Reset and Interrupts

1
Reset and Interrupts

• Advanced Programming

2
Resets and Interrupts

• See the Reset and Interrupts Section in the
  68HC11E Family Technical Data Sheet (pp.79-96)
• For a more detailed description see the Reset and
  Interrupt Section of the Reference Manual
  (pp.159-196)

3
Interrupts

• An interrupt is an event that causes the CPU to
  suspend whatever is doing (running a program)
  handle the interrupt (running a routine servicing
  the interrupt) and then resumes what it was doing
• To handle the interrupt the CPU jump to a special
  routine called an interrupt service routine (ISR)
  or an interrupt handler
• The difference from a subroutine is that ISRs are
  located at pre-determined starting addresses

4
Resets

• A Reset is a special type of interrupt.
• Resets do not return back to finish executing the
  interrupted program
• Resets are used to force the MCU to assume a set
  of initial conditions and to begin executing
  instructions from a predetermined starting
  address
• When a reset occurs, the CPU finishes executing
  the present instruction and then begins execution
  of the reset routine

5
Types of Reset

• RESET pin
• Power-On Reset (POR)
• Computer Operating Properly (COP) Watchdog Timer
  Reset
• Clock Monitor Fail (CMF) Reset

6
Resets Operation RESET and POR

• POR and the external RESET pin have highest
  priority that any other reset or interrupt.
• They share the address vector FFFE,FFFF
• POR is delayed by 4046 clock cycles (to allow the
  oscillator to settle)

7
Resets Operation COP

• COP failure is intended to detect software
  processing errors. If the CPU watchdog times out
  a reset is initiated.
• To prevent a COP failure reset from occurring the
  application program must clear the watchdog
  timer on a regular basis.
• To clear the COP timer the application program
  must follow a 2-step sequence. It must write a
  55 to the COPRST (at 103A) register followed by
  writing a AA to the COPRST register.
• The COP system is enabled or disabled depending
  on the state of the NOCOP bit in the CONFIG
  register (at 103F). The COP timeout period is
  set by the timer rate control bits CR1 and CR0 in
  the configuration OPTION register (at 1039).

8
Nominal COP Timeout
9
Control Registers
10
Resets Operation Clock Monitor

• This reset triggers if the CPU clock drops below
  a frequency of 10KHz.
• To enable the clock monitor reset, set the clock
  monitor enable (CME) bit in the systems
  configuration options register (OPTION at 1039)
• The clock monitor reset is based on an internal
  resistor-capacitor (RC) time delay.
• When a crystal fails it can still generate
  approximately 1000 more cycles due to its
  internal capacitance.

11
Types of Interrupt

• A microcontroller uses interrupts for critical
  tasks that cannot wait, such as I/O events.
• There are many separate interrupt sources
• Some are generated by a signal at an external pin
• Others are generated when special bits are set
  (a combination of hardware and software causes
  these bits to set).

12
(No Transcript)
13
Interrupt Vectors Customization

• The programmer can customize the service routine
  addresses by using a vector jump table.
• The elements of the vector jump table are
  called pseudo-vectors or jump vectors.
• The pseudo vectors are in RAM
• Each pseudo vector takes three bytes of RAM

14
Pseudo-vectors
15
Stacking the Registers

• An ISR will most likely change the content of
  some of the CPU registers
• An ISR also needs to know where to return to when
  it has completed servicing the request
• When an interrupt request occurs and it is
  enabled the CPU will push all the CPU register
  values onto the stack before it fetches the
  vector
• An ISR use the instruction RTI to return control
  back to the program interrupted.
• When RTI is executed, it pulls the data from the
  stack to restore them to the CPU registers
• Resets do not stack the CPU registers, since a
  reset routine does not normally return control
  back to the program interrupted.

16
Stacking Order
17
Interrupt Priority
18
Interrupt Priority
19
Priority of the Maskable Interrupts

• The priority of each interrupt source is fixed,
  however the user can promote one of the maskable
  interrupts to the highest priority among the
  maskable interrupts by programming the HPRIO
  register

20
Priority of the Maskable Interrupts
21
Nested Interrupts

• After Stacking the registers, the CPU sets the I
  bit in the CCR to prevent any other interrupts
  from occurring
• If the interrupt service routine does not clear
  the I bit, only non-maskable interrupts can
  interrupt the routine
• When interrupt routines are interrupted, a
  condition of nested interrupts is said to exist
• Many systems try to avoid nested interrupts
  because it makes the software more complicated
  and there is a danger of stack overflow
• Nonmaskable interrupts and resets will always be
  able to interrupt a low-priority maskable
  interrupt
• It is possible to change the priority level of
  any one of the maskable (I-bit related)
  interrupts using the highest priority interrupt
  (HPRIO at 103C) register

22
Interrupt masking and enabling

• Microcontrollers can be programmed to ignore some
  interrupt sources. This is achieved by not
  setting a special bit called the interrupts
  enable bit.
• The process of ignoring an interrupt is called
  masking.
• Interrupts that can be enabled/disabled are
  called maskable.
• Each maskable interrupt has its own corresponding
  enable or mask bit.
• Typically, an enable/mask bit is set or cleared
  by writing to a specific I/O control or status
  register
• When an enable bit is set to 1, the CPU will
  respond to the interrupt request, when is set to
  0, the CPU will ignore the request.
• When a mask bit is set to 1, the CPU will ignore
  the interrupt request, when is set to 1, the CPU
  will respond to the request.

23
CCR Register and Interrupts

• Most interrupts are maskable by the I bit in the
  CCR.
• If the I bit is set, all the associated
  interrupts are masked.
• The SEI instruction set the I bit of the CCR. It
  disables interrupt globally.
• The CLI instruction clear the I bit of the CCR.
  It enables interrupt globally.
• To mask only some of the interrupts covered by
  the I bit, the I bit is cleared using the CLI
  instruction and then each interrupt is
  individually masked by writing to the associated
  control register.

24
CCR Register and Interrupts
25
Example
26
Hardware Interrupts

• Illegal Opcode Trap
• Non-Maskable Interrupt (XIRQ)
• Interrupt Request (IRQ)

27
Illegal Op code Trap

• A trap is the part of a program that catches an
  error condition and indicate to the user that an
  error has occurred. In many cases, the errors
  are of such a nature that program execution must
  be aborted.
• It is up to the programmer to decide what error
  conditions are to be trapped and how they are to
  be handled. For example a divide by zero error
  may be a trap.
• The 68HC11 comes with a built in trap for illegal
  op codes. If the fetched code does not correspond
  to any instruction the illegal op code trap (IOP)
  interrupt takes place.
• What the IOP interrupt routine should do depends
  on the application.

28
Non maskable interrupt (XIRQ)

• By default when you power up or reset the
  microcontroller, XIRQ is masked. That is, the X
  bit in the CCR is set.
• To unmask XIRQ, you use the TAP instruction to
  clear bit X.
• TPA get original CCR
• ANDA BF reset bit 6, (X)
• TAP put it back in CCR
• Once the program has cleared X, executing another
  TAP will not set X again. The only way to set X
  again is through a reset.
• While the service routine is executing, the CPU
  will set bit X and I. Unless the service routine
  reset the I bit or the X bit this prevents other
  interrupts from interfering. When the service
  routine executes RTI the original CCR contents is
  recovered.

29
XIRQ Example
30
XIRQ Example in Assembly

• Demonstrate XIRQ
• ORG 9000
• main LDS FF define the stack
• LDX 1122 modify some registers
• LDY 3344
• LDAB 55
• enable XIRQ
• TPA get original CCR
• ANDA BF reset bit 6 (X)
• TAP put it back in CCR
• LDAA 1C now possible to interrupt
• LDAB C1
• here BRA here end main
• xirq service routine
• rxirq LDX 6677 modify some registers
• LDY 8899
• LDAA AA
• LDAB BB

31
XIRQ Example in C

• / XIRQ Example /
• unsigned int data / data to increment /
• void main(void)
• data 0 / initialize data /
• / setup jump vector /
• asm(ldaa 0x7E) /opcode of jump
  (extended) /
• asm(staa 0xF1) / the jump instr. is put
  at address 00F1/
• asm(ldd rxirq)
• asm(std 0xF2)
• /enable XIRQ /
• asm(tpa)
• asm(anda 0xBF)
• asm(tap)
• while(1) / loop forever /
• void rxirq(void) / interrupt service routine for
  XIRQ /

32
Interrupt Request (IRQ)

• Interrupt request is maskable by setting bit 1 in
  the CCR
• You can mask IRQ using the instruction SEI
• You can unmask IRQ using CLI
• It is also possible to program IRQ to be edge
  sensitive or level sensitive
• To make IRQ edge sensitive only you have to set
  the IRQE bit (bit 5) in the OPTION register (at
  1039).
• Some bits in OPTION are time protected. They can
  be changed only within the first 64 clock cycles
  after a reset.

33
Interrupt Configuration

• To set up interrupt operation, it is necessary to
  do some configuration (ritual)
• During the configuration steps it is prudent to
  disable interrupts
• Typically, after configuration is complete,
  interrupts are enabled

34
Interrupt Configuration Example

• Demonstrate Interrupt Configuration
• ORG 9000
• main LDS FF define the stack
• SEI mask IRQ interrupt
• LDX 1000
• BSET 39,X 20 turn on CR1 bit in OPTION
• CLI unmask IRQ interrupt
• NOP let interrupt drive program
• here BRA here
• irq service routine
• rirq INC 00 modify location 0000 of memory
• RTI return from rirq
• Define Vectors
• ORG FFF2
• VIRQ FDB rirq start address of rirq
• VXIRQ FDB here
• VSWI FDB here

35
Interrupt Polling

• Interrupt polling is a way to determine which one
  of multiple devices has requested the interrupt.
• If several devices are all connected through
  external logic circuitry to the interrupt pin of
  the microcontroller, there is no immediate way to
  know which device requested the interrupt.
• The microcontroller reads the status register of
  each device to find the one that requested the
  interrupt.
• It can then call the appropriate service routine
  for that device.

36
Software Interrupt

• Software interrupt (SWI) is a special instruction
  that has several aplications
• When executed, it behaves like an interrupt by
  stacking the registers, setting the I bit in the
  CCR, and fetching the contents of address FFF6,
  FFF7.
• It can be used to simulate hardware interrupts
  during system development
• It can be used for debugging programs (setting
  breakpoints in your program)

37
CPU Control and Monitoring

• COP failure reset
• Clock monitor fail reset
• The Real Time Interrupt (RTII) generates an
  interrupt whenever a specifies period of time
  expire.

38
Real Time Interrupt (RTII)

• Some application do not need to be executing a
  program all the time but need to be woken up
  when required.
• The RTII is useful for programs that dont need
  to be executing code all the time
• RTII can be used to wake up the program
• The microcontroller can reduce power consumption
  while waiting to be woken up.

39
Real Time Interrupt (RTII)
40
WAI and STOP instruction

• The WAI stacks the registers and waits for an
  unmasked interrupt, suspending execution
• The effect of executing STOP depends on the S bit
  in the CCR
• If the S bit is set. The CPU treats STOP like a
  NOP and continues on to execute any instructions
  following the STOP.
• If the S bit is reset all internal clocks in the
  CPU halt, thus halting execution. This puts the
  microcontroller in the state of lowest power
  consumption.
• To wake up the controller, a RESET, XIRQ or IRQ
  is needed.
