Researches and Applications for Automotive Field
Andrea Azzali, Eraldo Carpanoni, Angelo Farina
2
Topics

• Main Researches
• Objective evaluation index for audio performance
  characterization and Innovative Analysis
  technique for musical signal (AQT system)
• Virtual car cockpit for system comparison
• Algorithm for audio equalization (AQT, CTC)
• Simulation of digital system staying inside car
  cockpit
• Robust measuring technique for reliable and
  stable characterization with IR

3

• Innovative dynamic analysis technique

AQT Tool
4
Innovative dynamic analysis technique

• Goal
• Substitute classical analysis based on FFT with
  dynamic analysis
• Reasons
• FFT characterize system only in steady state
  condition
• BUT
• Hearing system is more sensible vs transient
• Musical signal is not a steady state signal
• Solution
• Aqt analysis system

5
AQT Analysis system

• Features
• Use transient stimulus instead steady-state ones
• Find psychoacoustics response more closed to real
  perceived curve than FFT response
• Find resonance in cockpit and tail that affect
  hearing
• Useful during car system development
• Output
• Articulation parameter
• Energy deviation from best curve corresponding to
  pleasant hearing inside the car

6
Objective evaluation system
Evaluation Test
7
Objective evaluation system

• Activity in Collaboration with CRF Fiat Research
  Centre
• Goal
• Reduce time needed for system characterization
  during car system development
• Obtain Reliable characterization of hearing
  inside the car and develop a series of objective
  parameter useful as project statement
• Status
• In progress (deadline 24/12/2003)

8
Objective evaluation system

• Proceeding
• Study of main features that affect subjective
  evaluation of car system gtgt OUTPUT Subjective
  Index of performance (New IPA)
• Study of a series of objective parameter able to
  describe this features gtgt OUTPUT statement
• Study of correlation between subjective and
  objective parameter gtgt OUTPUT Objective Index of
  Performance

9
Objective evaluation system

• Subjective evaluation parameters
• Intensity of Sound and SPL MAX.
• Distortion.
• Spectral attributes.
• Spatial attributes .
• Speech clarity and intelligibility.
• Low frequency quality.
• Articulation and clarity of sound (Fidelity)
• Objective Parameters
• Dynamic response of car inside (AQT Method)
• Articulation and energy recovery at low frequency
  (AQT)
• Spatial parameter (IACC and localization index)
• Speech clarity (STI)
• ..

10
Objective evaluation system

• Current activities
• Preparation of subjective test based on
  questionnaire developed for subjective database
  and statistical process
• Study of listening room as standard listening
  test environment instead of car inside

11
Virtual listening system
Listening room
12
Virtual listening system

• Goal
• Fast comparison between different car audio
  system
• Detailed highline of difference
• Reasons
• The tests not be done in the car because of the
  high switching time and the unavailability of the
  car after long time.
• Features
• Fast switch between different configurations
• Capability of comparison by audio system of the
  cars nevermore available
• The listening room reproduce the binaural
  recorded tracks in the car and doesnt insert any
  apparent alteration.

13
Virtual listening system

• Proceeding
• Record with dummy head Audio CD for subjective
  test and signal for characterization of car
  inside
• Reproduce the Audio track, recorded in several
  car, in Virtual system
• Use for audio comparison an automatic software
  developed in VB

14
Virtual listening system

• Virtual system
• Double stereo dipole
• Two central channel for voice and monophonic
  signal
• Two surround channel for reproduction of high
  uncorrelated signal and aimed to recreate lateral
  contribution from loudspeaker in car

15
Virtual listening system
Virtual system Plant
16
Algorithm for sound field correction
17
Algorithm for sound field correction

• Existing algorithms
• Time delay alignment
• Stereo dipole for new configuration system
  (dedicate loudspeaker central channel)
• Psychoacoustic curve correction (Aqt Filter)
• Algorithms under test
• Stereo dipole for standard system configuration
• Resonance and tail correction system (Aqt Filter)
• In the future gtgt Surround system 51
• Platform
• DSP board
• Technique
• FIR Filtering

18
Algorithm for sound field correction

• Time delay alignment
• Compensate the time difference existing between
  the time arrival of the direct sound of the two
  hearing channel
• Create a virtual symmetric system
• Enhance spatial sensation and create a wide scene
  in the driver position
• Stereo dipole for new configuration system
• Need a couple of loudspeaker for each seat
• Enhance spatial sensation and create a wide scene
  in all the listening position
• Perform Cross-Talk and reduce resonance and
  reflection effects on the hearing

19
Algorithm for sound field correction

• Psychoacoustic curve correction
• Invert dynamic curve response of car cockpit
  really perceived by hearing system
• Perform more pleasant filter than standard
  inversion technique
• A tool is already developed to perform this AQT
  Tool

20
Digital system simulation
21
Digital system simulation

• Overview
• its a difficult task compare a lot of algorithm
  and set of coefficients at the same time on DSP
  board
• Solution gtgt Simulation System on PC
• Goal
• Simulate different digital system for correction
  of the response inside the car Stereo Dipole
  Filtering, IIR, FIR,AQT Filter, 51 surround
  system
• Compare different configuration staying in
  listening position
• Features
• Let us to compare all the algorithms in real time
  and perform a fast switching between different
  configuration (Ex 51 vs Cross Talk)
• Let us to compare in a fast way several set of
  coefficients of FIR, IIR, AQT filter and to
  choose the set that retrieves the best
  performance and pleasure
• PERMIT ON THE ROAD TEST!!!

22
Car inside digital system simulation

• Simulation system
• A Notebook
• Existing Software
• digital block performing several algorithm
• Accept extern block programmed in VST standard
• We already have all the block that permit the
  simulation of the entire set of developed
  algorithm
• We have the know-how to perform new VST plug-in
  for new algorithm
• A multichannel (10 or more) Sound Card with
  PCIMCA interface as Echo Layla gtgt WE NEED IT!!!
• Amplifiers to drive all the loudspeaker

23
Car inside digital system simulation

• Simulation Block Diagram

Standard system
PCIMCA Multichannel Audio card
Multichannel Power Amplifier
Notebook
Stereo dipole system
51 surround system
24
Reliable measure technique
25
Reliable measure technique for IR

• Goal
• Introduce the Impulse Response as standard
  measure for characterization of the car inside
• Introduce the use of Cool-Edit and Aurora for IR
  measure
• Introduce AQT Tool as advanced analysis system
• Perform reliable and repeatable measures of
  response inside the car testing several
  procedures of average of binaural recording
• THE ACTUAL APPROACH Binaural recording of IR
  with rotating dummy head by step of 15 degrees
