1
Tools for Discovery
Digital Pulse Processing for Physics
Applications Ganil 2 February 2011 Carlo Tintori
2
Outline
  • Description of the hardware of the waveform
    digitizers
  • Overview on the CAEN Digitizer family
  • Use of the digitizers for physics applications
  • Comparison between the traditional analog
    acquisition chains and the new fully digital
    approach
  • DPP algorithms
  • Pulse triggering
  • Zero suppression
  • Pulse Height Analysis
  • Charge Integration
  • Gamma-Neutron discrimination
  • Time measurement
  • Multi Channel Scaler

Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
3
Digitizers vs Oscilloscopes
  • The principle of operation of a waveform
    digitizer is the same as the digital
    oscilloscope when the trigger occurs, a certain
    number of samples is saved into one memory buffer
    (acquisition window)
  • However, there are important differences
  • no dead-time between triggers (Multi Event
    Memory)
  • multi-board synchronization for system
    scalability
  • high bandwidth data readout links
  • on-line data processing (FPGA or DSP)

Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
4
Highlights
  • VME, NIM, PCI Express and Desktop
  • VME64X, Optical Link (CONET), USB 2.0, PCI
    Express Interfaces available
  • Memory buffer up to 10MB/ch (max. 1024 events)
  • Multi-board synchronization and trigger
    distribution
  • Programmable PLL for clock synthesis
  • Programmable digital I/Os
  • Analog output with majority or linear sum
  • FPGA firmware for Digital Pulse Processing
  • Software for Windows and Linux
  • From 2 to 64 channels
  • Up to 5 GS/s sampling rate - Up to 14 bit
  • FPGA firmware for Digital Pulse Processing

Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
5
Digitizers Table
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
6
Architecture
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
7
Digitizers for Physics Applications
  • Traditionally, the acquisition chains for
    radiation detectors are made out of mainly analog
    circuits the A to D conversion is performed at
    the very end of the chain
  • Nowadays, the availability of very fast and high
    precision flash ADCs permits to design
    acquisition systems in which the A to D
    conversion occurs as close as possible to the
    detector
  • The data throughput is extremely high it is no
    possible to transfer row data to the computers
    and make the analysis off-line!
  • On-line digital data processing in needed to
    extract only the information of interest (Zero
    Suppression Digital Pulse Processing)
  • The aim of the DPP for Physics Applications is to
    provide FPGA algorithms able to make in digital
    the same functions of analog modules such as
    Shaping Amplifiers, Discriminators, Charge ADCs,
    Peak Sensing ADCs, TDCs, Scalers, Coincidence
    Units, etc.

8
Traditional chain example 1charge sensitive
preamplifiers
9
Traditional chain example 2trans-impedance
(current sensitive) preamplifier
  • The QDC is not self-triggering need a gate
    generator
  • need delay lines to compensate the delay of the
    gate logic

10
Benefits of the digital approach
  • One single board can do the job of several analog
    modules
  • Full information preserved
  • Reduction in size, cabling, power consumption and
    cost per channel
  • High reliability and reproducibility
  • Flexibility (different digital algorithms can be
    designed and loaded at any time into the same
    hardware)

Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
11
Standard vs DPP firmware
  • Standard Firmware
  • common trigger on all channels simultaneously
  • programmable record length and pre/post trigger
  • channels self trigger digital discriminator with
    programmable threshold
  • multi board synchronization (clock, sync and
    trigger distribution)
  • trigger time stamps
  • multi event memory buffers (up to 1024 events)
  • waveform mode only (raw data)
  • DPP Firmware
  • trigger and timing filters for pulse
    identification and triggering
  • channels can trigger independently
  • energy filters for the pulse height analysis
    (trapezoidal filters)
  • energy filters for the digital charge integration
    (digital QDC)
  • configurable event data format (time and/or
    energy and/or waveform)
  • individual trigger propagation on channel basis,
    also from board to board
  • pulse shape analysis (e.g. gamma neutron
    discrimination)
  • event data packing for high counting rate

Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
12
Raw waveform mode vs DPP events
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
13
Individual vs Common trigger
empty event
400 ns 100100 samples 300 bytes/event (2ch)
80 ns 20 samples 30 bytes/event
Common
Individual
14
Trigger and timing filter (I)
  • Pulse triggering is the basis for all DPP and
    Zero Suppression algorithms
  • Fast Shaping filter RC-CRN (N1, 2)
  • Immune to baseline fluctuation and low frequency
    noise (ground loop)
  • Pulse identification also with the presence of
    pile-up
  • High frequency noise rejection (RC like mean
    filter)
  • Can operate as a digital CFD
  • Zero crossing for precise timing information
  • Off-line interpolation to overcome the sampling
    period granularity
  • Zero crossing of CFD can also be used for rise
    time discrimination

Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
15
Trigger and timing filter (II)
16
Zero Suppression
  • Data reduction algorithms can be developed to
    reduce the data throughput
  • Full event suppression one event (acquisition
    window) is discarded if no pulse is detected
    inside the window
  • Zero Length Encoding only the parts exceeding
    the threshold (plus a certain number of samples
    before and after) are saved.

ZLE
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
17
DPP for the Pulse Height Analysis (DPP-TF)
  • Digital implementation of the shaping amplifier
    peak sensing ADC (Multi-Channel Analyzer)
  • Charge sensitive preamplifier directly connected
    to the digitizer
  • Implemented in the 14 bit, 100MSps digitizers
    (mod. 724)
  • Use of trapezoidal filters to shape the long tail
    exponential pulses
  • Pile-up rejection, Baseline restoration,
    ballistic deficit correction
  • High counting rate, very low dead time
  • Energy and timing information can be combined
  • Best suited for high resolution spectroscopy
    (HPGe and Si detectors)

18
DPP-TF Block Diagram
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
19
Example of trapezoidal filter output
Trapezoid Height Energy
Pile-up
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
20
DPP-TF / Analog Chain set-ups
N1470High Voltage
N968 Shaping Amplifier
N957 Peak Sensing ADC
Energy
C.S. PRE
Ge / Si
DT5724 14bit _at_ 100MSps Digitizer DPP-TF
Energy
Time
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
21
High Rate spectroscopy (DPP-TF)
  • Rise Time Discriminator (RTD)
  • Detection of pulses piling-up on the rising edge
  • Cancellation of the sum peaks
  • Pulse count rate correction (true rate)
  • Baseline Restorer
  • Programmable number of points for the BL
    calculation
  • Programmable hold-off for a better BL recovery
  • Constraints on the pulse separation

Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
22
DPP-TF Test Results with CdTe
70 KHz
200 KHz
Sum Peaks with and withou RTD
800 KHz
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
23
Dead Time (DPP-TF)
  • Dead-timeless acquisition (no conversion time)
  • Double pulse resolution ? Rise Time (two pulses
    separated by at least the rise time can be
    distinguished)
  • The rise time discriminator allows double pulses
    piling up on the rising edge to be detected and
    counted twice
  • Although pile-up causes the loss of some
    energies, the DPP-TF is able to get the
    timestamps of nearly all pulses true rate can be
    calculated
  • Residual multiple pulses that cannot be
    distinguished (despite the RTD) can be taken into
    account on a statistical basis
  • Histogram (spectrum) calculated off-line easy
    implementation of techniques for the dead-time
    correction (loss of energy counts)
  • The number and the position of lost counts is
    known they can be dynamically re-distributed on
    the histogram. This is very important in the
    cases where the activity is not constant in time.

Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
24
Individual inter-channel triggering (DPP-TF)
  • Mainly needed in segmented (cloves) detectors
  • One channel triggers itself and also neighbour
    channels
  • Individual TRG-IN and TRG-OUT lines from each
    channel to the Front Panel GPIO connector (8
    inputs 8 outputs)
  • External trigger unit (V1495) for the coincidence
    matrix implementation
  • Can work also between cards
  • Available in the new DPP-TF (724 series)
  • Can be implemented in the 720 and 751 series as
    well

Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
25
Pulse Shape Analysis (DPP-TF)
  • Some applications need to perform pulse shape
    analysis to validate or correct the
    energy/timestamp information
  • Usually a small set of samples (short waveform)
    is required for the DPP-TF, this is typically
    the rising edge
  • Unlike the oscilloscope like acquisition mode,
    the recording of this waveform chunk has a little
    overhead in the readout rate
  • Also used to improve the timestamp resolution
    just two samples around the CFD zero crossing
    linearly interpolated off-line permit to make the
    resolution up to 100 times better than sampling
    period

Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
26
DPP-TF Test Results
  • Germanium Detectors at LNL (Legnaro - Italy) in
    Nov-08 and Feb-09, at GSI (Germany) on May-09, at
    INFN-MI on Jan-10, in Japan on Feb-10, at Duke
    University (USA) on Jul-10 Palermo on Jan 2011
    resolution 1.98 KeV _at_ 1.33 MeV (60Co)
  • Silicon Strip (SSSSD and DSSSD) and CsI detectors
    in Sweden at Lund and Uppsala (ion beam test)
  • CdTe at high rate (up to 800KHz) for spectroscopy
    imaging
  • NaI detectors in CAEN (see demo)
  • PET in U.S.A.
  • Homeland security application using CsI
  • BGO detector at ENEA Centro Ricerche Casaccia
    (Rome)

60Co with Ge
228Th with DSSSD
FWHM _at_ 1.33 MeV 1.98 KeV
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
27
DPP for the Charge Integration(DPP_CI)
  • Digital implementation of the QDC discriminator
    and gate generator
  • Implemented in the 12 bit, high speed digitizers
    ( Mod. 720() )
  • Self-gating integration no delay line to fit the
    pulse within the gate
  • Baseline restoration (pedestal cancellation)
  • Extremely high dynamic range
  • Dead-timeless acquisition (no conversion time)
  • Energy and timing information can be combined
  • Coincidences can be easily applied off-line
  • Typically used for PMT or SiPM/MPPC readout

() Implementation in the Mod751 is a work in
progress
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
28
DPP-CI Block Diagram
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
29
DPP-CI / Analog Chain set-ups
N1470High Voltage
DelayN108A
QDCV792N
Charge
Splitter A315
Dual TimerN93B
CFDN842
PMT
NaI(Tl)
TDC V1190
Time
DT5720 12bit _at_ 250MSps Digitizer DPP-CI
Charge
Time
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
30
DPP-CI Test Results
NaI detector and PMT directly connected to the
QDC or digitizer
DPP-CI Analog QDC
Energy (MeV) Res () Res ()
0.481 (137Cs Compton edge) 9.41 ? 1.18 12.80 ? 0.70
0.662 (137Cs Photopeak) 7.01 ? 0.04 8.17 ? 0.04
1.33 (60Co Photopeak) 5.67 ? 0.03 6.66 ? 0.18
1.17 (60Co Photopeak) 5.46 ? 0.02 5.89 ?0.13
2.51 (60Co Sum peak) 3.82 ? 0.11 4.10 ? 0.24
Resolution FWHM 100 / Mean
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
31
DPP-CI Other Tests
  • Tested with SiPM/MPPC detectors at Univerità
    dellInsubria (Como Italy) and in CAEN
    (2009/2010)
  • Dark Counting Rate
  • LED pulser
  • Readout of a 3x3mm Lyso Crystal Gamma source
  • Readout of a scintillator tile for beta particles

Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
32
DPP for ?-n Discrimination
  • Digital implementation of the ?E/E or Rise Time
    discriminator (both are Pulse Shape Analysis)
  • Digital ?E/E double gate charge integration
    (same as DPP-CI but with two gates) applied to
    fast detectors (typ. organic liquid
    scintillators)
  • Digital Rise Time discrimination ?T in the Zero
    Crossing of two CFDs at 25 and 75 applied to
    integrated output (either from C.S. preamp or
    digital integrator)
  • PSA used to discard unwanted events (typ.
    gammas) good events saved including waveform,
    energy and time stamp
  • Dead-timeless acquisition (no conversion time)
  • Algorithms tested at Duke University on July 2010
    (off-line). FPGA implementation just finished.
    Will be tested next week.

Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
33
DPP-NG vs DPP-CI
  • Dual Gate
  • Gate position and length settings with 4 ns
    granularity (DPP-CI has 8 ns)
  • Gate position can be referred to either the
    threshold crossing or the pulse peak
  • PSD parameter QSHORT / (QLONG-QSHORT) can be used
    to decide whether an event has to be saved or
    discarded
  • Better baseline restoration
  • Improved readout (event packing)
  • Two Channel coincidence discontinued
  • Need big FPGA option!

Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
34
?-n Discrimination Block Diagram (I)
Algorithms tested off-line Firmware under test
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
35
?-n Discrimination Block Diagram (II)
Algorithms tested off-line Firmware not planned
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
36
?-n Discrimination preliminary results (I)
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
37
?-n Discrimination preliminary results (II)
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
38
?-n Discrimination preliminary results (III)
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
39
?-n Discrimination preliminary results (IV)
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
40
DPP for Time Measurements
  • Digital implementation of the TDC CFD
  • DPP-TF and DPP-CI give time stamps with the
    resolution of the sampling period (10 ns and 4
    ns, ? Ts/?12) interpolation can improve timing
    resolution
  • Extremely high dynamic range
  • Dead-timeless acquisition (no conversion time)
    can manage long bursts of pulses (theoretical
    unlimited double pulse resolution)
  • Big dependence of the resolution from the
    rise-time and amplitude of the pulses (?V/ ?T)

Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
41
Digital CFD and Timing Filters
NOTE the higher ZC slope and the lower tail, the
better filter
42
ZC timing errors
  • The timing resolution is affected by three main
    sources of noise
  • Electronic noise in the analog signal (not
    considered here)
  • Quantization error Eq
  • Interpolation error Ei
  • Both simulations and experimental test
    demonstrate that there are two different regions
  • When Rise Time gt 5Ts the pulse edge can be well
    approximated to a straight line, hence Ei is
    negligible. The resolution is proportional to the
    rise time and to the number of bits of the ADC.
  • When Rise Time lt 5Ts the approximation to a
    straight line is too rough and Ei is the dominant
    source of error. The resolution is still
    proportional to the number of bit but becomes
    inversely proportional to the rise time.
    Resolution improvement expected for cubic
    interpolation.
  • The best resolution is for Rise Time 5Ts,
    regardless the type of digitizer
  • The resolution is always proportional to the
    pulse amplitude (more precisely to the slope
    ?V/?T)

Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
43
Sampling Clock phase effect (RTlt5Ts) (I)
When rise time lt 5Ts, the interpolation error
has a big variation with the phase between the
rising edge and the sampling clock.
  • DELAYAB N Ts
  • same clock phase for A and B ?
  • same interpolation error ?
  • ERRA ? ERRB ?
  • Error cancellation in calculating TIMEAB
  • DELAYAB (N0.5) Ts
  • rotated clock phase for A and B ?
  • different interpolation error ?
  • ERRA ? ERRB ?
  • No error cancellation. ERRA and ERRB are
    symmetric twin peak distribution

TIMEAB (ZCA ERRA) (ZCB ERRB) ZCA ZCB
(ERRA - ERRB )
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
44
Sampling Clock phase effect (RTlt5Ts) (II)
DELAY N Ts
DELAY (N 0.5) Ts
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
45
Sampling Clock phase effect (RTlt5Ts) (III)
Vpp 100mV Rise Time Ts Emulation
14bit 100MSps
12bit 250MSps
10bit 1GSps
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
46
Sampling Clock phase effect (RTlt5Ts) (IV)
Vpp 100mV Mod720 12bit 250MSps Emulation
5 ns
10 ns
15 ns
Rise Time
20 ns
30 ns
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
47
Preliminary results Mod724
(14 bit, 100 MS/s)
DELAYAB (N0.5) Ts (worst case)
50 mV
StdDev (ns)
100 mV
200 mV
500 mV
RiseTime (ns)
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
48
Preliminary results Mod720
(12 bit, 250 MS/s)
DELAYAB (N0.5) Ts (worst case)
50mV
100mV
200mV
StdDev (ns)
500mV
RiseTime (ns)
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
49
Preliminary results Mod751
(10 bit, 1 GS/s)
DELAYAB (N0.5) Ts (worst case)
50mV
100mV
200mV
StdDev (ns)
500mV
NOTE the region with Rise Time lt 5Ts (5 ns) is
missing in this plot
RiseTime (ns)
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
50
Mod724 vs Mod720 vs Mod751
Amplitude 100 mV
10 bit, 1 GS/s
12 bit, 250 MS/s
14 bit, 100 MS/s
StdDev (ns)
RiseTime (ns)
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
51
Mod751 _at_ 2 GS/s
The cubic interpolation can reduce the gap
between best and worst case as well as increase
the resolution for small signals!
StdDev (ns)
RT 1 ns - worst case
RT 5 ns
RT 1 ns - best case
? ? 2 ps !
Amplitude (mV)
Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
52
DPP for Pulse Counting (SCA)
  • Digital implementation of the discriminator
    scaler (Single-Channel Analyzer)
  • Can be implemented in the high density digitizers
    (mod. 740)
  • Pulse Triggering baseline restoration, noise
    rejection, etc
  • Single or Multi-Channel Energy Windowing

Reproduction, transfer, distribution of part or
all of the contents in this document in any form
without prior written permission of CAEN S.p.A.
is prohibited
Write a Comment
User Comments (0)
About PowerShow.com
