ADP, ATP and Cellular Respiration

1
ADP, ATP and Cellular Respiration
2
What Is ATP?
Energy used by all Cells
Adenosine Triphosphate
Organic molecule containing high-energy Phosphate
bonds
3
Chemical Structure of ATP
Adenine Base
3 Phosphates
Ribose Sugar
4
What Does ATP Do for You?

• It supplies YOU with ENERGY!

5
How Do We Get Energy From ATP?

• By breaking the high- energy bonds between the
  last two phosphates in ATP

6
What is the Process Called?

• HYDROLYSIS (Adding H2O)

H2O
7
How Does That Happen?
An Enzyme!
ATPase
8
How is ATP Re-Made?

• The reverse of the previous process occurs.

Another Enzyme is used ATP synthetase
9
The ADP-ATP Cycle
ATP
Energy released
Energy used
ADP
10
When is ATP Made in the Body?

• During a Process called Cellular Respiration that
  takes place in both Plants Animals

11
Cellular Respiration

• Process in which cells get energy from glucose.
• Requires oxygen
• Breakdown of one glucose results in 36 to 38 ATP
  molecules

12

• Analogy
• (between the process of cellular respiration in
  our cells and a car)
• The mitochondria are the engines of our cells
  where sugar is burned for fuel and the exhaust is
  CO2 and H2O.

13
Overall Equation for Cellular Respiration

C6H12O6 6O2
YIELDS
6CO2 6H20 36-38ATPs
14
What are the Stages of Cellular Respiration?

• Glycolysis
• The Krebs Cycle
• The Electron Transport Chain

15
Where Does Cellular Respiration Take Place?

• It takes place in two parts of the cell

Glycolysis occurs in the Cytoplasm
Krebs Cycle ETC Take place in the Mitochondria
16
Review of Mitochondria Structure

• Smooth outer Membrane
• Folded inner membrane
• Folds called Cristae
• Space inside cristae called the Matrix

17
Glycolysis Summary

• Takes place in the cytoplasm
• Process of splitting glucose (6 C) into two 3-C
  molecules of pyruvic acid.
• Needs 2 ATPs to start reaction
• Produces 4 ATPs Net gain of 2 ATPs
• Reactant Glucose
• Products
• 2 ATP energy
• 2 NADH electron carrier
• 2 Pyruvic acids will be broken down next
• Does not require O2 - anaerobic

18
Krebs Cycle Summary

• Requires Oxygen (Aerobic)
• Takes place in matrix of mitochondria

19
Krebs Cycle Summary

• For each Glucose molecule, the Krebs Cycle
  produces
• 6 NADH (electron carrier)
• 2 FADH2 (electron carrier)
• 4 CO2
• 2 ATP

20
Electron Transport Chain Summary

• 34 ATP Produced
• H2O Produced
• Occurs Across Inner Mitochondrial membrane

21
Fermentation

• Occurs when O2 NOT present (anaerobic)
• TWO TYPES
• Lactic Acid fermentation in muscle cells (makes
  muscles tired)
• Alcoholic fermentation in yeast (produces
  ethanol)
• Nets only 2 ATP

22
Alcohol Fermentation

• Products important in bread making and in beer
  and wine industries

23
Lactic acid fermentation

• Takes place in some fungi, some bacteria
  (Lactobacillus acidophilus), and occasionally in
  our muscles
• Makes energy (2 ATP) and lactic acid
• Lactic acid in yogurt gives the tart taste.
• Lactic acid in muscles causes soreness.
