EMOTION ANALYSIS IN MAN-MACHINE INTERACTION SYSTEMS

1
EMOTION ANALYSIS IN MAN-MACHINE INTERACTION
SYSTEMS

• T. Balomenos, A.Raouzaiou, S.Ioannou,
  A.Drosopoulos, K.Karpouzis and S.Kollias

Image, Video and Multimedia Systems
LaboratoryNational Technical University of Athens
2
Outline

• Facial Expression Estimation
• Face Detection
• Facial Feature Extraction
• Anatomical Constraints - Anthropometry
• FP Localization
• FAP calculation
• Expression Profiles
• Expression Confidence enforcement - Gesture
  analysis

3
Face Detection
4
Multiple cue Facial Feature boundary extraction
eyes mouth, eyebrows, nose

• Edge-based mask
• Intensity-based mask
• NN-based (Y,Cr,Cb, DCT coefficients of
  neighborhood) mask
• Each mask is validated independently

5
Multiple cue feature extraction an example
6
Final mask validation through Anthropometry
Facial distances Male/Female separation measured
by the US Army 30 year period
The measured distances are normalized by division
with Distance 7, i.e. the distance between the
inner corners of left and right eye, both points
the human cannot move.
7
Anthropometry based confidence
DA5n, DA10n distances in figures normalized by
division with distance DA7 (DA5nDA5/DA7,DA10nD
A10/DA7) DAewn eye width (calculated from DA5
and DA7) DAewn((DA5-DA7)/2)/DA7
D5n DA5n_min DA5n_max D10n DA10n_min DA10n_max Dew_ln Dew_rn DAewn_min DAewn_max
2.129 2.517 3.349 0.919 1.031 1.515 0.677 0.452 0.840 1.077
8
Detected Feature Points (FPs)
9
FAP-based description (Facial Animation
Parameters)

• Discrete features offer a neat, symbolic
  representation of expressions
• Not constrained to a specific face model
• Suitable for face cloning applications
• MPEG-4 compatible unified treatment of analysis
  and synthesis parts In MMI environments

10
FAPs estimation

• Absence of clear quantitative definition of FAPs

• It is possible to model FAPs through FDP feature
  points movement using distances s(x,y)

e.g. close_t_r_eyelid (F20) - close_b_r_eyelid
(F22) ? D13s (3.2,3.4) ? f13 D13 - D13-NEUTRAL
11
Sample Profiles of Anger
A1 F422, 124, F31-131, -25, F32-136,-34,
F33-189,-109, F34-183,-105, F35-101,-31,
F36-108,-32, F3729,85, F3827,89 A2
F19-330,-200, F20-335,-205, F21200,330,
F22205,335, F31-200,-80, F32-194,-74,
F33-190,-70, F34-190,-70 A3 F19
-330,-200, F20-335,-205, F21200,330,
F22205,335, F31-200,-80, F32-194,-74,
F3370,190, F3470,190
12
Gesture Analysis

• Gestures too ambiguous to indicate emotion on
  their own
• Gestures are used to support the confidence
  outcome of facial expression analysis

Emotion Gesture Class
Joy hand clapping-high frequency
Sadness hands over the head-posture
Anger lift of the hand- high speed
Anger italianate gestures
Fear hands over the head-gesture
Fear italianate gestures
Disgust lift of the hand- low speed
Disgust hand clapping-low frequency
Surprise hands over the head-gesture
HMM gesture class probabilities to emotional
state transformation table
Cr/Cb based hand detection
13
Emotion analysis system overview
G the value of a corresponding FAP
f Values derived from the calculated distances
14
System Interface
15
Conclusions

• Estimation of a users emotional state based on a
  fuzzy rules architecture
• MPEG-4 a compact and established means for HCI
• Evaluation approach based on anthropometric
  models and measurements
• Work validating the described developments in the
  framework of the IST ERMIS project and HUMAINE
