Sprinkler Buddy

1
Sprinkler Buddy
Low Cost Irrigation Management For Everyone !
Team M3 Panchalam Ramanujan Kalyan
Kommineni Kartik Murthy Sasidhar Uppuluri Design
Manager Bowei Gai

• Presentation 3
• New and Improved Floor Plan
• and Structural Verilog
• 2/14/2007

2
Current Status

• Determine Project ?
• Develop Project Specifications ?
• Plan Architectural Design ?
• Determination of all components in design ?
• Detailed logical flowchart ?
• Design a Floor Plan ?(refined)
• Create Structural Verilog ?
• (All Components done/simulated, tweaking control)
• Make Transistor Level Design and Schematic ?
• Layout ?
• Testing (Extraction, LVS, and Analog Sim.) ?

3
Slightly Revised Transistor
Count
Block ( used) Transistor Count
4020 Muxes (6) 480
6020 Muxes (2) 720
Counter (2) 250
KC ROM (1) 778
P ROM (1) 82
Metric Storage SRAMS (2) 2522
Constant Storage ROM (1) 202
Floating Point Adder (4) 3000
Floating Point Multiplier (2) 2800
10 Bit Registers (9) 140
Datapath Logic / Misc. 2000
Total 31,786
4
Block Size Estimates
Block ( used) Size Estimate (um)
4020 Muxes (4) 20 x 80
6020 Muxes (2) 20 x 120
Counter (2) 12 x 17
KC ROM (4 parts) 181 x 8
P ROM (1) 70 x 8
Metric Storage SRAMS (2) 181 x 60
Constant Storage ROM (1) 181 x 8
Floating Point Adder (4) 100 x 100
Floating Point Multiplier (2) 130 x 130
10 Bit Registers (8) 50 x 10
5
Old (Naïve) Floor Plan
Floor Plan
6
Somewhat Better Floor Plan
7
Current Floor Plan
8
Individual Modules Floating Point Add
Outputs
Will Use Metals 1-4
No Metal 3 below here
Inputs
9
Individual Modules Floating Point Multiply
Inputs
Inputs
Outputs
Outputs
Will Use Metals 1-4
10
Individual Modules Everything Else
Block Metal Layers That Can be Used
4020 Muxes M1 M2
6020 Muxes M1 M2
Counters M1 M2
KC ROM M1 M2 M3 M4
P ROM M1 M2 M3 M4
Metric Storage SRAMS M1 M2 M3 M4
Constant Storage ROM M1 M2 M3 M4
Floating Point Adders M1 M2 M3 M4
Floating Point Multipliers M1 M2 M3 M4
10 Bit Registers M1 M2
11
Metal Directionality

• M1, M2
• Local Connections
• Ground and VDD
• M3,M4
• Clock
• Inside FP Units
• Global Routing
• Control Signals

12
New Design Size
Block ( used) Size Estimate (um)
4020 Muxes (4) 20 x 80
6020 Muxes (2) 20 x 120
Counter (2) 12 x 17
KC ROM (4 parts) 181 x 8
P ROM (1) 70 x 8
Metric Storage SRAMS (2) 181 x 60
Constant Storage ROM (1) 181 x 8
Floating Point Adder (4) 100 x 100
Floating Point Multiplier (2) 130 x 130
10 Bit Registers (8) 50 x 10

• 454um x 450 um
• 1 1 aspect ratio
• .2 mm2 area
• .142 Transistor Density

13
Control Verilog
wire 90 hu_temp,hu_tmax,hu_tmin,hu_tempt
oadd //HU Control Signals wire
hu_tmax_en,hu_tmin_en,hu_mux_sel,hu_add_start,hu_t
emp_en //HU Output Signals wire
hu_add_done,hu_fsm_start,hu_add_sign wire
90 hu_add_out huFSM
_huFSM(hu_tmax_en,hu_tmin_en,hu_mux_sel,hu_add_sta
rt,hu_temp_en, hu_fsm_start,hu_add_si
gn,hu_add_done,clk,rst) not
_hun0(not_g_dclk,g_dclk) and
_huEn(hu_fsm_start,g_hclk,not_g_dclk)
reg_x (10,0) _temp(.q(hu_temp),.d(g_temp),.clk(cl
k),.reset(rst),.en(hu_temp_en)) reg_x
(10,10'b0011110001) _tmax(.q(hu_tmax),.d(hu_temp)
,.clk(clk),.reset(rst),.en(hu_tmax_en))
reg_x (10,10'b0011110001) _tmin(.q(hu_tmin),.d(hu
_temp),.clk(clk),.reset(rst),.en(hu_tmin_en))
mux21_10 _huMux(.out(hu_temptoadd),.sel(hu_mu
x_sel),.a(hu_tmax),.b(hu_tmin)) fpadder
_fpahr(.out(hu_add_out),.done(hu_add_done),.a(hu_t
emp),.b(hu_temptoadd),
.addSub(1'b1),.start(hu_add_start),.clk(clk),.rst(
rst)) assign hu_add_signhu_add_out9
14
Multiplier Verilog
wire signa,signb,cout1,cout2
//Assign pieces of Inputs assign signa
a9 assign signb b9 assign
expa a84 assign expb b84
assign siga a30 assign sigb
b30 //Calculate Exponent
addSub_6 ab(preExp,cout1,1'b0,expa,1'b0,expb,1
'b0) addSub_6 ba(postExp,cout2,preExp,6'b
001111,1'b1) //Calculate Significand
uMult_5 um(postSig,1'b1,siga,1'b1,sigb)
//Normalize fpmultnormalize
nm(postNormSig,postNormExp,postSig,postExp)
//Assign Final Output assign
out84postNormExp40 assign
out30postNormSig xor
msign(out9,signa,signb) endmodule
//modify if rounding later,combine adders
later module fpmultnormalize(sigPostNorm,expPost
Norm,sigPreNorm,expPreNorm) output
30 sigPostNorm output 50
expPostNorm input 90 sigPreNorm
input 50 expPreNorm wire cout
wire 50 addAmnt //Adjust
Significand mux21_4 mm(sigPostNorm,sigPreN
orm9,sigPreNorm74,sigPreNorm85)
//Adjust Exponent mux21_6
mm5(addAmnt,sigPreNorm9,6'b000000,6'b000001)
//reduce me later addSub_6
as5(expPostNorm,cout,expPreNorm,addAmnt,1'b1)
endmodule
15
Adder Verilog
module fpAddSigUnit(sigFinal,siga,sigb,expDiff,co
mpExpab,clk,rst,takeShiftSig,signa,signb,compSigab
,sRaEn,sRbEn) output 80 sigFinal
output compSigab input 30
siga,sigb input 30 expDiff
input compExpab,takeShiftSig,sRaEn,sRbEn,clk,rst,s
igna,signb wire compSigab,addSub,coutFin
al wire 70 sigFinala,sigFinalb,sigMuxa
,sigMuxb,shOut,mShiftOut wire 90
sigPreOut,sigFinOut //q,d,clk,rst,en
//Choose to register original or shifted sig
mux21_8 mSiga(sigMuxa,takeShiftSig,1'b1,si
ga,3'b000,shOut) mux21_8
mSigb(sigMuxb,takeShiftSig,1'b1,sigb,3'b000,shOu
t) reg_x (8,0) sRa(sigFinala,sigMuxa,clk
,rst,sRaEn(takeShiftSig(compExpab)) )
reg_x (8,0) sRb(sigFinalb,sigMuxb,clk,rst,sRbEn(
takeShiftSigcompExpab) ) //Choose
Significand to shift and shift it //0-gt b
is bigger, 1-gt a is bigger mux21_8
mshift(mShiftOut,compExpab,sigFinala,sigFinalb)
sbshiftr_8 sbs(shOut,mShiftOut,expDiff)
//AddSub significands based on signs
//10 bit adder to accomodate negative bit and
adding secret bits comp8
c8(compSigab,sigMuxa,sigMuxb) xor
x0(addSub,signa,signb) addSub_10
addSigs(sigPreOut,coutFinal,2'b00,sigMuxa,2'b00
,sigMuxb,addSub)
16
Design Challenges and Implementation
DecisionsFor The Past Week
Design Challenge Translation to HW
Low Power Design Ripple Carry Adder Quiet Bit Line SRAM Architecture Sense Amplifier Flip Flop
17
Quiet-Bitline Architecture for SRAM

• No Pre-Charging
• One side driving scheme where only a strong 0
  is forced in bit or bit bar when writing
• 85 power reduction over traditional methods

Citation A Low-Power SRAM Design Using
Quiet-Bitline Architecture by Cheng et. al.
18
Problems/Questions

• Our Floor plan has a hole in the top right
• Need to more accurately determine timing delays
  through modules

19
For Next Week

• Make Transistor Level Schematic
• Begin Layout of Smaller Modules
• Continue to Revise and Update Floor Plan
