Title: SOAR: The Sky in Motion


1
SOAR The Sky in Motion
  • Life on the Tilted Teacup Ride

The Day in all its Glory
The Analemma
Aileen A. ODonoghue
Priest Associate Professor of Physics
2

Kiva
December 1997 October 27, 2009
3
Celestial Coordinates
  • Right Ascension
  • RA or ?
  • From prime meridian (0h) to 23h59m59s Eastward
  • Declination
  • Dec or ?
  • From celestial equator (0º) to poles N S 90º

4
Tilted Sky
  • Observers see sky tilted due to latitude

To Celestial Equator
To NCP
We see ourselves on top of the Earth, beneath
the sky.
Zenith
To NCP
?
So we see sky motions tilted
Observers Latitude
5
Standard Clock Time
Its 6 pm (sunset).
  • Every Longitude at slightly different time

Its 3 pm.
Its 9 pm.
Its noon.
Its midnight.
Its 3 am.
Its 9 am.
Its 6 am (sunrise).
6
The Ecliptic (path of the sun)
  • View from Earth
  • Sun moves 1º/day eastward across stars
  • Sun moves north and south in declination
  • Solstices Equinoxes are positions in the sky.

This motion is through the YEAR!
7
Moon Phase is lit moon visible
  • Insert is moon as see from Earth

8
Moon Phases
  • New Moon Elongation 0 (angle from sun to
    moon)
  • Waxing Phases visible after sunset
  • Waxing Crescent 0 lt Elongation lt 90 E
  • First Quarter Elongation 90 E
  • Waxing Gibbous 90 E lt Elongation lt 180
  • Full Moon Elongation 180

Elongation Angle from Sun
9
Moon Phases
  • Full Moon Elongation 180
  • Waning Phases visible before sunrise
  • Waning Gibbous 90 W lt Elongation lt 180
  • Third Quarter Elongation 90 W
  • Waning Crescent 0 lt Elongation lt 90 W
  • New Moon Elongation 0

Elongation Angle from Sun
10
Fun with Time Phase
1st quarter
  • Determine rising, transit and setting times of
    each phase

waxing crescent
waxing gibbous
6pm
Transiting Moon Above
9pm
3pm
Setting Moon to West
Observers Time Above
Time is the one above the observers head!
noon
new
full
mdnt
Rising Moon to East
Earth rotation
3am
9am
waning gibbous
waning crescent
6am
3rd quarter
11
Question
1st quarter
  • An observer sees the moon rise at
    midnight. What phase is it?

waxing crescent
waxing gibbous
6pm
3pm
9pm
noon
new
full
mdnt
Observers Time Above
a) First Quarter b) Full Moon c) 3rd Quarter
Rising Moon to East
3am
9am
waning gibbous
waning crescent
6am
3rd quarter
12
Time
  • Clock Time
  • the position of the mean sun at TZ center
  • eg. 12 pm transit of mean sun (avg. of
    analemma)
  • Mean Solar Day 240000 (hoursminsec of
    time)
  • Solar Time
  • the position of the sun wrt the observer
  • eg. Noon sun transits
  • Solar Day varies as shown by analemma
  • Sidereal Time
  • the position of ? wrt the observer
  • eg. 0h Local Sidereal Time (LST) ? transits
  • Sidereal time R.A. on the meridian
  • Sidereal Day 235600

13
The Sidereal Day
Sidereal Day 360 rotation puts star back on
meridian
to distant star
1 along orbit
to distant star
to sun
14
The Solar Day
Solar Day 361 rotation puts sun back on meridian
to distant star
1
to sun
1 along orbit
to distant star
to sun
15
The Sun at Noon
  • Noon ? Sun on meridian
  • Suns position varies the Analemma

Observer's Meridian (due south)
16
The Sun at Noon
  • Noon ? Sun on meridian
  • Suns position varies the Analemma

Observer's Meridian (due south)
Analemma
17
The Analemma
  • Position of true sun at clock noon
  • Clock Noon
  • 1200 pm in a 240000 day
  • Position of Mean Sun
  • at noon
  • True Suns Position
  • varies due to Suns
  • speed along path
  • varies due to elliptical path
  • varies due to tilted path

Observer's Meridian (due south)
Mean Sun
True sun East of mean sun
True sun West of mean sun
18
Mean Sun True Sun
  • Mean sun on meridian defines clock noon
  • True sun on meridian defines solar noon

Observer's Meridian (due south)
Mean Sun
True sun East of mean sun Solar noon is late
sun slow
True sun West of mean sun Solar noon is early
sun fast
19
The Calendar
  • The Year
  • Tropical (equinox to equinox) 365.242190 d
  • Sidereal (star to star) 365.256363 d
  • Anomalistic (perigee to perigee) 365.259635 d
  • Lunar (node to node) 346.620076 d
  • Julian Calendar (45 BCE) 365.25 d
  • Add 1 day every four years
  • 365.25 365.24219 0.00781 days/year too many
  • ? Extra day every 128 years

20
The Calendar
  • Gregorian Calendar (1582) 365.2425 d
  • Council of Trent want ? on March 21
  • as it was during Council of Nicaea in 325 CE
  • Easter is 1st Sunday after 15th day of moon
    after ?
  • Moon phases tabulated, not observed!
  • 325 to 1582 (1257 years), 9.8 days ahead
  • Drop 10 days 10/15/1582 followed 10/4/1582
  • American Colonies 9/14/1752 followed 9/2/1752
  • George Washington born 2/22/1732, 2/11/1732 OS
  • http//en.wikipedia.org/wiki/Old_Style_and_New_St
    yle_dates
  • Century years divisible by 400 have leap days
  • 1600, 2000 had leap days, 1700, 1800, 1900 did
    not

21
Doing the Math
  • Adoption of the Gregorian Calendar

Leap year for Julian
Leap year for Julian
Leap year for Julian
Leap year for all
Leap year for all
Dropped 11 days
Dropped 12 days
Dropped 13 days
Dropped 10 days
22
Doing the Math
  • Old Style New Style dates

Marriage certificate from Warsaw (then in Russia)
Marriage Dated 3/16/1907
Certificate Dated Nov/Dec 23/6
23
Doing the Math
  • Mean Sun
  • Projection of sun onto Celestial Equator
  • moves 360 in one year (365.242191 days)
  • True Sun
  • speed varies due to
  • Suns changing Declination
  • Elliptical orbit

True Sun on Ecliptic
Mean Sun on Celestial Equator
24
Speed Variation Due to Tilt
  • Analogy Airplanes on Earth
  • Both fly at same speed (mph)

Airplane at high latitude covers more degrees of
longitude.
Airplane at angle covers fewer degrees of
longitude.
25
Speed Variation Due to Tilt
10 along Ecliptic (motion of true
sun in 10 days)
10 along Ecliptic (motion of true
sun in 10 days)
10 along Celestial Equator (motion of mean sun
in 10 days)
10 along Celestial Equator (motion of mean sun
in 10 days)
26
Speed Variation Due to Tilt
10 along Ecliptic (motion of true
sun in 10 days)
At equinoxes true
sun moves lt1 each day ? true sun
falls behind mean sun
12 in right ascension
(motion of true sun in sky)
10 along Ecliptic (motion of true
sun in 10 days)
At solstices, true
sun moves gt 1 each day
? true sun gets ahead of mean sun
9 in right ascension
(motion of true sun in sky)
10 along Celestial Equator (motion of mean sun
in 10 days)
10 along Celestial Equator (motion of mean sun
in 10 days)
27
True Sun Speed Variation
  • Solstices
  • True sun and mean sun aligned, but
  • True sun getting ahead of mean at maximum rate
  • Equinoxes
  • True sun and mean sun aligned, but
  • True sun getting behind mean at maximum rate
  • Cross-Quarter Days
  • Between solstices equinoxes
  • True sun farthest from mean
  • Switching between getting ahead behind

28
Cross Quarter Days
  • Days ½ way between solstices equinoxes
  • Beltane May 1
  • ½ way from Vernal Equinox to Summer Solstice
  • Lughnasa August 2
  • ½ way from Summer Solstice to Autumnal Equinox
  • All Hallows (Samhain) November 1
  • ½ way from Autumnal Equinox to Winter Solstice
  • Candlemas (Imbolc) February 2
  • ½ way from Winter Solstice to Vernal Equinox

If Candlemas Day be fair and bright, Winter will
have another flight
If Candlemas Day be damp black, It will carry
cold winter away on its back.
29
Speed Variation Due to Tilt
  • Solstices Equinoxes (June December)
  • mean and true sun align, fastest rate of change
  • Cross-Quarter Days
  • maximum separation of mean and true sun
  • switching direction of change

True sun farthest west (early, fast)
Mean sun true sun aligned
True sun farthest east (late, slow)
30
Speed Variation Due to Tilt
True Sun's Separation from Mean Sun
Maximum rate of change at solstices equinoxes
Beltane
Halloween
Vernal Equinox
Summer Solstice
Winter Solstice
Autumnal Equinox
Separation (degrees west)
Maximum difference at cross-quarter days
(direction of change switches)
Candlemas
Lughnasa
Date
31
Tilt Analemma
  • Position of true sun through the year for Earth
    in a circular orbit.

East
West
32
Tilt Analemma
  • Position of true sun through the year for Earth
    in a circular orbit.

True mean sun aligned at solstices equinoxes
(rate of change maximum)
East
West
Maximum difference
at cross-quarter days
(direction of change switches)
33
Tilt Analemma
  • Position of true sun through the year for Earth
    in a circular orbit.

True mean sun aligned at solstices equinoxes
(rate of change maximum)
East
West
Maximum difference
at cross-quarter days
(direction of change switches)
But its not this simple
34
Earths Orbit
  • Earths speed varies in orbit
  • area swept out in a given time stays equal
  • perihelion ( January 4)
  • Earth moves fastest (February is shortest
    month!)
  • aphelion ( July 4)
  • Earth moves slowest

Orbital Motion
Area at perihelion
Area at aphelion
Aaphelion Aperihelion
Orbital speed changes to keep swept areas equal
35
The Analemma
  • Perihelion, Earth moving fastest

to mean sun
to sun
gt 1 along orbit
to distant star
to sun
rperihelion 91.4 million miles, vperihelion
67,754 mph
36
The Analemma
  • Aphelion, Earth moving slowest

lt 1 along orbit
to sun
lt 1 along orbit
to distant star
to sun
raphelion 94.5 million miles, vaphelion
65,527 mph
37
Orbit Analemma
  • Position of true sun through the year for Earth
    in an elliptical orbit just due to orbital speed
    variation

Maximum rate of change at perihelion aphelion
Maximum difference at orbital mid-points
(direction of change switches)
Perihelion
Aphelion
38
Orbit Analemma
Oribt Analemma Potsdam, NY
  • Position of true sun through the year for Earth
    in an elliptical orbit just due to orbital speed
    variation

Sun's Altitude at Clock Noon (Degrees)
East
West
Sun's Position at Clock Noon (Degrees)
39
Total Analemma
  • Tilt and Orbit effects add

Equation of Time Potsdam, NY
Tilt Effect
Orbital Effect
Sum
True Sun's Position at Clock Noon (degrees)
40
Total Analemma
Analemma, Potsdam, NY
  • Tilt and Orbit effects add



Sun's Altitude at Clock Noon (Degrees)
Altitude of Sun at Noon
Sun's Position at Clock Noon (Degrees)
41
Potsdams Analemma
Analemma, Potsdam, NY
June
July
May
August
West
East
April
September
Sun's Altitude at Clock Noon (Degrees)
March
October
February
November
January
December
Sun's Position at Clock Noon (Degrees)
42
Why is the earliest sunset on December 7, 2009?
Sun position at 330 pm EST through the year
7/7/10
6/7/10
8/7/10
5/7/10
4/7/10
9/7/10
3/7/10
10/7/10
2/7/10
Analemma closest to horizon in early December
11/7/10
1/7/10
12/7/9
43
The Analemma
  • Varies time of sunrise sunset
  • Earliest sunset on about December 8
  • Latest sunrise on about January 3

44
The Analemma
Solar noon was 5 minutes before clock noon
  • Position of sun at clock noon throughout year
  • Variation in the length of the Solar day as
    measured by clocks

Position of sun at clock noon on 9/16
At clock noon suns declination is 3
East
Equator
Clock Noon
West
At clock noon sun is 1.25 West of the meridian
0?
Write a Comment
User Comments (0)
About PowerShow.com
