Inventaires QA/QC

1
UNFCCC Workshop on National Systems Bonn,
April 2005
Current situation in France concerning the
National Emission Inventory System
Jean-Pierre Fontelle
Centre Interprofessionnel Technique dEtudes de
la Pollution Atmosphérique 7, cité Paradis
75010 PARIS www.citepa.org
2
Plan

• Organisation
• Planning
• QA/QC plan
• Inventory development
• Improvements
• Response to ERT comments

UNFCCC Workshop on National Systems Bonn, April
2005
3
National emission inventory system SNIEPA
(Système National dInventaire des Emissions de
Polluants dans lAtmosphère)
The single national inventory system covers all
national air emission inventories (ie for UN and
EC purposes) and other national needs The
Ministry of Ecology and Sustainable Development
(MEDD) is the national authority responsible for
managing this issue CITEPA is responsible for
inventory compilation for all source categories,
technical discussion with international
organisations, assists the MEDD in coordinating
activities, provides facilities for dissemination
(Internet) More details on National emission
inventory system and methodologies http//www.cite
pa.org/publications/Inventaires.htminv6
Various ministries and organisations (technical
and research centres, statistics institutes,
professional organisations, etc.) are also
involved as data providers Institutional
arrangements are still under discussion to fulfil
EC and UNFCCC decisions
UNFCCC Workshop on National Systems Bonn, April
2005
4
Overview of different steps in national system
UN and EC specifications
Statistics and other sources of information
CITEPA
Terms of reference
Multiple organis.
Archiving
National authority
Choice of methodologies
Publication www.citepa.org
Data identification
Transmission to UN and EC
International review
Data collection
Transmission to national authorities
Archiving
UNFCCC Workshop on National Systems Bonn, April
2005
Data treatment, main results
Approval by authorities
Action plan implementation
Final reports and products
Approval by Committee
5
Overview of inventory planning
UNFCCC Workshop on National Systems Bonn, April
2005
6
Overview of main features of QA/QC plan

• Inventory compilation based on processus and
  procedures driven by a quality management system
  (QMS)
• QA/QC is operational and implemented through a
  QMS (CITEPA is certified ISO 9001 version 2000
  for emission inventories)
• The QA/QC plan focuses on improvements on an
  ongoing basis, especially by reducing
  uncertainties, by covering more substances, both
  in a convenient and efficient way
• QA/QC plan developped according to QMS rules (ISO
  9001) and includes sections on
• quality objectives,
• quality control,
• quality assurance,
• overview of process, procedures and recording
  related to GPG
• Documentation, archiving stringent requirements
  in QMS to trace all information (including
  origin, primary data, assumptions, etc.) and all
  intermediate and final results

UNFCCC Workshop on National Systems Bonn, April
2005
7
Implementation of GPG requirements within the
Management Quality System - extract
UNFCCC Workshop on National Systems Bonn, April
2005
8
Quality control
QC procedures are applied to all input data
including those provided by statistics
institutes or administrations Priority is
focussed on non validated data vs official data
Checks on input data enables a high level of
reliability more than an accurate assessment of
absolute values Common QC procedures compatible
with IPCC good practices are applied to the
different stages in the processes

• Example
• documentation, assumptions, primary calculations
  are compiled
• within methodology files
• the national inventory system includes
  approximatively 140 files
• which cover the SNAP activities (some files
  deal with several SNAP
• codes).
• Some data (activity rates, emission factors, etc.
  are common to
• several files. Mapping these files makes it
  possible to check
• interlinked consistency

UNFCCC Workshop on National Systems Bonn, April
2005
9
CALCULATION FILES CHECK
UNFCCC Workshop on National Systems Bonn, April
2005
10
INPUT / OUTPUT MAPPING BETWEEN METHODOLOGY FILES
LCP
GENERAL
ENERGY
INDUS. PROC.
WASTE
TRANSPORTS
AGRICULTURE
BIOGENIC
OTHER
SOLVENTS
UNFCCC Workshop on National Systems Bonn, April
2005
11
Quality control

• IPCC Tier 1 requirements implemented through QMS
  procedures
• QC checks conducted by CITEPA and upstream
  compilation by statistics offices,
  administrations, etc. and by some experts
  depending on data and priorities (key sources)
• Annual process cycle based on automatic and
  manual procedures
• Examples of main check types Main methods
• Plausibility, reference range
• Exhaustivity of data (activity rates, check
  list
• emission factors, documentation, etc.)
• Accuracy of calculation simulation
• Comparability of estimation methods analysis
  and reference
• with guidelines (UNFCCC, IPCC, EMEP/
• CORINAIR, EC, WBCSD, etc.)
• Trends in activity rates, emission analysis,
  statistical
• factors, emissions treatment
• Consistency cross-checking

UNFCCC Workshop on National Systems Bonn, April
2005
12
Quality assurance
Procedures in place CCIIE (Coordination and
Information Committee on Emission Inventories)
international review (UNFCCC) external experts
(for some activities) Other complete external
reviews are expected but not yet implemented
because of resources needed but not available

• An action plan is progressively drawn up over
  time from
• decisions taken at recent CCIIE meetings,
• events occurring during the current year,
• changes and improvements following remarks from
  reviews, errors,
• new information available
• and approved / delayed / rejected by the CCIIE
• Every year, final statement by early December
  (data sent before
• 31st December N1, reports available within
  January / March N2

UNFCCC Workshop on National Systems Bonn, April
2005
13
Inventory development
Goals satisfy terms of reference including
specifications such as UNFCCC guidelines and GPG,
EC recommandations QMS procedures are applied to
continuously improve the inventory (and the
system)

• CURRENT PERCENTAGE OF TIER LEVELS (ABSOLUTE LEVEL
  2003)
• 90 of 42 key sources are estimated from Tier 2
  or more
• methods
• 82 of key sources emission are estimated from
  Tier 2 or
• more methods

• CURRENT PERCENTAGE OF TIER LEVELS (TREND 1990
  2003)
• 90 of 54 key sources are estimated from Tier 2
  methods or
• more
• 93 of key sources contribution are estimated
  from Tier 2
• methods or more

UNFCCC Workshop on National Systems Bonn, April
2005
14
Inventory development - improvements 1 / 3

• Identification of improvement areas
• Topics previously delayed,
• Feedback from UNFCCC ERT and EU GHG MM checks,
• Feedback from inventory compilers (ie. checks),
• Feedback from inventory users,
• Feedback from non GHG inventories (verification
  and use) This input can be valuable by
  pointing out problems affecting as well relevant
  items for GHG inventories -gt strong interest
  for a single inventory system
• All feedbacks pointing out problems are
  registered within the QMS (CITEPA is certified
  ISO 9001 version 2000 for emission inventories)

UNFCCC Workshop on National Systems Bonn, April
2005
15
Inventory development - improvements 2 / 3

• Analysis of topics
• Type of issue estimation method, complementary
  information, editorial, other,
• Amount of emissions affected, impact on reference
  year, indirect impacts,
• Prioritization (see below)

• Prioritization IMPROVEMENT
• IF
• items identified by the ERT or other Authorities
  and / or,
• significant gap with GPG and guidelines and /
  or,
• existing alternative methodology significantly
  increasing accuracy,
• AND METHODOLOGY APPLICABLE (data availability,
  delay for implementation, acceptable cost)
• OR ELSE
• either the implementation is delayed or
• longer term actions (ie. Studies, new
  statistics, etc.) or rejected

UNFCCC Workshop on National Systems Bonn, April
2005
16
Inventory development - improvements 3 / 3

• 3. Proposal for modifications
• Impacts of proposed changes ( of emissions
  affected, impact on reference year),
• Technical consequences (eg. on structural changes
  in the SNIEPA changes relating to reporting
  format),
• Delay and possible implementing difficulties
• Related documentation

April, September December

• 4. Decision of CCIIE
• Full agreement,
• Agreement with additional considerations,
• Postponed actions,
• Rejection

UNFCCC Workshop on National Systems Bonn, April
2005

• 5. Implementation
• According to decision (content and delay)

17
Respond to ERT comments

• Differents steps
• Arrange availability of experts to respond during
  the review period,
• Provide explanations as quickly as possible (high
  priority),
• Treat ERT comments as feedback in the improvement
  process for the next inventory release,
• ERT review report is carefully analysed,
• Response is provided to UNFCCC through official
  authority,
• Communication to EC for EU inventory reporting

UNFCCC Workshop on National Systems Bonn, April
2005
