Chapter two

• TYPE OF AERIAL PHOTOGRAPHS

2
Introduction to Aerial Photographs

• Aerial photogrammetry is the oldest and most
  widely used method of remote sensing.
• Photography from aircraft received a big
  attention in the interest of military
  reconnaissance during World War I.
• After World War I, former military photographers
  founded aerial survey companies, and widespread
  aerial photography of the United States began.
• In 1934, the American Society of Photogrammetry
  (now the American Society for Photogrammetry and
  Remote Sensing) was founded as a scientific and
  professional organization dedicated to advancing
  this field.

3
TYPES OF AERIAL PHOTOGRAPHS

• Aerial photographs may be divided into two major
  types
• Vertical (taken with the camera axis aimed
  vertically downward.
• Oblique (made with the camera axis intentionally
  inclined at an angle between the horizontal and
  vertical).

4
Vertical.

• A vertical photograph is taken with the camera
  axis pointed as straight down as possible .
• Allowable inclination is usually 3 from the
  perpendicular (plumb) line to the camera axis.
• A vertical photograph has the following
  characteristics
• The lens axis is perpendicular to the surface of
  the earth.
• It covers a relatively small area.
• The shape of the ground area covered on a single
  vertical photo closely approximates a square or
  rectangle.
• Distance and directions may approach the accuracy
  of maps if taken over flat terrain.
• Relief is not readily apparent.

5
Relationship of the vertical aerial photograph
with the ground.
6
Types of aerial photograph Vertical is most
important as it has minimum distortion and can be
used for taking measurements
7

• Types of aerial photograph
• Vertical

8
Vertical photograph.
9
SCALE OF A VERTICAL PHOTOGRAPH

• Scale is ordinarily interpreted as the ratio of a
  distance on a map to that same length on the
  ground.
• The scale of a vertical photograph is the ratio
  of a photo distance to the corresponding ground
  distance.
• If L is the exposure station of a vertical
  photograph taken at an altitude H above datum.
• The camera focal length is f and o is the
  photographic principal point.

10
Cont

• Points A , B , C , and D ,which lie at elevations
  above datum of hA , hB , hC and hD respectively.

• Are imaged on the photograph at a , b , c and d.
• The scale at any point can be expressed in terms
  of its elevation, the camera focal length and
  flying height above datum.
• From the similar triangles Lab and LAB the
  following formula can be written.

11
Cont
12
Example
13
Class work

• Calculate the flight height above average terrain
  that is required to obtain vertical photographs
  at an average scale of 18000 if the camera focal
  length is 152.4 cm.
• 10 Minute

14
Low Oblique.

• This is a photograph taken with the camera
  inclined about 30 from the vertical .
• It is used to study an area before an attack, to
  substitute for a reconnaissance, to substitute
  for a map, or to supplement a map.
• A low oblique has the following characteristics
• It covers a relatively small area.
• The ground area covered is a trapezoid, although
  the photo is square or rectangular.
• Parallel lines on the ground are not parallel on
  this photograph therefore, direction (azimuth)
  cannot be measured.
• Relief is discernible but distorted.
• It does not show the horizon.

15

• Types of aerial photograph
• Low oblique (no horizon)

16
Relationship of low oblique photograph to the
ground
17
oblique photograph
18
High Oblique

• The high oblique is a photograph taken with the
  camera inclined about 60 from the vertical .
• A high oblique has the following characteristics
• It covers a very large area (not all usable).
• The ground area covered is a trapezoid, but the
  photograph is square or rectangular.
• The view varies from the very familiar to
  unfamiliar, depending on the height at which the
  photograph is taken.
• Relief may be quite discernible but distorted as
  in any oblique view. The relief is not apparent
  in a high altitude, high oblique.
• The horizon is always visible.

19
Relationship of high oblique photograph to the
ground
20

• Types of aerial photograph
• High oblique

21
High oblique photograph.
22
Image Parallax

• Parallax is defined as the apparent displacement
  of the position of an object with respect to a
  frame of reference due to a shift in the point of
  observation.
• For example, a person looking through the view
  finder of an aerial camera in an aircraft as it
  moves forward sees images of objects moving
  across the field of view.
• Points closer to the camera (of higher elevation)
  will appear to move faster and have greater
  parallaxes than lower ones.
• It is also possible to compute X and Y ground
  coordinates from parallax.

23
Cont .

• Suppose an overlapping pair of vertical
  photographs exposed at equal flight heights H
  above datum.

The distance between exposure stations L1 and
L2is called B, the air base. The inset figure
shows the two exposure station
24
Cont ..
25
The parallax displacements occur only parallel to
the line of flight
The line of flight for any given stereo pair
defines a photo coordinate x axis for use in
parallax measurement
The parallax of any point, such as A in the above
Figure, is expressed in terms of the flight line
coordinate system as
Where Pa parallax of point A Xa measured x
coordinate of image a on the left photograph of
the stereopair Xa x coordinate of image a on
the right photograph
26
Example
27
(No Transcript)
28
RELIEF DISPLACEMENT ON A VERTICAL PHOTOGRAPH

• Relief displacement on a vertical photograph is
• the shift or movement of an image from its
  theoretical datum location caused by the objects
  relief that is, its elevation above or below
  datum.
• Relief displacement on a vertical photograph
  occurs along radial lines from the principal
  point and increases in magnitude with greater
  distance from the principal point to the image.

29
Cont

• The concept of relief displacement in a vertical
  photograph taken from a flying height H above
  datum. where the camera focal length is f and o
  is the principal point.
• Points B and C are the base and top,
  respectively, of a pole with images at b and c on
  the photograph.
• A is an imaginary point on the datum plane
  vertically beneath B with corresponding imaginary
  position a on the photograph.
• Distance ab on the photograph is the image
  displacement due to the elevation of B above
  datum, and bc is the image displacement because
  of the height of the pole.

30
Relief displacement on a vertical photograph.
From similar triangles an expression for relief
displacement is formulated. First, from
triangles Figure 27.9
31
Cont .
32
Example
33
Homework
