Transport biofuels in Ireland

1
Transport biofuels in Ireland
Bernard Rice
2
Medium-term transport biofuel options

• Pure plant oil (rape-seed oil in modified
  engines)
• Biodiesel from vegetable oils, animal fats
• Ethanol from sugar/starch
• Biogas from animal manures, other organic
  wastes, energy crops (to CNG standard
• for vehicle use)

3
Alternative fuels for I.C. engines

• What defines a good fuel?
• How does the fuel affect engine performance?
• What aspects of engine performance does it affect?

4
Important fuel properties

• Calorific value
• Combustion properties (Cetane, octane)
• Viscosity
• Lubricating properties of fuel
• Effects on engine oil
• Low-temperature behaviour
• Emissions - particulates, NOx, CO, HC etc
• Other environmental issues
• Storage stability

5
Pure plant oil

• Four plants in Ireland
• Few quality problems
• Good demand from hauliers
• But limited uptake due to
• Rape-seed price and supply
• Oil price fluctuations
• Lack of acceptance by most car makers
• Need to modify engine

6
Engine modification for veg oil
7
(No Transcript)
8
(No Transcript)
9
(No Transcript)
10
(No Transcript)
11
(No Transcript)
12
Draft DIN 51605Oil quality for engine use

• Suspended solids (lt24 mg/kg)
• Water content (lt 0.075)
• Acid value (lt2.0 mg KOH/g)
• P content (lt12 mg/kg)
• Ash content (lt0.01)
• Oxidation stability (lt6 hours)

13
Uses of pure plant oil

• Rape-seed oil only (no other oil)
• Up to 100 blends in suitably modified engines
• Use of lt50 blends in unmodified engines
  practiced, but not recommended by anyone
• No acceptance by vehicle industry

14
Biogreen pure plant oil crushing/filtering unit
15
Glanbia plant, Gorey
16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
Fuel economy with biodiesel in routine work
Vehicle Fuel Distance travelled Fuel
economy (km) (km/l) Peugeot
306 100 biodiesel 5,753
16.3 100 Mineral 16,268
16.9 Isuzu Trooper 100 biodiesel
7,037 11.0 100 Mineral
8,915 11.2
4 reduction with biodiesel
2 reduction with biodiesel
20
Biodiesel

• Green Biofuels Ireland, New Ross
• Capacity 30M litres/year
• One year in operation
• Producing high quality biodiesel
• Three other small producers from RVO
• Other developers on hold

21
GREEN BIOFUELS biodiesel plant, New Ross

• Feedstocks
• Rape-seed oil
• Beef tallow
• Recovered veg oil

Capacity 30 million litres/annum
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
Pure plant oil vs biodiesel

• Biodiesel
• Some acceptance by vehicle industry
• Wider feedstock range
• No engine mods needed
• More expensive process
• Pure plant oil
• Smaller scale
• Lower start-up capital
• More local involvement
• No official acceptance by vehicle industry

26
Ethanol
Carbery Milk Processors 10,000 t/year from
whey Cooley Clearpower excess capacity for
potable alcohol Two more projects under study
27
2. BIO-ETHANOL from starch/sugar Fuel
extender/octane booster for petrol engines

• Current Irish possibilities
• Produce from cereals or beet
• Add 5 to petrol (no engine mods)
• Replace MTBE or lead
• Add up to 80 in FFV engines

28
Outline of multi-feedstock ethanol plant
Distillation
Preparation
Fermentation
29
Ethanol yields

• From wheat
• 350 litres per tonne
• 3000 litres per ha
• From sugar beet
• 90 litres per tonne
• 4500 litres per ha

30
Ethanol from wheat, beet

• For 2 substitution
• 15,300 ha beet
• or
• 23,000 ha wheat
• Needs
• Large scale
• Excise relief
• Investor/promoter interest
• Involvement of feedstock suppliers, oil importers

31
Wheat-ethanol plant proposal, Waterford
32
The Irish cereals market

• Future threatened by
• Low and fluctuating prices
• Fall in cattle numbers?
• Declining poultry industry?
• Threats to pig industry?
• Ethanol plant needed to sustain, rather than
  increase cereal production

33
Biogas for transport, CHP or big boilers
Electricity
Heat
Animal manure ( food wastes?) ( energy
crops?) ( grass?)
Fuel cell
Upgrade
Biogas
Gas grid
Digestate
34
Biogas as vehicle fuel
Neue Nutzungsmöglichkeiten, hohe Effizienz
In the future, up to 200,000 km/ha will be
attainable from biogas,with higher-yielding crops
and more efficient conversion
Biodiesel 11.885 kWh/ha
23.770 km
Bioethanol 14.825 kWh/ha
29.650 km
BTL (Biomass-to-Liquid) 30.252 kWh/ha
60.500 km
Biomethan 47.000 kWh/ha
94.000 km
Kraftstofferträge in kWh / ha
km-Umrechnung in Bezug auf Diesel-äquivalent
rund 10 kWh/l und 5 l/100 km
35
Medium-term production potential(1st-gen
biofuels)
Diesel Pure plant oil 10-30,000
t Biodiesel 40-60,000 t Petrol From
whey 10-15,000 t From cereals 100,000
t Total 200,000 t Substitution 3
36
Motor Oil Tax Relief (2007) allocations
Fuel No. of producers 5-year volume (million litres)
Bioethanol 4 306
Blended biodiesel 4 290
Biodiesel (captive fleets) 5 48
Pure plant oil 3 21
Most is being imported
37
What next!

• Obligation system to replace excise relief
• National Bio-energy Action Plan

38
How would it work?
Change to a biofuel obligation system

• Fuel suppliers given biofuel substitution target
• Certificates issued for biofuel sales
• Biofuel producers can sell certificates
• Fuel suppliers can either sell biofuels, buy
  certificates or pay buy-out penalty

39
Next-generation transport biofuels

• Ethanol from cellulosic biomass (e.g. wood)
• 2. Thermo-chemical biomass conversion (BtL)
• 3. Biogas from manures, food wastes, energy
  crops, municipal/industrial sludges
• 4. Bio-hydrogen use in engines, fuel cells
• 5. Bio-refineries (fuel other non-food
  products)

Still in development, potential in Ireland not
clear
40
Renewable Energy Directive

• By 2020 -
• 20 of consumed energy renewable
• 10 of transport energy renewable
• National Action Plans by June 2010, to include
• Sector targets
• Measures to achieve targets
• National policies for existing and new resources
• Not a re-hash of existing schemes

41
Conclusions (1)

• We should aim to
• expand liquid ppo and biodiesel production to
  maximum agronomic extent
• Promote native ethanol production from arable
  crops
• Develop biogas production from animal manure,
  food wastes and energy crops
• Expand cellulose crop production, initially for
  heat/electricity, later for liquid biofuels or
  bio-refineries

42
Conclusions (2)

• To achieve these targets, and to maximise home
  production of biofuels, we need
• Long-term policies and support programmes to
  reassure farmers and investors
• Transport biofuel supports sensitive to the needs
  of small-scale producers
