Arithmetic Circuits I

1
Arithmetic Circuits I
2
Iterative Circuit

• Like a hierachy, except functional blocks per bit

3
Adders

• Great example of this type of design
• Design a 1-bit adder circuit, then expand to
  n-bit adder
• Look at
• Half adder which is a 2-bit adder, no carry in
• Inputs are bits to be added
• Outputs result and possible carry
• Full adder includes carry in, really a 3-bit
  adder

4
Half Adder

• S X ? Y
• C XY

5
Full Adder

• Three inputs. Two are operand bits, third is Cin
• Two outputs sum and carry

6
K Map for S

• What is this?

7
K Map for C
8
Two Half Adders (and an OR)
9
Ripple-Carry Adder

• Straightforward connect full adders
• Chain carry-out (C4) to carry-in of FA of bits A4
  B4
• C0 in case this is part of larger chain, maybe
  just set to zero

10
Hierarchical 4-Bit Adder

• We can easily use hierarchy here
• Design half adder
• Use in full adder
• Use full adder in 4-bit adder

11
Carry Lookahead Adder

• Note that add itself is just a 2 gate levels
  function
• Idea is to separate carry from adder function
• Then make carry approx 2-level all way across
  larger adder

12
Four-bit Ripple Carry
Reference
Adder function separated from carry
13
Propagate

• The Pi signal is called propagate for stage i
• Pi Ai ? Bi
• Pi high means stage i propagates incoming carry
  Ci to stage i1

14
What Does This Mean(Pi active) ?

• No carry generated in stage i
• So the propagate signal indicates that incoming
  carry should pass on

15
Generate

• The Gi is generate
• Its Gi AiBi, so new carry created
• So its ORed with propagated incoming carry

16
Said Differently

• If Ai ? Bi AND theres incoming carry, carry will
  be propagated
• Si will be 0, of course
• If AiBi, then a carry is generated
• Incoming carry value will determine whether Si is
  0 or 1

17
Carry Lookahead (continued)

• In the ripple carry adder
• Gi, Pi, and Si are local in each cell of the
  adder
• Ci is also local in each cell
• In the carry lookahead adder, in order to reduce
  the length of the carry chain, Ci is changed to a
  more global function spanning multiple cells
• Defining the equations for the Full Adder in term
  of the Pi and Gi

18
Ripple Carry Delay 8 Gates
19
Carry Lookahead Functions

• C1 G0 P0 C0
• C2 G1 P1 C1
• Substitute the expression of C1 in the equation
  for C2
• C2 G1 P1 ( G0 P0 C0 )
• C2 G1 P1 G0 P1 P0 C0

20
Carry Lookahead Functions (continued)

• C2 G1 P1 G0 P1 P0 C0
• For C3
• C3 G2 P2 C2
• C3 G2 P2 (G1 P1 G0 P1 P0 C0 )
• C3 G2 P2 G1 P2 P1 G0 P2 P1 P0 C0
• C4 G3 P3 G2 P3P2 G1
• P3P2 P1 G0 P3P2 P1 P0 C0

21
Carry Lookahead Functions Summary

• C1 G0 P0 C0
• C2 G1 P1 G0 P1 P0 C0
• C3 G2 P2 G1 P2 P1 G0 P2 P1 P0 C0
• C4 G3 P3 G2 P3P2 G1
• P3P2 P1 G0 P3P2 P1 P0 C0

22
Ripple Carry Delay 8 Gates
23
Carries Produced In Two Gate Delays

• Two gate delays after Pi and Gi in all stages
  are generated (one gate delay)

24
C1 Just Like Ripple Carry
25
C2 Circuit Two Levels
G1 P1 G0
P1 P0 C0
26
C3 Circuit Two Levels
P2 P1 G0
G2 P2 G1
P2 P1 P0 C0
27
What Happens as Scale Up?

• Can I realistically make 64-bit adder like this?
• Have to AND 64 propagates and C0!
• Compromise
• Hierarchical design
• More levels of gates

28
Remember C4

• C4 G3 P3 G2 P3P2 G1
• P3P2 P1 G0 P3P2 P1 P0 C0
• C4 G0-3 P0-3 C0

29
Making 4-Bit Adder Module

• Create propagate and generate signals for whole
  module

30
Group Propagate

• Make propagate of whole 4-bit block
• P0-3 P3P2P1P0

31
Group Generate

• Make Generate of whole 4-bit block
• Indicates carry generated in block

32
Hierarchical Carry
A
B
4-bit adder
S
G
P
Cin
C4
C8
Look Ahead
C0

• lookahead block is exercise for you

33
Binary Subtraction

• Example
• (19)10 (30)10 - (11)10
• (10011)2 - (11110)2 - (01011)2
• Well use unsigned subtraction to motivate the
  use of
• complemented representation of signed numbers

34
Example
If no borrow, then result is non-negative
(minuend gt subtrahend).
Borrow 1 1 1 0 0
Minuend, 1910 1 0 0 1 1
Subtrahend, 3010 - 1 1 1 1 0
Difference 1 0 1 0 1
Correct Dif, -1110 - 0 1 0 1 1
Since there is borrow, result must be
negative. The result must be corrected to a
negative number.
35
Correcting Result of Example

• What, mathematically, does it mean to borrow?
• If borrowing at digit i-1 you are adding 2i

36
Correcting Result (continued)

• If there is a borrow, M is minuend and N
  subtrahend, the Difference was
• 2n M N
• What we want is magnitude of N-M with minus sign
  in front
• Can get the magnitude of the result (i.e. N - M )
  by subtracting previous result from 2n
• N - M 2n (2n M N)

37
Algorithm to Compute M - N

• Subtract N from M
• If no borrow, then M ? N and result is OK
• Otherwise, N gt M
• get the magnitude of the result
• N - M 2n (2n M N)
• Add minus before the magnitude
• Result is (N-M)

38
Design of Subtract Ciruit

• Could build a circuit to implement the previous
  algorithm but it will be expensive

39
Using 2s 1s Complement Representation of
Signed Numbers

• People use complemented interpretation for signed
  numbers
• 2s complement
• 1s complement

40
1s Complement

• Given binary number N with n digits
• 1s complement defined as
• (2n 1) - N
• Note that (2n 1) is a number with n bits, all
  of them 1
• For n 4, (2n 1) 1111

41
Example Find 1s Complement of N 1011001
2n - 1 1 1 1 1 1 1 1
- N 1 0 1 1 0 0 1
1s Compl. 0 1 0 0 1 1 0

• Notice that 1s complement is complement of each
  bit

42
2s Complement

• Given binary number N with n digits
• 2s complement defined as
• 2n N for N ? 0
• 0 for N 0
• Note that, since 1s complement is (2n 1) - N
• 2s complement is just a 1 added to 1s complement

43
Important Property

• Complement of a complement generates original
  number

44
New Algorithm for Computing M-N

• Add 2s complement of N to M
• This is M (2n N) M N 2n
• If M ? N, will generate carry
• Discard carry
• Result is positive M - N
• If M lt N, no carry
• Take 2s complement of result
• 2n - M N 2n N-M
• Place minus sign in front - (N-M)

45
Example 1

• X 8410 101 0100
• Y 6710 100 0011
• X Y 1710 001 0001
• X gt Y

M gt N Carry generated Discard carry Result is
positive M - N
46
Algorithm for Computing X - Y

• Add 2s complement of Y to X
• This is X (2n Y) X Y 2n
• X ? Y, will generate carry
• Discard carry
• Result is positive X - Y

47
Example 1 (continued)

• X 101 0100 minus Y 100 0011
• 2s comp Y ( 011 1100 ) 1 011 1101

X 1 0 1 0 1 0 0
2s comp Y 0 1 1 1 1 0 1
Sum 1 0 0 1 0 0 0 1
M gt N Carry generated Discard carry Result is
positive M - N
48
Example 2

• Y 6710 100 0011
• X 8410 101 0100
• Y lt X
• Y - X - 1710

49
Algorithm for Computing Y - X

• Add 2s complement of X to Y
• This is Y (2n X) Y X 2n
• Y lt X, no carry
• Take 2s complement of result
• 2n - Y X 2n X-Y
• Place minus sign in front - (X-Y)

50
Example 2 (continued)

• Y 100 0011 minus X 101 0100
• No end carry
• Answer - (2s complement of Sum)
• - 0010001

Y 1 0 0 0 0 1 1
2s comp X 0 1 0 1 1 0 0
Sum 1 1 0 1 1 1 1
We said numbers are unsigned. What does this
mean? How is -1710 represented?
51
Adder-Subtractor

• Need only adder and complementer for input to
  subtract
• Need selective complementer of output to make
  negative output from 2s complement of Sum

52
Design

• Output is result if A gt B Discard carry
• Output is 2s complement of result if B gt A

53
Signed Binary

• First review signed representations
• Signed magnitude
• Left bit is sign, 0 positive, 1 negative
• Other bits are number
• 2s complement
• 1s complement

54
Example in 8-bit byte

• Represent -910 -(0000 1001) in different ways
• Signed magnitude of - (0000 1001) is
• 1000 1001
• Signed 1s Complement of - (0000 1001) is
• 1111 0110
• Signed 2s Complement of - (0000 1001) is
• 1111 0111

55
Observations (assume 4-bit numbers)

• 1s C and Signed Mag have two zeros
• 2s C has more negative numbers than positive
• All negative numbers have 1 in highest-order bit

56
Advantages/Disadvantages

• Signed magnitude has problem that we need to
  correct after subtraction
• Ones complement has a positive and negative zero
• Twos complement is most popular
• Arithmetic operations easy

57
Twos Complement

• Addition easy on any combination of positive and
  negative numbers
• To subtract
• Take 2s complement of subtrahend B to produce -B
• Add to A
• This performs A ( -B), same as A B

58
Examples

• Assume we use 2s complement representation of
  signed numbers and store each number in 8 bits
• 6 (0000 0110) 13 (0000 1101)
• -6 (1111 1010) -13 (1111 0011)
• Addition
• 6 13
• -6 13
• 6 (- 13)
• (-6) (-13)
• Subtraction
• -6 - (-13)
• 6 - (- 13)

59
Overflow

• Two cases of overflow for addition of signed
  numbers
• Two large positive numbers overflow into sign bit
• Not enough bits for result
• Two large negative numbers added
• Same not enough bits
• Carry out can be OK

60
Examples

• Assume we use 2s complement representation of
  signed numbers and store each number in 4 bits
• 7 7
• -7 -7
• 4 4
• Generates no carry, but overflowed (i.e. result
  is NOT OK)
• 7 7
• Generates carry but result OK

61
Overflow Detection

• Condition for overflow
• either Cn-1 or Cn is high, but not both
• 4 4 only Cn-1 is high overflow
• 7 7 Cn-1 Cn are high no overflow
