Title: Mehrdad Nourani

1
Data Network Security

Mehrdad Nourani

2
Session 09

Security Services
Traffic Confidentiality

Security Management, Services and Threats

4
Security Management

Security management functions are concerned with
the management, control, and administration of
security services for all secured entities within
the security domain according to the defined
policies.
Security management is responsible for the
installation, monitoring, tuning, and
restructuring of the available security services.
Functions of security management include control
and distribution, monitoring, event logging,
event reporting, security audit trail and
security recovery.
Based on the corresponding policy and target
systems/network some of these functions may not
apply or need not to be implemented.

5
Security Services

Security services are remedies, defenses, and
countermeasures by which security threats are
countered.
The specific implementation of each security
service is based on one or more security
mechanisms.
In general, we define six security services aimed
to provide the following six basic security
objectives.
Some of these services may appear "overlapping."
key management is an important function that has
to be provided by any system involved in
providing security services and data encryption.

6
Security Services (I)

Confidentiality and Privacy - is the protection
of information exchange and traffic flow from
unauthorized disclosure (or all passive attacks).
This service can be implemented at different
layers of communication protocols and/or at
several application/system levels.

7
Security Services (II)

Integrity and Protection - is the protection of
information exchange and storage from mostly
active attacks and (wo)man-in-the-middle attacks/
It assures that information is received as sent,
with no duplication, insertion, modification,
reordering, or replay.

8
Security Services (III)

Access Control and Authorization - in the context
of network security, is the protection,
limitation, and control of access to the host,
operating system, and applications via
communications links.
Authorization is to provide access rights as
tailored to the individual user or application.

9
Security Services (IV)

Non-repudiation and Accountability - is concerned
with preventing either sender or receiver from
denying an exchanged information.
Sometimes, an arrangement to use an unbiased
arbitrator, called a notary, is used when both
parties are suspicious users.

10
Security Services (V)

Authentication - is concerned with assuring that
the communication is authentic, including source
of information, communicating systems or
applications, and/or users.

11
Security Services (VI)

Availability and Non-Denial of Service - is
concerned with assuring that a communication
resource is not destroyed or blocked or becomes
unavailable or unusable to its authorized users.
Denial of service means knocking off services
without permission, e.g., flooding the file
server with phony files causing a system crash,
or congesting remote access servers with
unauthorized access requests.

12
Security Threats

A threat or security attack is a potential
violation of security or an intrusion for
unauthorized, illegitimate, malicious or
fraudulent purposes.
These attacks are aimed to compromise security.
The points of attack (or attacking points) can
occur at various weakness points within a
security perimeter, and can be at any level or
layer of realization, e.g., at the physical
system realization level, at the system or
network level, at the communication protocol
level, and so on.

13
Security Threat Classification

The nature of the attacks varies with the
circumstances and according to the defined
perimeter for the security.
Threats may be classified by their
Type (e.g., accidental or intentional, passive
or active)
Consequences
Sources (e.g., users or programs)
Objects of threats

14
Typical Intentional Threats
15
Typical Intentional Threats (cont.)
16
Some Products Solutions

Some security products/solutions are designed for
a particular environment or for a special
application.
They are considered as custom-designed
combinations of the above services.
Examples of these are
PGP (Pretty Good Privacy) - a widely used
authentication and confidentiality service.
Kerberos - an authentication protocol based on
conventional encryption to authenticate clients
to servers, and vice versa. The Version 5
Kerberos was developed within the Internet
community.
PEM (Privacy Enhancement Mail) - developed
specifically as an Internet Standard for
electronic mail.

17
Businesses Threats
18
Security Mechanism

Security mechanisms are effective techniques and
schemes used to implement a given security
service with different degrees of complexity.
Security services are designed to detect,
prevent, or recover from a security violation or
attack.
For example, an abstract service like data
confidentiality might be implemented using either
the secret key data encryption mechanism or
public key data encryption scheme.
In most practical cases, a combination of
security mechanisms need to implement even one
particular security service.
The services can be implemented either with
strong mechanism or with weak mechanism (low,
medium, or high security).

19
Well-Known Mechanisms
20

Security Perimeter Domain

21
Security Borders

In communications network environment and where
encryption (confidentiality and privacy) is
desired, security borders can be established
around
Link-by-link
End-to-end (or application-to-application)
User-to-user (operating system to operating
system)
Network edge-to-network edge

22
Link-by-Link Security

Link-by-link security takes place at the lowest
layers, where every transaction through a
particular data-link is encrypted (secured).
Examples of this are data encryption devices
placed at the physical and/or datalink layers.
Key management in this case can be simple because
only the endpoints of the communication link need
to exchange keys independent from the rest of the
network.
The main problem is that leaving any link in the
network unencrypted jeopardizes the security of
the entire network.

23
End-to-End Security

If security is provided at higher layers, it is
called end-to-end, when information is encrypted
selectively and decrypted by the intended final
recipient.
In this case, security devices are placed between
the network layer and transport layer.
The security device must recognize protocols up
to network layer (layer 3) and encrypt only the
transport data units.
One problem is that the system is open to traffic
analysis attack because the routing information
for the data is not generally encrypted.

24
Security at Higher Levels

Data security and encryption can be performed at
higher layer and even for data storage.
At the application level, a hierarchy of security
services may be defined, each providing security
against a different perceived threat.
In general, security services are defined (within
a particular border against outside world) for
a user entity (either process or machine),
a network, a communication environment,
a computing environment, or
a stand-alone system.

25
Security Perimeter

A security perimeter as a homogeneous set of
tools and measures, established around some
communication and/or computing environment, to
protect it from the outside nonsecure
environment.
In general, security perimeters can be
established around user, data processing and/or
application, data storage, and data
communication.

26
Security Domain

In practice, a security perimeter environment can
be constituted of (or subdivided to) several
heterogeneous security domains, each domain
follows the same measures of its parent perimeter
plus some possible extra measures.
A security domain is, therefore, a subset of
users and resources of the global security
perimeter environment, conforming to
a unique security policy,
a single logical security management,
a single security administration,
a set of uniformly available elementary
mathematical macros for provision of security
services and mechanisms.

27
Domain Relationships

Entities that are subject to a single security
policy, grouped together logically or physically,
and administered by a single authority, called
security management system (SMS), constitute a
security domain.
The approach of structuring the boundaries of
domains leads to various relationships between
domains.
Domains may be disjoint, overlapping, or subsets
of other domains.

28
Security Perimeters and Domains

Each domain may be served by a central Security
Management Center (SMC), which will be
responsible for the policy making, management,
and control of security services and activity on
the network.
Some negotiation and resolutions is necessary in
order to establish common sets and levels of
security parameters.

Confidentiality Using Symmetric Encryption

30
Confidentiality

Traditionally symmetric encryption is used to
provide message confidentiality
Confidentiality has been the main goal of
encryption
Other considerations added in the past few
decades
Authentication
Integrity
Digital signature

31
Points of Vulnerability
2
3
4
1

snooping from another workstation
use dial-in to LAN or server to snoop
use external router link to enter snoop
monitor and/or modify traffic on external links

32
Potential Vulnerability

consider typical scenario
workstations on LANs access other workstations
servers on LAN
LANs interconnected using switches/routers
with external lines or radio/satellite links
consider attacks and placement in this scenario
snooping from another workstation
use dial-in to LAN or server to snoop
use external router link to enter snoop
monitor and/or modify traffic on external links

33
What to Encrypt?

have two major placement alternatives
link encryption
encryption occurs independently on every link
implies must decrypt traffic between links
requires many devices, but paired keys
end-to-end encryption
encryption occurs between original source and
final destination
need devices at each end with shared keys

34
Encrypt Across a Packet Network
35
Disadvantage of Link Encryption

One disadvantage of link encryption approach is
that the message must be decrypted each time it
enters a packet switch.
This is necessary because the packet switch must
read the address (i.e., the virtual circuit
number) in the packet header to route the packet.
Thus, the message is vulnerable at each switch.
If this is a public packet-switching network
(PSN), the user has no control over the security
of the nodes.

36
Disadvantage of End-to-End Encryption

End-to-end approach would seem to secure the
transmission against attacks on the network links
or switches.
when using end-to-end encryption must leave
headers in clear (unencrypted)
so network can correctly route information
hence although contents protected, traffic
pattern flows are not (as they can be read)

37
End-to-End vs. Link Encryption

With end-to-end encryption, the user data are
secure. However, the traffic pattern is not,
because packet headers are transmitted in the
clear.
To achieve greater security, both link and
end-to-end encryption are needed.
Ideally we want both at once
end-to-end protects data contents over entire
path and provides authentication
link protects traffic flows from monitoring but
it requires a lot of encryption devices

38
End-to-End vs. Link Encryption (cont.)
39
Logical Placement of Encryption

can place encryption function at various layers
in OSI Reference Model
link encryption occurs at layers 1 or 2
end-to-end can occur at layers 3, 4, 6, 7
E.g. the user data portion of all frames in ATM
cells is encrypted
as move higher less information is encrypted but
it is more secure though more complex with more
entities and keys

40
Using an Encryption Processor

In network layer (layer 3)
each end system can engage in an encrypted
exchange with another end system.
All the user processes and applications within
each end system would employ the same encryption
scheme with the same key to reach a particular
target end system.
With this arrangement, it is desirable to
off-load the encryption function to some sort of
front-end processor.

41
Front-End Encryption Processor

The front-end processor (FEP) accepts and
processes the packet
Red data unencrypted (in clear)
Black data encrypted

42
Scope of Encryption

Encryption service on end-to-end protocols (e.g.
frame-delay or TCP) provides end-to-end security
for traffic within a fully integrated
inter-network.
Such scheme cannot deliver the security service
to the traffic that crosses inter-network
boundaries, such as electronic mail, electronic
data interchange (EDI) and file transfer.

43
Scope of Encryption in OSI
Application Layer
44
Scope of Encryption in OSI (cont.)

For applications like electronic mail that have a
store-and-forward capability, the only place to
achieve end-to-end encryption is at the
application layer.
A drawback of the application layer encryption is
that the number of entities to consider increases
dramatically, e.g.
Supporting hundreds of hosts
Supporting thousands of users
Need to manage (generate and distribute) many
more secret keys
As we move up in the communication hierarchy,
less information is encrypted but it is more
secure.

45
Encryption and Protocol Levels

In application level
Only user data portion of a TCP segment is
encrypted
In transport/session (TCP) level
the user data and the TCP header are encrypted.
The IP header is needed by router to route the IP
datagram.

46
Encryption and Protocol Levels (cont.)

When a message passes through a gateway
TCP header is terminated and a new transport
connection is opened for the next hop
The gateway is treated as a destination by the
underlying IP. Thus, all data is decrypted in
gateway.
If the next hop is over TCP/IP, then the user
data and TCP header are encrypted again.

47
Encryption and Protocol Levels (cont.)

In link level
Entire data unit except for the link header and
trailer is encrypted on each link.
The entire data unit is in the clear
(unencrypted) at each router or gateway.

48
Traffic Analysis

is monitoring of communications flows between
parties
useful both in military commercial spheres
can also be used to create a covert channel
(using the communication channel in a way that
violates the security policy, e.g. an employee
sends a short message as 0 and a long message
as 1. If an outsider can monitor the channel
they effectively established a covert channel)
Traffic analysis violates confidentiality since
by monitoring length, duration etc. of
communication one can find useful information
like
Identity of partners
How frequently they communicated
Message pattern, level of importance
Correlation between events and communication

49
A Solution to Traffic Analysis

link encryption obscures header details
but overall traffic volumes in networks and at
end-points is still visible
Traffic padding
Generate random messages (even if there is none)
Uniform the length of messages at the
transport/application level
traffic padding can further obscure flows
but at cost of continuous traffic

50
A Solution to Traffic Analysis (cont.)

Protecting end-to-end encryption against traffic
analysis is more difficult.
Since two sides should do encryption and
decryption, the choices to defend against traffic
analysis is more limited.
Still you can obscure the underlying traffic by
Padding out data units to a uniform length at
transport or application layer
Inserting null messages into the stream randomly

Key Distribution

52
Symmetric Encryption

All of the methods discusses so far use a single
key that must be strictly kept secret. These
systems are called symmetric-encryption (or
secret-key or private-key) systems.
Key distribution is still a challenge. One
approach is based on sending pieces of key
through separate channels.

53
Importance of Key Distribution

symmetric schemes require both parties to share a
common secret key
issue is how to securely distribute this key
often secure system failure due to a break in the
key distribution scheme

54
Key Distribution Mechanisms

given parties A and B, there are various key
distribution alternatives
A can select key and physically deliver to B
third party can select deliver key to A B
if A B have communicated previously can use
previous key to encrypt a new key
if A B have secure communications with a third
party C, C can relay key between A B
For practical large distributed systems in which
many links/hosts/users need to exchange keys
option 4 is the answer.

55
Key Distribution Mechanisms (cont.)

Link Encryption Use methods (1) or (2) because
only two devices communicate.
End-to-end Encryption
Manual delivery is not possible due to
exponential growth.
At the network/IP level a key is needed for each
pair of hosts. (For N hosts, we need N(N-1)/2
keys).
At the application level a key is needed for
every pair of users/processes. (e.g. 1000 nodes
require C21000500000 keys)

56
Key Distribution Mechanisms (cont.)

(3) Can be used for both link and end-to-end
encryptions. However, if an attacker find one key
then all subsequent keys will be revealed.
(4) is widely used for end-to-end encryption
using at least 2-levels of keys
Session key a temporary key for the duration of
logical connection (e.g. transport connection)
Master key is used to encrypt and send session
keys. It is distributed in some non-cryptographic
way (e.g. physical delivery). For N pairs only N
master keys are needed.

57
Key Distribution Scenario
58
Key Distribution Scenarios (cont.)

A issues a request to KDC for a session key. The
message includes the identity of A and B and N1
(called nonce, e.g. a random number).
KDC responds with a message encrypted with Ka
(master key of A). The message includes
One-time session key Ks.
Original request and nonce of A
Ks and identifier of A (e.g. As network address)
encrypted with Kb
A stores Ks and send EKb(KsIDA) to B
Using Ks, B sends a nonce N2 to A.
Using Ks A responds f(N2) (a transformation of N2
e.g. N21) for authentication.

59
Key Distribution Scenarios (cont.)

Note that the actual key distribution involves
only steps 1 through 3.
After step 3, both A and B have the session key
Ks and they may begin their protected exchange of
information.
Steps 3, 4 and 5 together perform an
authentication function.
They assume B that the original message it
received in step 3 was not a replay.

60
Key Distribution Issues

hierarchies of KDCs required for large networks,
but must trust each other
session key lifetimes should be limited for
greater security
use of automatic key distribution on behalf of
users, but must trust system
use of decentralized key distribution
controlling purposes keys are used for

61
Automatic Key Distribution

For connection-oriented protocols (e.g. at
network or transport levels) the key can be
generated, using Front-End Processor, in a way
that is transparent to the end user.

62
Automatic Key Distribution (cont.)

The KDC provides a one-time session key for that
connection. The session keys are used for the
duration of a session. At the conclusion of the
session, or connection, the session key is
destroyed.
The automated key distribution approach provides
the flexibility and dynamic characteristics
needed to allow a number of terminal users to
access a number of hosts and for the hosts to
exchange data with each other.
Kerberos, used extensively in Microsoft Windows
2000, is modelled on a KDC.

63
Difficulties in Key Distribution

In general, a KDC supporting n sites, where each
site needs a secret key with every other site,
must make almost n2/2 keys.
The KDC is often burdened with extensive key
management and can become a bottleneck.
If the KDC also acts as a key escrow agent, the
KDC itself is an attractive target (e.g., for a
distributed denial-of-service attack).
For these reasons, the symmetrical encryption is
not very attractive in large networks and is
avoided altogether.
Another approach to security is the public-key
encryption, which makes key distribution much
easier. We will discuss it in the next chapter.

64
Decentralized Key Control

For small networks we may use a decentralized
approach. Each node must maintain n-1 master
keys.
A issues a request to B for a session key and
includes a nonce N1.
B responds with a message that is encrypted using
the shared master key (MKm). The response
includes the session key (Ks chosen by B), an
identifier of B, value f(N1) and another nonce
N2.
Using the new session key A returns f(N2) to B
for authentication.

65
Controlling Key Usage

Sometimes it is useful to define different
session keys on the basis of use (for various
applications)
e.g. for communication, PIN-encrypted
applications, file encryption, etc.
Its often desirable to institute controls in
systems that limit the ways in which keys are
used, based on characteristics associated with
those keys.
Method 1 Use a tag with each key
In DES, the actual key is 56 bits. 8 nonkey bits
are used to indicate something, e.g.
1 bit indicate whether the key is a session key
or a Master key
1 bit indicate whether its for encryption or
decryption
Two problems 1) the length is limited and 2) the
tag is not transmitted in clear form it can be
used only at the point of decryption, limiting
the ways in which the key can be controller.

66
Controlling Key Usage (cont.)

Method 2 Use control vector (CV).
KDC sends control vector in clear and can be used
in any stage.
For master key Km and session key Ks
Hash Value H h(CV)
Key Input Km XOR H
Ciphertext EKm XOR H Ks
Ks DKm XOR H
EKm XOR H Ks
There is no restriction on length which enables
arbitrarily complex controls to be imposed on
each key
The control vector is available in clear form at
all stages of operation. Thus, the control of key
use can be exercised in multiple locations.

67
Controlling Key Usage (cont.)

To control some of the bits (for identification
or hierarchy, etc.) a control vector is used. KDC
sends control vector in clear and can be used in
any stage.

Random Numbers

69
Importance of Random Numbers

many uses of random numbers in cryptography
nonces in authentication protocols to prevent
replay (attacker stores old messages and replays
them to fake his ID and get session key for A)
session keys
public key generation
Key stream for a one-time pad
in all cases its critical that these values be
statistically random
with uniform distribution, independent
unpredictable cannot infer future sequence on
previous values

70
Natural Random Noise

best source is natural randomness in real world
find a regular but random event and monitor
do generally need special hardware to do this
e.g. radiation counters, radio noise, audio
noise, thermal noise in diodes, leaky capacitors,
mercury discharge tubes etc
starting to see such hardware in new CPU's
problems of bias or uneven distribution in signal
have to compensate for this when sample and use
best to only use a few noisiest bits from each
sample

71
Published Sources

a few published collections of random numbers
earlier Tippett in 1927 published a collection
Rand Co, in 1955, published 1 million numbers
generated using an electronic roulette wheel
has been used in some cipher designs, e.g. Khafre
issues are that
these are limited
too well-known for most uses

72
Pseudorandom Number Generators (PRNGs)

For cryptography applications we need a
deterministic algorithm to generate pseudorandom
numbers.
how a deterministic algorithm generates random
values?
A philosophical objection not engineers concern
algorithmic technique to create random numbers
although not truly random
can pass many tests of randomness

73
Linear Congruential Generator

common iterative technique using
Xn1 (aXn c) mod m
where mgt0 and 0a,c,Xnltm
X0 is the seed
m must be very large to have a long sequence
given suitable values of parameters can produce a
long random-like sequence
suitable criteria to have are
function generates a full-period
generated sequence should appear random
efficient implementation with 32-bit arithmetic
note that an attacker can reconstruct sequence
given a small number of value

74
Practical Pseudorandom Generator

common iterative technique using
Xn1 (16807Xn) mod (231-1)
If m is prime and c0, the period of generating
numbers is m-1
To be efficient in implementation we chose 232-1.
Coefficient a7516807 generates very good random
sequence and is widely used.
If an opponent is able to get X0, X1, X2, X3
these three equations can be solved for a, c and
m.
To create unpredictability, use current clock mod
m as the new seed to change the sequence every N
numbers.

75
Using Block Ciphers as Stream Ciphers

can use block cipher to generate numbers
use Counter Mode
Xi EKmi
use Output Feedback Mode
Xi EKmXi-1

76
Using Counter Mode

use Counter Mode
Xi EKmi
The counter has period of N , e.g. 256 when
56-bit DES keys are used
Since the master key is protected it is not
possible to deduce the secret key from earlier
keys

77
Using Output Feedback Mode

The output of each stage is a 64-bit value of
which the s leftmost bits are fed back for
encryption.
Successive 64-bit outputs constitute a sequence
of pseudorandom numbers with good statistical
properties.

78
ANSI X9.17 Pseudorandom Number Gen.

ANSI X9.17 PRNG
uses date-time seed inputs and 3 triple-DES
encryptions to generate new seed random
Input two pseudorandom inputs
DTi a 64-bit representation of the current
date/time
a 64-bit seed Vi generated at the beginning of
ith stage
Keys (K1,K2) all 3DES modules use the same pair
of 56-bit keys
Output 64-bit pseudorandom number (Ri) and
64-bit seed value (Vi1)
Ri EDEK1,K2Vi ? EDEK1,K2DTi
Vi1 EDEK1,K2Ri ? EDEK1,K2DTi

79
Blum Blum Shub (BBS) Generator

based on public key algorithms
Choose
two prime numbers p,q such that pq3(mod 4)
np.q
a random number s (seed) such that it is
relatively prime to n (i.e. neither p nor q is a
factor of s).
The BBS generates sequence of bits Bi as follows
X0s2 mod n
For i1 to 8
Xi(Xi-1)2 mod n (All Xi is a number 0
Xi lt n )
BiXi mod 2 (Bi is least
significant bit of Xi)

80
Features of BBS Generator

unpredictable, passes next-bit test (see table
for n192649283x503 and s101355).
security rests on difficulty of factoring n (i.e.
given n determine its two prime factors p and q)
is unpredictable given any run of bits (given k
bits of the sequence it is impossible to
determine bit k1 with probability above ½)
slow, since very large numbers must be used
too slow for cipher use, good for key generation

i
81
Summary
