Sensation Perception
2
?
-Discussion Section- Session 4 Visual Cortex
I Icecube (Hubel Wiesel) Pinwheel (Issa
Stryker)
3
Administrative stuff
4
Presentation 1 Receptive fields and
functional architecture of monkey striate cortex
(1968)presented by John Scott-Railton

Presentation 2 Spatial Frequency Maps in Cat
Visual Cortex (2000)presented by Jasmine Kwong
5
Next week
Week 7 11/08/2004 Higher visual perception
Contours Paper 1 (Classic) von der Heydt et
al., 1984 (Perla) Paper 2 (Modern) Bakin et
al., 2000 (?)
6
BACKGROUND
7
This weeks issue
8
How can one effectively represent 6 stimulus
dimensions on a 2.5 dimensional sheet?
Orientation Ocular dominance Spatial frequency
Motion Depth Color
9
Essentially a mathematical optimization problem

• Similarly
• How to put as much of the sheet as possible into
  a sphere? (Cortex into skull)

Solution?
Folding!
10
Thats why cortex is folded

• It optimizes area while minimizing volume
• So far, so good.
• But what about the basic functional unit of
  cortex organization?
• How to represent all stimulus dimensions
  effectively in all locations?

11
Two proposals
12
1. The Iceblock model (Hypercolumns)
Nobel prize in Physiology, 1981
13
(No Transcript)
14
2. The Pinwheel model
15
(No Transcript)
16
Optical imaging

• Rationale
• Deoxygenated blood is darker than oxygenated
  blood.
• This is particularly true in the range of red
  light.
• Active neurons use up more oxygen than neurons
  that are less active.
• This leads to a local, spatial distribution of
  blood saturation levels.
• ? Regions of active neurons should appear darker.


17
Optical Imaging
18
Pro and Con

• Pro
• Very high spatial resolution
• Allows to visualize large scale activity patterns
• Relatively direct link to electrical activity of
  neurons
• Better time course than fMRI

• Con
• Still relatively bad time course (linked to
  oxygen dynamics)
• Invasive
• Very low signal to noise ? need to average many,
  many trials to see signal.
• Hemodynamics indirect, nonlinear.

19
BOLD time course
20
The case for spatial frequency
Orientation Ocular dominance Spatial frequency
Motion Depth Color
21
Picture representation in V1
22
The concept
Luminance
Wavelength Spatial Frequency
Amplitude Contrast
Space
23
Looks like
24
Fouriers theorem

• EVERY waveform can be decomposed into simple
  sine-waves with the right amplitude and
  frequency.
• EVERY waveform can be synthesized by adding
  sine-waves with the right amplitude and frequency.

25
(No Transcript)
26
V1 neurons are apt to represent sine waves of
different frequency
27
(No Transcript)
28
Philosophical implication

• The representation of the visual world by neurons
  in V1 is VERY different from our phenomenological
  experience. Each neuron only represents a tiny
  slice of oriented spatial frequency!
