Title: ELEN 468 Advanced Logic Design


1
ELEN 468Advanced Logic Design
  • Lecture 24
  • Design for Testability

2
Test Cost
  • Test pattern generation
  • Fault simulation
  • Generation of fault sites information
  • Test equipment
  • Test process
  • Test cost may overweight design cost

3
Why Design for Testability?
  • Testability is a design characteristic that
    influences various costs associated with testing
  • It allows for
  • Device status to be determined
  • Isolation of faults
  • Reduce test time and cost

4
Controllability
  • Ability to establish a specific signal value at
    each node by setting circuits inputs
  • Circuits typically difficult to control
    decoders, circuits with feedback, oscillators,
    clock generators

5
Observability
  • Ability to determine the signal value at any node
    in a circuit by controlling the circuits inputs
    and observing its output

6
Predictability
  • Ability to obtain known output values in response
    to given input stimuli
  • Factors affecting predictability
  • Initial state of circuit
  • Races
  • Hazards

7
Difficult Test Cases
  • Sequential logic is more difficult to test than
    combinational logic
  • Control logic is more difficult to test than
    data-path logic
  • Random logic is more difficult to test than
    structured bus-oriented designs
  • Asynchronous design is more difficult to test
    than synchronous design

8
Quantify Testability
  • Need approximate measure of
  • Difficulty of setting internal circuit lines to 0
    or 1 by setting primary circuit inputs
  • Difficulty of observing internal circuit lines by
    observing primary outputs
  • Uses
  • Analysis of difficulty of testing internal
    circuit parts redesign or add special test
    hardware
  • Guidance for algorithms computing test patterns
    avoid using hard-to-control lines
  • Estimation of fault coverage
  • Estimation of test vector length

9
Types of Measures
  • SCOAP Sandia Controllability and Observability
    Analysis Program
  • Combinational measures
  • CC0 Difficulty of setting circuit line to logic
    0
  • CC1 Difficulty of setting circuit line to logic
    1
  • CO Difficulty of observing a circuit line
  • Sequential measures analogous
  • SC0
  • SC1
  • SO

10
Range of SCOAP Measures
  • Controllabilities 1 (easiest) to infinity
    (hardest)
  • Observabilities 0 (easiest) to infinity
    (hardest)
  • Combinational measures
  • Roughly proportional to circuit lines that must
    be set to control or observe given line
  • Sequential measures
  • Roughly proportional to times a flip-flop must
    be clocked to control or observe given line

11
Controllability Examples
12
Observability Examples
13
Goal of Design for Testability (DFT)
  • Improve
  • Controllability
  • Observability
  • Predictability

14
Design and Test Trade-off
  • Most DFT ( Design for Testability ) techniques
    need extra hardware, or modification to circuits
    that may affect performances
  • DFT need to consider the cost trade-off between
    design and test

15
DFT Methods
  • DFT methods for digital circuits
  • Ad-hoc methods
  • Structured methods
  • Scan
  • Partial Scan
  • Built-in self-test (BIST)
  • Boundary scan

16
Ad-Hoc DFT Methods
  • Good design practices learnt through experience
    are used as guidelines
  • Avoid asynchronous (unclocked) feedback
  • Make flip-flops initializable
  • Avoid redundant gates
  • Avoid large fanin gates
  • Provide test control for difficult-to-control
    signals
  • Avoid gated clocks
  • Design reviews conducted by experts or design
    auditing tools
  • Disadvantages of ad-hoc DFT methods
  • Experts and tools not always available
  • Test generation is often manual with no guarantee
    of high fault coverage
  • Design iterations may be necessary

17
Scan Design
  • Circuit is designed using pre-specified design
    rules
  • Test structure (hardware) is added to the
    verified design
  • Add a test control (TC) primary input
  • Replace flip-flops by scan flip-flops (SFF) and
    connect to form one or more shift registers in
    the test mode
  • Make input/output of each scan shift register
    controllable/observable from PI/PO

18
Scan Design Rules
  • Use only clocked D-type of flip-flops for all
    state variables
  • At least one PI pin must be available for test
    more pins, if available, can be used
  • All clocks must be controlled from PIs

19
Correcting a Rule Violation
  • All clocks must be controlled from PIs

Comb. logic
D1
Q
Comb. logic
FF
D2
CK
Comb. logic
Q
D1
Comb. logic
FF
D2
CK
20
Scan Storage Cell
Q, So
D
Si
SSC
N/T
SSC
Clk
Q
D
21
Scan Flip-Flop (SFF)
Master latch
Slave latch
D
N/T
Q
Logic overhead
MUX
Q
Si
Clk
D flip-flop
22
Scan Methods
C1
C2
C2
C1
MUX
Si
23
Boundary Scan
MUX
24
Integrated Serial Scan
PI
PO
SFF
SCANOUT
Combinational logic
SFF
SFF
Control
SCANIN
