Title: Daniel Lerner


1
Daniel Lerner
Presentation 1 Basic Concept and Terminology
2
History of MPLS
The mid-1990s saw a large effort by many
private corporations to design a networking
solution that would marry two popular routing
solutions, IP and ATM, in an effort to gain the
speed of a costly ATM-based solution with a much
cheaper and easier (and yet slower) IP-based
solution. Companies that participated in this
effort included Ipsilon - IP
Switching Cisco Systems - tag
switching IBM - Aggregate route-based IP
switching Cascade - IP navigator
Otherwise known as the Olden days of the Modern
Internet
3
These products attempted to improve the
throughput and delay performance of IP by
utilizing standard routing protocols to create
the idea of paths between endpoints. Packets
would enter into the network and be assigned a
particular path based on the characteristics of
the packet. Within the network, ATM switches,
which then were faster than IP routers, would
then be used to pass the packets along the
network path quickly and efficiently.
4
In 1997, the IETF created the MPLS working group
in an effort to devise a standardized approach to
the problem. In 2001, the group put forward the
first set of Proposed Standards. By this time,
however, the networking industry had produced
IP-based routers that performed at comparable
speeds to ATM switches, negating the original
need for the MPLS solution.
5
Why do we still need MPLS?
Although the original need for MPLS had been met
by the increase in the performance of IP-based
routers, there is still a great deal of interest
in MPLS as an emerging protocol. Not only can
MPLS improve the performance of routers when
placed on top of IP, but MPLS provides new
capabilities important to areas of networking
such as Quality of Service, traffic engineering,
multiprotocol support, and Virtual Private
Networks.
6
How it all works (The Simple Version)
Our Network of Routers
Yeah, I know, the symbols shown are technically
for switches on a network. I couldnt make
PowerPoint draw the correct symbol. So lets
just pretend, shall we?
7
How it all works (The Simple Version)
P
In a non-MPLS based network, once a packet enters
the network
8
How it all works (The Simple Version)
P
that packet is processed at each node it
encounters before being sent onwards to a node
closer to its destination.
9
How it all works (The Simple Version)
P
that packet is processed at each node it
encounters before being sent onwards to a node
closer to its destination.
10
How it all works (The Simple Version)
P
that packet is processed at each node it
encounters before being sent onwards to a node
closer to its destination.
11
How it all works (The Simple Version)
P
that packet is processed at each node it
encounters before being sent onwards to a node
closer to its destination.
12
How it all works (The Simple Version)
P
that packet is processed at each node it
encounters before being sent onwards to a node
closer to its destination.
13
How it all works (The Simple Version)
P
that packet is processed at each node it
encounters before being sent onwards to a node
closer to its destination.
14
How it all works (The Simple Version)
P
that packet is processed at each node it
encounters before being sent onwards to a node
closer to its destination.
15
How it all works (The Simple Version)
P
that packet is processed at each node it
encounters before being sent onwards to a node
closer to its destination.
16
How it all works (The Simple Version)
At each node, we at the very least examine the
headers for the Data Link Layer (layer 2) and the
Network Layer (layer 3) for routing information
before repackaging the packet and sending it on
its way.
These days its not unheard of to go even farther
into the protocol stack to extract information
from the Transport and Application Layers!
17
How it all works (The Simple Version)
Thats quite a bit of processing done by a bunch
of nodes in our network! Surely there must be a
better way!
18
How it all works (The Simple Version)
MPLS reduces the amount of processing done by
interior nodes in the network by creating paths
that only forward certain kinds of traffic
through the network. Packets are processed by
an ingress router, examined for particular
characteristics, and then shuttled down a
particular path on its way to a destination. As
the path only accepts certain packets, the
processing at each node on the path is quick and
efficient. How are these packets guided down this
path?
19
How it all works (The Simple Version)
MPLS reduces the amount of processing done by
interior nodes in the network by creating paths
that only forward certain kinds of traffic
through the network. Packets are processed by
an ingress router, examined for particular
characteristics, and then shuttled down a
particular path on its way to a destination. As
the path only accepts certain packets, the
processing at each node on the path is quick and
efficient. How are these packets guided down this
path?
LABELS
20
Multi-Protocol Label Switching
P
The packet enters our network at our ingress
Label Switch Router (LSR).
21
Multi-Protocol Label Switching
P
Based on its characteristics, a path is
determined for the packet
22
Multi-Protocol Label Switching
P
L
And a Label is assigned to that packet
23
Multi-Protocol Label Switching
By using that label, the packet is quickly
forwarded to its destination without the need for
each intermediate node to process the IP
information for that packet
24
Too Simple?
Of course, that explanation was really a gross
simplification of the actual process. Lets take
a closer look at the process.
25
Forwarding Equivalency Classes
When a packet enters into an MPLS network, the
MPLS edge router classifies the packet as part of
a particular Forwarding Equivalency Class.
Based on information gleaned from the packet
such as source/destination address, the physical
interface the packet arrived on, Quality of
Service requirements, etc, these groups of
packets are forwarded through the MPLS network
over the same path with the same treatment.
26
Labels
Once it has been placed into a particular
Forwarding Equivalency Class, the packet is
assigned a label that identifies it as part of
that FEC. These labels are 32 bits long, and
consist of four sections
0
19
23
24
31
Label
EXP
TTL
Bits 0 - 19 Label Portion Bits 20 - 22
Experimental Use Bit 23 Bottom of the
Stack? Bits 24 - 31 TTL
27
Labels
0
19
23
24
31
Label
EXP
TTL
The Label portion of the label is a 20-bit long
field that denotes which FEC the packet belongs
to. In general, a label has significance LOCAL
to the nodes on either side of a particular link
only (allowing for greater flexibility in our
label domain).
28
Labels
0
19
22
24
31
Label
EXP
TTL
Bits 20 through 22 are reserved for experimental
use.
29
Labels
0
19
22
24
31
Label
EXP
TTL
Bit 23 is used to denote the bottom of a label
stack (discussed later). It is set to 1 for the
label at the bottom of the stack and 0 for all
other labels.
30
Labels
0
19
22
24
31
Label
EXP
TTL
Bits 24 through 31 are used to store the TTL
value for the packet. When a packet enters an
MPLS network, its TTL value is copied into this
field and adjusted as normal as the packet
traverses the network. When the packet leaves
the MPLS network, the value of its TTL is
modified appropriately.
31
Label Switch Paths (LSPs)
FEC 1
FEC 2
The Label Switch Path is the path that a
particular FEC utilizes as it sends packets
through the network.
32
Label Switch Routers (LSRs)
  • LSRs are nodes in our network that can forward
    MPLS packets. They are commonly referred to as
  • Edge Routers
  • These routers process incoming outgoing packets
    (ingress LSRs egress LSRs respectively),
    assigning them to particular FECs, or preparing
    them to leave the MPLS network.
  • Internal Routers
  • -- these routers pass labeled packets quickly
    through the network.

33
So what happens when a packet enters an MPLS
network? (Basic Version)
Ingress LSR
P
34
  • The ingress LSR examines the packet, looking for
    pieces of information it needs to assign the
    packet a label. This information could be
    extracted from
  • The physical characteristics of the packet (size,
    physical interface of arrival)
  • The network layer header (source/destination
    address, TOS, TTL, etc)
  • The transport layer header (source/destination
    port, flags, etc)
  • Quality of Service requirements that may exist
  • Information about the application itself
  • depending on the policies determined by the
    network administrator.

P
35
  • The ingress LSR does two things at this point
  • it determines which FEC the incoming packet
    belongs to based on the information gathered from
    the packet. It then assigns the appropriate
    label to the packet.
  • it takes the TTL value out from the packet and
    places it into the label entry, in order to
    properly handle the packets time out value as it
    passes through the MPLS network

TTL
Label
Packet Header
Data
The stack bit is set to 1
36
P
L2
At this point, the labeled packet is ready to be
sent through the network. The ingress LSR has a
table that states how the packet should be sent
to the next hop.
Out iface
Out label
FEC
A
1
L1
B
2
L2
C
3
L3
37
P
L2
At this point, the labeled packet is ready to be
sent through the network. The ingress LSR has a
table that states how the packet should be sent
to the next hop.
38
P
L2
39
P
L2
Compared to the ingress LSR, interior LSRs have a
much simpler task set before them
40
P
L2
Incoming label
Incoming iface
Outgoing label
Outgoing iface
L1
1
4
La
L1
5
3
Lb
L2
1
3
Lc
L3
2
3
Ld
L4
1
4
Le
L4
1
4
Lf
The interior LSR merely has to translate the
incoming label on the incoming interface
according to its transition table. After the
LSR adjusts the packets TTL, it can forward on
the packet in one of two ways
41
Stacking vs Swapping
According to the MPLS specification, the LSR can
either swap out the old label for a new label and
forward the packet onwards, or stack the new
label on top of the old one.
P
L2
P
Lc
OR
P
L2
P
Lc
L2
42
Swapping
Normally, nodes in an MPLS network merely swap
out labels upon receiving a packet before
forwarding the packet onwards.
P
L2
43
Swapping
Normally, nodes in an MPLS network merely swap
out labels upon receiving a packet before
forwarding the packet onwards.
P
L2
Incoming label
Incoming iface
Outgoing label
Outgoing iface




L2
1
3
Lc




44
Swapping
Normally, nodes in an MPLS network merely swap
out labels upon receiving a packet before
forwarding the packet onwards.

P
Lc
Incoming label
Incoming iface
Outgoing label
Outgoing iface




L2
1
3
Lc




dont forget to decrement the TTL
45
Stacking
As an alternative to merely swapping out labels,
our network could operate with a hierarchical
stack of labels. The interior LSRs could push
new labels on top of our stack of labels and send
it onwards, or pop a label off our stack before
it traverses to the next hop. As defined by the
RFC, the network would only be working with
labels a the top of the stack (though future uses
of MPLS could change that).
46
Stacking
P
L2
Our labeled packet is sent out from our first LSR
47
Stacking
P
L2
La
P
L2
The next LSR in the LSP pushes a new label (La)
onto the label stack before sending the packet
onwards
48
Stacking
P
L2
LG
P
L2
La
Here we see that the third node in our LSP swaps
the top level label for a new one (LG). The use
of stacking does not exclude the use of label
swapping.
49
Stacking
P
L2
The fourth node pops the top level label off the
label stack before forwarding the packet onwards
through the network.
50
Why Stack?
There are several reasons to utilize stacking for
labels. Lets expand the example we were just
working with to give us a clearer picture.
51
This is the view of the LSP we saw last time.
But what could this network really look like?
52
(No Transcript)
53
Of course, this is somewhat of an exaggeration,
but what we see here is a network where many LSPs
share a series of hops regardless of the FEC the
incoming packets might belong to.
54
We chose here to utilize label stacking to
aggregate these LSPs together for a series of
hops before allowing them to go their separate
way.
55
We can also use label stacking for other
purposes. Our last example showed aggregation of
stacks due to physical restrictions. We could
also chose to aggregate LSPs for conceptual
reasons
Georgia Tech Faculty computer traffic
Georgia Tech Faculty computer traffic
Georgia Tech computer traffic
Georgia Tech Resnet computer traffic
The Pipe
Georgia Tech Resnet computer traffic
UGA Faculty computer traffic
UGA Faculty computer traffic
UGA computer traffic
UGA Resnet computer traffic
UGA Resnet computer traffic
56
  • Label stacks can also be used
  • When crossing administrative domains within the
    same network or for a distributed network.
  • To establish tunnels for VPNs (BGP/MPLS VPNs)
  • To carry information about a given application
    before being processed by the network

57
Back to the problem at hand
Our Packet enters the network via the ingress LSR
58
Back to the problem at hand
Based on its characteristics, the packet will
follow an LSP.
59
Back to the problem at hand
60
Routing Hop-by-hop vs Explicit
  • Now that we kind of see how our packets travel
    through our MPLS network, lets explore how they
    are ROUTED through our MPLS network.
  • MPLS supports two different flavors of routing
  • Hop-by-hop routing
  • Explicit routing

61
Hop-by-hop routing in an MPLS network
With hop-by-hop routing, we revert back to our
traditional model of routing where each LSR
makes its own decision on how to route an
incoming labeled packet utilizing an ordinary
routing algorithm such as OSPF.
62
Hop-by-hop why?
Hop-by-hop routing is relatively simple to set up
in comparison to explicit routing as we shall
see. As we are still in an MPLS network, we can
still do fast switching based on labels, stack
labels to aggregate LSPs and convey information,
and have differential service for FECs.
63
Hop-by-hop why not?
As most traditional routing algorithms do not
keep track of many performance metrics of network
operation, we lose our capability for traffic
engineering and policy routing.
64
Explicit Routing in an MPLS network
  • With explicit routing, a packets entire path
    through a network is determined at the ingress
    LSR. Each LSR becomes a switch, quickly and
    efficiently forwarding packets based solely on
    their label along the LSP.
  • Explicit routing comes in two distinct flavors
    itself
  • Static explicit routing -- all possible LSPs are
    set up ahead of time
  • Dynamic explicit routing -- the routes may change
    over time as conditions warrant.

65
Dynamic Explicit Routing what do we need?
  • In order to set up dynamic explicit routing
    successfully, the LSR setting up the LSPs would
    need to know a bit of information about the
    network
  • The topology of the network
  • QoS-related information about that network
  • Attributes associated with an FEC(s) that
    collectively specify their behavioral
    characteristics.
  • Attributes associated with physical resources
    (LSRs, links) that constrain the placement of
    LSPs through them.

66
Dynamic Explicit Routing what do we need?
The LSR determining the LSPs then utilizes that
information in its routing algorithm. This
algorithm, known as a constraint-based routing
algorithm is aware of the networks utilization,
capacity, and committed services at all times and
adjust paths appropriately should conditions
change. Traditional routing algorithms, limited
in the cost metrics they account for, can not be
used in Dynamic Explicit Routing. New and more
complex algorithms (such as enhanced OSPF) are
required.
67
Uses for MPLS
The original need for MPLS as a marriage of IP
ATM technologies has passed. And yet, MPLS
continues to grow in popularity as scientists and
engineers explore the possibilities that this
fresh look at an old idea has to offer
  • Connection Oriented QoS
  • Traffic Engineering
  • VPNs
  • Application Based Switching
Write a Comment
User Comments (0)
About PowerShow.com
