Organische Chemie 1B

1
Organische Chemie 1B

• Prof. dr. Floris Rutjes

2
Organische Chemie 1B
Docent Prof. dr. Floris Rutjes Werkcollege
assistenten Pieter de Witte Bas
Gruijters UL 354 Tel. 53202, rutjes_at_sci.kun.nl B
oek Maitland Jones, Jr., Organic Chemistry, 2nd
ed Aanbevolen Student Version met antwoorden op
vragen uit het boek
3
Organische Chemie 1B

• Hoor- en werkcolleges worden door elkaar heen
  gegeven
• College wordt gegeven met PP slides
• PP files worden uitgereikt als dictaat
• Een deel zelfstudie vereist (oefenen van opgaven)
• Te lezen op http//www.sci.kun.nl/chemistry/index
  _nl.html
• Belangrijke mededelingen over dit college zijn
  hier te vinden

4
Topics in OC 1B

• Reactions with alkenes (Chapter 8 and 9)
• Reactions with alkynes (Chapter 9)
• Reactions with aromatic compounds (Chapter 11, 12
  and 13)
• Radical reactions (Chapter 10)

5
Electronegativity

• The electronegativity increases from left to
  right and from bottom to top in the periodic
  table
• A difference in electronegativity creates a
  dipole, or in other words an electrophilic and a
  nucleophilic part

6
The arrow formalism
This is what you have always learned.
This is how you must write it from now on !

• Extremely important
• the arrows represent the flow of electrons !

7
Stability of cations

• The stability of the cation increases with the
  presence of additional alkyl sbstituents

8
Why is Et more stable than Me ?

• The reason is called hyperconjugation overlap of
  one of the CH-orbitals with the empty 2p orbital.

9
Review of resonance (p 317-322)
Make problems 8.31, 8.34 and 8.35.
10
The allylic cation (orbitals)
The delocalization can also be explained by
considering the orbital overlap
11
Inductive effects

• Inductive effects the influence of
  electron-withdrawing or electron-donating groups
• Inductive effects take place via the CC-bonds

12
Inductive vs. resonance effects
Rule of thumb resonance effects are stronger
than inductive effects
13
Substitution reactions (SN2)

• SN2 direct substitution of the leaving group by
  the nucleophile
• Inversion of configuration
• Especially with primary and secondary carbon atoms

14
Substitution reactions (SN1)

• SN1 substitution proceeds via an intermediate
  carbocation
• Stereochemical information is lost
• Especially at stabilized carbocations, i.e.
  tertiary carbocations or carbocations stabilized
  by resonance structures

15
Elimination reactions (E2)

• E2 elimination takes place in a synchronous
  fashion, without the intermediacy of carbocations
• The substituents must be anti or
  anti-periplanar with respect to each other

16
Elimination reactions (E1)

• E1 elimination proceeds via the formation of a
  carbocation
• Occurs especially when a stable cation (tertiary,
  or stabilized by resonance) can be formed

17
Alkenes in Nature

• Fatty acids

• Terpenes

18
Alkene-containing amino acids
19
Addition reactions to alkenes
20
Nucleophiles
Species N?C HS I HO Br N3 NH3 Cl F CH3O
H H2O
Species cyanide thiolate iodide hydroxide bromid
e azide ammonia chloride fluoride methanol water
Relative nucleophilicity 126,000 126,000 80,000
16,000 10,000 8,000 8,000 1,000 80 1 1
Excellent nucleophiles
Good nucleophiles
Fair nucleophiles
21
Other types of nucleophiles

• Nucleophile an atom (or group of atoms) that
  contains free electron pairs such as heteroatoms
• A better definition is an atom (or group of
  atoms) that contains delocalizable electrons
• In other words p-bonds can also act as
  nucleophiles

22
An example
Olefins are very weak nucleophiles therefore, a
strong electrophile needs to be present (in this
case H) A relatively stable secondary
carbocation is formed, which is trapped by the
chloride nucleophile
23
The carbocation is planar

• The intermediate secondary carbocation is
  sp2-hybridized

24
The energy profile
25
Question
Which product do you expect for the following
reaction (give the mechanism) ?
1-pentene
26
Stability of cations
Which product will be formed in the following
reaction ?
In other words which cation is more stable ?
27
Stability of the cation (II)
Explain the outcome of the following reaction
28
The allylic cation
An allylic cation is relatively stable due to the
delocalization of the positive charge.
29
The rule of Markovnikov in addition reactions
the nucleophile ends up at the more substituted
carbon atom
The Markovnikov Rule
30
Problems

• Make problems 8.36, 8.38, 8.41

31
The addition of H2O
In the presence of a strong acid (e.g. H2SO4) and
water, the addition reaction also takes place.
32
Another example isobutene
33
Polymerization
In the presence of only a catalytic amount of H
and a high concentration of the olefin,
polymerization takes place.
34
Question
Give the product of the following reaction
styrene
35
Anti-Markovnikov addition of H2O

• Anti-Markovnikov addition of water is achieved
  via a hydroboration reaction, i.e. addition of
  BH3 to the double bond.

36
What does BH3 look like ?
BH3 exists as a dimer
It is usually sold as a stable complex with THF
37
The mechanism (I)
The nucleophilic alkene attacks the electron poor
boron atom
38
The mechanism (II)
Hydroboration selective syn-addition to the
double bond !
39
The mechanism (III)
The anti-Markovnikov outcome is largely explained
by steric interactions
40
BH3 can add to more olefins
41
Steric effects determine the outcome
The more substituted the olefin, the less olefins
will fit on one boron atom
42
Conversion of B into OH
43
The overall result
44
Cation rearrangements
How can this outcome be explained?
45
A hydride-shift occurs
The molecule rearranges to the thermodynamically
more stable tertiary carbocation via a
hydride-shift
46
How to explain this result?
Hint AgI is insoluble in water
47
A methyl-shift occurs
48
Problems

• Make problems 8.44, 8.45, 8.47, 8.48
