BODY CAVITIES,

1
BODY CAVITIES, MESENTERIES DIAPHRAGM
Dr. Ahmed Fathalla Ibrahim
2
INTRAEMBRYONIC COELOM
3
INTRAEMBRYONIC COELOM

• Appears as isolated spaces in the lateral
  mesoderm
• In the 4th week, the spaces fuse to form a single
  horseshoe-shaped (U-shaped) cavity
• The coelom divides the lateral mesoderm into
• Somatic (parietal) layer under ectoderm
• Splanchnic (visceral) layer over endoderm
• Somatopleure somatic mesoderm overlying
  ectoderm
• Splanchnopleure splanchnic mesoderm
  underlying endoderm

4
INTRAEMBRYONIC COELOM
5
INTRAEMBRYONIC COELOM

• DERIVATIVES It gives rise to three body
  cavities
• A pericardial cavity the curve of U
• Two pericardioperitoneal canals (future pleural
  cavities) the proximal parts of the limbs of U
• Two peritoneal cavities the distal parts of the
  limbs of U
• Each cavity has a parietal layer (derived from
  somatic mesoderm) a visceral layer (derived
  from visceral mesoderm)
• FUNCTION It provides space for the organs to
  develop move

6
DEVELOPMENT OF PERITONEAL CAVITY

• Major part of intraembryonic coelom
• Develop from the distal parts of the limbs of the
  U-shaped cavity
• Originally, it is connected with extraembryonic
  coelom (midgut herniates to the outside through
  this connection)
• At 10th week, it looses its connection with
  extraembryonic ceolom (when midgut returns to
  abdomen)

7
DEVELOPMENT OF PERITONEAL CAVITY

• Originally, there were 2 peritoneal cavities
• After lateral folding of embryo, the peritoneum
  becomes a single cavity
• HOW?

8
(No Transcript)
9
Dorsal Mesentery
Gut
Peritoneal Cavity
Ventral Mesentery
10
MESENTERIES

• A MESENTERY is a double layer of peritoneum that
  begins as an extension of the visceral
  peritoneum covering an organ
• The mesentery connects the organ to the body wall
  and transmits vessels and nerves to it
• Transiently, the dorsal ventral mesenteries
  divide the peritoneal cavity into right left
  halves
• The ventral mesentery disappears EXCEPT where
  stomach develops
• (WHY?)

11
(No Transcript)
12
PERICARDIAL CAVITY

• Develops from the curve of the U-shaped cavity
• During formation of head fold, the heart
  pericardial cavity move ventrocaudally become
  anterior to the foregut (esophagus)
• It is bounded by an outer somatic an inner
  visceral layer, forming the serous pericardium

13
PERICARDIAL CAVITY

• Originally, it is connected with the 2
  pericardioperitoneal canals
• Later on, it become separated from the 2
  pericardioperitoneal canals
• HOW?

14
(No Transcript)
15
PERICARDIAL CAVITY

• Originally, the bronchial buds are small relative
  to the heart
• Bronchial buds grow laterally into
  pericardioperitoneal canals (future pleural
  cavities)
• Pleural cavities expand ventrally around heart
  splits mesoderm into
• Outer layer forms thoracic wall
• Inner layer pleuropericardial membrane

16
PLEUROPERICARDIAL MEMBRANES

• THE PARTS SURROUNDING THE SEROUS PERICARDIUM
  form the fibrous pericardium
• THE PARTS BEHIND THE HEART fuse with the ventral
  mesentery of the esophagus (at 7th week), forming
  the mediastinum separating pericardial from
  pleural cavities
• N.B. The right pleural cavity separates from
  pericardial cavity earlier than left

17
PLEURAL CAVITIES

• Develop from the 2 pericardiperitoneal canals
• Originally, they are connected with pericardial
  peritoneal cavities
• Later on, they become separated from
• Pericardial cavity
• Peritoneal cavity (HOW?)

18
(No Transcript)
19
PLEUROPERITONEAL MEMBRANES

• Produced when developing lungs pleural cavities
  expand into the body wall
• During 6th week, they fuse with dorsal mesentery
  of esophagus septum transversum, separating
  pleural cavities from peritoneal cavity
• N.B. The right pleural cavity separates from
  peritoneal cavity earlier than left

20
DEVELOPMENT OF DIAPHRAGM
21
DEVELOPMENT OF DIAPHRAGM

• The diaphragm develops from
• Septum transversum forms the central tendon
• Dorsal mesentery of esophagus forms the right
  left crus
• Muscular ingrowth from lateral body wall
  posterolateral part (costal part)
• Pleuroperitoneal membranes small portion of
  diaphragm

22
SEPTUM TRANSVERSUM

• At 3rd week, it is in the form of mass of
  mesodermal tissue in the cranial part of embryo
  (opposite the 3rd, 4th 5th cervical somites)
• At 4th week (during formation of head fold), it
  moves ventrocaudally forming a thick incomplete
  partition between thoracic abdominal cavities
• At 6th week, it expands fuse with dorsal
  mesentery of esophagus pleuroperitoneal
  membranes to form the diaphragm

23
INNERVATION OF DIAPHRAGM

• Myoblasts from 3rd, 4th 5th cervical somites
  migrate into diaphragm bring their nerve fibers
  from them
• Nerve fibers derived from ventral rami of 3rd,
  4th 5th cervical nerves fuse to form phrenic
  nerve that elongate to follow the descent of
  diaphragm
• Both motor sensory supply of the diaphragm is
  derived from phrenic nerve
• The part of diaphragm derived from lateral body
  wall receives sensory fibers from lower
  intercostal nerves

24
ANOMALIES OF DIAPHRAGM

1. CONGENITAL DIAPHRAGMATIC HERNIA
2. EVENTRATION OF DIAPHRAGM
3. CONGENITAL HIATAL HERNIA

25
CONGENITAL DIAPHRAGMATIC HERNIA
26
CONGENITAL DIAPHRAGMATIC HERNIA

• A posterolateral defect of diaphragm
• Cause defective formation and/or fusion of
  pleuroperitoneal membrane with other parts of
  diaphragm
• Effects
• Herniation of abdominal contents into thoracic
  cavity
• Peritoneal pleural cavities are connected with
  one another
• The defect usually occurs in the left side (WHY?)

27
EVENTRATION OF DIAPHRAGM
28
EVENTRATION OF DIAPHRAGM

• Cause failure of muscular tissue from body wall
  to extend into pleuroperitoneal membrane on one
  side
• Effects superior displacement of abdominal
  viscera (surrounded by a part of diaphragm
  forming a pocket)

29
CONGENITAL HIATAL HERNIA

• Herniation of part of the stomach through a large
  esophageal hiatus (opening)
