends a broadcast message
    containing its entire routing table to its
    neighboring routers
  • The receiving station then uses its neighbors
    routing table to calculate a new routing table
  • The router then broadcasts its new routing table
    to its neighbors

54
Routers - Distance-Vector Algorithm
  • Routers use the metric values received to
    calculate the shortest path through the network
  • The routers do not know how the network segments
    are connected
  • This algorithm results in slow convergence
  • The exchange of Routing Tables uses a high
    amount of bandwidth

55
Routers - Link State Algorithm Protocols
  • Each router broadcasts the portion of its Routing
    Table which describes its links to its
    neighboring routers
  • This description includes links and metric values
  • From this information routers can determine the
    entire network topology - That is they know how
    all the segments are connected together

56
Routers - Link State Algorithm Protocols
  • Router use their knowledge of the network
    topology to calculate the optimum path though the
    network
  • When a router detects any changes in network
    topology it broadcasts an update to other routers
  • Converge faster than Distance Vector protocols
  • More CPU/memory intensive than Distance Vector
    Protocols

57
Routers
Interior Routers route within an
Autonomous System Run Interior Routing
Protocols Boarder Gateway Routers route between
Autonomous Systems Run Boarder Routing Protocols
58
Routers - Routing Information Protocol - RIP
  • Distance Vector protocol
  • Interior Gateway Protocol
  • One of the original Routing Protocols - Very
    widely used

59
Routers - Routing Information Protocol
  • Sends routing updates at regular intervals
  • Uses a Hop Count for metric value
  • Each Hop usually adds one Hop to the metric value
  • Uses IP address as next hop
  • There is limit of 15 hops between source and
    destination
  • Prevents routing loops

60
Routers - Interior-Gateway Routing Protocol IGRP
  • Developed by Cisco Systems
  • Distance Vector
  • Interior routing protocol
  • Uses a combination of Inter-network delay,
    bandwidth, reliability and load to determine the
    best path
  • A metric value is assigned to each of these
    factors
  • The weight of each factor is user definable

61
Routers - Interior-Gateway Routing Protocol
  • Permits Multi-path routing
  • Lines of equal-bandwidth will be used in equal
    amounts
  • Lines with unequal bandwidth will be used in
    proportion to its bandwidth, that is, a line
    with twice the bandwidth will be given twice the
    amount of traffic
  • Only routes with metrics within a specified range
    of the best route will be used as multiple routes

62
Routers - Interior-Gateway Routing Protocol
63
Routers - Interior-Gateway Routing Protocol
  • Routing updates are sent at regular intervals
  • When a router goes down its neighbors are able to
    detect this by their failure to receive a routing
    update
  • The router then recalculates it routing table
    based on this information - all routes though
    that router are now invalid
  • The router then sends out its routing table at
    the scheduled interval

64
Routers - Interior-Gateway Routing Protocol
  • Network Convergence takes time, during this
    interval a router which is not aware of the
    invalid routes will broadcast its routing table
    containing the now invalid routes, this table can
    find its way to a router which has already
    received the data about the downed router. This
    router now replaces its current routing table
    with an outdated one.

65
Routers - Interior-Gateway Routing Protocol
  • Hold Down Time
  • Hold down times are used to prevent a router from
    using a route which may have gone down
  • Routers hold down any changes which may affect
    routes for a specified period of time
  • Hold down times are usually calculated to be
    greater than the network convergence time

66
Routers - Interior-Gateway Routing Protocol
67
Routers - Interior-Gateway Routing Protocol
  • Split Horizon
  • Routers never send information about a route back
    in the same direction it came from
  • There is no reason for Sue to send Harry
    information about Bob because Harry is closer to
    Bob

68
Routers - Boarder Gateway Protocol BGP
  • Routes between autonomous systems
  • Only exchanges information with other BGP routers
  • When a BGP router first joins the network routers
    exchange their entire routing table after that
    they exchange incremental information
  • Responsible for exchanging information about the
    ability to reach other networks
Write a Comment
User Comments (0)
About PowerShow.com
