CMOS RFIC Design

1
CMOS RFIC Design for Direct Conversion Receivers
Zhaofeng ZHANG
ELEC, HKUST
2
Outline of Presentation

• Background Introduction
• Design Issues and Solutions
• A Direct Conversion Pager Receiver
• Conclusion

3
Research Goal

• Low Cost
• Process CMOS
• Device is good enough
• Improved passive components
• Integration level
• Minimize external components
• Minimize IC area and pin numbers
• Low Power
• High integration low power
• Low power individual block design
• System architecture is important

SOC
4
Heterodyne Receivers

• High IF more than 2 down-conversions
• Best sensitivity
• Need off-chip image-rejection SAW filters and
  channel-selection filters
• Highest cost, high power, low integration
• Low IF
• Relaxed image-rejection requirement compared to
  high-IF
• No DC offset problem
• Quadrature LO is required
• Flicker noise may be a problem
• High integration level, low cost

5
Homodyne Receivers
Pros
Cons

• Simple architecture
• No image problem
• No 50ohm interfaces
• High integration level
• Lowest cost, low power

• DC offsets
• Flicker noise
• LO leakage
• Even-order distortion

6
Origin of Problem

• DC offsets
• Flicker noise
• LO leakage
• Even-order distortion
• Linearity requirement
• Noise requirement
• IQ mismatch

All problems are limited by the mixer design!
The mixer the most critical component!
Our research focus!
7
DC Offsets LO Leakage

• The offset originates from self-mixing.
• It can be as large as mV range at the mixer
  output.
• It varies with the environment and moving speed
  of
• the mobile and changes with time.
• The maximum bandwidth can be as large as kHz
  range.
• LO leakage forms an interference to other
  receivers.

8
Spectrum Illustration
9
Existing Solutions on DC Offset

• AC coupling or high pass filtering
• Autozeroing or double sampling
• Offset cancellation in digital domain
• Double LO frequency method ISSCC99
• Adaptive dual-loop algorithm combined with the
  mixer RAWCON00
• Pulse-width-modulation based bipolar harmonic
  mixer CICC97

However, these methods are either not so
effective or too complicated, or not suitable for
CMOS process.
10
Proposed Harmonic Mixing
11
Square-law Based Mixer

• LO leakage free.
• Ideally self-mixing free.
• Current controlled switching.
• No noise contribution from LO stage.

12
Flicker Noise Reduction
Vrf

• Flicker noise is proportional to the current.
• Current injection is used to reduce flicker
  noise.
• No noise contribution from current source too.

13
Offset Cancellation
20
TSMC0.35?
10
gt35dB
0
-10
Gain (dB)
-20
-30
-40
-22
-20
-18
-16
LO Input Power (dBm)
14
Noise Performance
60
50
40
Noise Figure _at_ 10kHz (dB)
30
20
400
600
800
1000
Injected Current I0 (?A)
15
How to improve more?

• However, flicker noise is still too large due to
  CMOS devices, minimum noise figure achieved is
  larger than 24dB _at_ 10kHz for CMOS harmonic mixer.
  It requires a high gain and low noise LNA to
  overcome flicker noise while the front-end
  linearity suffers.
• For a narrow-band communication system such as
  FLEX pager, the noise requirement at low
  frequency is very tough.
• It is well known that bipolar device is a good
  candidate to eliminate flicker noise.
• But, can we do it in a CMOS process and how good
  is the device? YES!

16
Lateral Bipolar Transistor in a Bulk CMOS Process
17
Physical Model of LBJT
18
Gummel Plot of LBJT
TSMC0.35?
?gt40 at mAs max fT ?4GHz
19
LBJT Harmonic Mixer
20
Noise Performance
Large LO improves noise.
21
Even Order Distortion
a1xa2x2a3x3
f1
f2

• It is mainly introduced by layout asymmetry and
  device mismatch.
• Since direct-conversion, the intermodulation
  components IM2 will fall into the demodulated
  signal spectrum.
• Therefore, good IIP2 is required for homodyne
  receivers.
• It is found that varying the loading resister or
  voltage bias can compensate the device mismatch
  and improve IIP2 significantly.

22
IIP2 Improvement
Same DC bias
Compensation
IIP218dBm
IIP2gt40dBm
23
LBJT Mixer Performance
Technology TSMC 3M2P 0.35?m
VDD 3V
Signal Gain 15dB
DC offset suppression gt30dB
Noise figure _at_ 10kHz lt18dB
1dB compression point gt-20dBm
Input-referred IP3 gt-9dBm
Input-referred IP2 gt40dBm
Power consumption lt2.2mW
24
Summary on Mixer

• Flicker noise free, corner frequency is below
  10kHz.
• DC offset free, more than 30dB DC offset
  suppression is achieved.
• No LO leakage problem.
• Sufficient IIP2 after bias compensation.
• High gain and low power consumption.
• Complete CMOS process.
• Suitable for CMOS direct conversion applications.

25
Difficulties in FLEX Pager
-1
High pass effect
BER _at_ 12dB Eb/N0
-2
10
High pass corner (Hz)
Big Challenges

• Narrow band modulation
• Significant energy near DC
• High pass filtering is not viable
• DC offset problem
• Flicker noise is significant

DC Offset Effect
BER
4
8
12
16
Eb/N0 (dB)
26
4-FSK Pager Receiver
RF Zhaofeng BB Zhiheng

• Fully differential architecture to reject
  substrate noise.
• Harmonic mixers are used to solve time-varying
  DC offset.
• Peak detectors are used to cancel static DC
  offset.
• High front-end gain and current injection to
  reduce flicker noise.

27
LNA

• Non-quasi-static phenomenon makes it unnecessary
  to do on-chip matching.
• Off-chip matching by a single inductor and a
  balun.
• S11lt-20dB _at_ 930MHz
• Both on-chip and off-chip inductive loads were
  tried.

28
Double Balanced Mixer
Improve the linearity Provide constant impedance
to LNA Current injection provides more than 20dB
flicker noise reduction.
29
Ring Oscillator
Half RF frequency, Provide 45? phase.
30
Static DC Offset Cancellation
Peak Detector
Fmin?200Hz
31
Performance Summary
32
Die Photo
33
Summary on Pager Receiver

• Feasibility of direct conversion has been
  demonstrated.
• Proposed harmonic mixing technique solves
  self-mixing induced DC offset problem
  successfully.
• With the help of static DC offset cancellation,
  the total DC offset is less than 1mV at the
  receiver output.
• The modified ZIFZCD 4-FSK demodulator functions
  correctly.
• A 4-FSK FLEX pager receiver in a single chip has
  been implemented successfully.

34
Conclusion

• Circuit design for direct-conversion has been
  discussed.
• DC offset more than 30dB improvement
• LO leakage no longer a problem
• Flicker noise corner frequency is less than kHz
  due to lateral bipolar device.
• IIP2 larger than 40dBm after bias compensation.
• System on chip has been successfully demonstrated
  using CMOS direct conversion architecture.
