Indra Espacio
SMOG 26-6-2006 Final Presentation Technical Part
( Área reservada a imagen )
ESRIN Final Presentation, June 26th 2006
Smog Team- Indra Espacio
2
Index

• Progress Meeting Technical presentation
• Introduction to Smog project (General view)
• Technical Presentation
• Project achievements
• Goals met in PAS,PGS,FEP,DDS and MAN.
• Advantages of the actual system
• Scalability of the system
• Full system distribution

3
Introduction

• The main objectives of the SMOG project are
• To define a generic architecture, applicable to
  the Ground Segment of Earth Observation Small
  Missions.
• To define an Advanced Ground Facility, AGF, as a
  basic node of the future ground segment.
• To define and to construct an AGF Prototype for
  the validation of the major concepts applicable
  to AGF.

4
AGF Prototype functions

• Acquisition of telemetry data from MODIS and ERS
  satellites
• Transformation of the telemetry into Computer
  Compatible Format
• Generation of EO products MODIS and ERS products
• Storage, archive and catalogue the EO products
• Dissemination of products to the EO data users

5
AGF Design concepts

• What were we facing at?
• Prototype with 5 Main subsystems
• 1 Manager controling the system
• Smart Communication design to cope with modular
  architecture
• Databases
• Product Procesors Integration reuse
• Reusability, Distribution etc...

6
AGF Design concepts II

• What do we have to show?
• 5 Subsystems
• Manager
• PAS. Product Archive S/S
• PGS. Product Generation S/S
• DDS. Data Dissemination S/S
• FEP. Front End Processor
• JMS communications.
• Scalability,distribution, portability and
  reuseability.

7
AGF Design concepts III

• AGF management framework based on a hierarchical
  architecture composed by two layer
• MAN
• PGS, PAS, DDS and FEP with their own local
  manager, task manager, responsible for managing
  its resources and internal activities.

8
AGF SW architecture S/S

• 1.- Initial Stage

Commands/response (JMS)

• 2.- Intermediate Stage

DB access (JDBC)

• 3.- Final Stage

9
AGF Protocols

• Control flow orders from AGF_MAN to S/S
• Using JMS Communication middleware (software bus)
• Data flow horizontal among S/S
• Using FTP
• Transferences granted by AGF_MAN to each S/S
• S/S perform FTP transferences (pull mechanism)

10
AGF SW architecture GUI S/S
11
AGF SW architecture COTS used

• Programming languages.
• Java 1.4.2 .
• JSP.
• Javascript.
• OS scripting.
• HTML.
• Database
• Oracle 9i
• Operative Systems
• Linux
• Windows XP
• FTP server
• Log4j
• OpenJms
• EPSI-ERS 1.2.6 SLC processor and Viewer
• MODIS IMAPP 1.5
• MODIS Scanview

12
AGF SW architecture
13
AGF SW architecture Zoomable
Physical FEP
MAN
PGS
PAS
DDS
FEP MC
FEP
AGF
IQ
14
Final AGF HW configuration

• Smogl1
• PGS
• PAS
• DB Oracle

• Smogl2
• FEP
• DDS
• MAN
• Tomcat

15
Presentation of the Product (Components)

• Dell 650 Precision

• Dell 670 Precision

PGS PAS DB
MAN FEP DDS Web Server
16
Presentation of the Product (Components)

• FEP
• Demodulator
• Controlling FEP PC
• IQ
• Testmodulator
• Controlling IQ PC
• Distribution network
• 2 CISCO firewalls

17
Presentation of the Product (Components - IQ)
Test Modulator
Demodulator
Controlling FEP PC
Controlling IQ PC
18
Presentation of the Product (Dual Mission
Connectivity)
MODIS At 13.125Mbps
ERS-HR At 105Mbps
ERS-HR
MODIS
MODIS
ERS-HR
FEP
IQ
19
AGF Performances

• Facts
• Orbit period time 100 minutes.
• IAGD process time for MODIS is 56 minutes.
• Conclusion
• Processing product within 60 minutes lt orbit
  period using low cost HW.

20
AGF Achievements (I)

• Demonstrate the feasibility of developing a
  low-cost system able to generate automatically EO
  products.
• Distributed system 4 platforms.
• Most of generic part of system coded in JAVA
  MAN, PAS, PGS, DDS -gt portable to other systems
• Specific components, that is processors, coded in
  C.
• FEP reconfigurable
• Simple use, complexity is resolved by background
  running S/S AGF MAN, PAS, PGS, DDS, FEP.

21
AGF Achievements (II)

• Puzzle of SW components
• Three operating system running
• Red hat Linux AGF S/S
• FEP and IQ Suse Linux
• Windows Client
• Processors
• MODIS downloaded from SSEC
• ERS reused EPSIE SLC processor from INDRA
• Quick-Look Viewers
• MODIS scan view
• Reused INDRA EPSIE component
• Several open source components used (JMS, Log4)
  used for implementation
• Web access

22
Introduction
Roles in the Application
23
Main GUI components

• Administrators user interface

24
Main GUI components

• Coordination Services interface

25
Main GUI components

• User Services interface

26
Main GUI components

• User interface

27

• Generate IAGD DMAP File for MODIS sensor.
• Check DMAP Received.
• Go to Administrator Role and check Jobs.
• Verify disseminated Product in Scan Magic HDF
  viewer.
• Launch a IAGD DMAP file for EPSIE SAR sensor and
  IA for MODIS Sensor.

28
AGF L0 Viewers

• MODIS y ERS

• ERS viewer (slc)

Modis viewer (Scanview)
