Introduction to Verilog

1
Introduction to Verilog

2
Learning Objectives

• Get familiar with background of HDLs
• Basic concepts of Verilog languages
• Gate level primitives
• Module
• Ports
• Structural and behavioral descriptions
• Continuous assignment and procedural statements
• Verilog syntax

3
Hardware Description Languages

• A hardware description language is a computer
  language that is used to describe hardware.
• Two HDLs are widely used
• Verilog HDL
• VHDL (Very High Speed Integrated Circuit Hardware
  Description Language)
• Schematic design entry can be replaced by writing
  HDL code that CAD tools understand.
• CAD tools can verify the HDL codes, and create
  the circuits automatically from HDL codes.

4
Facts about Verilog

• We use Verilog, not VHDL, in ELEE 4303.
• Verilog is more popular in industry than VHDL
• They offer similar features
• History of Verilog
• In 1980s, originally developed by Gateway Design
  Automation.
• In 1990, was put in public domain.
• In 1995, adopted as an IEEE standard 1364-1995
• In 2001, an enhanced version, Verilog 2001

5
Use of Verilog

• Functions of Verilog
• Design entry, like schematic
• Simulation and verification of your design
• Synthesis
• Verilog is a complex, sophisticated language
• We focus on a subset of its features that is
  synthesizable.
• For complete Verilog, refer to reference books.
• Verilog will be taught in several stages through
  this course when the language elements are
  relevant to the design topics.
• Appendix A provides a concise summary of Verilog.

6
Representation of Digital Circuits in Verilog

• Design entry in several different ways
• Truth tables
• Schematic captures
• Hardware description languages (efficient !)
• Two types of representations in Verilog
• Structural
• Behavioral

7
Structural Representation (1)

• Gate level primitives
• Correspond to commonly used logic gates
• Built in CAD tools, so they can be used by user
  directly.
• All available gate primitives are listed in Table
  A.2
• examples
• AND gate ? and (y, x1, x2)
• OR gate ? or (y, x1, x2, x3, x4)
• NOT gate ? not (y, x)
• Keywords and, or, not are reserved

8
Structural Representation (2)

• Module
• A logic circuit ? module
• Its ports inputs and outputs
• Begins with module, ends with endmodule
• example

9
Structural representation (3)

• One more example

10
Behavioral Representation (1)

• Why behavioral representation?
• Using primitives can be tedious when circuits are
  large
• It is desired to describe the circuit in more
  abstract level behavior
• Two fundamental types of behavior model
• Logic expression
• Procedural statements
• CAD synthesis tools use this representation to
  construct the actual circuit

11
Behavioral Representation (2)

• Logic expression
• continuous assignment

12
Behavioral representation (3)

• Procedural statements
• always block
• Sensitivity list statements evaluated only when
  one or more signals in list changes value.
• Statements evaluated in order
• One or more statements in one always block
• One or more always blocks in a module
• Declare a signal as a variable reg if the signal
  is assigned a value by procedural statements

13
Lexical Conventions

• White space characters are ignored
• SPACE, TAB, new line, blank lines
• Two forms to introduce comments
• single line begin with //
• multiple lines /..long comments /
• Verilog is case sensitive
• Lower case letters are unique from upper case
  letter
• All Verilog keywords are lower case
• Identifiers
• begin with an alphabetic character or the
  underscore character
• may contain alphabetic characters, numeric
  characters, _, and
• up to 1024 characters long.
• The instance of a module must be named while the
  instance name of a primitive is optional.
• include .v

14
Examples of lexical conventions
Comments
Lower case key words
identifiers
15
Quiz

• Write Verilog code to implement the following
  circuit using the gate level primitives.

Figure 2.25 b
