1
Lead Optimization - From Leads to Developmental
Candidates -
2
Why do drugs fail in clinical development?
(Taken from Kennedy, Drug Discovery Today, 2
(10), 1997, 436-444)
3
Water Solubility as a parameter for lead
optimization
Is there a relationship between bioavailability
and water solubility?
Yes, there is. It's called MAD!
4
Water Solubility as a parameter for lead
optimization
The concept of the maximum absorbable dose
(MAD) MAD S x Ka x SIWV x SITT S water
solubility at pH 6.5 (mg/ml) Ka transintestinal
absorption rate constant (1/min) SIWV small
intestinal water volume ( 250 ml) SITT small
intestinal transit time ( 270 min)
Typical dose for a drug is 1 mg/kg ? for a 70 kg
patient, 70 mg drug substance must be
available in the blood
Ranges typical for drug candidates Ka 0.001 -
0.05 min-1 (50-fold) S 0.0001 - 100 mg/ml
(106-fold)
5
Water Solubility as a parameter for lead
optimization
The concept of the maximum absorbable dose (MAD)
6
Water Solubility as a parameter for lead
optimization
How soluble does a drug candidate have to be???
S MAD / (Ka x SIWV x SITT)
7
Water Solubility as a parameter for lead
optimization
Azithromycin
Very poor absorption (Ka 0.001 min-1) Very high
water solubility (S 50 mg/ml) ?MAD 3375 mg ?
Good oral bioavailability!
8

• Goals and Concepts in Lead Optimization

• Increasing in-vitro potency/efficacy by
• bioisosteric replacement of functional groups
• gradual modification of 3D shape and/or
  physicochemical properties
• Improving PC/ADME/Tox behaviour by
• replacement of toxophores
• modification of physicochemical properties (e.g.
  lipophilicity, charge, flexibility etc.)
• replacement of metabolically labile groups
• pro-drug concept

9
Lead Optimization
What can be modified?
10
Lead Optimization
?Modifications of aromatic substituents
11
Lead Optimization
? Modifications of amide group
12
Lead Optimization
? Modifications of cyclohexyl group
13
Lead Optimization
? Modifications of carboxyl group
14
Lead Optimization
? Modifications of chain length
15
Lead Optimization
? Modifications of aromatic substituents
16
The Topliss Tree A systematic lead optimization
approach
17
Lead Optimization - Example I

• hormone of the thyroidal gland
• agonist of thyroxine receptor

• bioisosterical replacements of iodo groups
• potent agonist of thyroxine receptor

18
Lead Optimization - Example II

• hydrophilic neurotransmitters
• orally inactive
• no penetration of blood-brain barrier

• lipophilic adrenaline mimics
• orally active
• good penetration of blood-brain barrier
• centrally stimulating effect

19
Lead Optimization - Example III

• analgesic drug
• activity due to COX inhibition

• no analgesic effect
• bioisosteric replacement of ester by amide
  failed!

20
Acetyl salicylic acid Mechanism of Action

• acetyl group is transferred to serine in
  active site of COX
• gt labile ester group is required!

21
Lead Optimization - Example IVFrom Peptides to
Peptidomimetics
22
Lead Optimization - Example IVFrom Peptides to
Peptidomimetics
23

• The Prodrug concept

• Prodrugs are weak or inactive precursers of drugs
• Active drug is only generated after
  biotransformation of prodrug
• by metabolic transformation
• by spontaneous chemical degradation
• Goal improved ADME/Tox- or physicochemical
  properties

24
The Prodrug concept - Example I

• central analgesic
• orally inactive
• slow penetration of blood-brain barrier

• orally inactive
• rapid penetration of blood-brain barrier
• degradation to morphine in brain
• accumulation of morphine in brain

25
The Prodrug concept - Example II

• anti-hypertensive drug
• orally inactive

• orally active due to amino acid carrier
• degradation to Enalaprilat by esterases

26
The Prodrug concept - Example III

• Morbus Parkinson drug
• orally inactive
• slow penetration of blood-brain barrier

• orally active
• rapid penetration of blood-brain barrier due
  to amino acid carrier!

Auxillary drugs
27
The Prodrug concept - Example IV

• anti-convulsive neurotransmitter
• orally inactive
• no penetration of blood-brain barrier

• orally active
• rapid penetration of blood-brain barrier

28
Drug Discovery What's next?
29
Differences between leads and drugs

• Drugs compared to leads
• are heavier
• are more lipophilic
• have more ring systems, rotatable bonds,
  H-acceptors

30
The Graffinity Approach
Technology

• Small molecules are immobilized on gold surface
• Protein-Ligand Affinity is measured via
  Surface-Plasmon Resonance

31
The Graffinity ApproachScreening Scenarios
drug like
lead like
Library Size
1,000,000 100,000 10,000 1,000 100 10
100 200 300
400 500 600
Molweight
32
The Graffinity Approach Library Synthesis
Technology

• Diversity in Microtiterplates

• LC/MS Quality control

• Daughter Microarrays

33
The Graffinity Approach Library Synthesis
Technology
34
The Graffinity Approach Detection
Technology

• Minimal Amounts of Protein
• Protein-Ligand Affinity Maps
• Surface-Plasmon Resonance
• No Assay Development
• Function-Blind

35
Principle of Surface Plasmon Resonance - a
means to detect Protein-Ligand binding
36
The Graffinity Approach Detection
Technology

• Immediate Rank-Order of Affinities

37
The Graffinity Approach SAR Analysis
Technology
