Title: VHDL Overview


1
VHDL Overview
A Quick Start Tutorial
2
What does VHDL stand for ?
  • VHSIC Hardware Description Language
  • VHSIC Very High Speed Integrated Circuits

3
HDLs
  • VHDLUSA Department of DefenseIEEE Std 1076-1993
  • VerilogIEEE Std 1364-1995
  • Super Verilog
  • SystemC

4
HDL applications
  • High Level Modeling (Behavioral style)
  • Design Entry (Structural RTL styles)
  • Simulation (Behavioral style)
  • validation by mean of a test bench

dut_tb.vhd
dut.vhd
instantiate design to test
generate stimuli
observe responses
TESTBENCH
5
HDL vs. Schematic Entry
  • The Design Description is independent from the IC
    Vendors Cell Libraries (in other words
    independent from physical implementation)
  • Enable portability
  • Foster reuse
  • Higher Level of Abstraction (hiding details)
  • The design task become simpler
  • The design is less error prone
  • Productivity is increased

6
HDLs vs. Software Languages
  • Concurrent (parallel) Statements
    vs. Sequential Statements

7
HDL coding Styles
  • Register Transfer Level
  • Structural
  • Behavioral

Be careful NOT everybody gives the same meaning
to the term BEHAVIORAL !
8
RTL
  • Only a small subset of the Language statements
    can be mapped in real Silicon.

area and timing constraints
generic technology
target technology
unoptimized generic boolean netlist
optimized gate level netlist
optimization mapping
translation
HDL code
SYNTHESIS
9
Structural
  • Sub-Modules interconnection
  • Primitive cells interconnection (net-list)
  • The code describes a bunch of port mappings.

10
Behavioral
  • Modeling a system (mimic functionality and
    performances)
  • All language constructs can be used

11
Levels of Abstraction
BehavioralRTLStructural
12
VHDL Design Organization
  • Entitythe symbol (input/output ports)
  • Architectureone of the several possible
    implementation of the design
  • Configurationbinding between the symbol and one
    of the many possible implementation. Can be used
    to express hierarchy.

13
Entity
entity mux is port ( a in std_logic b in
std_logic s in std_logic f out std_logic
) end mux
MUX
A
B
F
S
14
Architecture 1
  • architecture first_rtl of mux is
  • begin
  • mux_p process (a,b,s)
  • begin f lt (a and s) or (b and not s) end
    process mux_p
  • end first_rtl

15
Architecture 2
  • architecture rtl of mux is
  • begin
  • mux_p process (a,b,s)
  • begin if (s1) then f lt a
  • else f lt b end if
  • end process mux_p
  • end rtl

16
Configuration
  • configuration mux_c of mux isfor rtlend for
  • end mux_c

17
Where did we get std_logic ?
  • Ohps !! We need to include some library before we
    can use this predefined data type
  • library ieeeuse ieee.std_logic_1164.alluse
    ieee.std_logic_arith.all

18
Predefined data types
  • bit 0 , 1
  • boolean false, true
  • integer from negative 231-1 to positive 231-1
  • std_ulogic 1,0,H,L,X,U,Z,-,W
  • std_logic 1,0,H,L,X,U,Z,-,W

19
std_logic, and std_ulogic
  • 1, 0, X ? logic 1, logic 0, unknown
  • H, L, W ? weak 1, weak 0,
    weak unknown
  • U, Z, - ? uninitialized, high
    impedance, dont care

20
resolved or unresolved ?
  • VHDL Driver it is one contributor to the final
    value of a signal
  • Drivers are created by concurrent signal
    assignments
  • Recommendation use std_logic, but always check
    that you do not have any multiple drivers (you
    dont want any wired OR inside an ASIC !!!)

21
Bad Multiple Drivers!!!
  • architecture bad of mux is
  • begin
  • -- the two assignment works in parallel
  • f lt a when s 0 else 0
  • f lt b when s 1 else 0
  • end bad

22
Better way of coding the mux
  • architecture better of mux is
  • begin
  • f lt a when s 0 else
  • f lt b when s 1 else
  • X -- what should the synthesis tool do here
    ?
  • end better

23
One more coding for the mux
  • architecture even_better of mux is
  • begin
  • f lt a when s 0 else
  • f lt b when s 1 else
  • - -- there are tools that wont appreciate
    all this -- freedom (e.g. some formal
    verification tool)
  • end even_better

24
Good way of coding the mux
  • architecture good of mux is
  • begin
  • f lt a when s 0 else
  • f lt b -- here all ambiguity are gone !!!
  • end good

25
What is a process ?
  • A process statement is a concurrent statement,
    but all statements contained in it are sequential
    statement (statements that executes serially, one
    after the other).
  • The use of processes makes your code more
    modular, more readable, and allows you to
    separate combinational logic from sequential
    logic.

26
The sensitivity list
  • List of all signals that the process is sensitive
    to. Sensitive means that a change in the value
    of these signals will cause the process to be
    invoked.

27
The sensitivity list must be complete !!!
  • process (a)
  • variable a_or_b
  • begin
  • a_or_b a or b
  • z lt a_or_b
  • end process

-- since b is not in the -- sensitivity list,
when -- a change occurs on b -- the process is
not -- invoked, so the value -- of z is not
updated -- (still remembering the -- old value
of z)
28
Incomplete sensitivity list effect
a
b
z
(VHDL)
z
(gate level)
29
What to put in sensitivity list ?
  • All signals you do a test on and all signals that
    are on the right side of an assignment.
  • In other words all the signals you are reading
    in the value
  • Dont read and write a signal at the same time
    !!!

30
Object Types
  • Constants
  • Signals
  • Variables

31
Constant
  • It is just a name for a value.reset_c 0
    bus_width_c 32- a better documented design.
    - it is easier to update the design.- But do
    not exaggerate !!! (since you have to remember
    all these names you defined)

32
Signals
  • It is a physical signal (you can think of it like
    a piece of wire)
  • It is possible to define global signals (signals
    that can be shared among entities)
  • But more often signals are just locally defined
    for a given architecture
  • A signal assignment takes effect only after a
    certain delay (the smallest possible delay is
    called a delta time).

33
Variables
  • It is a used as a local storage mechanism,
    visible only inside a process
  • All assignment to variables are scheduled
    immediately

34
Signals vs. Variables
  • Signals assignments are scheduled after a certain
    delay d
  • Variables assignments happen immediately, there
    is no delay

35
Delta Time
  • architecture rtl of logic is
  • signal a_or_b std_logic
  • begin
  • a_or_b lt a or b -- a_or_b is scheduled _at_
    tD
  • z lt a_or_b and c -- z is scheduled _at_ t2D
  • end rtl

36
Bad example !!!
  • architecture bad of logic is
  • signal a_or_b std_logic
  • begin
  • logic_p process(a,b,c)
  • begin
  • a_or_b lt a or b
  • z lt a_or_b and c
  • end process
  • end bad

37
How to fix the bad example
  • architecture good of logic is
  • variable a_or_b std_logic
  • begin
  • logic_p process(a,b,c)
  • begin
  • a_or_b a or b
  • z lt a_or_b and c
  • end process
  • end good

38
Packages
  • Packages offers a mechanism to globally define
    and share values, types, components, functions
    and procedures that are commonly used.
  • package declaration and package body

39
Subprograms
  • Procedures can return more than one value (they
    can have both input and output parameters)
  • Functions return always just one value (can have
    only input parameters)Example conversion
    functions, resolution functions,

40
Attributes
  • Info attached to VHDL objects
  • Some predefined attributesleft ? the
    leftmost value of a typerighthigh ? the
    greatest value of a typelowlength ? the
    number of elements in an arrayevent ? a
    change on a signal or variablerange ? the
    range of the elements of an array object

41
Generic
  • parameter that pass information to an
    entityentity adder isgeneric (width integer
    5)port ( in_a std_logic_vector(width-1
    downto 0) in_b std_logic_vector(width-1
    downto 0) z std_logic_vector(width-1
    downto 0) carry std_logic))end entity
    adder

42
Component (socket mechanism)
  • Declare the name and interface of a sub-unit,
    to be used in the current level of design
    hierarchy.component addergeneric (width
    integer 5)port ( in_a, in_b in
    std_logic_vector z std_logic_vector carry
    std_logic)end component

adder
adder instance 1
adder instance 2
43
Example a 7 bit adder (with bugs ?)
  • adder-rtl.vhd
  • big-adder-struct.vhd

a(30)
4 bits
b(30)
z(60)
a(64)
3 bits
b(64)
c
44
adder-rtl.vhd
  • --
  • -- author Claudio Talarico
  • -- file adder-rtl.vhd
  • -- comment example of how to use generics and
    components
  • --
  • library ieee
  • use ieee.std_logic_1164.all
  • use ieee.std_logic_arith.all
  • entity adder is
  • generic (width integer 2)
  • port ( a in std_logic_vector(width-1 downto
    0)
  • b in std_logic_vector(width-1 downto
    0)
  • c out std_logic --carry
  • z out std_logic_vector(width-1 downto 0)
  • )
  • end adder

45
big-adder-struct.vhd
  • --
  • -- author Claudio Talarico
  • -- file big-adder-struct.vhd
  • -- comment example of how to use generics and
    components
  • --
  • library ieee
  • use ieee.std_logic_1164.all
  • use ieee.std_logic_arith.all
  • entity big_adder is
  • port ( a in std_logic_vector(6 downto 0)
  • b in std_logic_vector(6 downto 0)
  • c out std_logic --carryout
  • z out std_logic_vector(6 downto 0)
  • )
  • end big_adder
  • architecture struct of big_adder is

46
big-adder-struct.vhd
  • -- CONTINUE FROM PREVIOUS PAGE
  • begin
  • inst_add_l adder -- low adder
  • generic map (width gt 4) -- if there is
    more than one generic the separator is ,
  • port map ( a gt a_in(3 downto 0),
  • b gt b_in(3 downto 0),
  • z gt z_out(3 downto 0),
  • c gt c_l
  • )
  • inst_add_h adder -- high adder
  • generic map (width gt 3) -- if there is
    more than one generic the separator is ,
  • port map ( a gt a_in(6 downto 4),
  • b gt b_in(6 downto 4),
  • z gt z_out(4 downto 4),
  • c gt c_h
  • )

47
ASSERT statement
  • The ASSERT checks a boolean expression and if the
    value is true does nothing, else will output a
    text string to std output.It can have different
    severity levelsNOTE, WARNING, ERROR,
    FAILUREASSERT falseREPORT End of
    TestBenchSEVERITY ERROR

48
COMPLEX TYPES
  • enumerated typesTYPE color is (red, blue,
    yellow, green)
  • ARRAYTYPE dbus is ARRAY (31 downto 0) of
    std_logic

49
COMPLEX TYPES
  • RECORDTYPE instruction isRECORD opcode
    integer src integer dest integerEND
    RECORD

50
COMPLEX TYPES
  • FILETYPE ram_data_file_t IS FILE OF
    INTEGERFILE ram_data_file ram_data_file_t IS
    IN /claudio/vhdl/tb/ram.txt

51
More on FILEs
  • use std.textio.all
  • READ, WRITE, READLINE, WRITELINE, ENDFILE,

52
Advanced Topics
  • VHDL supports overloading
Write a Comment
User Comments (0)
About PowerShow.com
