CSC 213

1
CSC 213 Large Scale Programming

• Lecture 37
• External Caching (a,b)-Trees

2
Todays Goal

• Look at advanced Tree structures
• Part of most databases, operating systems
• Anywhere there is lot of data to be held
• Already examined related (2,4) trees
• Now look at more general definition
• Also examine why we should care

3
Lies My Professor Told Me

• Big-Oh notation not always accurate
• For example, treats memory accesses equally
• But many different memories inside machine
• Organized in a pyramid
• Higher faster
• Lower cheaper
• (Cheaper also means more memory available)

register
L1 cache
L2 cache
main memory (RAM)
hard drive
4
Hierarchy In Perspective

• Suppose the processor needs a beverage
• Registers -- Drink from the mug in its hand
• L1 Cache -- Get from a case in the fridge
• L2 Cache -- Get from tapped barrel in the cellar
• Main memory -- Purchase corner Wilson Farms
• Hard drive -- Drive to closest brewery buy vat
• Network -- Go to Germany buy Bavaria

5
Waiting Is a Pain
6
Not All Access Are Equal

• Want to limit access to lowest possible level
• Easy when we are only using a few objects
• Difficult when working with non-trivial data sets
• Two common approaches to avoid the wait
• Caching -- hold data from hard drive in RAM
• Usually stores most recently or frequently used
  data
• Locality -- organize data to limit amount used
• By matching internal storage to improve cache
  effectiveness

7
Virtual Memory

• Extends RAM by using space on hard drive
• Big win if we rarely access the material on disk
• Incredibly slow if always stuck driving to
  brewery
• Works by dividing memory into pages
• Each page is a constant size (usually 4096 bytes)
• Operating system handles memory at page level
• Limits overhead and maximizes efficiency
• Evicts unused pages to the hard drive for storage
• Reloads pages when it is then accessed

8
Problems with Binary Trees

• Good way to organize information
• Provides consistent O(log n) processing times
• Organization is very bad for locality, however
• Nodes contain only 1 piece of data
• Must then jump to one of its two children
• Nodes can get randomly spread over heap
• Good torture test for roommates computer
• (2,4) trees provide some improvement
• Still have at most 3 elements 4 children
• Does not use anything like 4096 bytes in a page

9
(a, b) Trees to the Rescue!

• Real-world solution to killing disks by paging
• Linux MacOS to track files directories
• Organization used by MySQL other databases
• Found in many other places where paging occurs
• (2,4) trees are one example of these
• Can also create others, just follow the rules
• All leaves are found at same level of the tree
• All internal nodes but root have at least a
  children
• All internal nodes have at most b child Nodes

10
Improving Locality

• For (2,4) trees, a 2 and b 4
• Process of splitting and merging nodes still
  holds
• We only vary the number of children in Node
• Minimize paging using good size for a b
• Store all the elements in an additional
  dictionary
• Make sure full node, including dictionary and
  child references fill a page
• Limit number of nearly empty pages by selecting
  reasonable value for a

11
Insertion

• Always insert data into a leaf node
• Once inserted check for overflow!
• Trying to make larger than allowed
• Example insert(30)

15 24
27 30 32 35
27 32 35
12
18
3
4
5
1
2
12
Split In Case Of Overflow

• Split overflowing Node 2 new nodes
• Promote median element to the parent Node
• Divide remaining elements into the two new Nodes
• This may cause parent Node to overflow
• So must repeat the process until we hit the root
• If the root node overflows, we create a new root!

15 24 32
27 28 29 30
27 28 30
12
18
35
13
Parent Overflow

• Example insert(29)

15 24 29 32
27 28
12
18
35
30
14
Parent Overflow

• Example insert(29)

29
15 24
32
12
27 28
18
35
30
15
Underflow and Fusion

• Deleting Entry may cause underflow
• Two possible solutions depending on situation
• Example remove(15)

9 14
15
2 5 7
10
16
Case 1 Transfer

• Has adjacent sibling with elements to spare
• Steal closest Entry from parent siblings child
• Parent takes siblings closest Entry
• Were done
• Example remove(10)

4 9
4 9
4 9
4
4 8
6 8
6 8
2
10
2
9
6 8
6
17
Case 2 Fusion

• Emptied node has siblings of minimum size
• Merge node sibling into one
• Steal Entry from parent that was between siblings
• May propagate underflow to parent!
• Example remove(15)

9 14
9 14
9
9 14
2 5 7
10
15
10 14
2 5 7
10
18
For Next Lecture

• Look at most popular version of (a, b)Tree
• How a BTree is implemented
• Ways of reading an writing these trees to disk
