Lesson 4.14
EXAM REVIW
G
B
4
CLASS TOPICS
1. Definitions2. Stability Reference Points3.
Stability Triangle4. Conditions of Stability5.
Stability Curve6. Ships Hull Markings 7. Draft
Diagram and Cross Curves
5
STABILITY - THE TENDENCY OF A SHIP TO ROTATE ONE
WAY OR THE OTHER (TO RIGHT ITSELF OR OVERTURN)
INITIAL STABILITY - THE STABILITY OF A SHIP IN
THE RANGE FROM 0 TO 7/10
OVERALL STABILITY - A GENERAL MEASURE OF A SHIP'S
ABILITY TO RESIST CAPSIZING IN A GIVEN CONDITION
OF LOADING
DYNAMIC STABILITY - THE WORK DONE IN HEELING A
SHIP TO A GIVEN ANGLE OF HEEL
6
SIX MOTIONS OF A SHIP
ROLL SIDE TO SIDE OR PORT TO STBD. (Rotate
about Longitudinal Axis)
PITCH UP DOWN OR BOW STERN. (Rotate about
Transverse Axis)
YAW TWISTING (Rotate about Vertical Axis)
SWAY SLIDING LATERALLY OR SIDE TO SIDE
HEAVE UP DOWN AS IN LIFTED BY WAVES.
SURGE SLIDING LONGITUDINALLY OR FRONT BACK
7
LAWS OF BUOYANCY
A FLOATING OBJECT HAS THE PROPERTY OF BUOYANCY
A FLOATING BODY DISPLACES A VOLUME OF WATER
EQUAL IN WEIGHT TO THE WEIGHT OF THE BODY.
A BODY IMMERSED (OR FLOATING) IN WATER WILL BE
BUOYED UP BY A FORCE EQUAL TO THE WEIGHT OF THE
WATER DISPLACED.
8
DISPLACEMENT

• THE WEIGHT OF THE VOLUME OF WATERTHAT THE SHIP'S
  HULL IS DISPLACING
• UNITS OF WEIGHT LONG TON 2240 LBS SHORT
  TON 2000 LBS METRIC TON 2204.72 LBS

9
VOLUME - NUMBER OF CUBIC UNITS
IN AN OBJECT
UNITS CUBIC FEET CUBIC INCHES
V L x B x D
V 30 FT x 20 FT x 6 FTV 3600 FT3
10
SPECIFIC VOLUME - VOLUME PER UNIT
WEIGHT
UNITS CUBIC FEET PER TON
SW 35 FT3/TONFW 36 FT3/TONDFM 43 FT3/TON
WT VOLUME SP. VOL
WT 3600 FT3 35 FT3/TON
WT 102.86 TONS
11
CLASS TOPICS
1. Definitions2. Stability Reference Points3.
Stability Triangle4. Conditions of Stability5.
Stability Curve6. Ships Hull Markings 7. Draft
Diagram and Cross Curves 8. Model
12
STABILITY REFERENCE POINTS
M
etacenter
G
ravity
B
uoyancy
K
eel
CL
13
CENTER OF GRAVITY

• POINT AT WHICH ALL WEIGHTS COULD BE CONCENTRATED.
• CENTER OF GRAVITY OF A SYSTEM OF WEIGHTS IS FOUND
  BY TAKING MOMENTS ABOUT AN ASSUMED CENTER OF
  GRAVITY, MOMENTS ARE SUMMED AND DIVIDED BY THE
  TOTAL WEIGHT OF THE SYSTEM.

14
MOVEMENTS IN THE CENTER OF GRAVITY

• G MOVES TOWARDS A WEIGHT ADDITION

15
MOVEMENTS IN THE CENTER OF GRAVITY

• G MOVES TOWARDS A WEIGHT ADDITION
• G MOVES AWAY FROM A WEIGHT REMOVAL

16
MOVEMENTS IN THE CENTER OF GRAVITY

• G MOVES TOWARDS A WEIGHT ADDITION
• G MOVES AWAY FROM A WEIGHT REMOVAL
• G MOVES IN THE DIRECTION OF A WEIGHT SHIFT

17
METACENTER
THEMETACENTER
M
B
B2
B1
M20
M45
M
M70
B70
CL
18
METACENTER
M
19
MOVEMENTS OF THE METACENTER

• THE METACENTER WILL CHANGE POSITIONS IN THE
  VERTICAL PLANE WHEN THE SHIP'S DISPLACEMENT
  CHANGES
• THE METACENTER MOVES IAW THESE TWO RULES
• 1. WHEN B MOVES UP M MOVES DOWN.2. WHEN B MOVES
  DOWN M MOVES UP.

20
(No Transcript)
21
LINEAR MEASUREMENTS IN STABILITY
M
GM
BM
G
KM
B
KG
K
CL
22
CLASS TOPICS
1. Definitions2. Stability Reference Points3.
Stability Triangle4. Conditions of Stability5.
Stability Curve6. Ships Hull Markings 7. Draft
Diagram and Cross Curves 8. Model
23
M
CL
THE STABILITY TRIANGLE
G
Z
24
Sin q opp / hyp

• Where opposite GZ
• hypotenuse GM
• Sin q GZ / GM
• GZ GM x Sin q
• Growth of GZ a GM

25
CL
26
AS GM DECREASES RIGHTING ARM ALSO DECREASES
27
M
INITIALSTABILITY
G
B
0 - 7
CL
28
M
OVERALLSTABILITY
Z
G
B
B1
RM GZ x Wf
CL
29
CLASS TOPICS
1. Definitions2. Stability Reference Points3.
Stability Triangle4. Conditions of Stability5.
Stability Curve6. Ships Hull Markings 7. Draft
Diagram and Cross Curves 8. Model
30
M
THE THREE CONDITIONS OF STABILITY
G
Z
B1
POSITIVE
G
M
B
B1
G
NEUTRAL
M
B
B1
NEGATIVE
31
POSITIVE STABILITY
CL
32
NEUTRAL STABILITY
CL
33
NEGATIVE STABILITY
CL
34
CLASS TOPICS
1. Definitions2. Stability Reference Points3.
Stability Triangle4. Conditions of Stability5.
Stability Curve6. Ships Hull Markings 7. Draft
Diagram and Cross Curves 8. Model
35
RIGHTING ARM CURVE
RIGHTING ARMS (FT)
90
60
30
0
10
20
40
50
70
80
ANGLE OF HEEL (DEGREES)
GZ 1.4 FT
GZ 2.0 FT
GZ 1 FT
36
RIGHTING ARMS (FT)
90
60
30
0
10
20
40
50
70
80
ANGLE OF HEEL (DEGREES)
WL
WL
WL
60
40
20
G
Z
G
Z
G
Z
B
B
B
GZ 1.4 FT
GZ 2.0 FT
GZ 1 FT
37
CLASS TOPICS
1. Definitions2. Stability Reference Points3.
Stability Triangle4. Conditions of Stability5.
Stability Curve6. Ships Hull Markings 7. Draft
Diagram and Cross Curves 8. Model
38
Vertical Weight Shifts
GG1 KG1 - KGo
39
KG1 (Wo x KGo) (w x kg)
Wf
WHEREw Weight Shifted
kg Distance Shifted
Wo Original Displacement
KGo Original Height of G
Wf Final Displacement
if shift up/- if shift down
40
KG1 19.8 FT
Sin 0 0Sin 30 0.5Sin 90 1.0
GT0 .8FT x 0 0 FT
GT30 .8FT x .5 .4 FT
GT90 .8FT x 1 .8 FT
X
41
Horizontal Weight Shifts
42
WHEREw Weight Added or Removed
d Distance Added/Removed from Centerline
Wf Final Displacement
43
KG1 19.0 FT
GG2 .9 FT
Cos 0 1.0Cos 60 0.5Cos 90 0
GP0 .9FT x 1 0.9 FT
GP60 .9FT x .5 .45 FT
GP90 .9FT x 0 0 FT
X
44
(No Transcript)
45
FREE SURFACE EFFECT
Greater with increased length and width of the
compartment Increases as draft decreases
(de-ballasting) Independent of the depth of
the liquid Can be reduced by pocketing
46
(No Transcript)
47
FREE COMMUNICATIONEFFECT

• COMPARTMENT OPEN TO THE SEA
• COMPARTMENT PARTIALLY FLOODED
• COMPARTMENT OFF-CENTERLINEOR ASYMMETRICAL ABOUT
  THECENTERLINE

48
LCF - The Longitudinal Center of
Flotation
49
DRAG -
A design feature having the draft aft greater
than the draft fwd. Primarily done to increase
plant effectiveness.
DRAG
2 FT By the Stern
50
TRIM -
The difference between the forward and after
drafts in excess of drag.
DRAG 0
TRIM
2 FT By the Stern
51
Trimming Moment w x TA
w
52
Trimming Moment w x TA
CT
53
(No Transcript)
54
PARALLEL SINKAGE
Parallel Sinkage (PS) is the distance that the
drafts fore and aft increase due to a weight
addition.
Parallel Rise (PR) is the distance that the
drafts fore and aft decrease due to a weight
removal.
-
PARALLEL RISE
55
ABILITY TO REFLOAT

• IF THE PROPS ARE REVERSED AND THERE ISNO
  TENDENCY OF THE SHIP TO BACK AWAYFROM THE BEACH,
  NO FURTHER ATTEMPTS TOMOVE THE SHIP BY MEANS OF
  THE PROPELLERSSHOULD BE USED.
• NSTM 079 VOL 1 REPAIR
  PARTY MANUAL NTTP 3-20.31

56
BRIDGE ACTIONS

• RIG GROUND TACKLE KEDGE ANCHORS (IFPOSSIBLE)
• COORDINATE LIGHTENING SHIP WITH HIGH TIDE
• TAKE A STRAIN ON GROUND TACKLE
• REQUEST SALVAGE ASSISTANCE

57
DCA ACTIONS
WEIGH THE SHIP DOWN HARD
58
AGROUND DCA ACTION
WEIGH THE SHIP DOWN HARD
INVESTIGATE FOR DAMAGE

• SOUND ALL TANKS VOIDS
• CHECK FUEL TANKS FOR LEAKAGE
• STRUCTURAL DAMAGE?
• EXTENSIVE SOUNDINGS (LOWER SMALL BOATS)
• ABOUT THE SHIP
• SEAWARD

59
AGROUND DCA ACTION
DETERMINE AMOUNT OF TONS AGROUND

• FM KNOWN DRAFTS, DETERMINE ORIGINAL
  DISPLACEMENT
• READ DRAFTS AFTER AGROUND
• DETERMINE NEW DISPLACEMENT
• DIFFERENCE EQUALS TONS AGROUND

CALCULATE CRITICAL DRAFT

• IF STABILITY IS CRITICAL, LOWER G
  ESTIMATE TIME
• ELIMINATE HIGH WEIGHT
• FLOOD LOW COMPARTMENTS

60
M
G
B
K
61
Remember G moves faster than M!!
M
G
B
K
62
M
G
B
K
63
HULL GIRDER STRESS
INDICATORS
-SHIP IS HOGGING OR SAGGING-STRESS FRACTURES,
CRACKS, "CRINKLING", OR PANTING OF BULKHEADS,
DECKS AND STIFFENERS
ACTIONS
-RELIEVE HOGGING OR SAGGING-SHORE UP
BULKHEADS/DECKS. -REINFORCE WHERE POSSIBLE.
64
Sagging Stresses
C
T
Quiz What would be the corrective actions??
65
Hogging Stresses
66
Docking

• Transfer of Responsibility
• Pumping of Drydock
• Upon Touching Blocks Hull Inspection
• Dock Pumped Dry
• Hull Board Inspection
• Ship Properly Docked and Shores in Place
• NOTE Condition of Screws, Rudders, Sea Suctions
  Discharges, Cathodic Protection, ANY DAMAGE

67
Undocking

• Ensure all Sea Valves Have Been Properly
  Reinstalled
• Man All Spaces with Sea Valves
• Augment Sounding and Security Watches
• Docking Officer Provide Ship with Undocking Report

68
"IF PERSONNEL WAIT UNTIL CATASTROPHE IS ACTUALLY
IMPENDING BEFORE STARTING TO LEARN THEIR SHIP BY
MEANS OF THE FOREGOING PREPARATORY MEASURES, THE
SHIP AND ITS COMPANY MAY BE LOST."
NSTM 079 VOL I
69
"IF PERSONNEL WAIT UNTIL CATASTROPHE IS ACTUALLY
IMPENDING BEFORE STARTING TO LEARN THEIR SHIP BY
MEANS OF THE FOREGOING PREPARATORY MEASURES, THE
SHIP AND ITS COMPANY MAY BE LOST."
NSTM 079 VOL I
70
"IF PERSONNEL WAIT UNTIL CATASTROPHE IS ACTUALLY
IMPENDING BEFORE STARTING TO LEARN THEIR SHIP BY
MEANS OF THE FOREGOING PREPARATORY MEASURES, THE
SHIP AND ITS COMPANY MAY BE LOST."
NSTM 079 VOL I
71
SHIP SINKINGS
WATER LEVEL
G
BODILY SINKAGE
LOSS OF BUOYANCY
B
CAPSIZING
LOSS OF TRANSVERSE STABILITY
PLUNGING
LOSS OF LONGITUDINAL STABILITY
BREAKING UP
LOSS OF SHIP'S GIRDER
72
METACENTRIC HEIGHT

• RIGHTING ARM (GZ) IS PROPORTIONAL TO
  METACENTRICHEIGHT (GM)
• A SHIP WITH
• LARGE GM IS STIFF AND RESISTS ROLLS
• SMALL GM IS TENDER AND ROLLS EASILY AND
  SLOWLY
• VERY SMALL GM IS APT TO HANG AT THE END OF
  EACH ROLL BEFORE STARTING UPRIGHT
• SLIGHTLY NEGATIVE GM IS APT TO LOLL
  (STAYING HEELED AT ANGLE OF INCLINATION
  WHERE RIGHTING AND UPSETTING FORCES ARE
  EQUAL) AND FLOP FROM SIDE TO SIDE
• NEGATIVE GM WILL CAPSIZE WHEN INCLINED

73
3 BASIC CONDITIONS WHICH MAY CAUSE THESHIP TO
TAKE ON A PERMANENT LIST

• G MOVED OFF CENTERLINE (99)
• -GM (1)
• COMBINATION OF -GM AND G OFF CL

74
CAUSES of -GM
1. Removal of low weights 2. Addition of high
weights (ice)3. Moving weights upward4. Free
Surface Effect5. Free Communication Effect
75
FLOODABLE LENGTH
A LIST OF FLOODABLE COMPARTMENT GROUPS IS OFTEN
FOUND. FOR EXAMPLE, FOR A FFG-7
STEM - FRAME 100FRAMES - 32-140FRAMES -
64-180FRAMES - 100-212FRAMES - 140-250FRAMES -
180-292FRAMES - 212-328FRAMES - 250-368FRAMES
- 292-STERN
GENERAL RULE SHIP'S LBP gt 300 FT ä 15 LBP lt
300 FT ä 2 SPACESlt100 FT ä 1 SPACE
76
FLOODABLE LENGTH DAMAGE
77
HEELING EFFECTS OF BEAM WINDS
FULL LOAD
RIGHTING ARMS (FT)
100 KT
ANGLE OF HEEL (DEG)
78
HEELING EFFECTS OF BEAM WINDS
FULL LOAD
RIGHTING ARMS (FT)
100 KT
DAMAGED
ANGLE OF HEEL (DEG)
79
(No Transcript)
80
Limitations to Ships Design Criteria

• In order to maintain a satisfactory condition
  with regard to stability and reserve buoyancy,
  the following guidelines must be adhered to
• Limiting Draft Marks not Submerged Prior to
  Damage
• No Abnormal Topside Weights
• Liquid Loading Instructions are Followed
• Watertight Integrity is Maintained

81
IMMEDIATE STEPS
STEP ONE -
ESTABLISH FLOODING BOUNDARIES
STEP TWO -
DEWATER ANY SPACE COLORED PINK ON THE FLOODING
EFFECTS DIAGRAM.
82
IMMEDIATE STEPS
STEP THREE -
SIZE UP THE SITUATION TO DETERMINE WHETHER
STABILITY IS CRITICAL BEFORE ANY FURTHER ACTION
IS TAKEN.
83
CRITICAL STABILITY
1. The ship has a negative GM
2. The ship is listing to the danger angle (1/2
angle of max GZ)
3. The extent of flooding exceeds floodable
length.
4. High winds or rough seas combined with flooding
84
IMMEDIATE STEPS
STEP FOUR -
ELIMINATE OR REDUCE LIST
85
Dont forget about
EXCESSIVE TRIM (gt 1 LBP)
ACTIONS
SHIFT CENTER OF GRAVITY TOWARDS "HIGH" END.
86
894
9
5-292-2-W
5-276-0-F
6
8
9
5-308-1-W
5-292-3-W
83
84
(GREEN) - FLOODING OF GREEN SPACES WILL IMPROVE
STABILITY, EVEN THOUGH FREE SURFACE EXISTS.
CAPACITY-TONS SW
(YELLOW) - FLOODING OF YELLOW SPACES WILL IMPROVE
STABILITY IF NO FREE SURFACE EXISTS. IF SPACE IS
NOT 100 FULL STABILITY WILL BE IMPAIRED.
COMPARTMENT NUMBER
(PINK) - FLOODING OF PINK SPACES WILL DECREASE
STABILITY BECAUSE OF ADDED HIGH WEIGHT, FREE
SURFACE EFFECT OR BOTH.
INCLINING MOMENTS FT-T
(WHITE) - FLOODING OF WHITE SPACES HAS NO
APPPRECIABLE EFFECT ON STABILITY.
87
0.5
9
0.4
8
5-292-2-W
5-308-2-W
0
1
1
0
0.5
8
0.4
9
5-308-1-W
5-292-3-W
1
0
1
0
CLEAN BALLAST
CAPACITY-TONS
LIST
POTABLE WATER
COMPARTMENT NUMBER
JP-5
CHANGE IN DRAFTFWD - INCHES
CHANGE IN DRAFTAFT - INCHES
88
WEIGHT AND MOMENT COMPENSATION PROGRAM
89
Intentionally Left Blank
90
LIMITATIONS

• Follow Liquid Loading Instructions
• No Abnormal Topside Weights
• Dont Submerge Limiting Draft Marks
• Maintain Watertight Integrity

91
LIMITATIONS

• Follow Liquid Loading Instructions
• No Abnormal Topside Weights
• Dont Submerge Limiting Draft Marks
• Maintain Watertight Integrity

92
LIMITATIONS

• Follow Liquid Loading Instructions
• No Abnormal Topside Weights
• Dont Submerge Limiting Draft Marks
• Maintain Watertight Integrity

93
DEFINITIONS
ROLL -
The action of a vessel involving a recurrent
motion (Longitudinal Axis).
HEEL -
Semi-permanent angle of inclination, caused by
external forces.
LIST -
Permanent angle of inclination caused by a shift
in the center of gravity so as to cause G off
CL, a -GM, or a combination of the two.
94
(No Transcript)
95
INCLINING EXPERIMENT

• Completed upon commissioning, and following
  each major overhaul or shipalt.
• It is done to verify the exact location of the
  ship's center of gravity (KG).
• Basis for updates to Section II(a) of the DC
  book and for changes to weight and moment
  compensation status

96
INACCURACIES
1. UNACCOUNTED FOR FSE
2. MOVEMENT OF PERSONNEL
3. INACCURATE WEIGHTS
4. TAUGHT LINES
5. POOR WEIGHT VERIFICATION WALK THROUGH
97
MOB-D-6-SF Righting Ship

• Conducted Every 18 Months (SEMI annual for
  CG)
• Purpose To train the damage control
  organization in correcting a list.
• Requirements Condition 1 and zebra set.
  Liquid loading may be varied to put an actual
  list or trim on the ship if desired.

98
REASONS FOR BALLASTING

• INCREASE WEIGHT LOW TO IMPROVE STABILITY
• ELIMINATE EXCESSIVE LIST / TRIM
• COUNTERFLOOD FOLLOWING DAMAGE TO OFF CENTER
  COMPARTMENT
• EXPLOSION ABSORPTION (CV CVN)
• WET WELL OPERATIONS (AMPHIBS)
• GROUNDING Weigh the ship down hard
• SUPPRESS FREE SURFACE EFFECT

99
DEFINITION

• BALLASTING is the process of filling low
  compartments from the sea to improve ship
  stability or control list / trim.
• BALLASTING systems may be independent (clean
  ballast) or they may incorporate sections of the
  fuel and drainage systems (dirty ballast).

100
LIQUID BALLAST SYSTEMS

• AUTOMATIC
• (FUEL OIL COMPENSATION)
• MANUAL SYSTEMS

101
MANUAL BALLAST SYSTEMS

• INDEPENDENT
• FUEL TANK SYSTEMS

102
ARGUMENTS AGAINST BALLASTING

• "It Will Destroy My Tanks"- MPA
• "I've Never Seen It Done Before. It Must Not Be
  Necessary." - CHENG
• "When We Pump Out The Ballast Tanks, It Will
  Pollute The Water." - CO

103
BALLASTING RESPONSIBILITIES OF DCA

• Maintain Awareness Of Ship's Liquid Loading
  Condition. (Full Load - Min Ops)
• Determine The Risks Associated With Violating LLI
  And Report To CHENG If Necessary.
• HOGGING AND SAGGING STRESSES.
• SUBMERGING LIMITING DRAFT MARKS.
• SURVIVABILITY OF BEAM WINDS AND SEAS.
• MAINTAIN ADEQUATE METACENTRIC HEIGHT.
• Ensure Most Current Fuel And Water Report Is
  Posted Daily At Each Repair Locker and DC Central.

104
50 Theory 50 Problems

• Study in groups
• Check your work
• Follow your units
• Check your work
• Draw a picture
• Check your work

105
Good Luck!

• Check your work
• Follow your units
• Draw a picture
