MICROSCOPE REVIEW

1
MICROSCOPE REVIEW

• PARTS

2
EYE PIECE(OCULAR LENS)
3
BODY TUBE
4
NOSE PIECE
5
OBJECTIVE LENSES
6
ARM
7
STAGE STOP
8
STAGE CLIPS
9
STAGE
10
LIGHT APERTURE
11
DIAPHRAGM

• ROTATABLE CIRCLE UNDERNEATH STAGE WITH PINHOLES
  OF VARYING SIZE.

12
COURSE ADJUSTMENT
13
FINE ADJUSTMENT
14
LIGHT SOURCE

• LAMP IS SHOWN. ON EARLY VERSIONS OF LIGHT
  MICROSCOPES MIRRORS WERE USED!

15
POWER SWITCH

• ON/OFF

16
BASE
17
PROPER USES

• MAGNIFY SPECIMEN
• STUDY MICROSCOPIC SPECIMEN
• ALIVE
• DEAD
• WET MOUNTED
• DEHYDRATED PRESERVED

18
MAGNIFICATIONS

• OCULAR LEN MAGNIFYS SPECIMEN 10X
• LOW POWER OBJECTIVE 10X
• MID POWER OBJECTIVE 25X
• HIGH POWER OBJECTIVE 40X

19
TOTAL MAGNIFICATION

• OCULAR LENS x OBJECTIVE
• 10 X LOW POWERED (10)
  100
• 10 X MID POWERED (25)
  250
• 10 X HIGH POWERED (40)
  400
