AD SC PS PA Acquisitions
3
Field Instrumentation
Level
Flow
Temperature
Radar
Capacitance
Ultrasonic
Ultrasonic
MID
RPM
VA
Rack
Head
2-wire
PA
Clamp On
Coriolis
Field
HART
Pressure
Positioners
Panel Instruments
Software
Weighing
? P / P
P
Process Controllers
ProcessDeviceManager
Electropneumatic
SIWAREXComponents
WeighFeeders
BeltScales
Pneumatic
Process Recorders
4
Portfolio Strategy Analytics
Gas Analytics
Spectrometry
Series 6 Rack
Mass Spec
Laser Diode
FIDAMAT
CALOMAT
Series 6 Field
OXYMAT
AOTF
ULTRAMAT 23
Gas Chromatography
SIPAN 32 Eex
Maxum edition II
SIBENCH
MicroSam
SIPAN 34
E-BOX

AD PI has increased its technology and product
portfolio to a large extend with own
developments and with acquisitions
5
SC is Best in Class worldwide
Gaschromatography MicroSam
Maxum edition II
Ultrasonic LevelProbe, EnviroRanger, HydroRanger
Radar 24 GHz
Smart pneumatic PostionersSIPART PS2
6
Focused Industry Sectors
Introduction Pressure TemperatureFlow Level
Positioners Process Protection Process
Controllers Process Recorders Weighing
Components Dynamic Weighing Gas
Analyzers Gas-Chromatographs Spectrometers SIMATIC
PDM System Integration
  • Also
  • served
  • Glass
  • Pulp Paper
  • Power generation

more infos
7
Pressure Measuring InstrumentsSITRANS P
Introduction Pressure TemperatureFlow Level
Positioners Process Protection Process
Controllers Process Recorders Weighing
Components Dynamic Weighing Gas
Analyzers Gas-Chromatographs Spectrometers SIMATIC
PDM System Integration
  • Get a firm grip on pressure
  • MPS series
    for convenient hydrostatic level
    measurements
  • Z series
    single-range transmitters for pressure and
    absolute pressure
  • MK II series
    for universal pressure measurements
  • MS series
    digital solution with HART
    communication
  • DS III series/P300
    digital transmitter with integrated
    diagnostic functions, HART or PROFIBUS-PA
    communications and convenient pushbutton
    operation
  • Compact series/P300
    for the special needs of the food,
    pharmaceutical and biotechnology industries

Z
P300
MPS
Compact
MK II
MS
more infos
DS III
8
Temperature Measuring InstrumentsSITRANS T
Introduction Pressure TemperatureFlow Level
Positioners Process Protection Process
Controllers Process Recorders Weighing
Components Dynamic Weighing Gas
Analyzers Gas-Chromatographs Spectrometers SIMATIC
PDM System Integration
  • Keep cool in hot environments
  • SITRANS TW
    Universal transmitter for rail mounting. HART
    communications, programmable via PC with
    SIMATIC PDM
  • SITRANS TF
  • For field installation, IP 65 protection,
    optional programmable digital readout
  • SITRANS TK/TK-L
  • Head mounted transmitters. Programmable with
    SIMATIC PDM, HART protocol and SIPROM TK
  • SITRANS T3K PA
  • Head mounted transmitter. PROFIBUS-PA
    communications, programmable with SIMATIC PDM
  • All transmitters are also available as
  • intrinsically safe versions SITRANS TF
    is available with EEx d certification.

SITRANS
TK-L
SITRANS TW
T3K-PA
TK
SITRANS TF
more infos
Sensors
9
Flow Measuring InstrumentsSITRANS F MID,
Ultrasonic, Massflow
Introduction Pressure TemperatureFlow Level
Positioners Process Protection Process
Controllers Process Recorders Weighing
Components Dynamic Weighing Gas
Analyzers Gas-Chromatographs Spectrometers SIMATIC
PDM System Integration
  • State-o-the-art flow
  • measurement
  • SITRANS F M
  • MAGFLO/MAG8000
  • Electro-Magnetic Flowmeters
  • For nearly every application of electrically
    conductive media. Mag 8000 - battery operated
    flow meter for district monitoring/irrigation/
    revenue metering
  • SITRANS F US
  • SONOFLO
  • Ultrasonic Flowmeters
    Applications with low flow rates high viscosity
    solvents, organically-based liquids and
    condensates, water or wastewater and many more.
  • MASSFLO
  • Massflow flowmeters based on Coriolis technology
  • The only fully user configurable massflowmeter
    on the market

MAGFLO
SITRANS F M
SONOFLO
SITRANS F US
more infos
MASSFLO
MAG8000
10
Flow Measuring InstrumentsSITRANS F - Mechanical
Introduction Pressure TemperatureFlow Level
Positioners Process Protection Process
Controllers Process Recorders Weighing
Components Dynamic Weighing Gas
Analyzers Gas-Chromatographs Spectrometers SIMATIC
PDM System Integration
  • Know exactly what is flowing
  • SITRANS F VA Variable Area Flowmeters
  • For flow measurements of liquids and gases from
    1 l/h to 100 m3/h (0.0045 USgpm to 440 USgpm)
  • SITRANS F I Flow Indicators Mechanical
    flowmeters for liquids and gases.
  • SITRANS F R Rotary Piston Meters
  • Positive-diplacement meters for liquids
  • SITRANS F O Orifice Flowmeters
    Universal flow measurement for liquids,
    gases and vapors

SITRANS F VA
SITRANS F I
SITRANS F R
SITRANS F O
more infos
11
Level Measuring InstrumentsSITRANS LR - Radar
Introduction Pressure TemperatureFlow Level
Positioners Process Protection Process
Controllers Process Recorders Weighing
Components Dynamic Weighing Gas
Analyzers Gas-Chromatographs Spectrometers SIMATIC
PDM System Integration
  • A complete radar family
  • SITRANS Probe LR/LR 200
  • New 2-wire, loop-powered pulse radar instrument
    offers a cost-effective level measurement
    solution for liquid bulk storage or simple
    process vessels
  • SITRANS LR 300
  • Compact, easy-to-install pulse radar instrument
    for liquids in process vessels delivers high
    performance at an affordable price
  • SITRANS LR 400
  • 24 GHz high-frequency radar unit offers reliable
    continuous level measurement for liquid storage
    and for difficult applications on dusty solids

Probe LR
SITRANS LR 200
SITRANS LR 300
more infos
SITRANS LR 400
12
Level Measuring InstrumentsSITRANS LU -
Ultrasonics
Introduction Pressure TemperatureFlow Level
Positioners Process Protection Process
Controllers Process Recorders Weighing
Components Dynamic Weighing Gas
Analyzers Gas-Chromatographs Spectrometers SIMATIC
PDM System Integration
  • Number 1 in ultrasonics
  • MultiRanger
  • Transceiver, ideal for single or dual point
    applications up to 15 m (49.2 ft) in virtually
    any application
  • EnviroRanger
  • State-of-the-art technology for the
    water/wastewater industries
  • SITRANS LU
  • Highly-funcionality instrument which can monitor
    up to 10 points
  • Echomax Transducers
  • Non-contacting ultrasonic technology with
    virtually no maintenance. Easy to install and
    built to withstand harsh environments
  • SITRANS Probe LU
  • Award-winning instrument integrates sensor and
    electronics in the same enclosure

MultiRanger
EnviroRanger
SITRANS LU
Transducers
more infos
SITRANS Probe LU
13
Level Measuring InstrumentsSITRANS LC -
Capacitance
Introduction Pressure TemperatureFlow Level
Positioners Process Protection Process
Controllers Process Recorders Weighing
Components Dynamic Weighing Gas
Analyzers Gas-Chromatographs Spectrometers SIMATIC
PDM System Integration
  • Specialists for level
  • measurement and interface
  • detection
  • SITRANS LC 300
  • Cost-effective instrument for level measurement
    in high-accuracy applications such as food
    processing and pharmaceuticals
  • SITRANS LC 500
  • Level measurement and interface detection for
    extreme and critical process conditions, such as
    toxic and aggressive chemicals and vapors

SITRANS LC 300
SITRANS LC 500
more infos
14
Level Measuring InstrumentsSITRANS LC -
Capacitance
Introduction Pressure TemperatureFlow Level
Positioners Process Protection Process
Controllers Process Recorders Weighing
Components Dynamic Weighing Gas
Analyzers Gas-Chromatographs Spectrometers SIMATIC
PDM System Integration
  • When it comes to point level
  • detection
  • Capacitance
  • The full line of capacitance point level
    switches includes Pointek CLS 100 for compact
    spaces, CLS 200 for a wide range of applications,
    CLS 300 for harsh conditions or abrasive
    materials, and CLS 500 for use in extreme
    temperatures or pressure. CLS 200 and CLS 300
    offer PROFIBUS PA communications
  • Ultrasonic
  • Pointek ULS, using non-contacting ultrasonic
    technology, is effective in bulk solids, liquids
    and slurries, and is ideal in sticky materials
  • Mechanical
  • For level detection of low-density powders and
    granular solids, choose the Pointek PLS 200
    electro-mechanical rotary paddle switch or the
    Pointek VLS 200 ectromechanical vibratory switch

Pointek ULS
Pointek CLS
Pointek PLS 200
more infos
Pointek VLS 200
15
Positioners
Introduction Pressure TemperatureFlow Level
Positioners Process Protection Process
Controllers Process Recorders Weighing
Components Dynamic Weighing Gas
Analyzers Gas-Chromatographs Spectrometers SIMATIC
PDM System Integration
  • Control valves accurately
  • SIPART PS2
  • Intelligent electropneumatic positioner with
    everything a leader in this field requires
  • Control via 4-20 mA, HART or PROFIBUS PA
  • For use with linear and part-turn actuators
  • Easy local operation with pushbuttons and LCD
    display
  • Automatic set-up feature with self-adjusting
    zero and span
  • Integrated diagnostic functions
  • Available for use in hazardous areas as
    intrinsically safe device (EEx ia/ib) or in
    flame-proof housing (EEx d)
  • Available in plastic or metal housing
  • With optional plug-in modules for alarms,
    position feedback and external position
    transducers

SIPART PS2
more infos
SIPART PS2 EEx d
16
Process Protection Instruments
Introduction Pressure TemperatureFlow Level
Positioners Process Protection Process
Controllers Process Recorders Weighing
Components Dynamic Weighing Gas
Analyzers Gas-Chromatographs Spectrometers SIMATIC
PDM System Integration
  • Protect your process
  • Acoustic Sensors
  • The SITRANS AS 100 Acoustic Sensor detects
    changes in high frequency sound waves from
    equipment and materials in motion. It detects and
    reacts instantly to changes in solids flow to
    warn of blockages, product absence or equipment
    failure such as burst filter bags. The associated
    control unit SITRANS CU 02 which offers
    convenient operating and control functions
  • Motion Sensors
  • These devices monitor the motion of conveyor
    belts, screw conveyors and bucket conveyors, and
    report any overshoot / undershoot compared to set
    limits, or any stoppage. They operates on the
    principle of disruption of a magnetic field by a
    ferrous target

SITRANS AS 100
SITRANS CU 02
ME 100
Zero Speed Switch
more infos
MFA 4p
17
Process Controllers
Introduction Pressure TemperatureFlow Level
Positioners Process Protection Process
Controllers Process Recorders Weighing
Components Dynamic Weighing Gas
Analyzers Gas-Chromatographs Spectrometers SIMATIC
PDM System Integration
  • Optimize your control loops
  • SIPART DR 19
  • 96 x 96 mm (3.8 x 3.8 in) format, for
    applications in mechanical and systems
    engineering and many other processes
  • SIPART DR 21
  • The ideal solution with comprehensive display
    functions for all standard tasks. Various control
    functions and status messages.
  • SIPART DR 22
  • Solves complex closed-loop control tasks as
    single or dual-channel controller
  • SIPART DR 24
  • The multi-talented unit for all process-specific
    tasks such as mathematical calculations, logic
    operations, open-loop controls. Up to four
    independent control loops.

SIPART DR 19
SIPART DR 21
SIPART DR 22
more infos
SIPART DR 24
18
Process RecordersSIREC Paper Tape Recorders
Introduction Pressure TemperatureFlow Level
Positioners Process Protection Process
Controllers Process Recorders Weighing
Components Dynamic Weighing Gas
Analyzers Gas-Chromatographs Spectrometers SIMATIC
PDM System Integration
  • Precise monitoring and
  • documentation
  • SIREC L/LA
  • Low-cost line recorder for 1,2 or 3 analog
    channels, 2 digital channels, 300 ms measuring
    cycle, with or without alphanumeric printout
  • SIREC P/PA
  • Low-cost 6-channel dot recorder, 640 ms
    measuring cycle in all channels, with or without
    alphanumeric printout
  • SIREC PU
  • The versatile recorder with mathematical
    functions, 6 analog channels, digital display,
    300/500 ms measuring cycle, real time clock
  • SIREC Variograph
  • 3 or6 analog plus 6 digital channels or up to 12
    analog channels, 1500 ms measuring cycle, 288 x
    288 mm front panel

SIREC LA
SIREC PA
SIREC PU
more infos
VARIOGRAPH
19
Process RecordersSIREC Display Recorders
Introduction Pressure TemperatureFlow Level
Positioners Process Protection Process
Controllers Process Recorders Weighing
Components Dynamic Weighing Gas
Analyzers Gas-Chromatographs Spectrometers SIMATIC
PDM System Integration
  • Recording today
  • SIREC DS
  • The cost-effective solution
  • Up to 6 general purpose inputs, 144 x 144
    mm ( 5.7 x 5.7 in) front panel, 5 color LCD
    display, floppy disk storage
  • SIREC DM
  • The flexible solution
  • Up to 16 general purpose inputs, accuracy /-
    0.02 , 144 x 144 mm ( 5.7 x 5.7 in) front
    panel, PCMCIA and floppy disk storage
  • SIREC DH
  • The ultimate solution
  • Up to 32 general purpose inputs, 300 x 300 mm
    (11.8 x 11.8 in) front panel, 12.1 color TFT,
    PCMCIA and floppy disk storage

SIREC DS
SIREC DM
more infos
SIREC DH
20
Components for Weighing SystemsSIWAREX
Introduction Pressure TemperatureFlow Level
Positioners Process Protection Process
Controllers Process Recorders Weighing
Components Dynamic Weighing Gas
Analyzers Gas-Chromatographs Spectrometers SIMATIC
PDM System Integration
  • Get the right weight
  • SIWAREX Weighing Electronics
  • Totally integrated in SIMATIC or connected via
    PROFIBUS
  • High precision and high functionality for
    complex batching and filling applications
  • Suitable for hazardous environments
  • Official calibration certificate
  • Load Cells
  • 5 load cell series for different applications
  • High precision and large measuring range from 10
    kg to 280 t (22 lbs to 276 tons)
  • Hermetically sealed, extremely
  • long life

SIWAREX AWS
SIWAREX R Load cells
more infos
21
Dynamic Weighing Systems
Introduction Pressure TemperatureFlow Level
Positioners Process Protection Process
Controllers Process Recorders Weighing
Components Dynamic Weighing Gas
Analyzers Gas-Chromatographs Spectrometers SIMATIC
PDM System Integration
  • Get the right weight
  • Belt Scales
  • Patented weigh bridge and unique load cell
    technology for accurate and reliable measurement
    of flow rate, totalized weight, belt load and
    conveyor speed.
  • Weigh Feeders
  • Compact, accurate weigh feeders for control of
    bulk solid feed rates. Models include low-,
    medium- and high capacity load feeders with a
    variety of belt widths, inlet configurations and
    construction materials
  • Solids Flowmeters
  • Totally enclosed flowmeters for fine powders or
    granular products. They combine accurate
    measurement with product containment and dust
    reduction
  • Dynamic Weighing Integrators
  • Display instantaneous readings of rate and total
    material flow for flowmeters or for rate, total
    load and speed for belt scales.

Autoweigh Feeder Series
BW 500
Beltscale MMI
SF 500
more infos
E-Series
22
Process Gas Analyzers
Introduction Pressure TemperatureFlow Level
Positioners Process Protection Process
Controllers Process Recorders Weighing
Components Dynamic Weighing Gas
Analyzers Gas-Chromatographs Spectrometers SIMATIC
PDM System Integration
  • Monitor and determine gases
  • ULTRAMAT 23
  • For a wide variety of infrared-active gases as
    well as oxygen. It is a low-cost multi-component
    NDIR analyzer for standard applications,
    e.g. emission monitoring.
  • ULTRAMAT 6
  • High-end analyzers in 19" design or field
    housing. They can be used in all applications
    from emission measurement to process control,
    even in the presence of highly corrosive gases
  • ULTRAMAT/OXYMAT 6
  • Highly efficient combination of NDIR and oxygen
    analyzer in one instrument

ULTRAMAT 23
ULTRAMAT 6
ULTRAMAT/OXYMAT 6
more infos
Series 6 Field Mounting Ex
23
Process Gas Analyzers
Introduction Pressure TemperatureFlow Level
Positioners Process Protection Process
Controllers Process Recorders Weighing
Components Dynamic Weighing Gas
Analyzers Gas-Chromatographs Spectrometers SIMATIC
PDM System Integration
  • Monitor and determine gases
  • OXYMAT 61
  • Low-cost oxygen analyzer for standard
    applications. It can use ambient air as a
    reference gas that is supplied to the analyzer
    section with the integral pump
  • OXYMAT 6
  • High-end analyzer in 19" design or field housing
    based on the paramagnetic principle
  • CALOMAT 6
  • Primarily designed for the measurement of
    hydrogen and rare gas concentrations in blast
    furnace gas and carbon dioxide mixtures based on
    thermal conductivity
  • FIDAMAT 6
  • Gas analyzer for continuous hydrocarbon
    measurement based on flame ionization detection

OXYMAT 61
OXYMAT 6
CALOMAT 6
FIDAMAT 6
more infos
24
Process Gas Chromatographs
Introduction Pressure TemperatureFlow Level
Positioners Process Protection Process
Controllers Process Recorders Weighing
Components Dynamic Weighing Gas
Analyzers Gas-Chromatographs Spectrometers SIMATIC
PDM System Integration
  • Selective identification in
  • complex mixtures
  • MicroSAM
  • The smallest explosion-proof online process gas
    chromatograqph based on state-of-the-art
    micromechanical components.
  • Rugged and small for mounting directly at the
    sampling point
  • MAXUM edition II
  • Best suited to perform a wide range of
    applications in the chemical and petrochemical
    industries and in refineries.
  • Flexible oven concept, temperature programmable
    and energy-saving single or dual oven
    configurations
  • Valveless live sample injection and column
    switching
  • Parallel chromatography allows to break a single
    analysis into multiple single runs

/01
9

MicroSAM
MAXUM edition II
more infos
25
Process Spectrometers
Introduction Pressure TemperatureFlow Level
Positioners Process Protection Process
Controllers Process Recorders Weighing
Components Dynamic Weighing Gas
Analyzers Gas-Chromatographs Spectrometers SIMATIC
PDM System Integration
  • Detect traces in every medium
  • Laser Diode Spectrometer
  • The LDS 6 can measure one or several gases
    under extreme conditions. Even at temperatures
    of 1.500 C (2732 F) or when operating in hiogh
    dust concentrations. The LDS 6 is an in-situ
    analyzer to measure concentrations e.g. in smoke
    gas purification or in filter plants
  • ProcessMass Spectrometer
  • The QUANTRA detects every trace of mass. High
    resolution analyzer for online applications. Due
    to its unique mass resolution, Quantra can
    reliably identify even nearly identical masses
  • AOTF Spectrometer
  • SINIS A a light-weight, compact unit is designed
    for the routine analysis of liquids, pastes,
    powders, and solids. SINIS A optimizes the
    quality control of raw materials and end
    products, provides fast results and ensures
    seamless, continuous documentation and data
    exchange

LDS 6
SINIS A
more infos
QUANTRA
26
SIMATIC PDM The Process Device Manager
  • SIMATIC PDM
  • The Process Device Manager is a consistent,
    manufacturer-independent software tool for the
    operation, configuration, parameterization,
    maintenance and diagnosis of intelligent field
    instruments based on the worldwide leading EDD
    standard

Introduction Pressure TemperatureFlow Level
Positioners Process Protection Process
Controllers Process Recorders Weighing
Components Dynamic Weighing Gas
Analyzers Gas-Chromatographs Spectrometers SIMATIC
PDM System Integration
more infos
27
Engineered Analyzer Systems
Introduction Pressure TemperatureFlow Level
Positioners Process Protection Process
Controllers Process Recorders Weighing
Components Dynamic Weighing Gas
Analyzers Gas-Chromatographs Spectrometers SIMATIC
PDM System Integration
  • Analyzer systems for custom
  • solutions
  • To offer solutions for your application needs,
    we can rely on many years of worldwide experience
    from process automation and engineering and a
    collection of specialized knowledge in key
    industries and industrial sectors, including
  • Chemical industry
  • Petrochemical industry
  • Pharmaceutical industry
  • Food and beverage industry
  • Steel industry
  • Building materials industry
  • All kinds of combustion and furnace processes

more infos
28
  • Thank You
  • for your
  • attention !
Write a Comment
User Comments (0)
About PowerShow.com
