Protapers

1
Protapers.an edge ahead of 0.02 Taper.
2
Basic introduction

• Protaper is a based on a unique concept and
  comprised of just 6 endodontic instruments, made
  up of NICKEL TITANIUM.
• It consists of 3-shaping files and 3-finishing
  files.
• It was designed by
• Dr Cliff Ruddle
• Dr John West
• Dr Pierre Machtou.

3

• The cross section of Protaper is a modified
  K-type of design with sharp cutting edge and no
  radial lands. This creates a stable core and
  sufficient flexibility for smaller files, though
  the cross section of finishing files is slightly
  relieved for increased stability.

4
Unique design factors are.

• Varying tapers along the long axis of the
  instrument.
• The three shaping files have tapers that
  increases coronally and reverse pattern is seen
  in finishing files.
• Color coding.
• Currently lengths available are 21 mm 25 mm.
• Available as hand as well as rotary endodontic
  files.

5

• Protaper files

Hand Protaper
Rotary Protaper
6
Shaping files.

• There are 3-shaping files , S1, S2 Sx.
• S1 is the shaping file-one, purple colour.
• S2 is the shaping file-two, white colour.
• Sx is the shaper x or auxillary shaper, golden
  colour.
• The taper of all the shaping files increases
  coronally.

7
Finishing Files.

• There are 3-finishing files, F1,F2 F3.
• F1 is the finishing file one, yellow coloured ,
  Do diameter is 0.20 mm.
• F2 is the finisher file two, red coloured , D0
  diameter is 0.25 mm
• F3 is the finisher three ,blue coloured ,D0
  diameter is 0.30 mm.
• The taper increases apically.
• .Newer addition is F4 ( 40 mm) ,F5( 50 mm) , F6
  ( 60 mm )..

8
S 1 ( Shaper one )

• Shaping File one.
• Purple coloured.
• D0 diameter is 0.17 mm D14 diameter is 1.20 mm
• Prepares coronal 1/3rd of the canal.
• Non cutting modified guided tip.
• There are 12 increasing tapers along the length
  of the blade.

9
(No Transcript)
10
S 2 ( Shaper two )

• Shaping file two.
• White coloured.
• D0 diameter is 0.20 mm D14 diameter is 1.20mm.
• Prepares middle 1/3rd of the canal.
• Non cutting modified guided tip.
• There are 9 increasing tapers.

11
(No Transcript)
12
Sx ( Shaper X / auxillary shaper)

• Shaper X / Auxillary shaper.
• Golden coloured handle.
• D0 diameter is 0.20 D14 diameter is 1.20mm.
• It is used to do coronal flaring in the same way
  as done with GG drills i.e. cutting in out
  strokes.
• There is an aggressive cutting tip.
• There is a much faster rate of taper from D0 to
  D9 as compared to S1 S2 , i.e. at D6,D7,D8,D9
  the CS diameter is 0.50,0.70,90,1.10
  respectively.

13
(No Transcript)
14
F 1 ( Finishing file one )

• Finishing file one.
• Yellow in colour.
• Used for finishing of apical 1/3rd
• D0 diameter is 0.20 mm.
• Between D0-D3 F1 has a fixed taper of 7 percent.

15
(No Transcript)
16
F 2 ( Finisher File Two )

• Finishing file two.
• Red in colour.
• Used in preparation of apical 1/3rd
• Do diameter is 0.25 mm.
• Between D0-D3 F2 has a fixed taper of 8 percent.

17
(No Transcript)
18
F 3 ( Finishing file three )

• Finishing file three.
• Red in colour.
• Used in the preparation of apical 1/3rd.
• D0 diameter is 0.30 mm.
• Between D0-D3 , F3 has a fixed diameter of 9
  percent.

19
(No Transcript)
20
Unique features

• 1.MULTIPLE TAPERS.
• 2.CONTINOUSLY CHANGING HELICAL ANGLE PITCH.
• 3.MODIFIED GUIDED TIP WITH VARIABLE TIP
  DIAMETERS.
• 4.NEW INSTRUMENT SERIES WITH JUST 6 INSTRUMENTS.
• LESS RECAPITULATIONS ARE NEEDED.

21
Technique of use.

• 1.Diagnostic radiograph.
• 2.Endo anesthesia
• 3.Placement of rubber dam.
• 4.Access cavity preparation.
• 5.Recommended technique CROWN DOWN PRESSURE
  LESS.
• 6.Scout the coronal 2/3rd .
• 7.Take the working length..
• 8.Reach till apex.
• 9.Apical gauging....
• 10.Prepare the apical 1/3rd
• 11.Dry the canal using Protaper absorbent points

• 12.Fitting of master GP cone.
• 13.Apply the sealer..
• 14.Obturation , post Obturation radiograph.
• 15.Final restoration..

22
Technique of Use.
23
(No Transcript)
24
Clinical cases... ByDr Sanjay
Chauhan
25
1.Sarita/39/F / Rewari
( A Case Of Single Sitting R.C.T.)
Before treatment
After treatment
26
2. Anamika/24/F
( A Case of Single Sitting R.C.T.)
Before treatment
After treatment
27
3.Mehandiratta/42/M
(A Case Of Single Sitting R.C.T. )
Before Treatment
After Treatment
28
4.Naveen Kumar/42/M
Diagnostic Radiograph
Fitting of GP Cone
Post Obturation Radiograph
29
5.Suman/34/F/Rewari
( C-Shaped canals)
Before Treatment
After Treatment
30
6. Dinesh/24/M/Rewari
(A Case of Single sitting R.C.T. )
After Treatment
Before Treatment
31
7.Kitabo Devi/ 64/F /Rewari
( A Case of Re R.C.T. )
After treatment
Before Treatment
32
8. Shashi/24/F/Rewari
(A Case of Single sitting R.C.T. )
Before Treatment
After treatment
33
9. Ramesh/24/M/Rewari
( A Case Re R.C.T. )
Before Treatment
After Treatment
34
10. Sarita/22/F/Rewari
A case of Single sitting R.C.T.
Before Treatment
After Treatment
35
11. Anita/24/f/Rewari
A Case of Single sitting R.C.T.
Before treatment
After treatment
36
12. Anita/23/f/Rewari
A case of single sitting R.C.T.
Before treatment
After treatment
37
13. Renu/26/F/Rewari
A Case Of Single sitting R.C.T.
Before treatment
After treatment
38
14. Rakesh/28/M/Rewari
A Case of single sitting R.C.T.
Before treatment
After treatment
39
15. Sunita/26/F/Rewari
A Case of single sitting R.C.T.
After Treatment
Before Treatment
40
16. Sunita/39/F/Rewari
A Case Of single sitting R.C.T.
Before treatment
After treatment
41
17.Shagun/32/F/Rewari
A case of single sitting R.C.T.
Before treatment
After Treatment
42
18. Ramesh/21/M/Rewari
A case of single sitting R.C.T.
Working Length radiograph
Post Obturation radiograph
43
19. Manisha/24/F/Rewari
A Case of single sitting R.C.T.
After treatment
Before treatment
44
20. Praveen/24/M/Rewari
A Case Of Intentional Replantation
Diagnostic radiograph
45
Extra oral stages of Treatment
46
Before treatment
After treatment
47

• Thank you..
