Programowanie obiektowe w jezyku Java Threads
Bartosz Sakowicz
2
Threads - basics
A thread is a single sequential flow of control
within a program. A thread itself is not a
program it cannot run on its own. Rather, it
runs within a program.
3
Threads basics(2)

• Some texts use the name lightweight process
  instead of thread.
• A thread is similar to a real process in that a
  thread and a running program are both a single
  sequential flow of control.
• A thread is considered lightweight because it
  runs within the context of a full-blown program
  and takes advantage of the resources allocated
  for that program and the program's environment.
• As a sequential flow of control, a thread must
  carve out some of its own resources within a
  running program. (It must have its own execution
  stack and program counter for example) The code
  running within the thread works only within that
  context. Thus, some other texts use execution
  context as a synonym for thread.

4
Using the Timer and TimerTask
import java.util. public class Reminder
Timer timer public Reminder(int seconds)
timer new Timer() timer.schedule(new
RemindTask(), seconds1000) class RemindTask
extends TimerTask public void run()
System.out.println("Time's up!")
timer.cancel() //Terminate the timer thread
public static void main(String args)
new Reminder(5) System.out.println("Task
scheduled.")
5
Scheduling task for execution at particular hour
... //Date corresponding to 100100 pm
today. Calendar calendar Calendar.getInstance()
calendar.set(Calendar.HOUR_OF_DAY,
22) calendar.set(Calendar.MINUTE,
1) calendar.set(Calendar.SECOND, 0) Date time
calendar.getTime() timer new Timer()
timer.schedule(new RemindTask(), time) ...
6
Stoping Timer Threads

• By default, a program keeps running as long as
  its timer threads are running. You can terminate
  a timer thread in four ways
• Invoke cancel on the timer. You can do this from
  anywhere in the program, such as from a timer
  tasks run method.
• Make the timers thread a daemon by creating
  the timer like this new Timer(true). If the only
  threads left in the program are daemon threads,
  the program exits.
• After all the timers scheduled tasks have
  finished executing, remove all references to the
  Timer object. Eventually, the timers thread will
  terminate.
• Invoke the System.exit method, which makes the
  entire program (and all its threads) exit.

7
Programming threads

• There are two techniques for providing a run
  method for a thread
• Subclassing Thread and Overriding run
• Implementing the Runnable Interface
• java.lang.Thread represents a thread of
  control. It offers methods that allow you to set
  the priority of the thread, to assign a thread to
  a thread group and to control the running state
  of the thread (e.g., whether it is running or
  suspended).
• The java.lang.Runnable interface represents the
  body of a thread. Classes that implement the
  Runnable interface provide their own run()
  methods that determine what their thread actually
  does while running. If a Thread is constructed
  with a Runnable object as its body, the run()
  method on the Runnable will be called when the
  thread is started.

8
Programming threads(2)
There are two ways to define a thread One is
to subclass Thread, override the run() method,
and then instantiate your Thread subclass. The
second is to define a class that implements the
Runnable method (i.e., define a run() method) and
then pass an instance of this Runnable object to
the Thread() constructor. In either case, the
result is a Thread object, where the run() method
is the body of the thread.
9
Programming threads(3)
When you call the start() method of the Thread
object, the interpreter creates a new thread to
execute the run() method. This new thread
continues to run until the run() method exits, at
which point it ceases to exist. Meanwhile, the
original thread continues running itself,
starting with the statement following the start()
method.
10
Programming threads(4)
final List list // Some unsorted list
initialized elsewhere / A Thread class for
sorting a List in the background / class
BackgroundSorter extends Thread List l
public BackgroundSorter(List l) this.l l
public void run() Collections.sort(l)
11
Programming threads(5)
... Thread sorter new BackgroundSorter(list)
// Start it running / the new thread runs
the run() method above, while the original thread
continues with whatever statement comes next/
sorter.start() // Here's another way to
define a similar thread Thread t new
Thread(new Runnable() public void run()
Collections.sort(list) ) t.start() ...
12
Subclassing Thread
public class SimpleThread extends Thread
public SimpleThread(String str) super(str)
public void run() for (int i 0 i lt 10
i) System.out.println(i " "
getName()) try sleep((long)(Math.rando
m() 1000)) catch (InterruptedException
e) //thrown when other thread //
interrupt when one sleeping
System.out.println("DONE! " getName())
13
Implementing Runnable
The difference between the two classes is that a
Thread is supposed to represent how a thread of
control runs (its priority level, the name for
the thread), and a Runnable defines what a thread
runs. In both cases, defining a subclass usually
involves implementing the run() method to do
whatever work you want done in the separate
thread of control. If your class must
subclass some other class (the most common
example being Applet), you should use Runnable.
14
Creating threads
public class TwoThreadsDemo public static
void main (String args) new
SimpleThread("One").start() new
SimpleThread("Two").start()
15
The Thread Life Cycle(2)
public class Clock extends Applet implements
Runnable private Thread clockThread null
public void start() if (clockThread
null) //we check if the user
//already have seen an applet // create a
Thread clockThread new Thread(this,
"Clock") // start a Thread clockThread.sta
rt()
16
The Thread Life Cycle
17
Making a Thread not runnable

• A thread becomes not runnable when one of these
  events occurs
• Its sleep method is invoked.
• The thread calls the wait method to wait for a
  specific condition to be satisifed.
• The thread is blocking on I/O.
• The escape route for every entrance into the not
  runnable state
• If a thread has been put to sleep, then the
  specified number of milliseconds must elapse.
• If a thread is waiting for a condition, then
  another object must notify the waiting thread of
  a change in condition by calling notify or
  notifyAll.
• If a thread is blocked on I/O, then the I/O must
  complete.

18
Stopping a Thread
A thread arranges for its own death by having a
run method that terminates naturally. For
example, the while loop in this run method is a
finite loop - it will iterate 100 times and then
exit public void run() int i 0
while (i lt 100) i
System.out.println("i " i)
A thread with this run method dies naturally when
the loop completes and the run method exits.
19
Interrupts
An interrupt is an indication to a thread that
it should stop what it is doing and do something
else. A thread sends an interrupt by invoking
interrupt on the Thread object for the thread to
be interrupted.
20
Supporting interruption

• Situation when thread often invokes methods which
  throw InterruptedException
• for (int i 0 i lt importantInfo.length i)
• try
• Thread.sleep(4000) //Pause for 4 seconds
• catch (InterruptedException e)
• return //We've been interrupted no more
  messages.
• System.out.println(importantInfoi) //Print a
  message

21
Supporting interruption (2)
2) If a thread goes a long time without invoking
a method that throws InterruptedException, it
must periodically invoke Thread.interrupted,
which returns true if an interrupt has been
received for (int i 0 i lt inputs.length
i) heavyCrunch(inputsi) if
(Thread.interrupted()) //We've been
interrupted no more crunching. return
OR in more complex applications if
(Thread.interrupted()) throw new
InterruptedException()
22
The interrupt status flag

• The interrupt mechanism is implemented using an
  internal flag known as the interrupt status.
• Invoking Thread.interrupt sets this flag.
• When a thread checks for an interrupt by invoking
  the static method Thread.interrupted, interrupt
  status is cleared.
• The non-static Thread.isInterrupted, which is
  used by one thread to query the interrupt status
  of another, does not change the interrupt status
  flag.
• By convention, any method that exits by throwing
  an InterruptedException clears interrupt status
  when it does so. However, it's always possible
  that interrupt status will immediately be set
  again, by another thread invoking interrupt.

23
Joins
The join method allows one thread to wait for the
completion of another. If t is a Thread object
whose thread is currently executing t.join()
causes the current thread to pause execution
until t's thread terminates. Overloads of join
allow the programmer to specify a waiting period.
Like sleep, join responds to an interrupt by
exiting with an InterruptedException.
24
Thread priority

• When a Java thread is created, it inherits its
  priority from the thread that created it.
• You can also modify a thread's priority at any
  time after its creation using the setPriority
  method.
• Thread priorities are integers ranging between
  MIN_PRIORITY and MAX_PRIORITY (constants defined
  in the Thread class).
• The higher the integer, the higher the priority.
• At any given time, when multiple threads are
  ready to be executed, the runtime system chooses
  the runnable thread with the highest priority for
  execution.
• At any given time, the highest priority thread is
  running, but this is not guaranteed. For this
  reason, use priority only to affect scheduling
  policy for efficiency purposes. Do not rely on
  thread priority for algorithm correctness.

25
The consumer/producer example (synchronization)

• The Producer generates an integer between 0 and
  9 and stores it in a CubbyHole object, and
  prints the generated number.
• The Consumer consumes all integers from the
  CubbyHole (the exact same object into which the
  Producer put the integers) as quickly as they
  become available.

26
The consumer/producer ...(2)
public class Producer extends Thread private
CubbyHole cubbyhole private int number
public Producer(CubbyHole c, int number)
cubbyhole c this.number number
public void run() for (int i 0 i lt 10
i) cubbyhole.put(i) System.out.println(
"Producer " this.number " put " i)
try sleep((int)(Math.random()
100)) catch (InterruptedException e)

27
The consumer/producer ...(3)
public class Consumer extends Thread private
CubbyHole cubbyhole private int number
public Consumer(CubbyHole c, int number)
cubbyhole c this.number number
public void run() int value 0 for (int
i 0 i lt 10 i) value cubbyhole.get()
System.out.println("Consumer " this.number
" got " value)
28
The consumer/producer ...(4)
One problem arises when the Producer is quicker
than the Consumer (e.g. higher priority) and
generates two numbers before the Consumer has a
chance to consume the first one. Part of the
output might look like this Consumer 1 got
3 Producer 1 put 4 Producer 1 put 5
Consumer 1 got 5 Or Consumer is quicker
then Producer Producer 1 put 4 Consumer
1 got 4 Consumer 1 got 4 Producer 1
put 5
29
The consumer/producer ...(5)
The main program public class
ProducerConsumerTest public static void
main(String args) CubbyHole c new
CubbyHole() Producer p1 new Producer(c,
1) Consumer c1 new Consumer(c, 1)
p1.start() c1.start()
30
The consumer/producer ...(6)

• Problems such as described are called race
  conditions.
• The activities of the Producer and Consumer must
  be synchronized in two ways
• The two threads must not simultaneously access
  the CubbyHole. A Java thread can prevent this
  from happening by locking an object. When an
  object is locked by one thread and another thread
  tries to call a synchronized method on the same
  object, the second thread will block until the
  object is unlocked.
• The two threads must do some simple
  coordination. That is, the Producer must have
  some way to indicate to the Consumer that the
  value is ready and the Consumer must have some
  way to indicate that the value has been
  retrieved.

31
The consumer/producer ...(7)
Will it work? public class CubbyHole private
int contents private boolean available
false public synchronized int get() if
(available true) available false return
contents public synchronized void
put(int value) if (available false)
available true contents value
Answer No, it will not.
32
The consumer/producer ...(8)
The correct implementation of get method public
synchronized int get() while (available
false) try wait() // wait for
Producer to put value catch
(InterruptedException e) available
false notifyAll() // notify Producer that
value has been retrieved return contents
33
The consumer/producer ...(9)
The correct implementation of put method public
synchronized void put(int value) while
(available true) try wait() //
wait for Consumer to get value catch
(InterruptedException e) contents
value available true notifyAll() //
notify Consumer that value has been set
34
notifyAll, notify and wait
The notifyAll method wakes up all threads
waiting on the object in question (in this case,
the CubbyHole). The awakened threads compete for
the lock. One thread gets it, and the others go
back to waiting. The Object class also defines
the notify method, which arbitrarily wakes up one
of the threads waiting on this object (but you
cannot choose which). There are two other
versions of the wait method wait(long timeout)
Waits for notification or until the timeout
period has elapsed. timeout is measured in
milliseconds. wait(long timeout, int nanos)
Waits for notification or until timeout
milliseconds plus nanos nanoseconds have elapsed.
35
Atomic access

• In programming, an atomic action is one that
  effectively happens all at once.
• Increment expression, such as c, does not
  describe an atomic action.
• Actions that are atomic
• Reads and writes are atomic for reference
  variables and for most primitive variables (all
  types except long and double).
• Reads and writes are atomic for all variables
  declared volatile (including long and double
  variables).
• Changes to a volatile variable are always visible
  to other threads.
• Using simple atomic variable access is more
  efficient than accessing these variables through
  synchronized code.

36
Deadlock
The philosophers problem Five philosophers are
sitting at a round table. In front of each
philosopher is a bowl of rice. Between each pair
of philosophers is one chopstick. Before an
individual philosopher can take a bite of rice he
must have two chopsticks--one taken from the
left, and one taken from the right. The
philosophers must find some way to share
chopsticks such that they all get to eat. What
is a solution, when all starts immediately?
37
Deadlock (2)
We can change the rules by numbering the
chopsticks 1 through 5 and insisting that the
philosophers pick up the chopstick with the lower
number first. The philosopher who is sitting
between chopsticks 1 and 2 and the philosopher
who is sitting between chopsticks 1 and 5 must
now reach for the same chopstick first (chopstick
1) rather than picking up the one on the right.
Whoever gets chopstick 1 first is now free to
take another one. Whoever doesn't get chopstick 1
must now wait for the first philosopher to
release it. Deadlock is not possible. The best
choice is to prevent deadlock rather than to try
and detect it. Deadlock detection is very
complicated . The same with starvation.
38
Starviation and Livelock
Starvation describes a situation where a thread
is unable to gain regular access to shared
resources and is unable to make progress. This
happens when shared resources are made
unavailable for long periods by "greedy" threads.
For example, suppose an object provides a
synchronized method that often takes a long time
to return. If one thread invokes this method
frequently, other threads that also need frequent
synchronized access to the same object will often
be blocked. Livelock A thread often acts in
response to the action of another thread. If the
other thread's action is also a response to the
action of another thread, then livelock may
result. As with deadlock, livelocked threads are
unable to make further progress. However, the
threads are not blocked they are simply too
busy responding to each other to resume work
39
Grouping Threads
Every Java thread is a member of a thread group.
Thread groups provide a mechanism for collecting
multiple threads into a single object and
manipulating those threads all at once, rather
than individually. For example, you can start or
suspend all the threads within a group with a
single method call. Java thread groups are
implemented by the ThreadGroup class in the
java.lang package. The runtime system puts a
thread into a thread group during thread
construction. When you create a thread, you can
either allow the runtime system to put the new
thread in some reasonable default group or you
can explicitly set the new thread's group. The
thread is a permanent member of whatever thread
group it joins upon its creation - you cannot
move a thread to a new group after the thread has
been created.
40
The default Thread Group

• If you create a new Thread without specifying
  its group in the constructor, the runtime system
  automatically places the new thread in the same
  group as the thread that created it.
• When a Java application first starts up, the
  Java runtime system creates a ThreadGroup named
  main. Unless specified otherwise, all new threads
  that you create become members of the main thread
  group.
• If you create a thread within an applet, the new
  thread's group may be something other than main,
  depending on the browser or viewer that the
  applet is running in

41
Creating Thread in a Group
ThreadGroup myTG new ThreadGroup( "My Group
of Threads") Thread myThread new
Thread(myTG, "a thread for my group") To find
out what group a thread is in, you can call its
getThreadGroup method theGroup
myThread.getThreadGroup()
42
The ThreadGroup class
ThreadGroups can contain not only threads but
also other ThreadGroups. The top-most thread
group in a Java application is the thread group
named main. You can create threads and thread
groups in the main group. You can also create
threads and thread groups in subgroups of main.
43
High level concurrency API
Lock objects support locking idioms that
simplify many concurrent applications.
Executors define a high-level API for launching
and managing threads. Executor implementations
provided by java.util.concurrent provide thread
pool management suitable for large-scale
applications. Concurrent collections make it
easier to manage large collections of data, and
can greatly reduce the need for synchronization.
Atomic variables have features that minimize
synchronization and help avoid memory consistency
errors.
