Respiratory System

1
Chapter 9

• Respiratory System

2
Points to Ponder

• What are the parts and function of the upper and
  lower respiratory system?
• What is the mechanism for expiration and
  inspiration?
• How is breathing controlled by the nervous system
  and through chemicals?
• Where and how is exchange of gases accomplished?
• What are some common respiratory infections and
  disorders?
• What do you know about tobacco and health?
• What is your opinion about bans and legislation
  on smoking?

3
9.1 The respiratory system
4
Respiratory Pathway Air Flow
8.1 Overview of digestion

• nose
• pharynx
• larynx
• trachea
• bronchus
• bronchioles
• alveoli

5
What constitutes the upper respiratory tract?
9.2 The upper respiratory tract

• Nose
• Pharynx
• Larynx

6
The Nose
9.2 The upper respiratory tract

• Opens at the nostrils/nares and leads into the
  nasal cavities
• Hairs and mucus in the nose filters the air
• Mucus ? helps trap dust and move it to the
  pharynx to be swallowed
• The nasal cavity has lot of capillaries that warm
  and moisten the air
• Specialized ciliated cells act as odor receptors
• Nerve impulses generated by the receptors are
  interpreted as smell
• Tear (lacrimal) glands drain into the nasal
  cavities that can lead to a runny nose

7
The Pharynx
9.2 The upper respiratory tract

• Funnel-shaped cavity commonly called the throat
• Connects the nasal and oral cavities to the
  larynx
• 3 portions based on location
• Nasopharynx ? where the Nasal cavity opens
• Auditory tubes empty into this location
• Oropharynx ? where the Oral cavity opens
• Laryngopharynx ? opens into the larynx
• Tonsils provide a lymphatic defense during
  breathing at the junction of the oral cavity and
  pharynx
• Contain lymphocytes that protect against invasion
  of foreign antigens that are inhaled
• Respiratory tract assists the immune system in
  maintaining homeostasis

8
The Larynx
9.2 The upper respiratory tract

• Triangular, cartilaginous structure that passes
  air between the pharynx and trachea
• Called the voice box and houses vocal cords
• Vocal Cords
• 2 mucosal folds that make up the vocal cords with
  an opening in the middle called the glottis
• Creation of Sound
• Air is expelled through glottis forcing the vocal
  cords to vibrate
• Pitch
• High ? greater the tension, glottis becomes
  narrower
• Lower ? glottis is wider
• Amplitude (volume) degree of vocal cord
  vibrations

9
The Larynx

• Creation of Sound
• Air is expelled through glottis forcing the vocal
  cords to vibrate
• Pitch
• High ? greater the tension, glottis becomes
  narrower
• Lower ? glottis is wider
• Amplitude (volume) degree of vocal cord
  vibrations

10
Lower Respiratory Tract
9.3 The lower respiratory tract

• Trachea
• Bronchial tree
• Lungs

11
The Trachea
9.3 The lower respiratory tract

• A tube, often called the windpipe, that connects
  the larynx with the 1 bronchi
• Made of connective tissue, smooth muscle and
  C-shaped cartilaginous rings
• Lined with cilia and mucus that help to keep the
  lungs clean
• Mucus membrane line trachea
• Pseudostratified ciliated columnar epithelium
• Mucus from goblet cells

12
The Trachea

• Coughing
• 1. Tracheal wall contracts, narrowing the
  diameter
• 2. Air moves more rapidly through the trachea
• 3. Expels mucus and foreign objects

13
The bronchial tree
9.3 The lower respiratory tract

• Starts with two primary bronchi that lead from
  the trachea into the lungs
• The bronchi continue to branch into secondary
  bronchi until they are small bronchioles about
  1mm in diameter with thinner walls
• Bronchioles eventually lead to elongated sacs
  called alveoli
• Asthma Attach
• smooth muscle of bronchioles contract ? wheezing

14
The Lungs
9.3 The lower respiratory tract

• The bronchi, bronchioles and alveoli beyond the
  1 bronchi make up the lungs
• Right lung has 3 lobes --- Left lung has 2
  lobes
• Lobes are divided into lobules
• Each lobule has a bronchiole serving many alveoli
• Each lung is enclosed by membranes called pleura
• Double layer of serous membrane that produces
  serous fluid
• Parietal Pleura adhere to thoracic cavity wall
• Visceral Pleura adhere to surface of lungs
• Surface tension holds the two pleural layers
  together, therefore lungs follow the movement of
  the thorax when breathing
• Surface tension tendency of water molecules to
  cling to one another due to hydrogen bonding
  between molecules

15
The Alveoli
9.3 The lower respiratory tract

• 300 million in lungs that increase surface area
• Alveoli are enveloped by blood capillaries
• The alveoli and capillaries are simple squamous
  epithelium to allow exchange of gases
• Oxygen diffuse across alveolar wall to
  bloodstream
• CO2 diffuse from blood across the alveolar wall
  to the aveoli
• Alveoli lined with surfactant that act to keep
  alveoli open
• Decrease surface tension of water

16
Two Phases of Breathing/Ventilation
9.4 Mechanism of breathing

• 1. Inspiration an active process of
  inhalation that brings air into the lungs
• 2. Expiration usually a passive process of
  exhalation that expels air from the lungs

17
Thoracic Cavity

• Lungs in thoracic cavity
• Rib cage joined to vertebral column and sternum
• Intercostal muscles line between the ribs
• Diaphragm and connective tissue

18
Inspiration Active Phase
9.4 Mechanism of breathing

• 1. The diaphragm and external intercostal
  muscles contract
• The diaphragm flattens and the rib cage moves
  upward and outward (active phase)
• 2. Volume of the thoracic cavity and lungs
  increase
• The air pressure within the lungs decrease
• - creating partial vacuum
• Air flows into the lungs
• - Actual flow of air into the alveoli is passive

19
Expiration Passive Phase
9.4 Mechanism of breathing

• 1. The diaphragm and external intercostal
  muscles relax
• 2. The diaphragm moves upward and becomes
  dome-shape
• The rib cage moves downward and inward
• 3. Volume of the thoracic cavity and lungs
  decrease
• 4. The air pressure within the lungs increases
• 5. Air flows out of the lungs

20
Maximum Inspiratory Effort and Forced Expiration

• Maximum inspiratory effort involves Back, chest,
  and neck
• Increases the size of the thoracic cavity
• Maximize expansion of the lungs
• Maximum Expiration effort
• Contraction of the internal intercostal muscles
• Force rib cage to move downward and inward
• Abdominal wall muscles contract and push against
  the diaphragm
• Increased pressure in the thoracic cavity expels
  air

21
Different volumes of air during breathing
9.4 Mechanism of breathing

• Tidal volume
• the small amount of air that usually moves in and
  out with each breath (500 mL)
• Vital capacity
• the maximum volume of air that can be moved in
  plus the maximum amount that can be moved out
  during one breath
• Inspiratory and expiratory reserve volume
• the increased volume of air moving in or out of
  the body (2,900 mL)
• Residual volume
• the air remaining in the lungs after exhalation
• Air is no longer useful for gas exchange

22
Visualizing the Vital Capacity
9.4 Mechanism of breathing
23
Breathing controlled by the nervous system
9.5 Control of ventilation

• Breathing 12 20 ventilations/min
• Rhythm of ventilation controlled by nervous
  system
• Nervous control (involuntary)
• Inspiration
• Respiratory control center in the brain (medulla
  oblongata) sends out nerve impulses to contract
  muscle for inspiration
• Expiration
• Respiratory control center stops sending neuronal
  signals to the diaphragm and rib cage
• Sudden infant death syndrome (SIDS) is thought to
  occur when this center stops sending out nerve
  signals
• Can voluntarily control breathing to force
  inspiration
• 1. Stretch receptors in alveolar walls initiate
  inhibitory nerve impulses
• 2. Stops respiratory center from sending out
  nerve impulses temporarily

24
(No Transcript)
25
Breathing is chemically controlled
9.5 Control of ventilation

• Chemical control
• 2 sets of chemoreceptors sense the change in
  chemical composition in body fluids (blood pH)
• 1. Brain (medulla oblongata)
• 2. Circulatory system (carotid bodies and aortic
  bodies)
• Sensitive (stimulated by) carbon dioxide levels
  that change blood pH due to metabolism
• Decrease pH (below 7, increase in H ions)
• Respiratory center increases rate and depth of
  breathing
• More CO2 is removed from blood

26
Exchange of gases in the body
9.6 Gas exchanges in the body

• Oxygen and carbon dioxide are exchanged in the
  lungs and tissues
• The exchange of gases is dependent on diffusion
• Partial pressure is the amount of pressure each
  gas exerts (PCO2 or PO2)
• Oxygen and carbon dioxide will diffuse from the
  area of higher to the area of lower partial
  pressure

27
External respiration
9.6 Gas exchanges in the body

• Exchange of gases between the lung alveoli and
  the blood capillaries
• PCO2 is higher in the lung capillaries than the
  air thus CO2 diffuses out of the plasma into the
  lungs
• CO2 carried in plasma as bicarbonate ions (HCO3-)
• The partial pressure pattern for O2 is just the
  opposite so O2 diffuses the red blood cells in
  the lungs
• O2 diffuses into plasma and into RBC in lungs
• Carbon dioxide transport carbonic
• H HCO3- H2CO3 anhydrase H2O
  CO2
• Oxygen transport
• Hb O2 HbO2 (oxyhemoglobin)
• (deoxyhemoglobin)

28
External respiration

• Hyperventilate (breathe at a high rate)
• Push reaction to the right
• Fewer hydrogen ions ? alkalosis
• High blood pH
• Solution Inhibit breathing
• Hypoventilate (breathe at a low rate)
• Hydrogen ions build up in the blood ? acidosis
• Buffer compensate for low pH
• Solution Increase breathing

29
Internal respiration
9.6 Gas exchanges in the body

• The exchange of gases between the blood in the
  capillaries outside of the lungs and the tissue
  fluid
• PO2 is higher in the capillaries than the tissue
  fluid therefore, O2 diffuses out of the blood
  into the tissues
• Oxyhemoglobin gives up oxygen
• HbO2 Hb O2
• Most CO2 is carried as a bicarbonate ion
• carbonic
• CO2 H2O anhydrase H2CO3 H3
  HCO3-

30
Internal respiration

• Oxygen diffuses out of the blood into tissues
• - PO2 of tissue fluid is lower than that of
  blood because cells use up oxygen in cellular
  respiration
• CO2 diffuses into the blood from tissues
• PCO2 of tissue fluid is higher than the blood
  because CO2 is produced by cells and collected in
  tissue fluid
• CO2 enters the RBCs and plasma to be either
• Taken up by hemoglobin in RBC to from HbCO2
• Taken up by RBC and formed into HCO3-
• Excess H from this reaction combines with
  Hemoglobin to form HHb, reduced hemoglobin

31
(No Transcript)
32
Upper respiratory tract infections
9.7 Respiration and health

• Sinusitis blockage of sinuses
• Otitis media infection of the middle ear
• Tubes placed in the eardrums to prevent buildup
  of pressure in the middle ear
• Tonsillitis inflammation of the tonsils
• Laryngitis infection of the larynx that leads
  to loss of voice

33
Lower respiratory tract disorders
9.7 Respiration and health

• Pneumonia
• infection of the lungs with thick, fluid build up
• Tuberculosis
• bacterial infection that leads to tubercles
  (capsules)
• Pulmonary fibrosis
• lungs lose elasticity because fibrous connective
  tissue builds up in the lungs usually because of
  inhaled particles
• Emphysema
• chronic, incurable disorder in which alveoli are
  damaged and thus the surface area for gas
  exchange is reduced
• Asthma
• bronchial tree becomes irritated causing
  breathlessness, wheezing and coughing
• Lung cancer
• uncontrolled cell division in the lungs that is
  often caused by smoking and can lead to death

34
Health focus Things you should know about
tobacco and health
9.7 Respiration and health

• All forms of tobacco can cause damage
• Smoking increases a persons chance of lung,
  mouth, larynx, esophagus, bladder, kidney,
  pancreas, stomach and cervix
• The 5-year survival rate for people with lung
  cancer is only 13
• Smoking also increases the chance of chronic
  bronchitis emphysema, heart disease, stillbirths
  and harm to an unborn child
• Passive smoke can increase a nonsmokers chance of
  pneumonia, bronchitis and lung cancer
