The Skeletal System

1
The Skeletal System

• Chapter 6
• Anatomy and Physiology
• Mr. Knowles
• Liberty Senior High School

2
Question of the Day!

• Do bones remain the same?
• How do bones know when to stop growing? What
  happens when they dont?

3
The Skeletal System! Our First System

• Cells (Osteocytes)
• Tissues (Osseous Tissue)
• Organs (Bones)
• Systems (Skeletal)

4
All C.T. have Three Parts

• 1. Specialized Cells
• 2. Extracellular Protein Fibers
• 3. The Fibers above and a ground substance
  (usually a liquid)- make up the Matrix that
  surrounds cells. (most of the volume of C.T.)

5
The Fibers

• Collagen Fibers- long, straight, unbranched,
  fibers of twisted protein rope-like, very
  flexible, yet strong. (Tendons and Ligaments)

6
Bone (Osseous Tissue)

• G.S. almost no liquid collagen fibers
  calcium salts (CaPO4 and some CaCO3)
• Strong and flexible properties.
• Lacunae in matrix contain osteocytes.

7
Bone (Osseous Tissue)

• Lacunae organized around a central canal
  (Haversian canal) which contains blood vessels.
• Diffusion cannot occur through calcium salts.
• Cytoplasm of osteocytes extend to central canal
  by canaliculi.

8
A Basic Pattern in Bone Tissue

• Lacunae with osteocytes arranged around and
  connected to a central canal by radiating
  canaliculi- Osteon
• Many osteons in one bone.

9
(No Transcript)
10
Bone-Low Mag.
11
Haversian or Central Canal
12
Bone-High Mag.
13
Osteons
14
Bone (Osseous Tissue)

• Bone surfaces covered by periosteum- fibrous
  layer of C.T. attachment for tendons and
  ligaments.
• Site of appositional growth of bone.
• Bone is constantly remodeled- grow thicker with
  stresses.

15
(No Transcript)
16
(No Transcript)
17
Anatomy of Bone (4 Parts)

• 1. Diaphysis- long, tubular shaft, mostly compact
  bone.
• 2. Epiphysis- expanded areas at the ends of bone,
  mostly spongy bone.

18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
Anatomy of Bone (4 parts)

• 3. Marrow Cavity- core of bone with red and
  yellow marrow.
• 4. Metaphysis- area that connects the epiphysis
  and diaphysis. Contains the Epiphyseal plate-
  area of growth between epiphysis and diaphysis

22
Other Parts to Bone

• Periosteum- outermost layer of bone made of
  cells and fibers.
• Provides the point of attachment for tendons
  and ligaments on the outside.
• Route for vessels to enter the bone.
• Participates in bone growth and repair.

23
(No Transcript)
24
(No Transcript)
25
Other Parts of the Bone

• Endosteum- a layer of cells that lines marrow
  cavity lines trabeculae of spongy bone and
  central canal of compact bone.
• Also site of bone growth.

26
Two Types of Osseous Tissue

• 1. Compact bone- dense bone, solid, more on
  surface of bone, shaft of bone.
• Function osteons are all alignedstrengthen
  bone, the tissue of bone is parallel to stresses.

27
Two Types of Osseous Tissue

• 2. Spongy Bone- open network of trabeculae which
  are struts and plates in the interior of bone
  (matrix) , light in weight
• Function has no osteons withstand stress from
  a variety of directions, reduce the weight of the
  overall bone.

28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
Bone Development

• Skeleton begins to develop at 6 weeks after
  conception, embryo is only 12 mm (0.5 in ) long.
• Bone growth continues through the age of 25 yrs.
• Bone is continuously remodeled or reshaped.

34
How do bones grow in humans?

• Can we see bone growth in a developing embryo?

35
(No Transcript)
36
The Players in Osteogenesis

• Ossification- formation of bone is a dynamic
  process.
• Osteoblasts- produce new bone matrix.
• Osteoclasts- produce acids and enzymes to release
  the stored minerals in the matrix.
• Osteocytes- mature bone cells that do not divide.

37
Bone Grows in Two Ways

• Intramembranous Ossification- bone forms from
  mesenchyme cells or fibrous connective tissue.
  Deep layers of the dermis.
• Endochondral Ossification- bone replaces a mold
  of cartilage.

38
Intramembranous Growth

• Step 1 Mesenchymal cells (stem cells) cluster
  at a site (ossification center) within the dermis
  (skin layers) and secrete bone matrix (collagen
  Ca 2). These cells will become osteoblasts.
• Step 2 Bone grows outward in spicules which
  will become the struts of spongy bone. Vessels
  grow into area.
• Step 3 Osteoblasts at the outer edge become
  less active and become osteocytes.

39
(No Transcript)
40
Intramembranous Bones

• Dermal bones of the skull- parietal, occipital,
  etc, the mandible, the clavicle, and the scapula.
• Bones that are mostly spongy tissue are made by
  intramembranous ossification.

41
Osteogenesis

• Intramembranous ossification- bone growth within
  C.T. (mandible, parietal) see p. 181, 4th Ed.,
  Martini)
• Want to see what happens when this growth is
  uncontrolled? Heterotopic Bone Formation, p. 50
  of the A.M.

42
Heterotopic Bone Formation
43
FOP
44
Endochondral Ossification

• Endo means inside -chondros means cartilage.
• Bone tissue gradually replaces a cartilage model
  or mold for the bone.
• Most bones form this way all of the appendicular
  (limb) skeletal bones.

45
Endochondral Growth

• Step 1 Cartilage forms a mold and the
  chondrocytes grow very large in the center of the
  mold. Lacunae expand and the matrix thins to
  struts. Chondrocytes die.
• Step 2 Blood vessels grow into the shaft of
  cartilage cells of the perichondrium become
  osteoblasts. The perichondrium now becomes the
  periosteum.

46
Endochondral Growth

• Step 3 Blood supply increases fibroblasts
  migrate to the center and become osteoblasts.
  They start to make spongy bone- Primary Center of
  Ossification.
• Step 4 As bone enlarges, osteoclasts appear and
  erode the trabeculae in the center- creates the
  marrow cavity.

47
(No Transcript)
48
Show Me the BMU in Action!
49
Endochondral Ossification

• Osteoblasts of the diaphysis and chrondrocytes of
  epiphysis continue to grow elongate bone.
• Epiphyseal Plate is the interface between the
  two.
• At puberty, the osteoblasts overcome
  chondrocytes the plate becomes more narrow-
  epiphyseal line.

50
Fetal Long Bone
51
Developing Long Bone
52
Endochondral Ossification
53
(No Transcript)
54
Endochondral Ossification

• Lengthening Bones-
• Hyaline chondrocytes die and leave calcified
  struts.
• Blood vessels grow at edges and perichondrial
  cells become osteoblasts.
• Osteoclasts- create a marrow cavity by dissolving
  struts

55
Bone Growth

• Intramembranous
• Occurs in a layer between dermis (dermal bones).
• Mesenchymal (stem) cells ?osteoblasts.
• Spongy Bone.
• Skull bones, mandible, scapula, clavicle.

• Endochondral
• Fills in a cartilage mold in a center of
  ossification.
• Fibroblasts ?osteoblasts in the center of mold.
• Osteoclasts form a marrow cavity.
• Compact Bone.
• Most other bones long bones.

56
Basic Multicellular Unit (BMU)

• A group of wandering cells that constantly reform
  or remodel bone.
• Many BMU move throughout the bones center and
  surface.
• Specific sequence of 5 events or steps.

57
5 Steps to Bone Formation

• Osteoclast Recruitment- osteoclasts arrive at the
  site of repair or reformation.
• Resorption- osteoclasts resorb or release the Ca
  2 from the matrix. This forms a cavity in the
  area (2 weeks).
• Osteoid Formation- osteoclasts self-destruct and
  attract osteoblasts to the area. The osteoblasts
  secrete new collagen and Ca 2 into the cavity.

58
5 Steps to Bone Formation

• Mineralization- the new osseous tissue begins to
  mineralize Ca 2 fills the cavity.
• Quiescence- the last osteoblasts develop into
  osteocytes and remain quiet in the bone tissue.
  They have long cell processes that can detect
  mechanical stresses.

59
Show me Normal Bone Remodeling in Spongy Bone!
60
When bones dont stop growing!
61
(No Transcript)
62
(No Transcript)
63
(No Transcript)
64
(No Transcript)
65
Diseases of Bone Growth

• Read bottom of p. 48 52 of Martini, F. (1998)
  Applications Manual. 4th Ed. Prentice Hall New
  Jersey.
• Complete the Table on Bone Growth Diseases.

66
Acromegaly?
67
Diseases of Bone Growth

• Gigantism overproduction of growth hormone
  before puberty, growth plates still open
  pituitary tumor.
• Acromegaly overproduction of growth hormone
  after puberty, growth plates closed but abnormal
  growth of cartilage and small bones.
• Marfans Syndrome defect in fibrillin, a
  protein of C. T. matrix excessive cartilage at
  plates that is weak blood vessels are not as
  elastic genetic.

68
Marfans Syndrome?
69
Achondroplasia
70
Diseases of Bone Growth

• Achondroplasia a without, chondro
  cartilage, plasia formation cartilage within
  the epiphyseal plates grow extremely slow
  affects appendicular skeleton more than axial
  skeleton.

71
(No Transcript)
72
(No Transcript)
73
Osteoporotic Spongy Bone
Normal Spongy Bone
74
Show Me Post-Menopausal Bone in Action
75
The Skeletal System

• Anatomy and Physiology
• Chapters 7 and 8
• Mr. Knowles
• Liberty Senior High School

76
The Skeletal System

• How many bones do women and men have?
• 206 bones in humans

77
Two Divisions

• Appendicular Skeleton-
• bones of limbs (appendages), pectoral and pelvic
  girdlesattach the limbs to the trunk of the body.

• Axial Skeleton-
• bones of skull, vertebral column, ribs, and
  sternum- 80 bones

78
Functions of the Skeletal System

• 1. Support- framework,
• 2. Storage of Minerals- Ca3(PO4)2, and CaCO3
• 3. Storage of Lipids- yellow marrow.

79
Functions of the Skeletal System

• 4. Blood cell production- red marrow makes
  erythrocytes, leukocytes, and others.
• 5. Protection- protect vital organs. Ex. Ribs.
• 6. Leverage- change magnitude and direction of
  forces.

80
(No Transcript)
81
Classification of Bones

• 1. Long bones- long, slender shapes (femur,
  phalanges)
• 2. Short bones- boxlike (carpal and tarsal bones)
• 3. Flat bones- thin, flat bones (sternum, ribs,
  scapula, parietal)

82
Short Bones
?
Carpals
83
Bones of the Skull
84
Classification of Bones

• 4. Irregular bones- complex shapes, notched or
  ridged surfaces vertebra(ae)
• 5. Sesamoid- like a sesame seed, small, flat, and
  inside joints patella(ae)

85
Vertebra (ae) irregular bones
86
The Patella (ae) a sesamoid bone
87
Sesamoid Bone in Hand
88
A Sesamoid Bone
89
Other Sesamoid Bones!
90
Classification of Bones

• 6. Sutural bones- small, flat, irregular bones of
  skull (sutural bone in skull)

91
Many Irregular, Flat, and Sutural
92
(No Transcript)
93
Your Assignment

• Finish the handouts over the tissues of bone.
• Identify all bones and structures listed in the
  outline (Refer to Table 6-2 on p. 192).
• Classify these bones into the six major types of
  bones.

94
What can we learn about a persons life from
their bones?

• G. B. Dyson (2000). The Aleutian Kayak.
  Scientific American (April) 84-91.
