Title: Diapositiva 1


1
Talking about Eiffel
Course of Software Engineering II a.a. 2001/2002
Massimo Ruffa
2
  • Bertrand Meyer
  • EiffelStudio
  • Eiffel
  • Software Process in Eiffel
  • Cluster and Cluster Model
  • What is a cluster
  • What is the Cluster Model
  • Project Leader and Cluster Model
  • Seamlessness and Reversibility
  • Generalization
  • Design by Contract
  • Contract Form
  • Assertion
  • Precondition
  • Postcondition
  • Invariant
  • RUP vs EIFFEL
  • BON
  • Bibliography

3
Bertrand Meyer
  • hold the chair of Software Engineering at ETH,
    the Swiss Federal Institute of Technology in
    Zürich
  • adjunct professor at Monash University,
    Melbourne, Australia (school of Computer Science
    and Software Engineering, CSSE) since 1998
  • Chairman of the TOOLS Conference Series (
    Technology of Object-Oriented Languages and
    Systems )
  • CTO at Interactive Software Engineering (ISE)
  • ISE co-founder in 1985 ( is best-known for
    introducing the Eiffel method, language, and ISE
    Eiffel software development environment )

4
  • Bertrand Meyer
  • EiffelStudio
  • Eiffel
  • Software Process in Eiffel
  • Cluster and Cluster Model
  • What is a cluster
  • What is the Cluster Model
  • Project Leader and Cluster Model
  • Seamlessness and Reversibility
  • Generalization
  • Design by Contract
  • Contract Form
  • Assertion
  • Precondition
  • Postcondition
  • Invariant
  • RUP vs EIFFEL
  • BON
  • Bibliography

5
EiffelStudio 1/2
  • EiffelStudio is the central tool of ISE Eiffel,
    letting you
  • Design
  • Develop
  • Debug
  • Document
  • Measure
  • Maintain
  • Revise
  • Expand systems
  • using the full power of object technology and
    Design by Contract
  • is available for the major industry platforms
  • it is at its best when used as a combination
    technology to reuse software components written
    in various languages
  • 100000 licenses all over the world

6
EiffelStudio 2/2
  • Some ISE Eiffel Projects
  • EuroDisney S.C.A. Marne-la-Vallee (France)
  • Simulation of park's attractions
  • National Defense Research Establishment
  • Database query language evaluator analysis and
    simulation system for hostile submarine activity
  • Telesoft Rome (Italy)
  • Telecommunications applications, networking
  • Lucent Technologies Middletown, New Jersey (USA)
  • Telecommunications
  • Hewlett-Packard, printer division Marina del Rey
    (California)
  • Embedded systems
  • CALFP Bank (Credit Agricole Lazard Financial
    Products Bank) London, New York, Paris,
    Singapore, Tokyo
  • Futures trading, pricing, bank operations

7
  • Bertrand Meyer
  • EiffelStudio
  • Eiffel
  • Software Process in Eiffel
  • Cluster and Cluster Model
  • What is a cluster
  • What is the Cluster Model
  • Project Leader and Cluster Model
  • Seamlessness and Reversibility
  • Generalization
  • Design by Contract
  • Contract Form
  • Assertion
  • Precondition
  • Postcondition
  • Invariant
  • RUP vs EIFFEL
  • BON
  • Bibliography

8
EIFFEL
  • covers the whole spectrum of software development
  • Analysis and specification
  • Design and architecture
  • Implementation
  • Maintenance
  • Documentation
  • method and language for the efficient description
    and development of quality systems
  • Reliability
  • Reusability
  • Extendibility
  • Portability
  • Maintainability

9
  • Bertrand Meyer
  • EiffelStudio
  • Eiffel
  • Software Process in Eiffel
  • Cluster and Cluster Model
  • What is a cluster
  • What is the Cluster Model
  • Project Leader and Cluster Model
  • Seamlessness and Reversibility
  • Generalization
  • Design by Contract
  • Contract Form
  • Assertion
  • Precondition
  • Postcondition
  • Invariant
  • RUP vs EIFFEL
  • BON
  • Bibliography

10
SOFTWARE PROCESS IN EIFFEL
  • supports the entire lifecycle
  • radically different from the traditional
    Waterfall model and from its more recent variants
    such as the spiral model or rapid prototyping
  • Principles
  • Cluster, basic organizational unit
  • seamlessness and reversibility
  • generalization for reusability
  • Constant availability ( current demo )

in the authors mind these are that fit best with
the language and the rest of the method, even if
some highly competent and successful Eiffel
developers may disagree with some of them and use
a different process model.
11
CLUSTER
SW PROCESS in EIFFEL 2/11
  • group of related classes or, recursively, of
    related clusters
  • natural unit for single-developer mastery
  • each cluster should be managed by one person
  • and one person should be able to understand all
    of it
  • Each of the individual cluster lifecycles is
    based on a continuous progression of activities,
    from the more abstract to the more
    implementation-oriented in a process of
    accretion, where each step enriche the results of
    the previous one
  • The principle is here to treat the software as a
    single product which will be repeatedly refined,
    extended and improved
  • Eiffel language supports this view by providing
    high-level notations that can be used throughout
    the lifecycle ( BON )

12
INDIVIDUAL CLUSTER LIFECYCLE
SW PROCESS in EIFFEL 3/11
identify the classes (data abstractions) of the
cluster and their major features and constraints
(yielding invariant clauses)
define the architecture of the classes and their
relations
finalize the classes, with all details added
check that the clusters classes perform
satisfactorily (through static examination,
testing and other techniques)
prepare for reuse
13
CLUSTER MODEL
SW PROCESS in EIFFEL 4/11
  • assumes that the system is divided into a number
    of subsystems or clusters
  • keeps from the Waterfall a sequential approach to
    the development of each cluster ( without the
    gaps ), but promotes concurrent engineering for
    the overall process using
  • information hiding
  • Design by Contract
  • clearly defined interfaces of clusters

14
SW PROCESS in EIFFEL 5/11
Feasibility Study
The Cluster Model Sequential and Concurrent
Engineering
Division into Cluster
15
PROJECT CLUSTER AS A SET of ABSTRACTION LAYERS
SW PROCESS in EIFFEL 6/11
  • information hiding properties of the
    object-oriented method make possible concurrent
    engineering
  • thanks to data abstraction it is possible for a
    cluster to proceed even if the clusters on which
    it depends are not yet finished, it suffices that
    the analisys phase of the needed classes be
    complete
  • clusters may depend on each other
  • rotating the preceding figure we emphasize the
    software layers corresponding to the various
    clusters
  • design and implementation of each cluster depend
    only on the analisys of clusters below it, not on
    their own design and implementation

16
SW PROCESS in EIFFEL 7/11
Cluster n
Cluster 2
Cluster 1
17
PROJECT LEADER and CLUSTER MODEL
SW PROCESS in EIFFEL 8/11
  • has the responsibility for finding clusters
  • is in charge of deciding when to start
  • a new cluster
  • a new task
  • can advances or delay various clusters and steps
    through dynamic reallocation of resources
  • by the task of Integration can
  • avoid divergence between the current states of
    the various clusters development
  • ensures that at every stage after start-up there
    will be a current demo

18
  • Bertrand Meyer
  • EiffelStudio
  • Eiffel
  • Software Process in Eiffel
  • Cluster and Cluster Model
  • What is a cluster
  • What is the Cluster Model
  • Project Leader and Cluster Model
  • Seamlessness and Reversibility
  • Generalization
  • Design by Contract
  • Contract Form
  • Assertion
  • Precondition
  • Postcondition
  • Invariant
  • RUP vs EIFFEL
  • BON
  • Bibliography

19
SEAMLESSNESS and REVERSIBILITY
SW PROCESS in EIFFEL 9/11
  • defines a single framework for analysis, design,
    implementation and maintenance instead of
    erecting barriers between successive lifecycle
    steps
  • Reversibility wisdom sometimes blooms late in
    the season

20
SW PROCESS in EIFFEL 10/11
21
  • Bertrand Meyer
  • EiffelStudio
  • Eiffel
  • Software Process in Eiffel
  • Cluster and Cluster Model
  • What is a cluster
  • What is the Cluster Model
  • Project Leader and Cluster Model
  • Seamlessness and Reversibility
  • Generalization
  • Design by Contract
  • Contract Form
  • Assertion
  • Precondition
  • Postcondition
  • Invariant
  • RUP vs EIFFEL
  • BON
  • Bibliography

22
GENERALIZATION
SW PROCESS in EIFFEL 11/11
  • has no equivalent in traditional approaches
  • Its goal is to polish the classes so as to turn
    them into potentially reusable software
    components
  • may involve the following activities
  • Abstracting
  • Factoring
  • Adding assertions ( postconditions and invariant
    clauses )
  • Adding rescue clauses to handle exceptions
  • Adding documentation

23
  • Bertrand Meyer
  • EiffelStudio
  • Eiffel
  • Software Process in Eiffel
  • Cluster and Cluster Model
  • What is a cluster
  • What is the Cluster Model
  • Project Leader and Cluster Model
  • Seamlessness and Reversibility
  • Generalization
  • Design by Contract
  • Contract Form
  • Assertion
  • Precondition
  • Postcondition
  • Invariant
  • RUP vs EIFFEL
  • BON
  • Bibliography

24
DESIGN by CONTRACT
  • A system is made of a number of cooperating
    components. Design by Contract states that their
    cooperation should be based on precise
    specifications contracts describing each
    partys expectations and guarantees
  • Contract Form is the fundamental tool for using
    supplier classes in the Eiffel method. It enables
    client authors to reuse software without having
    to read their source code, this is a crucial
    elements requirement in large-scale industrial
    developments

25
DESIGN by CONTRACT 2/6
  • Eiffel directly implements this idea, which
  • enhance software reliability
  • provide a sound basis for software
  • specification
  • documentation ( Assertions - Reusable Components
    )
  • testing, debugging and quality assurance
  • exception handling
  • inheritance
  • The underlying theory, the centerpiece of the
    Eiffel method, views software construction as
    based on contracts between clients (callers) and
    suppliers (routines), relying on mutual
    obligations and benefits made explicit by the
    assertions

26
  • Bertrand Meyer
  • EiffelStudio
  • Eiffel
  • Software Process in Eiffel
  • Cluster and Cluster Model
  • What is a cluster
  • What is the Cluster Model
  • Project Leader and Cluster Model
  • Seamlessness and Reversibility
  • Generalization
  • Design by Contract
  • Contract Form
  • Assertion
  • Precondition
  • Postcondition
  • Invariant
  • RUP vs EIFFEL
  • BON
  • Bibliography

27
DESIGN by CONTRACT 3/6
  • are logical properties of object states
  • method and notation support writing the
    assertions to express the terms of the contracts
  • syntactically, the assertions of our notation
    will simply be boolean expressions, with a few
    extensions ( old in postcondition )
  • assertions generally cover correctness
  • mathematically, the closest notion is that of
    predicate, although the assertion language that
    we shall use has only part of the power of full
    first-order predicate calculus
  • can express many higher-level properties through
    function calls,although the functions involved
    must be simple and of unimpeachable correctness

28
DESIGN by CONTRACT 4/6
  • assertions include preconditions, postconditions,
    class invariants and also appear in check
    instructions
  • precondition
  • binds the callers
  • expresses the constraints under which a routine
    will function properly, appears in the official
    documentation
  • postcondition
  • binds the class/routine
  • expresses properties of the state resulting from
    a routines execution
  • invariant
  • a need for expressing global properties of the
    instances of a class, which must be preserved by
    all routines
  • capturing the deeper semantic properties and
    integrity constraints characterizing a class

29
CORRECTNESS
DESIGN by CONTRACT 5/6
  • with preconditions, postconditions and
    invariants, we can now define precisely what it
    means for a class to be correct
  • this provides a basis against which to assess
    correctness the class is correct if and only if
    its implementation, as given by the routine
    bodies, is consistent with the preconditions,
    postconditions and invariant
  • a class, like any other software element, is
    correct or incorrect not by itself but with
    respect to a specification. By introducing
    preconditions, postconditions and invariants we
    have given ourselves a way to include some of the
    specification in the class text itself

30
DESIGN by CONTRACT 6/6
  • instruction is
  • prescriptive
  • describes the how
  • part of the implementation
  • imperative
  • assertion is
  • descriptive
  • describes the what
  • an element of specification
  • is applicative

31
  • Bertrand Meyer
  • EiffelStudio
  • Eiffel
  • Software Process in Eiffel
  • Cluster and Cluster Model
  • What is a cluster
  • What is the Cluster Model
  • Project Leader and Cluster Model
  • Seamlessness and Reversibility
  • Generalization
  • Design by Contract
  • Contract Form
  • Assertion
  • Precondition
  • Postcondition
  • Invariant
  • RUP vs EIFFEL
  • BON
  • Bibliography

32
RUP vs EIFFEL
Design by Contract
Integration Current Demo
RUP Acknowledgment
33
  • Bertrand Meyer
  • EiffelStudio
  • Eiffel
  • Software Process in Eiffel
  • Cluster and Cluster Model
  • What is a cluster
  • What is the Cluster Model
  • Project Leader and Cluster Model
  • Seamlessness and Reversibility
  • Generalization
  • Design by Contract
  • Contract Form
  • Assertion
  • Precondition
  • Postcondition
  • Invariant
  • RUP vs EIFFEL
  • BON
  • Bibliography

34
Business Object Notation
  • The original designer of BON was Jean-Marc Nerson
    of SOL (Paris)
  • design was completed with the collaboration of
    Kim Waldén of Enea Data (Stockholm)
  • is a method and graphical notation for high-level
    object-oriented analysis and design
  • static part of the model focuses
  • Classes, interfaces, their interrelationships,
    and their
  • clusters ( denoting a group of logically related
    classes )
  • dynamic part describes
  • objects
  • object interactions
  • scenarios for message sequencing

35
BON 2/4
  • formalisms include
  • textual notation
  • not have to be directly compilable
  • use extensions in the area of assertions
  • delta a
  • forall
  • exists
  • member_of
  • tabular form
  • tabular class chart ( convenient to summarize the
    properties of a class compactly )
  • graphical diagrams

36
BON 3/4
Static Diagrams
37
BON 4/4
Dinamic Diagrams
38
  • Bibliography

Object Oriented Software Construction ( second
edition) Published by Prentice Hall isbn
0-13-629155-4 all about Eiffel method, Ise
Eiffel, Bon Method/Notation
ISE web site www.eiffel.com all information
about Meyer, Ise Eiffel, Eiffel Method
An Eiffel Tutorial ISE Technical Report
TR-EI-66/TU information about Eiffel method
and notation
Invitation to Eiffel ISE Technical Report
TR-EI-67/IV information about Ise Eiffel
EiffelStudio A Guided Tour ISE Technical Report
TR-EI-68/GT. (Replaces TR-EI-38/EB.)
information about Ise Eiffel scopes and usage
Meyer s Personal web page www.inf.ethz.ch/persona
l/meyer Meyer the man and his history
Book
Book
Web Link
Web Link
39
Calcolo dei Predicati
  • Diversi alfabeti
  • Simboli di costanti
  • Simboli di variabile
  • Simboli di funzione
  • Simboli di predicato
  • Una frml f appartenente al CdP è
  • t1 t2 (t1, t2 sono termini)
  • p(t1,,tn) (p è predicato t1, t2 sono termini)
  • frml1ANDfrml2 (OR,gt,sse,)
  • NOT frml1
  • per ogni x . frml
  • esiste x . Frml
  • Un termine è
  • Costante
  • Variabile
  • F(t1,,tn) (F funzione, t1,..,tn termine)

40
RUP and UML 1/7
RUP and UML
  • is a Software Engineering Process
  • is a configurable process
  • It provides
  • disciplined approach to assigning tasks and
    responsibilities within a development
    organization
  • Its goal
  • is to ensure the production of high-quality
    software that meets the needs of its end-users,
    within a predictable schedule and budget
  • is a guide for how to effectively use the Unified
    Modeling Language
  • UML is a industry-standard language that allows
    us to clearly communicate requirements,
    architectures and designs

41
RUP and UML 2/7
  • horizontal axis represents time and shows the
    dynamic aspect of the process as it is enacted,
    and it is expressed in terms of
  • Cycles
  • Phases
  • Iterations
  • Milestones
  • vertical axis represents the static aspect of the
    process how it is described in terms of
    activities, artifacts, workers and workflows

42
RUP and UML 3/7
  • The software lifecycle is broken into cycles
  • Each cycle working on a new generation of the
    product
  • RUP divides one development cycle in four
    consecutive phases
  • Inception phase
  • Elaboration phase
  • Construction phase
  • Transition phase
  • Each phase can be broken down into iterations
  • An iteration is a complete development loop
    resulting in a release (internal or external) of
    an executable product, a subset of the final
    product under development, which grows
    incrementally from iteration to iteration to
    become the final system

43
Inception phase
RUP and UML 4/7
  • You establish the business case for the system
  • success criteria
  • risk assessment
  • estimate of the resources needed
  • phase plan showing dates of major milestones
  • delimit the project scope
  • identify all external entities (with which the
    system will interact actors)
  • define the nature of this interaction at a
    high-level
  • dentifying all use cases

44
Elaboration phase
RUP and UML 5/7
  • analyze the problem domain
  • establish a sound architectural foundation
  • develop the project plan
  • and eliminate the highest risk elements of the
    project

45
Construction phase
RUP and UML 6/7
  • remaining components and application features are
    developed and integrated into the product, and
    all features are thoroughly tested
  • Is a manufacturing process where emphasis is
    placed on
  • managing resources
  • controlling operations to optimize
  • Costs
  • Schedules
  • Quality
  • Is a transition from the development of
    intellectual property during inception and
    elaboration, to the development of deployable
    products during construction and transition

46
Transition phase
RUP and UML 7/7
  • delivering the software product to the user
    community
  • prepare new releases
  • correct some problems
  • finish the features that were postponed

47
Analisys and Specification
EIFFEL 1/3
  • Analisys
  • understand the problems that the eventual
    software system should solve
  • prompt relevant questions and provide a basis for
    answering questions about specific properties of
    the problem and system
  • decide what the system should do and should not
    do
  • ascertain that the system will satisfy the needs
    of its users
  • provide a basis for the development of the system
  • Specification
  • elaborate all analisys results using Design by
    Contract
  • every system component can be accompanied by a
    precise specification of its abstract properties

48
EIFFEL 2/3
  • Analisys and Specification
  • where Eiffel can be used as a purely descriptive
    tool to analyze and document the structure and
    properties of complex systems (even non-software
    systems)
  • Design and Architecture
  • where Eiffel can be used to build solid, flexible
    system structures
  • Implementation
  • where Eiffel provides practical software
    solutions with an efficiency comparable to
    solutions based on such traditional approaches as
    C and Fortran
  • Maintenance
  • where Eiffel helps thanks to the architectural
    flexibility of the resulting systems
  • Documentation
  • where Eiffel permits automatic generation of
    documentation, textual and graphical, from the
    software itself, as a partial substitute for
    separately developed and maintained software
    documentation

49
EIFFEL 3/3
  • Reliability
  • producing bug-free systems, which perform as
    expected
  • Reusability
  • making it possible to develop systems from
    prepackaged, high-quality components, and to
    transform software elements into such reusable
    components for future reuse
  • Extendibility
  • developing software that is truly soft easy to
    adapt to the inevitable and frequent changes of
    requirements and other constraints
  • Portability
  • freeing developers from machine and operating
    system peculiarities, and enabling them to
    produce software that will run on many different
    platforms
  • Maintainability
  • yielding software that is clear, readable, well
    structured, and easy to continue enhancing and
    adapting

50
SW PROCESS in EIFFEL
Requirements Analisys
Waterfall Model with iteration
Problem
Val
Requirements Specification
Design
Val Ver
Implementation
Design Specification
Val Ver
Code
Testing
Working System
Operation Maintenance
Val Ver
Val Validation
Ver Verification
51
DESIGN by CONTRACT
  • Meaning of a correctness formula Any
    execution of A, starting in a state where P
    holds, will terminate in a state where Q holds.
  • Es
  • meaning of such a correctness formula is
    whenever A is executed in a state satisfying P,
    the execution will terminate in a state
    satisfying Q
  • not empty (put (s, x))
  • remove (put (s, x)) s

52
BON
  • three key concepts of the BON method
  • seamlessness use of a continuous process
    throughout the software lifecycle
  • seversibility support for both forward and
    backward engineering
  • contracting precise definition, for each
    software element, of the associated semantic
    properties
  • is based on concepts similar to those of Eiffel
    but can be used independently of Eiffel, for
    example by people using another O-O language for
    implementation
Write a Comment
User Comments (0)
About PowerShow.com
