EndNote X2

1
EndNote X2 Your Bibliographic Management
Tool 11-17 September 2008 Patrick
Pu Engineering Computer Science Resource Team
2
Objectives

• What is EndNote?
• EndNote Library
• References
• Cite While You Write
• Other Features
• Windows Installation

3
What is EndNote? EndNote Library References
Cite While You Write Other Features Windows
Installation
What is EndNote?

• Introduction to EndNote
• EndNote Flowchart
• Software Hardware Requirements
• New Features of EndNote X2
• Comparison Between EndNote EndNote Web
• User Needs of EndNote Solutions

4
Introduction to EndNote

• A software that
• stores and organizes citations found from many
  sources
• inserts these citations into a Word document, and
• automatically formats your references according
  to a predefined citation style

5
EndNote Flowchart
Direct Export
Manual Data Entry
Online Search
Import Text File
INPUT
EndNote Library
OUTPUT
Cite While You Write
Word Processor
6
Software Hardware Requirements

• Software Requirements
• Windows XP with SP2 or Vista
• Microsoft Word 2003 or 2007
• NUS Software Catalogue (ccebox58_at_nus.edu.sg)
• Hardware Requirements
• Pentium 450 MHz or faster processor
• At least 180MB hard disk free space
• Minimum of 256 MB RAM
• Internet or LAN connection

7
New Features of EN X2

• Search for references easily with new integrated
  tab
• Quickly initiate an Online Search
• Use Smart Group to view and manage references
• Track new and updated features with the Auto Date
  Stamp
• View library and record summaries
• Compress your EndNote library and attach it to an
  email automatically
• New reference types Aggregated Database, Blog,
  Catalog, Pamphlet, Serial Publication and Standard

8
Comparison Between EN ENW
9
User Needs of EndNote Solutions
10
What is EndNote? EndNote Library References
Cite While You Write Other Features Windows
Installation
EndNote Library

• Launch EndNote X2
• Library Window
• Reference Window
• Groups
• Create a Library
• Preferences

11
Launch EndNote X2

• Start gt Programs gt EndNote gt EndNote Program
• Start gt Run gt \\libstore\endnote
• ..\ENX2 Exercise\Sample_Library.enl

12
Library Window

• A collection of references, each containing the
  information required to create a bibliography
• No limit to the number of references
• Not recommended exceeding 100,000 references
• Can open more than one library at a time
• Compatible between Windows Macintosh
• Can be independently moved, copied, renamed or
  deleted using the Windows Explorer
• .ENL file EndNote library
• .DATA folder contains figures, groups and other
  significant files

13
Library Window
Groups Pane
References List Pane
EndNote Window
Menu
Library Window
Toolbar
Tab Pane
Status Bar
Hide/Show Tab Pane
14
Reference Window

• Stores the information required to cite it in a
  bibliography, and other information (e.g.
  keywords, notes, abstract)
• Automatically assigned a unique record number
  pertaining to the library that cannot be changed
• 45 different reference types
• Up to 52 fields per reference
• Text should remain as plain text, unless
  special term or character
• Only 1 graphic or file in the Figure field
• Automatically saved when it is closed

15
Reference Window
Reference Fields
EndNote Window
Menu
Reference Window
Record Number
Reference Type List
Toolbar
Previous Next Reference Buttons
Hide/Show Empty Field
Status Bar
16
Groups

• Add up to 500 custom smart groups to a library
• Types of Groups
• Automatic Groups
• (Permanent Temporary)
• Custom Groups
• Smart Groups
• Online Search
• EndNote Web

17
Create a Library

• File gt New
• Key-in the library filename (.enl)
• Select location to save the library
• Click Save to create the new library

18
Preferences

• Edit gt Preference
• Change for
• Libraries - Set a default library
• Display Fonts - Change the library display font
• Display Fields - Change the fields in Reference
  List pane

19
What is EndNote? EndNote Library References
Cite While You Write Other Features Windows
Installation
References

• Direct Export
• Import Text File
• Online Search
• Manual Data Entry

20
Direct Export
21
Direct Export - Exercise
22
Import Text File
23
Import a Text File - Exercise
24
Online Search
Change to 10
25
Manual Data Entry
http//www.endnote.com/training/WMVs/ENX2/06-Manua
l_Data_Entry.wmv
26
Manual Data Entry - Exercise
27
What is EndNote? EndNote Library References
Cite While You Write Other Features Windows
Installation
Cite While You Write

• CWYW Toolbars in Microsoft Word
• Find Insert Citations
• Customize Citations
• Additional CWYW Features

28
Cite While You Write (CWYW)

• Easily and quickly cite references, figures
  tables, and create a paper with properly
  formatted citations, a bibliography, figures
  tables
• DO NOT edit the citations and bibliographies in
  Word Processor. Edit the reference in the EndNote
  Library ONLY
• To locate citation and bibliography fields,
  change the Microsoft Words Field Shading option

29
CWYW Toolbars in Microsoft Word

• Microsoft Word 2003
• Microsoft Word 2007

30
Find Insert Citations

• Find Citation(s)
• This command will provide a search window where
  you can enter text that is in any field. You can
  then select references from a list of those that
  contain your search terms and insert them into
  your paper.
• Insert Selected
• Citation(s)
• This command will insert
• the references you
• selected in EndNote into
• your document at the
• location of the Word cursor.

31
Customize Citations

• Format Bibliography
• This command will allow you to change the
  EndNote style used for your document. It will
  also let you make other changes to the layout of
  your bibliography, such as adding titles and
  changing the line spacing.

32
Customize Citations

• Edit Citation(s)
• Use this command to make any changes inside a
  citation, such as adding page numbers or removing
  author names from author-date citations.
• Edit Library
• Reference(s)
• This command allows
• you to quickly access
• the specific record for
• any selected citation.

33
Additional CWYW Features

• Unformat Citation(s)
• This command will remove the formatted
  bibliography and citations and replace all
  citations with plain-text placeholders that
  EndNote can match to library records to create
  formatted citations. This command is commonly
  used when moving documents between
  word-processing programs.

34
Additional CWYW Features

• Remove Field Codes
• This command will create a second copy of the
  document with all EndNote field coding removed
  (you can generally recognize field codes such as
  formatted EndNote citations by their turning grey
  when you select them in Word). It is used when
  sending documents to a publisher because the
  field coding used for EndNote citations can
  sometimes cause problems for publishers page
  layout programs.

35
Additional CWYW Features

• Export Traveling Library
• EndNote creates a hidden traveling library
  containing only the references used in each
  paper. This traveling library is part of the
  coded information contained in each citation. Use
  this command to export the references (exclude
  Notes, Abstract, Figure Caption) in this
  traveling library to a regular EndNote library.

36
Additional CWYW Features

• Insert Note
• Use this command to insert explanatory notes to
  be numbered as though they were bibliography
  entries, and then placed in the bibliography.

37
Additional CWYW Features

• Find Figure(s)
• This command will provide a search window much
  like the Find Citation window where you can enter
  text that is in any field in the record you want
  to find. You can then select references from a
  list of those records with figures attached that
  contain your search terms. A reference to the
  figure will be inserted at the location of your
  cursor. The image will be inserted either below
  the cursor location or in a list at the end of
  the document, depending on the selected EndNote
  style.
• Generate Figure List
• If you insert a new figure reference, all of the
  figures in the document will automatically be
  updated, but if you delete or move a figure
  reference you will need to force an update of the
  figure numbering and placement. Use the Generate
  Figure List command to do this.

38
Additional CWYW Features

• Cite While You Write Preferences
• Use this command to set preferences for
  EndNotes cite while you write settings for
  future documents. (Note If you use Word as your
  e-mail editor in Microsoft Outlook, you should
  leave the Open EndNote when Starting Word option
  in the CWYW preferences unchecked.)

39
What is EndNote? EndNote Library References
Cite While You Write Other Features Windows
Installation
Other Features

• Backup Libraries
• Recover Library
• Find Duplicates
• Transfer References to EndNote Web

40
Backup Libraries

• Save a Copy
• Create an exact copy of the library, including
  library name.DATA folder
• File gt Save a Copy...

41
Backup Libraries

• Compressed Library
• Save the complete library to a single compressed
  file, including library name.DATA folder
• To save File gt Compressed Library (.enlx)
• To restore File gt Open gt Open Library

42
Recover Library

• Repair the damaged EndNote Library
• Tool gt Recover Library

43
Find Duplicates

• Edit gt Preferences gt Duplicates

44
Find Duplicates

• References gt Find Duplicates

45
Transfer References to EndNote Web

• Edit gt Preferences gt EndNote Web

46
Transfer References to EndNote Web
ENW to EN
EN to ENW
47
What is EndNote? EndNote Library References
Cite While You Write Other Features Windows
Installation
Windows Installation

• New Installation
• Upgrade from Earlier Version of EndNote
• Post-Installation
• Update Maintenance

48
New Installation http//libpweb1.nus.edu.sg/lion/
e/Step1detailed.pdf
Windows XP with Microsoft Word 2003
49
New Installation http//libpweb1.nus.edu.sg/lion/
e/Step1detailed.pdf
Windows Vista with Microsoft Word 2007
50
Upgrade from Earlier Version of EN

• Backup any custom styles, import filters and
  connection files. Libraries will not be deleted.
  Move the files back into the respective folders
  after installation
• Uninstall any earlier version of EndNote before
  installing EndNote X2
• EndNote Libraries
• To convert File gt Open gt Open Library
• No conversion - 8, 9, X and X1
• Convert automatically - 5, 6 or 7
• Macintosh Windows is compatible X, X1 and X2

51
Post-Installation

• Launch EndNote Start gt All Programs gt EndNote gt
  EndNote Program
• Check Cite While You Write in Microsoft Word
• Installed files and folders
• C\Program Files\EndNote X2
• Folders Connections, Filters, Styles Templates

52
Update Maintenance

• Program Updates Patches
• http//www.endnote.com/support/enupdates.asp
• Output Styles
• http//www.endnote.com/support/enstyles.asp
• Import Filters
• http//www.endnote.com/support/enfilters.asp
• Connection Files
• http//www.endnote.com/support/enconnections.asp

• Microsoft Word Templates
• http//www.endnote.com/support/entemplates.asp
• EndNote Term List
• http//www.endnote.com/support/faqs/Files/Terms.
  zip

53
Summary EndNote X2 Your Bibliographic Management
Tool

• What is EndNote?
• EndNote Library
• References
• Cite While You Write
• Other Features
• Windows Installation

54
Help

• Email askalib_at_nus.edu.sg
• LION How to Use EndNote
• LION How to Use EndNote Web
• EndNote X2 Getting Started Guide
• EndNote X2 Users Guide
• EndNote X2 Tutorial
• - View Online or Download
• EndNote FAQs
• EndNote Discussion Forum

55
Thank You
Wish you all the best!
Patrick Pu patrick.pu_at_nus.edu.sg Tel 6516
6212 Engineering Computer Science Resource Team
